Summary of Contents for PLC2 PGC-1000
- Page 1 User Guide (EN) PGC-1000 Grabber Card Rev. 1.2.14 plc2 Design GmbH Ersteiner Straße 19 79346 Endingen a. K. Deutschland +49 7642 92118 0 plc2.com Fehler! Kein Text mit angegebener Formatvorlage im Dokument.
- Page 2 Standardization of references to other product documents March 09, 2023 1.2.12 First Version in Word March 14, 2023 1.2.13 Standardization of sublines in tables Jul 11, 2023 1.2.14 Footnote corrections F-00k-114-438.201 2023 - © plc2 Design GmbH PGC-1000_User_Guide_EN_1.2.14 Page 2 of 20...
- Page 3 Copyright The information in this document must not be changed without separate notification from plc2 Design GmbH. Furthermore, plc2 Design GmbH does not enter into any further obligations with this document. The software presented in this document is provided based on a general licensing agreement or an individual license.
-
Page 4: Table Of Contents
PGC-1000 Interfaces ................................10 04.1 QSFP+ Interface ..................................11 PGC-1000 Installation Instructions ............................12 05.1 Safety Instructions ................................... 12 05.2 Installation of the PGC-1000 Grabber Card .......................... 12 05.3 Wiring ....................................... 12 05.4 Checking the Function of the PGC-1000 ..........................13 Appendix ....................................14 06.1 Appendix: Abbreviations ................................ -
Page 5: About This Document
Indicates a dangerous, low-risk situation which, if not avoided, may lead to a minor or moderate injury. Notice Indicates a situation which, if not avoided, can lead to material damage. 01.2 Presentation of Supporting Information Note Contains additional supporting information. F-00k-114-438.201 2023 - © plc2 Design GmbH PGC-1000_User_Guide_EN_1.2.14 Page 5 of 20... -
Page 6: General Safety Information
Failure to comply with the safety instructions may lead to the risk of damage to life and limb or property. The companies of the plc2 Group and its representatives accept no liability for any damage or injury caused by improper operation or improper use of the product. Only use the product if you have read and understood the information concerning safe operation and have the required qualifications and training for this product. -
Page 7: Electrical Safety And Power Supply
PGC-1000. 02.2.6 Approved Cables Only use PLC2 cables or other cables certified for the application. Route the cables such that they are protected against abrasion, damage, deformation and kinking. Do not place any objects on the cables. -
Page 8: Cleaning
Only clean the product when it is de-energized. Do not use compressed air to clean the fans. Make sure that no moisture enters the product. Carefully vacuum off dust particles and loose foreign bodies. F-00k-114-438.201 2023 - © plc2 Design GmbH PGC-1000_User_Guide_EN_1.2.14 Page 8 of 20... -
Page 9: Product Description
® transmitting up to 4 x 10 Gbit/s via QSFP+. The PGC-1000 is very well suited for recording data from high-end multi-camera systems in average PCs. Through the use of the PGC-1000, high costs for high-end multiprocessor PCs are avoided. The use of the PGC-1000 significantly reduces CPU load by pre-processing camera data on the PGC-1000's programmable hardware. -
Page 10: Pgc-1000 Interfaces
PGC-1000 Interfaces The PGC-1000 grabber card is a PCIe card in low-profile half-length format, which can be installed in any CPU-based standard motherboard with at least one PCIe x8 slot. The card provides the following interfaces: One PCIe x8 connector One QSFP+ interface Not for use: A PCIe 6-pin 12 V power connector. -
Page 11: Qsfp+ Interface
Only use short-range QSFP+ transceivers with a maximum cable length of 30 m. Figure 3: QSFP+ interface pin layout, copyright © 2018 SNIA Figure 4: function of the different pins of the QSFP+ interface, copyright © 2018 SNIA F-00k-114-438.201 2023 - © plc2 Design GmbH PGC-1000_User_Guide_EN_1.2.14 Page 11 of 20... -
Page 12: Pgc-1000 Installation Instructions
Shut down the PC and disconnect the power connector of the PC. Open the PC by removing the housing or part of the housing. Remove the slot bracket of the housing at the position where the PGC-1000 card is to be installed. Additionally, remove the adjacent slot bracket if necessary. -
Page 13: Checking The Function Of The
Checking the Function of the PGC-1000 Install the drivers according to the Software User Guide and make sure that the PGC-1000 is displayed in the Windows Device Manager. Note The product is capable of forwarding data even in the event of an error. Use the monitoring capabilities and error indicators of the product and of the transmitted data to detect erroneous data. -
Page 14: Appendix
QSFP+ 4X Hardware and Electrical Specification, page 14 https://www.snia.org/technology-communities/sff/specifications (as of 11/30/2022) Pad function definition QSFP+ 4X Hardware and Electrical Specification, page 15 https://www.snia.org/technology-communities/sff/specifications (as of 11/30/2022) Table 3: references F-00k-114-438.201 2023 - © plc2 Design GmbH PGC-1000_User_Guide_EN_1.2.14 Page 14 of 20... -
Page 15: General Data
12 V DC, 3 A max (via PCIe interface) 3.3 V DC, 11.75 A max (via PCIe interface) Max. power consumption 58 W Overvoltage category (IEC 60664-1) Table 6: electrical data F-00k-114-438.201 2023 - © plc2 Design GmbH PGC-1000_User_Guide_EN_1.2.14 Page 15 of 20... -
Page 16: Rohs Conformity
Pollution Caused by Electronic Information Products Regulation) applicable in the People's Republic of China. 07.3 CE Conformity With the CE marking attached to the product or its packaging, plc2 Design GmbH confirms that the product corresponds to the applicable product-specific directives of the European Union. 07.4 UKCA Conformity With the UKCA marking attached to the product or its packaging, plc2 Design GmbH confirms that the product meets the applicable product-specific standards and directives of Great Britain. -
Page 17: Use Of Open Source Software
Reference must be made to the use of the software in order to fulfill OSS licensing terms. More information can be found in the OSS Attribution document. F-00k-114-438.201 2023 - © plc2 Design GmbH PGC-1000_User_Guide_EN_1.2.14 Page 17 of 20... -
Page 18: Self-Help
Self-Help Problem description Trouble shooting questions PGC-1000 is not visible in Windows Device Manager Set the DIP switches on the PGC-1000 PCIe as "PGC1K Device" or as "Ethernet Controller". card as shown in the image below. PGC-1000 is visible in Windows Device Manager as Install the PGC-1000 driver. -
Page 19: Contact Information
Fax: +49 7642 92118-29 www.plc2.com Technical support Please contact the distributor or get in touch with us directly via our website www.plc2.com. Shipment and packaging Please contact the distributor or get in touch with us directly via our website www.plc2.com. -
Page 20: List Of Figures
List of Figures Figure 1: PGC-1000 Grabber Card Figure 2: PCIe power connector pinout Figure 3: QSFP+ interface pin layout Figure 4: function of the different pins of the QSFP+ interface Figure 5: WEEE Symbol List of Tables Table 1: minimum system requirements...
