- Page 1 Binswitch Elite CAPACITANCE POINT LEVEL SENSOR ® APPROVED Class II Div. 1 INSTALLATION INSTRUCTIONS OPERATION MANUAL Part No. BSE1V10C / BSE2V10C www.go4b.com/usa...
-
Page 3: Table Of Contents
TABLE OF CONTENTS CUSTOMER SAFETY RESPONSIBILITIES Page 4 - 5 PRODUCT OVERVIEW Page 6 SPECIFICATIONS Page 6 DIMENSIONS Page 6 INSTALLATION Page 7 WIRING DIAGRAMS Page 8 SENSOR CALIBRATION Page 9 TESTING & COMMISSIONING Page 9 TROUBLESHOOTING GUIDE Page 10 BINSWITCH ACCESSORIES Page 10 PRODUCT WARRANTY... -
Page 4: Customer Safety Responsibilities
Please read the safety precautions carefully before operating the product. With each product you purchase from 4B, there are some basic but important safety considerations you must follow to be sure your purchase is permitted to perform its design function and operate properly and safely, giving you many years of reliable service. - Page 5 Correct installation of the product is important for safety and performance. If you have not asked 4B to perform the installation of the unit on your behalf, it is critical for the safety of your operation and those who may perform work on your operation that you select a qualified and competent electrical installer to undertake the installation.
-
Page 6: Product Overview
WARNING Always lockout and tagout machinery prior to installation PRODUCT OVERVIEW The Binswitch Elite sensor detects level or plug situations for bulk granular solids or liquids in tanks, bins, or silos and can be used as a plug or choke detector in chutes, conveyors and elevator legs. The sensor is fully encapsulated in a 30 mm diameter nylon body that is corrosion and abrasion resistant, dust-tight and waterproof. -
Page 7: Installation
INSTALLATION The Binswitch Elite may be mounted horizontally or vertically. 4B offers two mounts, SMP or the BMPG36 (see illustrations below). The end of the sensor must be at least one inch from the bin wall or other metalwork. It is important that the Binswitch is not located in the direct flow path of any abrasive material. However, if the Binswitch must be located in the path of an abrasive material, use in conjunction with the BAS (Binswitch Abrasion Shield). -
Page 8: Wiring Diagrams
WIRING DIAGRAMS All wiring must be In accordance with local and national electrical codes and should be undertaken by an experienced and qualified electrician. Always use dust/liquid tight flexible metal conduit with approved fittings to protect the sensor cables. Use rigid metal conduit to protect the cables from the sensors to the control unit. Conduit systems can channel water due to ingress and condensation directly to sensors and sensor connections which over time will adversely affect the performance of the system. -
Page 9: Sensor Calibration
3. Introduce material to the Binswitch. If calibrated correctly, the Binswitch will activate when material has been detected. Machinery shut down will depend on your specific monitoring setup. 4B recommends an instant shutdown when maximum fill level or a plug condition has been detected. WARNING If the system does not immediately shutdown as expected or alarm as required, then remove the machine from service until the problem has been diagnosed and corrected. -
Page 10: Troubleshooting Guide
1. If monitoring different types of materials, calibrate the sensor Sensor Not Detecting Material sensitivity to the lightest material being monitored. 2. Re-calibrate sensor, if problem continues contact 4B. BINSWITCH ACCESSORIES BMPA MOUNT BAS ABRASION SHIELD SMP MOUNTING PLATE... -
Page 11: Product Warranty
DEFECTS IN WORKMANSHIP OR MATERIALS UNDER NORMAL USE FOR ONE (1) YEAR AFTER DATE OF PURCHASE FROM 4B. ANY PRODUCT DETERMINED BY 4B AT ITS SOLE DISCRETION TO BE DEFECTIVE IN MATERIAL OR WORKMANSHIP AND RETURNED TO A 4B BRANCH OR AUTHORIZED SERVICE LOCATION, AS 4B DESIGNATES, SHIPPING COSTS PREPAID, WILL BE, AS THE EXCLUSIVE REMEDY, REPAIRED OR REPLACED AT 4B’S OPTION. - Page 12 Fax: +33 (0) 3 22 42 37 33 Tel: +27 (0) 11 708 6114 Tel: +61 (0) 7 3711 2565 Fax: +27 (0) 11 708 1654 Fax: +61 (0) 7 3711 2574 www.go4b.com Copyright © 2021 4B Group - All Rights Reserved REV010421...
