https://wiki.teltonika-networks.com/view/QSG_TSW202
QSG TSW202
Main Page
>
TSW Switches
This Wiki page contains the online version of the Quick Start Guide (QSG) for the TSW202
managed switch . Here you will find an overview of the various components on the front and back
of a TSW202 device, hardware installation instructions, first login information, device specifications,
and general safety information. It is highly recommended to acquaint yourself with the Quick Start
Guide before using the device. You can also locate a printed version of the Quick Start Guide in the
packaging box of your device.
Contents
•
1 Safety information
-
1.1 General
-
1.2 CE Declaration of Conformity
-
1.3 Operating conditions
-
1.4 Faulty and damaged products
-
1.5 Electrical safety
-
1.6 Product handling
•
2 Front view
•
3 Back view
•
4 Connectors
•
5 Video Quick Start Guide
•
6 Hardware installation
•
7 Login to device
Safety information
Before starting operating the device, please review recommendations and precautions to minimize
the possibility of accidents. Safety precautions presented are supplementary and subject to the local
safety regulations. When various operations are executed on the device, the user must fully follow
the safety instructions and recommendations provided with the device.
General
Technical specifications
Input voltage range
Max power consumption
Max PoE power budget at PSE 240 W*
Bundled accessories specifications**
Power adapter
PoE operates properly only when connected power supply outputs 44 V or higher voltage.
Order code dependant.
TSW202 must be used in compliance with any and all applicable national and international laws and
>
TSW202
> QSG TSW202
7-57 VDC
8 W
No accessories
Advertisement
Related Manuals for Teltonika QSG TSW202
Summary of Contents for Teltonika QSG TSW202
- Page 1 TSW Switches > TSW202 > QSG TSW202 This Wiki page contains the online version of the Quick Start Guide (QSG) for the TSW202 managed switch . Here you will find an overview of the various components on the front and back of a TSW202 device, hardware installation instructions, first login information, device specifications, and general safety information.
- Page 2 С настоящото TELTONIKA NETWORKS декларира, че този TSW202 е в [BG] Bulgarian съответствие със съществените изисквания и други разпоредби на Директиви 2014/30/EU, 2014/35/EU, 2011/65/EU. Ovim TELTONIKA NETWORKS izjavljuje da je ovaj TSW202 u skladu s bitnim [HR] Croatian zahtjevima i ostalim relevantnim odredbama Direktive 2014/30/EU, 2014/35/EU, 2011/65/EU.
- Page 3 TELTONIKA NETWORKS b'dan tiddikjara li dan TSW202 jikkonforma mar- [MT] Maltese rekwiżiti essenzjali u dispożizzjonijiet oħra tad-Direttivi 2014/30/EU, 2014/35/EU, 2011/65/EU. TELTONIKA NETWORKS erklærer herved at denne TSW202 er i samsvar med de [NO] grunnleggende kravene og andre bestemmelser i Direktivene 2014/30/EU, Norwegian 2014/35/EU, 2011/65/EU.
- Page 4 This sign on the package means that all used electronic and electric equipment should not be mixed with general household waste. Hereby, TELTONIKA NETWORKS declares that this TSW202 is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. The full text of the EU Declaration of Conformity is available at the following internet address: https://wiki.teltonika-networks.com/view/TSW202_CE/RED...
- Page 5 Hereby, TELTONIKA NETWORKS declares that the radio equipment type TSW202 is in compliance with Radio Equipment Regulations 2017. The full text of the UK declaration of conformity is available at the following internet address: https://wiki.teltonika-networks.com/view/TSW202_UKCA. Operating conditions Operating temperature: -40° to +75° Celsius Humidity should be in the range of 10% to 90% (non-condensing).
- Page 6 Do not attempt to disassemble your device (exemptions for devices that require disassembly for SIM insertion) or its accessories: it does not contain any user-serviceable parts. For safety reasons, the equipment should be opened only by qualified personnel. Make sure to use ESD personal protective equipment while the equipment is serviced. Do not use your device in an enclosed environment where heat dissipation is poor.
- Page 7 SFP LED MEANING Video Quick Start Guide Need some help setting up your Teltonika Networks TSW202 PoE+ managed switch? Watch our quick start guide video and follow the step-by-step instructions to easily set up your new router for operation. Hardware installation Login to device 1.
- Page 8 2. Right-click on Network Adapter and select Properties. Then select Internet Protocol Version 4 and click Properties. 3. If not selected, check to Use the following IP address and enter 192.168.1.5. 4. Click in the Subnet mask it should get auto-filled with 255.255.255.0.
- Page 9 6. After logging in, you must set a new password for security reasons. You will not be able to interact with the managed switch ’s WebUI until the default password is changed. The new password must consist of a minimum of 8 characters.
