Page 1
942512G PREDATOR PRO 33HP GEN W/61” SIDE DISCHARGE SN 0112 thru 0134 942513G PREDATOR PRO 33HP GEN W/72” SIDE DISCHARGE SN 0104 thru 0105 942514G PREDATOR PRO 34HP KAW W/61” SIDE DISCHARGE SN 0260 thru 0383 942515G PREDATOR PRO 37HP KAW DFI W/61” SIDE DISCHARGE SN 0190 thru 0239 942516G PREDATOR PRO 37HP KAW DFI W/72”...
Page 2
CALIFORNIA Proposition 65 Warning WARNING Diesel engine exhaust and some The engine exhaust from this product of its constituents are known to the contains chemicals known to the State State of California to cause cancer, of California to cause cancer, birth birth defects and other reproductive defects or other reproductive harm.
Your safe use of this Schiller Grounds Care, Inc.product is one of our prime design objectives. Many safety features are built in, but we also rely on your good sense and care to achieve accident-free operation.
Page 4
Schiller of hazard seriousness. These words appear in this Grounds Care, Inc.Engineering Department. Any manual and on the safety labels attached to Schiller Schiller Grounds Care, Inc.product that is altered, Grounds Care, Inc.machines. For your safety and...
ASSEMBLY AND SETUP PREDATOR-PRO SERIES TOOLS REQUIRED FOR ASSEMBLY Wrecking bar Claw hammer Ratchets: 3/8” Drive Sockets: 9/16”, 3/4" Wrenches: 3/8", 9/16", 3/4"” Straight edge Tire pressure gauge Blocks (for deck leveling) NOTE: All references below to the “right” or “left” are with respect to an operator at the controls. 1.
ASSEMBLY AND SETUP PREDATOR-PRO SERIES 6. COUNTERBALANCE SPRINGS a) Raise the cutterdeck all the way. b) Adjust the spring A with nut B: Approximately 1" of threads should be extending past the spring mounting bracket at nut B. The springs may be tightened or loosened from this point according to personal preference.
MAINTENANCE RECORD PREDATOR-PRO SERIES NOTES ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ & & r i f , l i t l i...
MAINTENANCE PREDATOR-PRO SERIES CHECK DAILY Operator Presence Interlock System - Start Operation For the engine to crank, the parking brake must be on, the PTO (blades) off and traction levers in the neutral lock position. Sit in the seat and check, one by one, if the engine will crank with the parking brake off, the blades on, and either traction lever out of neutral lock.
Page 10
MAINTENANCE PREDATOR-PRO SERIES LUBRICATION Every 50 hours of operation, lubricate the following points (1-4) with grease: 1. Deck lift rockshaft (1 point) 2. Deck lift pivots (6 points) 3. Brake lever pivot (1 point) 4. Push arms (2 points located at rear of cutterdeck under each fuel tank) 5.
MAINTENANCE PREDATOR-PRO SERIES HYDRAULIC SYSTEM Fluid level in the hydraulic system should be checked after the first 5 hours of operation, and every 100 hours thereafter, or when a leak has occurred. If the fluid is low, check all components for leaks. To check, remove reservoir cap M.
MAINTENANCE PREDATOR-PRO SERIES ENGINE OIL Do not perform engine maintenance without the engine off, spark plug wires disconnected and PTO disengaged. AFTER FIRST FIVE (5) HOURS While the engine is warm: 1. Release the oil drain hose assembly from the engine clip J.
MAINTENANCE PREDATOR-PRO SERIES ENGINE COOLING Continued operation with a clogged cooling system will cause severe overheating and can result in en- gine damage. Daily: Clean air intake screen S on air cooled engines and T on liquid cooled engines. Every 100 hours: Clean cooling fins beneath blower housing H with reference to information in the engine manufacturer's manual.
MAINTENANCE PREDATOR-PRO SERIES CLEANING MACHINE Clean the machine after use. Compressed air is recommended. Do not use a pressure washer. The machine will run cooler and last longer if kept free of clippings and other debris. A clean machine also re- duces the risk of fire due to accumulation of combus- tible debris and chaff.
Page 15
MAINTENANCE PREDATOR-PRO SERIES BLADE REMOVAL BLADE BALANCE Follow these instructions to prevent injury during Blade balance must be maintained at 5/8 oz-in blade removal: (19.4 g-cm) or less. Failure to keep blades balanced 1. Loosen with a box wrench or a socket and long causes excess vibration, wear, and shortened life of breaker bar.
ADJUSTMENTS PREDATOR-PRO SERIES DECK LEVELING a) Park the machine on a smooth, level surface. Raise the deck to the transport position. b) Lower the deck onto a pair of equal height blocks A under the rear corners of the deck. Place another pair of adjustable blocks B under the front of the deck so that the deck top is pitched forward 1/8”.
ADJUSTMENTS PREDATOR-PRO SERIES HEIGHT OF CUT The height of cut is set by moving height of cut pin C to the hole designated for the height of cut desired. To change the height of cut: 1. Lift the deck to the highest position. 2.
ADJUSTMENTS PREDATOR-PRO SERIES CONTROL LEVERS There are two mounting positions for the control levers, upper and lower. The lower position works well for most people. Taller operators may need the upper position. To adjust the height of the control levers: Remove bolts A and nuts B.
Page 19
ADJUSTMENTS PREDATOR-PRO SERIES TRACKING HANDLES An adjustment is provided to allow the operator to adjust machine tracking during operation. 1. Turn knob W clockwise to shorten control lever travel. 2. Turn knob W counter-clockwise to increase con- trol lever travel. DAMPERS Different damper mounting holes have been provided for various operator preferences with control lever...
Page 20
ADJUSTMENTS PREDATOR-PRO SERIES HYDROSTAT ADJUSTMENTS A turnbuckle-style hydrostat neutral adjustment is provided. Neutral: 1. Support the machine with the rear wheels off the ground. Use jackstands or equivalent sup- port. Do not rely only on mechanical or hydraulic jacks. 2. Move the traction levers out into the neutral lock position and raise the seat.
PREDATOR-PRO SERIES Note: Always use Schiller Grounds Care, Inc.replacement belts, not general purpose belts. Schiller Grounds Care, Inc.belts are specially designed for use on commercial mow- ers and will normally last longer. CUTTERDECK BELT 1. Tilt floorplate all the way forward.
SPECIFICATIONS PREDATOR-PRO SERIES POWER UNITS ENGINES: CONTROLS: Construction: Aluminum block with cast-in cast iron sleeves. Aluminum head. Throttle; choke; power takeoff (PTO) clutch switch; Configuration: 4-stroke, vertical shaft, V-twin cylin- traction levers; parking brake lever; lift lever. der, overhead valve, air-cooled. FUEL SYSTEM: DRIVE SYSTEM: One tank on each side of operator.
Page 23
SPECIFICATIONS PREDATOR-PRO SERIES ENGINE MODEL NUMBERS 942512G, 942513G 942515G, 942516G 942518G 942514G MANUFACTURER Kohler Generac Kawasaki Kawasaki MODEL CV750 GTV990 FX1000V FX921V CYLINDERS COOLING 3.3 X 2.7" 3.54 X 3.07" 3.5 X 3.2" 3.5 X 3.2" BORE/STROKE (83 X 69mm) (90 X 78mm) (89.2 X 80mm) (89.2 X 80mm)
Page 24
SPECIFICATIONS PREDATOR-PRO SERIES & & r i f , l i t l i...
Page 25
SPECIFICATIONS PREDATOR-PRO SERIES CUTTERDECKS 942513G, 942516G MODEL NUMBER 942512G, 942514G 942518G 942515G TYPE Side Discharge Side Discharge CUTTING WIDTH 61" (155 cm) 71.5" (181 cm) WIDTH WIDTH 62" (157 cm) 72.5" (184 cm) (CHUTE UP) WIDTH 73" (185 cm) 84.0" (213 cm) (CHUTE DOWN) high lift high lift...
OIL COOLER PREDATOR-PRO SERIES FIGURE 8 TO RH FUEL TANK TO ENGINE TO LH FUEL TANK TO PUMP CASE DRAIN...
Page 43
OIL COOLER PREDATOR-PRO SERIES FIGURE 8 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 4165919 S ENGINE DECK W/LABS ITEMS 22-30 ARE USED ON DFI ONLY 4166416.7 BRKT-COOLER FRONT (USED ON KAWASAKI MODELS) ITEMS 22-26 ORDER 4162977-016 LENGTH 48" 4166418.7 BRKT-COOLER FRONT 4162977-016 CUT TO 26"...
Page 44
AIR COOLED HYDRAULICS PREDATOR-PRO SERIES FIGURE 9...
Page 45
AIR COOLED HYDRAULICS PREDATOR-PRO SERIES FIGURE 9 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 4165920 S HYD RESERVOIR W/LAB 2720396 FILTER 25 MICRON 4165236 CAP-RESERVOIR 4160243 PLUG-HYDRAULIC TANK 158058-04 FTG-90 BRB 9/16-18X.38 108205-03 ELBOW-MALE 45 37-ORB 69053-05 3/8 HIGH TEMP HSE (69053-05 IS A SERVICEABLE LENGTH OF 55") LH PUMP PORT A-HOSE KAW MODEL 2188157-02...
Page 46
HYDROGEAR PUMP PREDATOR-PRO SERIES FIGURE 10...
Page 47
HYDROGEAR PUMP PREDATOR-PRO SERIES FIGURE 10 ITEM HYDROGEAR PART NO. CGC, INC. PART NO. DESCRIPTION 71019 4157242-001 PUMP SHAFT KIT-TAPERED 2000038 4157242-002 RETAINING RING 2000023 4157242-003 SPACER 51092 4157242-004 LIP SEAL 70739 4157242-005 TRUNNION SEAL/RETAINER 2000014 4157242-006 TRUNNION ARM 2000015 188059-09 SLOT GUIDE 70738...
Page 48
NON-DFI WIRE HARNESS PREDATOR-PRO SERIES FIGURE 11 CLUTCH ELECTRIC WIRE COLORS WHITE ENGINE GROUND STARTER WHITE W/ BLACK STRIPE PURPLE ORANGE ORANGE W/ BLACK STRIPE PURPLE W/ ORANGE STRIPE ORANGE W/ PURPLE STRIPE DARK BLUE BLACK GREEN BATTERY BATTERY YELLOW YELLOW W/ BLACK STRIPE RED W/ WHITE STRIPE GREEN W/ YELLOW STRIPE...
Page 49
NON-DFI WIRE HARNESS PREDATOR-PRO SERIES FIGURE 11 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 4165575 HARNESS-WIRING MAIN 148082-20 FUSE-20 AMP 108061-13 CABLE-BATTERY 36 BLACK 1 4124009 SWITCH-SEAT, NO 4143068 JUMPER-SEAT SWITCH 4165120 METER-HOUR 2722227-02CABLE-BATT W/CONDUIT (INCLUDES ITEMS 20 & 21) 128010 KEY-SWITCH 2722325...
Page 68
DECALS-POWER UNIT PREDATOR-PRO SERIES FIGURE 22 BACK OF ENGINE DECK DOCUMENT TUBE LOCATED UNDER FOOTPLATE UNDER SEAT LOCATED BEHIND SEAT ON OIL COOLER LOCATED UNDER FOOTPLATE...
Page 69
DECALS-POWER UNIT PREDATOR-PRO SERIES FIGURE 21 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 4165866 LABEL-PREDATOR-PRO 4158401 LABEL-BOB-CAT, 10.5" 2000735 LABEL-OPER MAN 2000590 LABEL, WARN BATTERY 4165722 LABEL - HYDR OIL FILL 4165639 LABEL-CONTROL PANEL (USED ON NON-DFIMODELS) 4165638 LABEL-CONTROL PANEL (USEDON DFI MODEL ONLY) 2000693 LABEL - PARK BRAKE...
Page 70
DECALS-CUTTERDECKS PREDATOR-PRO SERIES FIGURE 23...
Page 71
DECALS-CUTTERDECKS PREDATOR-PRO SERIES FIGURE 22 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 4164269 LABEL-WARNING BLADES 1 2000577 LABEL-WARNING...
