- Page 1 Operating manual Operating manual SOLAREG SDC 307 Microcontroller-controlled temperature difference controller for solar thermal systems...
-
Page 2: Table Of Contents
Explanation of the Inhalt graphic symbols Application area / device features 1.1 Application area Attention! 1.2 Device features Symbol indicates Safety instructions possible dangers Mounting the device and errors 3.1 Opening the device Attention 230V~ 3.2 Wall mounting voltage! 3.3 Connections Symbol indicates 3.4 Temperature sensor connection risks posed by... -
Page 3: Application Area / Device Features
1.1 Application area SDC 307 controllers are high-performance microprocessor-controlled units for controlling the functions of solar thermal systems. The SDC 307 perfectly controls solar power systems equipped with up to two collectors or two storage tanks and can be used for numerous system types. The controllers are designed for use in dry rooms as well as residential, business and commercial applications. -
Page 4: Mounting The Device
Mounting the device The controller must only be installed in dry and 3.1 Opening the device non-explosive areas. Mounting the controller on an inflammab- Prior to opening the device, make sure to disconnect the mains voltage and le surface is prohibited ensure that it cannot be switched back on again! The upper part of the housing is locked to the lower part using two latches. -
Page 5: Connections
3.3 Connections The following points must be followed for the 230V connections: ■ In case of a fixed mains connection, there must be a switch installed outside the controller that can disconnect the device from the mains power supply. This switch is not required if the mains supply is connected using a cable and an earthed mains plug. -
Page 6: Operating The Device
4.2 Operating the device The SOLAREG II controller is convenient and easy to operate using four operating buttons. Using the operating buttons, you can: ■ Access display values ■ Perform device settings The graphic display symbols allow you to easily navigate through the operating structure. -
Page 7: Programming" Menu
Display Can be Meaning e.g. reset Temperature difference controller for heat 35°C consumer Anti-freeze protection sensor (T1 – T6 adjust- 25°C able) Displays general temperature measur- ing point (T6) (hidden, if not connected) Operating hours for charging storage tank 1234 h Can be reset to 0 h Energy yield for storage tank 927 kWh... -
Page 8: Manual Operation" Menu
Display Value Typical Current Meaning e.g. range setting setting Temperature dif- dT min ference controller: 2 – 35K Hysteresis dTmax Time frame1(2,3): 0:00 0:00 – 23:59 0:00 Start 1(2,3) Time frame 1(2,3): 23:59 0:00 – 23:59 23:59 Stop 1(2,3) Time frame1(2,3): Start 6:00 0:00 –... - Page 9 Display Factory Current Meaning Value range setting setting Line Value Tube collector function, 0 = Off 0 = Off time-controlled 1 = On Function 0 = Off Energy yield measure- 0 = Off 1 = On ment Energy yield measure- ment 0 –...
-
Page 10: System Diagrams
System diagrams 6.1 Diagram 0: 1 collector, 1 storage tank Options with „Independant Controller“: Heating Reload Return line boost Cooling FUSE PE - PE A3 A2 A1 L1 S1 S2 S3 S4 S5 S6 S7 M M M M M M M PE - PE N N N N 230V connections Mains phase... - Page 11 6.2 Diagram 1: 1 collector, 2 storage tanks, pump valve Type 1: one collector, two storage tanks with a three-way valve: ■ A2 = Off: The valve must es- tablish the connection between the collector and storage tank 1. Installation notes for type 1 and type 3 with a three-way valve: The specified hydraulic dia-...
- Page 12 6.3 Diagram 2: 1 collector, 2 storage tanks with 2 pumps Alternative diagram FUSE PE - PE A3 A2 A1 L1 S1 S2 S3 S4 S5 S6 S7 M M M M M M M PE - PE N N N N 230V connections Mains phase Neutral conductor - mains and outputs...
- Page 13 6.2 Diagram 3: 2 collectors, 1 storage tank, pump valve Type 3: two collectors, one storage tank with a three-way valve: ■ The valve must es- tablish the connection between collector 1 and the storage tank. Installation notes for type 1 and type 3 with a three-way valve: The specified hydraulic dia- grams are recommendations.
- Page 14 6.5 Diagram 4: 2 collectors, 1 storage tank with 2 pumps FUSE PE - PE A3 A2 A1 L1 S1 S2 S3 S4 S5 S6 S7 M M M M M M M PE - PE N N N N 230V connections Mains phase Neutral conductor - mains and outputs...
-
Page 15: Controller Functions
Controller functions 7.1 General controller functions The controller compares the temperatures of the various measuring points and optimally charges the storage tank. If the collector temperature exceeds the storage tank temperature, the solar circuit pump is switched on. Monitoring and protection functions ensure safe operation. -
Page 16: Independent Controller
7.1.3 Independent controller This function is reserved for output 3 and can be allocated the following functions: ■ Cooling ■ Heating ■ Difference controller The temperature sensor for the temperature source can be selected as required. Cooling If the measured temperature exceeds the target value, output A3 is switched on until the measured temperature falls below the target value hysteresis. - Page 17 "Programming" menu Display Meaning Typical set- Value range ting Switch-on temperature of the 20 – 90°C 40°C min 40°C heating function Heating function hysteresis 1 – 30K dT 10K min 0:00 Time frame 1(2,3): 0:00 – 23:59 0:00 1(2,3) Start max 23:59 Time frame 1(2,3): 0:00 –...
-
Page 18: Tube Collector Or Start Function
7.1.4 Tube collector or start function If this function is activated, the solar circuit pump is started for the entered time frame regardless of the actual collector temperature. This allows the medium to reach the measuring point to determine the collector temperature. "Basic Setup"... -
Page 19: System Protection
7.2.3 System protection If the collector temperature exceeds the collector protection temperature (see 7.2.2) by 10K, the solar circuit pump is switched off to protect the system compo- nents. If the collector temperature drops below the collector protection temperature, the solar circuit pump is switched on. The function is always activated. -
Page 20: System Monitoring
System monitoring If an error occurs, the flashing symbol is generally displayed. 8.1 Sensor monitoring The connected sensors and sensor cables are monitored for interruptions and short-circuits. Errors are indicated by the symbol. You can find the error source by scrolling up or down the Info menu. 8.2 Flow monitoring The controller is programmed to display a message if the flow is interrupted, e.g. -
Page 21: Troubleshooting
Troubleshooting System faults are distinguished into two general categories: ■ Faults that are automatically detected by the controller and therefore can be displayed using error messages ■ Faults that the controller cannot detect 9.1 Faults with error messages Error indication in Possible causes Measures the display... -
Page 22: Faults Without Error Messages
9.2 Faults without error messages Faults that affect the 230V/A mains power Faults and malfunctions that cannot be displayed as well as possible causes and supply must only be remedied their error source can be identified using the following table. If you cannot rem- by a specialist! edy the fault using the description below, contact the supplier or installer. -
Page 23: Specifications
10 Specifications Housing Subject to change in 100% recyclable ABS housing for wall mount- accordance with techni- Housing material cal advances! Dimensions L x W x D in mm, 175 x 134 x 56; approx. 360 g weight IP20 according to DIN 40050, IEC 529, VDE Protection class 0470, EN 60529 Electrical specifications... -
Page 24: Disposing Of The Controller
The product complies with the regulatory requirements and standards on CE conformity and therefore carries the CE mark. Manufacturer Address Prozeda Technology GmbH In der Büg 5 D-91330 Eggolsheim Telefon: +49(0)9191/6166-0 E-Mail: info@prozeda.com www.prozeda.com Operation manual for SDC 307 1316BED026-22B-E...
