Aplab VSP1060 Instruction Manual

High power switching dc power supplies
Hide thumbs

Advertisement

Quick Links

MODELS
VSP1060, VSP2030, VSP3020,VSP4015,
VSP6010, VSP1205, VSP2060, VSP3040,
VSP4030, VSP6020, VSP12010, VSP8015,
VSP3080, VSP4060,VSP6040, VSP8030,
VSP12020, VSP20180, VSP30120, VSP4090,
VSP6060, VSP12030, VSP8045, VSP30240,
VSP40180,VSP60120, VSP8090, VSP12060
High Power Switching DC Power Supplies
Instruction Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the VSP1060 and is the answer not in the manual?

Questions and answers

Summary of Contents for Aplab VSP1060

  • Page 1 MODELS VSP1060, VSP2030, VSP3020,VSP4015, VSP6010, VSP1205, VSP2060, VSP3040, VSP4030, VSP6020, VSP12010, VSP8015, VSP3080, VSP4060,VSP6040, VSP8030, VSP12020, VSP20180, VSP30120, VSP4090, VSP6060, VSP12030, VSP8045, VSP30240, VSP40180,VSP60120, VSP8090, VSP12060 High Power Switching DC Power Supplies Instruction Manual...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS SECTION DESCRIPTION PAGE NO. TEST INSTRUMENT SAFETY GENERAL INFORMATION INSTALLATION OPERATING INSTRUCTION MAINTENANCE REMOTE INTERFACE CUSTOMER SUPPORT WARRENTY INFORMATION SERVICE INFORMATION...

  • Page 3: Test Instrument Safety

    This is a safety feature to keep the housing or other exposed elements at earth ground. 8. Aplab products are not authorized for use in any application involving direct contact between our product and the human body or for use as a critical component in a life support device or system.

  • Page 4: General Information

    Section 2 General information INTRODUCTION FEATURE MARKINGS INTERFACE SPECIFICATION ORDERING INFORMATION INTRODUCTION The VSP SERIES power supplies are designed to deliver power in constant voltage and constant current mode by switch mode conversion in sleek 1U high cabinet and in a 19’’ rack construction. This series comprises the two device soft switching technology that yields very high efficiency of conversion for dc-to-dc converter part.
  • Page 5 Some of the features of the power supply are listed below: FEATURES MAINS OPERATED, WITH WIDE INPUT RANGE. POWER FACTOR CORRECTED INPUT. ISOLATED D.C. OUTPUT. CONSTANT VOLTAGE OPERATION FROM 0 TO FULL-SCALE LEVEL. CONSTANT CURRENT OPERATION FROM 0 TO FULL-SCALE LEVEL. OVER VOLTAGE CONTROL FACILITY.
  • Page 6 SPECIFICATIONS Output Specification Model VSP1060* VSP2030* VSP3020* VSP4015* Power 0.6KW 0.6KW 0.6KW 0.6KW Output Voltage 0–10V 0–20V 0–30V 0–40V Output Current 0–60A 0–30A 0–20A 0–15A Noise (10Hz to 20MHz) <45mVpp <45mVpp <45mVpp <45mVpp Model VSP6010 VSP1205 VSP2060 VSP3040 Power 0.6KW 0.6KW...
  • Page 7 Programming Resolution (Digital Interface), LSB (not LED displays) Voltage 20 mV 10 mV 10 mV 100 mV Current 10 mA 20 mA 10 mA 10 mA Output Programming Accuracy (Analog Programming 0 To 5V & 0 To 10V) Voltage 0.5 % of F. S. ± 1 Digit (spec. for all VSP models) Current 0.5 % of F.
  • Page 8 Operating Environment Temperature 0 - 50°C Relative Humidity < 80% rh – non condensing Storage Temperature - 20°C. to + 70°C. Warm-up Time 15 minutes. Safety Standards EMI Filtering EN55022 Class-A Safety Class EN60950 Mechanical Specifications Weight (appox.) 13.7lbs. (6.2 KG.) Dimensions (WxHxD) 19 x 1.75 x 18”...

  • Page 9: Installation

    Section 3 Installation INTRODUCTION UNPACKING INPUT POWER REQUIREMENTS SYSTEM CONFIGURATION INSTALLATION TEST EQUIPMENT REQUIREMENTS Introduction VSP series power supply is configured, calibrated and tested prior to shipment. This unit is therefore ready for immediate use upon receipt. The initial physical inspec- tions should be made to ensure that no damage has been sustained during shipment.
  • Page 10 Input Power Requirements The Model VSP power supply is configured at the factory to operate from 95-264 VAC at 47-63 Hz power line. System Configuration The Model VSP series power supply comes in ready to use fashion and does not require any configuration in the field for operation in the local mode.
  • Page 11 Test Equipment Requirements The following instruments will be required to test the complete installation of the unit. 1). A four and half digit or better digital multimeter for verifying the voltage and current output of the unit. 2). A 20 MHz dual channel oscilloscope for verifying the Ripple in Output of the Source. 3).
  • Page 12 Fig 3.1a : CONNECTION DETAILS IN LOCAL & REMOTE INTERFACE LOCAL MODE SWITCH CONFIGURATION VPROGI VPIN (ON REAR PANEL) VPROGR AGND3 IPIN IPROGI IPROGR +12V AGND3 REMOTE ON/OFF AGND3 VPSET VMSET IPSET IMSET CS BUS CS BUS Output +VE Output +VE Output -VE Output -VE LOAD...

  • Page 13: Operating Instruction

    Section 4 Operating instruction INTRODUCTION FRONT PANEL DESCRIPTION REAR PANEL DESCRIPTION POWER ON CHECK OPERATING INSTRUCTIONS IN LOCAL MODE OPERATING INSTRUCTIONS IN ANALOG REMOTE INTERFACE OPERATING INSTRUCTIONS IN DIGITAL INTERFACE TRIP INDICATIONS INTRODUCTION The VSP series Model is a variable switch mode power supply to provide wide range of DC supply from 0 to full-scale specified voltage.
  • Page 14 FRONT PANEL DESCRIPTION Figure 4.1 shows layout of front panel. On the front panel following controls and indicators are provided. Main ON/OFF switch with neon indication. 3 digit display for Voltage/ Set Voltage/ Set Over Voltage indication 3 digit display for Current/ Set Current indication. 10 turn POT for voltage control.
  • Page 16 Sr. No. Description Sr. No. Description Input Line Cable Output Sense Terminals Input Fuse Analog Interface Connector Input R. F. Filter DIP switches for Analog Interface selection VSP-PFC-1.2KW-1103D, PCB Cooling Fans Input ON/OFF Switch SBC-IEB-0504A, PCB (For GPIB) Heat Sinks VSP-POT-IMON-0604A, PCB PFC Choke VSP-FPDAC CONV-0604A, PCB...
  • Page 17 4.3.1 LINE INPUT The mains input range is clearly indicated on rear panel. The unit comes stan- dard with a U.S. standard plug and a mains input rating of 95VAC to 265VAC, 50/60Hz. 4.3.2 INPUT FUSE This fuse protects the unit against short circuits and over loading. The 20A fuse of type ’F’...
  • Page 18 Pin no.14: N.C. Pin no.15: +12 V- Remote on/off relay supply +ve. Pin no.16: AGND3 - Common terminal for remote programming. Pin no.17: Remote On/Off - Remote on/off relay. Pin no.18: AMX- Output Current monitoring. (Factory set to 0 to 5 volts for full scale) Pin no.19: VMX - Output Voltage monitoring.
  • Page 19 OPERATING INSTRUCTIONS IN LOCAL MODE These are the instructions for operating the source in local mode. Initially after Power ON Unit work in local mode.In local mode the power supply can be controlled through front panel potantion meters. Also Refer to the settings of 8Way DIP Switch provided on rear panel to operate in Local mode.
  • Page 20 OPERATING INSTRUCTIONS IN ANALOG REMOTE INTERFACE The Remote analog interface is Provided to control the power supply with external analog signals.Before using the interface check the type of digital interface provided with the system. A slide switch no. 7 on 8 pin DIP switch array is provided at the rear panel to bypass digital and front panel pot controls.
  • Page 21 Refer figure 4.1b for external resistance programming 0 to 4.85kohms for full scale voltage and current . It also shows the load connections required in this mode. As shown in the figure for Voltage Control connect the resistance of 4.85 K ohms at pin 4 &...

  • Page 22: Maintenance

    Section 5 Maintenance INTRODUCTION PREVENTIVE MAINTENANCE SERVICE INFORMATION Introduction This chapter contains the problems that may occur in the field in the event of long use. The procedure to test the unit is explained under the proper section. The individual is advised to use the correct procedure provided for the purpose of operating the particular sequence to set proper voltages and current required to test the proper working of the unit.
  • Page 23 When the unit is not turning ON. Check if the power ON/OFF switch is turned ON. Check whether fuse mounted on the rear panel is OK? If fuse is good then check the power cord. Please make sure that the power cord connecting to the unit is properly connected. Please also check the mains switch.

  • Page 24: Remote Interface

    Section 6 Remote interface INTRODUCTION RS232C INTERFACE RS232C OPERATION IEEE-488 OPERATION INTRODUCTION TO SCPI LANGUAGE COMMAND SUMMARY MANDATORY COMMANDS INSTRUMENT COMMANDS IEEE-4888 COMPLIANCE INFORMATION 6.10 SRQ HANDLING DETAILS 6.11 ERROR MESSAGES & REPORTING 6.12 APPLICATION PROGRAM EXAMPLES Introduction VSP series power supplies are configured for either RS232C or GPIB as per the order placed (refer chapter 1 for ordering information).
  • Page 25 RS232C INTERFACE: The basic principle of RS232C operation is achieved by 3-wire interface. The 3-wire interface comprises of transmit pin (abbreviated as TXD), receive pin (abbre- viated as RXD) and a common ground pin (GND). TXD pin of host is connected to the RXD pin of the instrument and the RXD pin of the host is connected to the TXD pin of the instrument and the third line connects the GROUNDs of the two sides.
  • Page 26 6.3.1 RS232 Data Format One Start Bit 8 Data Bits No Parity Bit 1 Stop Bit 6.3.2 RS232 Connector Details On the rear panel of the unit, a 9 pin D-type male connector is provided for the RS232 communication. The DSR and DTR handshake lines are not used. But the interface cable which connects the COMM INTF on the instrument to the PC COM port (COM 1 or COM 2) should interconnect the RXD and the TXD line, such that the RXD input the instrument is the TXD output of the host controller or PC.
  • Page 27 6.3.3 INSTALLATION OF RS232 CARD The RS232 Interface (ISO_RS232_CONV-1103 Card) card may come already installed, if ordered. If this interface is to be installed later, the card can be mounted on the rear panel of the unit using L-clamp provided on the card itself & following cards &cables shall be provided along.
  • Page 28 6.3.4 RS232 Commands Following section deals with the commands set for RS232 interface. It specifies the syntax of each command, which reads the status of power supply or configures it to the requirements of users. NOTE: The command uses following notations <SP>...
  • Page 29 Command: VOLT: PROT<SP><NR.DATA><EOS> Description: Set Over Voltage Protection Limit of OUTPUT Function: This command sets the Over Voltage Protection Limit of the Power Supply output with the <NR.DATA> given in the command in Volts. The input VOLTAGE data is in Numeric Data format. Once this OVP limit is set, any time if the actual Output Voltage of the channel exceeds the OVP limit, the OUTPUT will be ‘TRIPed’.
  • Page 30 Command : STAT? <EOS> Description: Read Status Query. Function: This command reads the status of various events occurred in the system. The definition of events is given below Over voltage Trip Over Temperature Trip Power On event (Sets when unit is turn ON. The bit gets cleared after the quarry.) Internal Failure Always 1 (THIS STATUS BIT MAY BE CHANGED IN FUTURE)
  • Page 31 6.4.1 IEEE-488 Interface Configuration The IEEE-488 Interface is a parallel BUS for Communication in the Program- mable Instruments. Multiple instruments can be connected on the same BUS and can be hooked up to a single HOST controller or computer. In order that instruments from different manufacturers can be built into the same system, it was necessary that all interfaces be compatible.
  • Page 32 6.4.2 IEEE-488 Connector Details The instrument provides a standard 24 pin GPIB connector (marked as COMM INTF on the rear panel of the instrument) to connect it with the standard GPIB (IEEE- 488) bus. Refer FIG. 6.3 for connector types definition diagram. Description of the GPIB Signals is given below.
  • Page 33 6.4.3 IEEE-488 Operational Sequence Guidelines Most interface communication tasks require a sequence of coded mes- sages to be sent over the interface. It is recommended that a careful study of the available controller capabilities be made many of them assigning one programming instruction to these sequences.
  • Page 34 UNL = Unlisten SPE = Serial Poll Enable SPD = Serial Poll Disable SBN = Status Byte Negative, where BIT 6 = 0 (BIT 7 is the MSB) SBA = Status Byte Affirmative, where BIT 6 = 1 (BIT 7 is the MSB) 6.4.4 Installation procedure for GPIB interface option in the VSP series power Refer to the general assembly layout of the VSP series power supplies.
  • Page 35 f) Compile the project. g) Connect line input to the unit. Keep the front panel output ON/OFF switch in OFF position. Turn the unit on with the input ‘Line’ switch. h) Run CSPY to download program in flash memory of the controller. Press the RESET button in the window and exit from CSPY.
  • Page 36 Remove JP2,JP3, JP4 & JP5 From J3 of SBC-IEB Install JP1 From J2 Remove Jumper Link here. VSP-DPM-CONT To J7 To J5 To J1 of VSP-POT-IMON To J1 of INSTR-TO-GPIB 6.4.5 IEEE-488 Instrument Address Selection The instrument address is set manually using an eight way miniature switch near the interface connector on the rear panel.
