S
®
UPER
X6DHR-8GS
USER'S MANUAL
Revision 1.0a

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X6DHR-8GS and is the answer not in the manual?

Questions and answers

Related Manuals for Supermicro X6DHR-8GS

Summary of Contents for Supermicro X6DHR-8GS

  • Page 1 ® UPER X6DHR-8GS USER’S MANUAL Revision 1.0a...
  • Page 2 The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product. Unless you request and receive written permission from SUPER MICRO COMPUTER, you may not copy any part of this document.

  • Page 3: Preface

    Please refer to the motherboard specifications pages on our web site (http:// www.supermicro.com/Product_page/product-m.htm) for updates on sup- ported processors. This product is intended to be professionally installed. Manual Organization...

  • Page 4: Table Of Contents

    Checklist ... 1-1 Contacting Supermicro ... 1-2 X6DHR-8GS Image ... 1-3 X6DHR-8GS Layout ... 1-4 X6DHR-8GS Quick Reference ... 1-5 Motherboard Features ... 1-6 Intel Lindenhurst-VS Chipset: System Block Diagram ... 1-8 Chipset Overview ... 1-9 Special Features ... 1-10 Recovery from AC Power Loss ...
  • Page 5 Power Button ... 2-13 Chassis Intrusion ... 2-14 Universal Serial Bus (USB0/1) ... 2-14 Front Panel Universal Serial Bus Headers (USB2/3) ... 2-15 Serial Ports ... 2-15 GLAN1/GLAN2 (Ethernet Ports) ... 2-16 Fan Headers ... 2-16 SMB ... 2-17 ATX PS/2 Keyboard and Mouse Ports ... 2-17 Power LED/Speaker Header (JD1) ...
  • Page 6 X6DHR-8GS User's Manual Chapter 4: BIOS Introduction ... 4-1 Running Setup ... 4-2 Main BIOS Setup ... 4-2 Advanced Setup ... 4-7 Security Setup ... 4-19 Boot Setup ... 4-21 Exit ... 4-22 Appendices: Appendix A: BIOS POST Messages ... A - 1 Appendix B: BIOS POST Codes ...

  • Page 7: Chapter 1: Introduction

    If anything listed here is damaged or missing, contact your retailer. One (1) Supermicro Mainboard One (1) ribbon cable for IDE devices One (1) floppy ribbon cable One (1) Supermicro CD or diskettes containing drivers and utilities One (1) User's/BIOS Manual Chapter 1 Introduction...

  • Page 8: Contacting Supermicro

    X6DHR-8GS User's Manual Contacting Supermicro Headquarters Address: SuperMicro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: SuperMicro Computer B.V.

  • Page 9: X6Dhr-8Gs Image

    Chapter 1: Introduction Figure 1-1. X6DHR-8GS Image...
  • Page 10 X6DHR-8GS User's Manual Figure 1-2. SUPER J 3 3 DIMM 1A DIMM 1B J 3 4 DIMM 2A J 1 6 DIMM 2B DIMM 3A DIMM 3B DIMM 4A J 1 4 DIMM 4B Notes: 1. Jumpers not indicated are for test purposes only.
  • Page 11 Quick Reference (X6DHR-8GS) (*Please refer to Chapter 2 for pin definitions and detailed information.) J u m p e r Description JBT1 CMOS Clear JPL1 GLAN Enable/Disable JP10 3rd PWR Supply Fail Detect JPA1 SCSI Enable/Disable(*Note) JPA2,JPA3 SCSI Term. A/B Enable (*Note)

  • Page 12: Motherboard Features

    X6DHR-8GS User's Manual Motherboard Features ® • Single or dual Intel 800 MHz front side (system) bus speed. *Notes: The CPU FSB is set at 800 MHz by the Manufacturer. Please do not change the CPU FSB setting. Please refer to the support section of our web site for a complete listing of supported processors (http:// www.supermicro.com/TechSupport.htm.)
  • Page 13 • System resource alert (via Supero Doctor III) ACPI Features (optional) • Microsoft OnNow • Slow blinking LED for suspend state indicator • Main switch override mechanism Onboard I/O • Support for up to two Ultra 320 Channels • 2015S ZCR support (*Note) •...
  • Page 14 X6DHR-8GS User's Manual S CS I 7902 PCI - X BUS ( 100 M HZ) S OCKE T 7902 PCI - X BUS ( 133 M HZ) Gbi t L AN 82546GB PCI - X BUS 1_ PCI - X133...

  • Page 15: Chipset Overview

    Built upon the functionality and the capability of the Intel E7520 (Lindenhurst) chipset, The X6DHR-8GS motherboard provides the perfor- mance and feature set required for dual processor-based servers, with configuration options optimized for communications, presentation, storage, computation or database applications. The Intel E7520 (Lindenhurst) chipset...

  • Page 16: Special Features

    Always On. PC Health Monitoring This section describes the PC health monitoring features of the SUPER X6DHR-8GS. All have an onboard System Hardware Monitor chip that sup- ports PC health monitoring. Onboard Voltage Monitors for the CPU Cores, Chipset Voltage, +3.3V, +5V, +12V, -12V and +5V Standby...

  • Page 17: Acpi Features

    damage to the CPU. The onboard chassis thermal circuitry can monitor the overall system temperature and alert users when the chassis temperature is too high. CPU Fan Auto-Off in Sleep Mode The CPU fan activates when the power is turned on. It continues to operate when the system enters Standby mode.
  • Page 18 X6DHR-8GS User's Manual Microsoft OnNow The OnNow design initiative is a comprehensive, system-wide approach to system and device power control. OnNow is a term for a PC that is always on but appears to be off and responds immediately to user or other re- quests.

  • Page 19: Power Supply

    It is even more important for processors that have high CPU clock rates. The SUPER X6DHR-8GS accommodates ATX power supplies. most power supplies generally meet the specifications required by the sys- tem, some are inadequate. 400W of power.
  • Page 20 X6DHR-8GS User's Manual reduces the number of components required for interfacing with floppy disk drives. The Super I/O supports 360 K, 720 K, 1.2 M, 1.44 M or 2.88 M disk drives and data transfer rates of 250 Kb/s, 500 Kb/s or 1 Mb/s. It also provides two high-speed, 16550 compatible serial communication ports (UARTs), one of which supports serial infrared communication.

  • Page 21: Chapter 2: Installation

    Static-Sensitive Devices Electric-Static-Discharge (ESD) can damage electronic components. To pre- vent damage to your system board, it is important to handle it very carefully. The following measures are generally sufficient to protect your equipment from ESD. Precautions • Use a grounded wrist strap designed to prevent static discharge. •...

  • Page 22: Xeon Em64T Processor And Heatsink Installation

    X6DHR-8GS User's Manual Xeon EM64T Processor and Heatsink Installation When handling the processor package, avoid placing direct pressure on the label area of the fan. Also, do not place the motherboard on a conductive surface, which can damage the BIOS battery and prevent the system from booting up.
  • Page 23 2. Insert the CPU in the socket, making sure that pin 1 of the CPU aligns with pin 1 of the socket (both corners are marked with a triangle). When using only one CPU, install it into CPU socket #1 (socket #2 is automatically disabled if only one CPU is used).
  • Page 24 X6DHR-8GS User's Manual To Un- Install Heatsink 1. Unscrew and remove the heatsink screws from the motherboard in the sequence as show in the second picture on the right. 2. Hold the heatsink as show in the picture on the right and gently wriggle the heatsink to loosen it from the CPU.
  • Page 25 Chapter 2: Installation Mounting the Motherboard in the Chassis All motherboards have standard mounting holes to fit different types of chassis. Make sure the location of all the mounting holes for both the motherboard and the chassis match. Although a chassis may have both plastic and metal mounting fasteners, metal ones are highly recommended because they ground the motherboard to the chassis.

  • Page 26: Installing Dimms

    Repeat for all modules (see step 1 above). Memory Support The X6DHR-8GS supports up to 16 GB of Registered DDR II-400 (PC3200) memory (recommended by the Manufacturer). signed to support 2 GB modules in each slot, but has only been verified for up to 1.0 GB modules.

  • Page 27: I/Oports/Control Panel Connectors

    Top View of the DDRII Slot To Remove: Use your thumbs to gently push near the edge of both ends of the module. This should release it from the slot. I/OPorts/Control Panel Connectors The I/O ports are color coded in conformance with the PC 99 specification. See Figure 2-3 below for the colors and locations of the various I/O ports.
  • Page 28 JF1 contains header pins for various buttons and indicators that are nor- mally located on a control panel at the front of the chassis. These connec- tors are designed specifically for use with Supermicro server chassis. See Figure 2-4 for the descriptions of the various control panel buttons and LED indicators.

  • Page 29: Connecting Cables

    Connecting Cables ATX Power Connector primary power connector(J1B1) on the X6DHR- 8GS meets the SSI (Superset ATX) 20-pin specification. also connect the 4-pin (J38) pro- cessor power connector to your power supply. Refer to the table below right for the J38 4-Pin (12V) connector.

  • Page 30: Nmi Button

    X6DHR-8GS User's Manual NMI Button The non-maskable interrupt button header is located on pins 19 and 20 of JF1. Refer to the table on the right for pin definitions. Power LED The Power LED connection is lo- cated on pins 15 and 16 of JF1.

  • Page 31: Hdd Led

    HDD LED The HDD LED connection is located on pins 13 and 14 of JF1. Attach the hard drive LED cable here to display disk activity (for any hard drives on the system, including SCSI, Serial ATA and IDE). the table on the right for pin defini- tions.

  • Page 32: Overheat Led

    X6DHR-8GS User's Manual Overheat LED (OH) Connect an LED to the OH connec- tion on pins 7 and 8 of JF1 to pro- vide advanced warning of chassis overheating. Refer to the table on the right for pin definitions. Power Fail LED The Power Fail LED connection is located on pins 5 and 6 of JF1.

  • Page 33: Reset Button

    Reset Button The Reset Button connection is lo- cated on pins 3 and 4 of JF1. At- tach it to the hardware reset switch on the computer case. Refer to the table on the right for pin definitions. Power Button The Power Button connection is located on pins 1 and 2 of JF1.

  • Page 34: Chassis Intrusion

    X6DHR-8GS User's Manual Chassis Intrusion A Chassis Intrusion header is lo- cated at JL1. Attach the appropri- ate cable to inform you of a chas- sis intrusion. Universal Serial Bus (USB0/1) Two USB 2.0 ports (J16) are lo- cated beside the Mouse and COM1 ports.

  • Page 35: Serial Ports

    Front Panel Universal Serial Bus Headers An Extra USB header: FPUSB0/ FPUSB1(JD2) can be used for front side USB access. need a USB cable to use the con- nections. Refer to the tables on the right for pin definitions. Serial Ports COM Port1(J14) is located beside the Back Panel USB0/1, and COM Port 2 is located next to Chassis...

  • Page 36: Fan Headers

    This ports accepts RJ45 type cables. Fan Headers There are five fan headers (Fan 1 to Fan 5) on the X6DHR-8GS. See the table on the right for pin defini- tions. (The fan speeds are con- trolled by Thermal Management via BIOS.

  • Page 37: Smb

    System Management header is located at J11. Connect the appropriate cable here to uti- lize SMB on your system. ATX PS/2 Keyboard and PS/2 Mouse Ports The ATX PS/2 Keyboard(J34) and PS/2 Mouse(J33) are located be- side the USB0/1 Ports on the backpanel.

  • Page 38: Wake-On-Ring

    X6DHR-8GS User's Manual Power LED/Speaker On the JDI header, pins 1-3 for a power LED and pins 4-7 are for the speaker. See the table on the right for speaker pin defini- tions. Note: The speaker connec- tor pins are for use with an exter- nal speaker.

  • Page 39: Wake-On-Lan

    Wake-On-LAN The Wake-On-LAN header is des- ignated WOL. See the table on the right for pin definitions. You must enable the LAN Wake-Up setting in BIOS to use this feature. must also have a LAN card with a Wake-on-LAN connector cable.

  • Page 40: Jumper Settings

    X6DHR-8GS User's Manual Jumper Settings Explanation of Jumpers To modify the operation of the motherboard, jumpers can be used choose optional settings. create shorts between two pins to change the function of the connector. Pin 1 is identified with a square solder pad on the printed circuit board.

  • Page 41: Glan Enable/Disable

    GLAN Enable/Disable JPL1 enables or disables the GLAN port(s) on the motherboard. See the table on the right for jumper settings. The default set- ting is enabled. VGA Enable/Disable JPG1 enables or disables the VGA Connector on the motherboard. See the table on the right for jumper settings.

  • Page 42: Scsi Enable/Disable

    X6DHR-8GS User's Manual Watch Dog JWD controls Watch Dog, a system monitor that takes action when a software application freezes the system. Pins 1-2 will have WD re- set the system if a program freezes. Pins 2-3 will generate a...

  • Page 43: Scsi Termination Enable/Disable

    SCSI Termination Enable/ Disable Jumpers JPA2 and JPA3 allow you to enable or disable termination for the SCSI connectors. Jumper JPA2 controls SCSI channel A and JPA3 is for SCSI channel B. The default setting is open to enable (terminate) both SCSI channels.

  • Page 44: Onboard Indicators

    X6DHR-8GS User's Manual Onboard Indicators GLAN LEDs The Gigabit Ethernet LAN ports has two LEDs. The yellow LED in- dicates activity while the other LED may be green, orange or off to indicate the speed of the con- nection. See the table at right for the functions associated with the second LED.

  • Page 45: Floppy Connector

    Floppy/Hard Disk Drive, IPMI, IDE and SCSI Connections Note the following when connecting the floppy and hard disk drive cables: • The floppy disk drive cable has seven twisted wires. • A red mark on a wire typically designates the location of pin 1. •...

  • Page 46: Ipmi

    X6DHR-8GS User's Manual IPMI J9 is designated as the IPMI Socket for the Motherboard. IDE Connectors There are no jumpers to configure the onboard IDE#1 and #2 connectors (at J5 and J6, respectively). the table on the right for pin definitions.

  • Page 47: Ultra 320 Scsi Connector

    Ultra320 SCSI Connectors Refer to the table below for the pin definitions of the Ultra320 SCSI connectors located at JA1 and JA2. 4-Pin PW SMB J 3 8 J 3 2 J 3 3 2 0 - P i n P W DIMM 1A J P 9 DIMM 1B...
  • Page 48 X6DHR-8GS User's Manual (*Note: For software installation instructions, please refer to Ap- pendix C. For Adaptec's SCSI HostRAID Utility, please refer to the CDs that came with your motherboard.) 2-28...

  • Page 49: Chapter 3: Troubleshooting

    Troubleshooting Procedures Use the following procedures to troubleshoot your system. followed all of the procedures below and still need assistance, refer to the ‘Technical Support Procedures’ and/or ‘Returning Merchandise for Service’ section(s) in this chapter. Note: Always disconnect the power cord before adding, changing or installing any hardware components.

  • Page 50: Memory Errors

    X6DHR-8GS User's Manual If you are a system integrator, VAR or OEM, a POST diagnos- tics card is recommended. For I/O port 80h codes, refer to Memory Errors 1. Make sure the DIMM modules are properly and fully installed. 2. Determine if different speeds of DIMMs have been installed and verify that the BIOS setup is configured for the fastest speed of RAM used.

  • Page 51: Frequently Asked Questions

    Question: What are the various types of memory that my mother- board can support? Answer: The X6DHR-8GS has eight 240-pin DIMM slots that support regis- tered ECC DDR II (PC3200) SDRAM modules. It is strongly recommended that you do not mix memory modules of different speeds and sizes.

  • Page 52: Returning Merchandise For Service

    X6DHR-8GS User's Manual sary to set BIOS boot block protection jumpers on the motherboard. At the DOS prompt, enter the command "phlash." This will start the flash utility and give you an opportunity to save your current BIOS image. Flash the boot block and enter the name of the update BIOS image file.

  • Page 53: Chapter 4: Bios

    Introduction This chapter describes the Phoenix BIOS™ Setup utility for the X6DHR-8GS. The Phoenix ROM BIOS is stored in a flash chip and can be easily upgraded using a floppy disk-based program. Note: Due to periodic changes to the BIOS, some settings may have been added or deleted and might not yet be recorded in this manual.

  • Page 54: Running Setup

    X6DHR-8GS User's Manual Running Setup *Default settings are in bold text unless otherwise noted. The BIOS setup options described in this section are selected by choos- ing the appropriate text from the main BIOS Setup screen. All displayed text is described in this section, although the screen display is often all you need to understand how to set the options (see on next page).

  • Page 55: Main Bios Setup Menu

    Chapter 4: BIOS Main BIOS Setup Menu Main Setup Features System Time To set the system date and time, key in the correct information in the appropriate fields. Then press the <Enter> key to save the data. System Date Using the arrow keys, highlight the month, day and year fields and enter the correct data.
  • Page 56 X6DHR-8GS User's Manual Legacy Diskette A This setting allows the user to set the type of floppy disk drive installed as diskette A. The options are Disabled, 360Kb 5.25 in, 1.2MB 5.25 in, 720Kb 3.5 in, 1.44/1.25MB, 3.5 in and 2.88MB 3.5 in.
  • Page 57 Chapter 4: BIOS Type Selects the type of IDE hard drive. The options are Auto (allows BIOS automatically determine the hard drive's capacity, number of heads, Sectors, Maximum Capacity, LBA Format, ect.). Enter a number from 1- 39 to select a predetermined type of hard drive, CD-ROM and ATAPI Removable.
  • Page 58 X6DHR-8GS User's Manual Multi-Sector Transfers Select the number of transfer sectors. The options are Disabled, 2, 4, 6, 8 and 16 Sectors. LBA Mode Control This item determines whether Phoenix BIOS will access the IDE Primary Master Device via LBA mode. The options are Disabled and Enabled.

  • Page 59: Advanced Setup

    Chapter 4: BIOS Advanced Setup Choose Advanced from the Phoenix BIOS Setup Utility main menu with the arrow keys. You should see the following display. The items with a triangle beside them have sub menus that can be accessed by highlighting the item and pressing <Enter>.
  • Page 60 X6DHR-8GS User's Manual ACPI Mode Use the setting to determine if you want to employ ACPI (Advanced Configuration and Power Interface) power management on your system. The options are Yes and No. Power Button Behavior If set to Instant-Off, the system will power off immediately as soon as the user hits the power button.
  • Page 61 Chapter 4: BIOS Cache Base 0-512K If enabled, this feature will allow the data stored in the base memory area: block 0-512K to be cached (written) into a buffer, a storage area in the Static DRM (SDROM) or written into L1, L2, L3 cache inside the CPU to speed up CPU operations .
  • Page 62 X6DHR-8GS User's Manual ! ! ! ! ! PCI Configuration Access the submenu to make changes to the following settings for PCI devices. Onboard GLAN (Gigabit- LAN) OPROM Configure Enabling this option provides the capability to boot from GLAN. The options are Disabled and Enabled.
  • Page 63 ! ! ! ! ! PCI-X 133MHz Slot #1/Slot#2, PCI-Expx8 (Slot#1)/PCI-Expx4 (Slot#2) Access the submenu for each of the settings above to make changes to the following: Option ROM Scan When enabled, this setting will initialize the device expansion ROM. Enable Master This setting allows you to enable the selected device as the PCI bus master.
  • Page 64 X6DHR-8GS User's Manual Memory RAS Feature Control Select this option to enable the Memory RAS Feature Control The options are Miirroring, Sparing and Standard. Clock Spectrum Feature If "Enabled", BIOS will monitor the level of Electromagnetic Interference caused by the components and will attempt to decrease the interference whenever needed.
  • Page 65 ! ! ! ! ! Advanced Processor Options Access the submenu to make changes to the following settings. CPU Speed This is a display that indicates the speed of the installed processor. Hyper Threading Technology This setting allows you to Enable or Disable the function of Hyper Threading.
  • Page 66 X6DHR-8GS User's Manual KBC Clock Input This setting allows you to select clock frequency for KBC. The options are 6MHz, 8MHz, 12MHz and 16MHz. On-board COM 1 This setting allows you to assign control of serial port A. The options are Enabled (user defined), Disabled and Auto (BIOS controlled).
  • Page 67 port. The options are 378, 278 and 3BC. Interrupt This setting allows you to select the IRQ (interrupt request) for the parallel port. The options are IRQ5 and IRQ7. Mode This setting allows you to specify the parallel port mode. The options are Output Only, Bi-directional, EPP and ECP.
  • Page 68 X6DHR-8GS User's Manual ! ! ! ! ! DMI Event Logging Access the submenu to make changes to the following settings. Event Log Validity This is a display, not a setting, informing you of the event log validity. Event Log Capacity This is a display, not a setting, informing you of the event log capacity.
  • Page 69 Chapter 4: BIOS ! ! ! ! ! Console Redirection Access the submenu to make changes to the following settings. COM Port Address Specifies to redirect the console to On-board COM A or On-board COM B. This setting can also be Disabled. BAUD Rate Select the BAUD rate for console redirection.
  • Page 70 X6DHR-8GS User's Manual ! ! ! ! ! Hardware Monitor Logic CPU Temperature Threshold This option allows the user to set a CPU temperature threshold that will activate the alarm system when the CPU temperature reaches this pre-set temperature threshold. The options are 85 Highlight this and hit <Enter>...
  • Page 71 Chapter 4: BIOS Security Choose Security from the Phoenix BIOS Setup Utility main menu with the arrow keys. You should see the following display. Security setting options are displayed by highlighting the setting using the arrow keys and pressing <Enter>. All Security BIOS settings are described in this section.
  • Page 72 X6DHR-8GS User's Manual Set Supervisor Password When the item "Set Supervisor Password" is highlighted, hit the <Enter> key. When prompted, type the Supervisor's password in the dialogue box to set or to change supervisor's password, which allows access to BIOS.
  • Page 73 Chapter 4: BIOS Boot Choose Boot from the Phoenix BIOS Setup Utility main menu with the arrow keys. You should see the following display. Highlighting a setting with a + or - will expand or collapse that entry. See details on how to change the order and specs of boot devices in the Item Specific Help window.

  • Page 74: Exit

    X6DHR-8GS User's Manual Exit Choose Exit from the Phoenix BIOS Setup Utility main menu with the arrow keys. You should see the following display. All Exit BIOS settings are described in this section. Exit Saving Changes Highlight this item and hit <Enter> to save any changes you made and to exit the BIOS Setup utility.
  • Page 75 Chapter 4: BIOS Discard Changes Highlight this item and hit <Enter> to discard (cancel) any changes you made. You will remain in the Setup utility. Save Changes Highlight this item and hit <Enter> to save any changes you made. You will remain in the Setup utility.
  • Page 76 X6DHR-8GS User's Manual Notes 4-24...

  • Page 77: Appendix Abios Post Messages

    Appendix A: BIOS POST Messages Appendix A BIOS POST Messages During the Power-On Self-Test (POST), the BIOS will check for problems. If a problem is found, the BIOS will activate an alarm or display a message. The following is a list of such BIOS messages.
  • Page 78 X6DHR-8GS User's Manual System CMOS checksum bad - Default configuration used System CMOS has been corrupted or modified incorrectly, perhaps by an application program that changes data stored in CMOS. The BIOS installed Default Setup Values. If you do not want these values, enter Setup and enter your own values.
  • Page 79 Appendix A: BIOS POST Messages System cache error - Cache disabled RAM cache failed and BIOS disabled the cache. On older boards, check the cache jumpers. You may have to replace the cache. See your dealer. A disabled cache slows system performance considerably. CPU ID: CPU socket number for Multi-Processor error.
  • Page 80 X6DHR-8GS User's Manual Fixed Disk n Fixed disk n (0-3) identified. Invalid System Configuration Data Problem with NVRAM (CMOS) data. I/O device IRQ conflict I/O device IRQ conflict error. PS/2 Mouse Boot Summary Screen: PS/2 Mouse installed. nnnn kB Extended RAM Passed Where nnnn is the amount of RAM in kilobytes successfully tested.
  • Page 81 Appendix A: BIOS POST Messages Parity Check 2 nnnn Parity error found in the I/O bus. BIOS attempts to locate the address and display it on the screen. If it cannot locate the address, it displays ????. Press <F1> to resume, <F2> to Setup, <F3> for previous Displayed after any recoverable error message.
  • Page 82 X6DHR-8GS User's Manual Notes...

  • Page 83: Appendix Bbios Post Codes

    BIOS POST Codes This section lists the POST (Power On Self Test) codes for the PhoenixBIOS. POST codes are divided into two categories: recoverable and terminal. Recoverable POST Errors When a recoverable type of error occurs during POST, the BIOS will display an POST code that describes the problem.
  • Page 84 X6DHR-8GS User's Manual POST Code Description 8254 timer initialization 8237 DMA controller initialization Reset Programmable Interrupt Controller 1-3-1-1 Test DRAM refresh 1-3-1-3 Test 8742 Keyboard Controller Set ES segment register to 4 GB Auto size DRAM Initialize POST Memory Manager...
  • Page 85 POST Code Description Test RAM between 512 and 640 kB Test extended memory Test extended memory address lines Jump to UserPatch1 Configure advanced cache registers Initialize Multi Processor APIC Enable external and CPU caches Setup System Management Mode (SMM) area Display external L2 cache size Load custom defaults (optional) Display shadow-area message...
  • Page 86 X6DHR-8GS User's Manual POST Code Description Check for SMART Drive (optional) Shadow option ROMs Set up Power Management Initialize security engine (optional) Enable hardware interrupts Determine number of ATA and SCSI drives Set time of day Check key lock Initialize typematic rate...
  • Page 87 POST Code Description Re-map I/O and memory for PCMCIA Initialize digitizer and display message Unknown interrupt The following are for boot block in Flash ROM POST Code Description Initialize the chipset Initialize the bridge Initialize the CPU Initialize system timer Initialize system I/O Check force recovery boot Checksum BIOS ROM...
  • Page 88 X6DHR-8GS User's Manual Notes...

  • Page 89: Appendix C: Installing Software Drivers And Windows Operating System

    After all the hardware has been installed, you must first configure the Adaptec Embedded Serial ATA RAID Driver before you install the Windows operating system. The necessary drivers are all included on the Supermicro bootable CDs that came packaged with your motherboard.

  • Page 90: Configuring Bios Settings For The Sata Raid Functions

    X6DHR-8GS User's Manual Configuring BIOS settings for the SATA RAID Functions 1. Press the <Del> key during system bootup to enter the BIOS Setup Utility. (*Note: If it is the first time to power on the system, we recommend that you load the Optimized Default Settings.
  • Page 91 RAID mirroring (RAID 1) allows the data to be simulta- neously written to two drives, so critical data is always available even if a single hard disk fails. Due to the built-in functionality, the X6DHR-8GS is specially designed to keep pace with the increasing performance demands of computer systems by improving disk I/O throughput and providing data accessibility regardless of a single disk failure.
  • Page 92 X6DHR-8GS User's Manual Managing Arrays Select this option to view array properties, and delete arrays. The following sections describe the operations Of "Managing Arrays". To select this option, use the arrow keys and the <enter> key to select "Managing Arrays" from the main menu (as shown above).
  • Page 93 Viewing Array Properties To view the properties of an existing array: 1. At the BIOS prompt, press Ctrl+A. 2. From the ARC menu, select Array Configuration Utility (ACU). 3. From the ACU menu, select Manage Arrays (as shown on the previous screen.) 4.
  • Page 94 X6DHR-8GS User's Manual Creating Arrays Before creating arrays, make sure the disks for the array are connected and installed in your system. Note that disks with no usable space, or disks that are un-initialized are shown in gray and cannot be used. See Initializing Disk Drives.
  • Page 95 Appendix C: Software Installation Instructions Assigning Array Properties Once you've create a new array, you are ready to assign the properties to the array. *Caution: Once the array is created and its properties are assigned, you cannot change the array properties using the ACU. You will need to use the Adaptec Storage Manager - Browser Edition.
  • Page 96 X6DHR-8GS User's Manual 2. Under the item "Arrays Label", type in an label and press Enter. (*Note: The label shall not be more than 15 characters.) 3. For RAID 0, select the desired stripe size. (*Note: Available stripe sizes are 16, 32, and 64 KB-default. It is recommended that you do not change the default setting.)
  • Page 97 Appendix C: Software Installation Instructions 5. When you are finished, press Done (as the screen shown below). Notes: 1. Before adding a new drive to an array, back up any data contained on the new drive. Otherwise, all data will be lost. 2.
  • Page 98 X6DHR-8GS User's Manual Adding a Bootable Array To make an array bootable: 1. From the Main menu, select Manage Arrays. 2. From the List of Arrays, select the array you want to make bootable, and press Ctrl+B. 3. Enter Y to create a bootable array when the following message is displayed: "This will make all other existing bootable array non-bootable.
  • Page 99 Appendix C: Software Installation Instructions Adding/Deleting Hotspares (*Note: In order to rebuild a RAID (RAID 0 or RAID 1), you would need to add a new HDD as a hotspare.) 1. Turn on your computer and press Ctrl+A as prompted to access the ARC Utility.

  • Page 100: Initializing Disk Drives

    X6DHR-8GS User's Manual Initializing Disk Drives If an installed disk does not appear in the disk selection list for creating a new array, or if it appears grayed out, you may have to initialize it before you can use it as part of an array. Drives attached to the controller must be initialized before they can be used in an array.
  • Page 101 Appendix C: Software Installation Instructions 4. Use the up and down arrow keys to highlight the disk you wish to initialize and press Insert (as shown in the screen below). C-13...
  • Page 102 X6DHR-8GS User's Manual 5. Repeat Step 4 so that both drives to be initialized are selected (as shown in the screen below). 6. Press Enter. 7. Read the warning message as shown in the screen. 8. Make sure that you have selected the correct disk drives to initialize.
  • Page 103 Appendix C: Software Installation Instructions Rebuilding Arrays *Note 1: Rebuilding applies to Fault Tolerant array (RAID 1) only. If an array Build process (or initialization) is interrupted or critical with one member missing, you must perform a Rebuild to optimized its function- ality.

  • Page 104: Using The Disk Utilities

    X6DHR-8GS User's Manual Using the Disk Utilities The Disk Utilities enable you to format or verify the media of your Serial ATA hard disks. To access the disk utilities: 1. Turn on your computer and press Ctrl+A when prompted to access the ARC utility (as shown in the screen below.)
  • Page 105 Appendix C: Software Installation Instructions 2. From the ARC menu, select Disk Utilities as shown in the screen below. 3 Select the desired disk and press Enter (as shown in the screen below.) C-17...
  • Page 106 2. Press Yes to exit the Utility. (*For more information regarding Adaptec RAID Utility, please refer to Adaptec's User's Guide in the CD included in your shipping package. You can also download a copy of Adaptec User's Guide from our web site at: www. supermicro.com.) C-18...
  • Page 107 Appendix C: Software Installation Instructions C-2 Installing Intel's ICH5R Driver by Adaptec and Windows Operating System a. Insert Supermicro's bootable CD that came with the package into the CD Drive during the system reboot, and the screen:"Super Micro Driver Diskette Maker" will appear.
  • Page 108 X6DHR-8GS User's Manual B-3 Installing Other Software Programs and Drivers A. Installing Drivers other than Adaptec Embedded Serial ATA RAID Controller Driver After you've installed Windows Operating System, a screen as shown be- low will appear. You are ready to install software programs and that have not yet been installed.
  • Page 109 Appendix C: Software Installation Instructions Supero Doctor III The Supero Doctor III program is a Web base management tool that supports remote management capability. It includes Remote and Local Management tools. The local management is called SD III Client. The Supero Doctor III program included on the CDROM that came with your motherboard allows you to monitor the environment and operations of your system.
  • Page 110 Supero Doctor III Interface Display Screen-II (Remote Control) (*Note: SD III Software Revision 1.0 can be downloaded from our Web site at: ftp://ftp.supermicro.com/utility/Supero_Doctor_III/. You can also download SDIII User's Guide at: http://www.supermicro.com/PRODUCT/ Manuals/SDIII/UserGuide.pdf. For Linux, we will still recommend Supero Doctor II.)
