- Page 1 Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Lenovo Yoga Duet 7 82AS003VIX o cerca il tuo prodotto tra le migliori offerte di Notebook Hardware Maintenance Manual Yoga Duet 7 (13″, 05)
- Page 2 First Edition (May 2020) © Copyright Lenovo 2020.
-
Page 3: Table Of Contents
Trademarks ....xlv Service tools ....General guidelines ....© Copyright Lenovo 2020... - Page 4 Hardware Maintenance Manual...
-
Page 5: About This Manual
Important: • This manual is intended only for trained service technicians who are familiar with Lenovo products. • Before servicing a Lenovo product, be sure to read all the information under Chapter 1 “Safety information” on page 1. © Copyright Lenovo 2020... - Page 6 Hardware Maintenance Manual...
-
Page 7: Chapter 1. Safety Information
• Do not work alone under hazardous conditions or near equipment that has hazardous voltages. • Disconnect all power before: – Performing a mechanical inspection – Working near power supplies © Copyright Lenovo 2020... -
Page 8: Safety Inspection Guide
This guide addresses only those items. You should use good judgment to identify potential safety hazards due to attachment of non-Lenovo features or options not covered by this inspection guide. -
Page 9: Handling Devices That Are Sensitive To Electrostatic Discharge
4. Check for cracked or bulging batteries. 5. Remove the cover. 6. Check for any obvious non-Lenovo alterations. Use good judgment as to the safety of any non-Lenovo alterations. 7. Check inside the unit for any obvious unsafe conditions, such as metal filings, contamination, water or other liquids, or signs of fire or smoke damage. -
Page 10: Grounding Requirements
Grounding requirements Electrical grounding of the computer is required for operator safety and correct system function. Proper grounding of the electrical outlet can be verified by a certified electrician. Safety notices (multilingual translations) The safety notices in this section are provided in the following languages: •... - Page 11 DANGER DANGER DANGER DANGER DANGER Chapter 1 Safety information...
- Page 12 Hardware Maintenance Manual...
- Page 13 PERIGO PERIGO PERIGO Chapter 1 Safety information...
- Page 14 PERIGO PERIGO PERIGO PERIGO PERIGO Hardware Maintenance Manual...
- Page 15 DANGER DANGER DANGER DANGER Chapter 1 Safety information...
- Page 16 DANGER DANGER DANGER DANGER VORSICHT Hardware Maintenance Manual...
- Page 17 VORSICHT VORSICHT VORSICHT VORSICHT Chapter 1 Safety information...
- Page 18 VORSICHT VORSICHT VORSICHT Hardware Maintenance Manual...
- Page 19 Chapter 1 Safety information...
- Page 20 Hardware Maintenance Manual...
- Page 21 Chapter 1 Safety information...
- Page 22 Hardware Maintenance Manual...
- Page 23 Chapter 1 Safety information...
- Page 24 Hardware Maintenance Manual...
- Page 25 Chapter 1 Safety information...
- Page 26 Hardware Maintenance Manual...
-
Page 27: Chapter 2. General Checkout
• Scratched (cosmetic) parts • Distortion, deformation, or discoloration of the cosmetic parts • Plastic parts, latches, pins, or connectors that have been cracked or broken by excessive force • Damage caused by liquid spilled into the system © Copyright Lenovo 2020... -
Page 28: Cru List
Table 1. Model: Yoga Duet 7 13IML05 (Machine type: 82AS) Type ac power adapter self-service Power cord self-service Card tray self-service Bluetooth folio keyboard * self-service Lenovo Digital Pen * self-service Lenovo E-Color Pen * self-service * for selected models Hardware Maintenance Manual... -
Page 29: Chapter 3. Idetifying Frus (Crus)
Chapter 3. Idetifying FRUs (CRUs) Locate FRUs and CRUs The exploded illustrations help Lenovo service technicians identify FRUs or CRUs that they may need to replace when servicing a customer’s computer. Figure 1. Yoga Duet 7 (13″, 05) exploded view... - Page 30 Table 2. FRU (CRU) categories FRU (CRU) category LCD module LTE bracket Auxiliary Wi-Fi module Heat sink Function board cable Function board System board Speaker Solid-state drive (SSD) mylar Solid-state drive (SSD) ToF board cable ToF board LCD cover Side switch module Pogo pin module Battery pack Card tray...
-
Page 31: Chapter 4. Removing A Fru Or Cru
Chapter 4. Removing a FRU or CRU Service tools The following table lists tools for servicing Lenovo computers. Tools with a cross mark are needed for serving the product models as described by this publication. Prepare them before you service the product. -
Page 32: Remove The Card Tray
Remove the card tray Step 1. Use the ejection tool to eject the card tray carefully. Figure 2. Remove the card tray Go to to look up the Lenovo part number of the following replacement https://support.lenovo.com/partslookup part: Card tray Remove the LCD module Make sure the computer has been shut down before servicing the computer. - Page 33 Figure 3. Open the kickstand and then remove six screws Screw specifications Number of screws M1.6 x L4 Step 2. Pry up the latches carefully. Note: The screen is very fragile, remove it with care. Figure 4. Pry up the latches carefully Step 3.
-
Page 34: Remove The Edp Cable
Attention: Use your fingernails to pull the connector to unplug it. Do not pull the cable. Figure 6. Disconnect the EDP cable from the LCD module and remove the LCD module Go to to look up the Lenovo part number of the following replacement https://support.lenovo.com/partslookup part:... -
Page 35: Remove The Solid-State Drive (Ssd) Module
Screw specifications Number of screws M2 x L2 Go to https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement part: Battery pack Remove the solid-state drive (SSD) module Make sure the following FRU (or CRU) has been removed. -
Page 36: Remove The Speakers
Disconnect the speaker cables from the system board and release the speaker cable from the cable guide. Remove the speakers. Figure 12. Remove the speakers Go to to look up the Lenovo part number of the following replacement https://support.lenovo.com/partslookup part: Speakers... -
Page 37: Remove The Fan
Figure 14. Remove the fan Screw specifications Number of screws M2 x L2.8 Go to to look up the Lenovo part number of the following replacement https://support.lenovo.com/partslookup part: Remove the heat sink Make sure the following FRU (or CRU) has been removed. -
Page 38: Remove The Front Camera And Rear Camera
Figure 15. Remove four screws and then remove the heat sink Screw specifications Number of screws M2 x L2 Go to to look up the Lenovo part number of the following replacement https://support.lenovo.com/partslookup part: Heat sink Remove the front camera and rear camera Make sure the following FRU (CRU) has been removed. - Page 39 Remove the main Wi-Fi module, auxiliary Wi-Fi module and LTE bracket. Figure 19. Remove the main Wi-Fi module, auxiliary Wi-Fi module and LTE bracket Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement parts: LTE bracket...
-
Page 40: Remove The Side Switch Module
Figure 21. Remove two screws and remove the side switch module Number of screws Screw specifications M2 x L2 Go to to look up the Lenovo part number of the following replacement https://support.lenovo.com/partslookup part: Side switch module Remove the USB board module Make sure the following FRUs (or CRUs) have been removed. - Page 41 Separate the USB board cable from the USB board. Figure 24. Separate the USB board cable from the USB board Go to https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following replacement parts: USB board USB board cable...
-
Page 42: Remove The Function Board Module
Remove the function board module Make sure the following FRUs (or CRUs) have been removed. “Remove the LCD module” on page 26 “Remove the EDP cable” on page 28 “Remove the battery pack” on page 28 Step 1. Disconnect the function board cable from the system board and disconnect the side switch cable from the function board. -
Page 43: Remove The Tof Module
Figure 27. Separate the function board cable from the function board Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement parts: Function board Function board cable Remove the ToF module Make sure the following FRUs (or CRUs) have been removed. -
Page 44: Remove The Pogo Pin With Cable
Figure 29. Separate the ToF cable from the ToF board Go to https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following replacement parts: ToF cable ToF board Remove the pogo pin with cable Make sure the following FRUs (or CRUs) have been removed. -
Page 45: Remove The System Board
Screw specifications Number of screws M2 x L3.2 Go to https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement part: Pogo pin with cable Remove the system board Make sure the following FRUs (or CRUs) have been removed. - Page 46 Figure 32. Disconnect cables connected to the system board Step 2. Remove five screws and then remove the system board. Hardware Maintenance Manual...
-
Page 47: Remove The Lcd Cover
Figure 33. Remove the system board Screw specifications Number of screws M2 x L2 Go to to look up the Lenovo part number of the following replacement https://support.lenovo.com/partslookup part: System board Remove the LCD cover Make sure the following FRUs (CRUs) have been removed. - Page 48 Hardware Maintenance Manual...
-
Page 49: Appendix A. Label Locations
43 mm x 24 mm Country label KCC label TW vision warning label 70 mm x 10 mm Indonesia rating label 26 mm x 10 mm 32 mm x 12 mm SDPPI label Malaysia label 8 mm x 8 mm © Copyright Lenovo 2020... - Page 50 Table 4. All base cover labels (continued) Argentina adapter label 65 mm x 20 mm 10 mm x 9 mm Vietnam MEPS label Hardware Maintenance Manual...
-
Page 51: Trademarks
Trademarks LENOVO and the LENOVO logo are trademarks of Lenovo. All other trademarks are the property of their respective owners. © 2020 Lenovo.
