INDEX Page Introduction Safety precaution Basic operation Contents Inputs SWL/SWLT specific information Remote Control For SDS/SWL/SWLT Remote control buttons (FR5) Remote control buttons (FR-IR) Main Operations Volume Control OSD Menu Operations OSD Menu Structure Picture Menu Sound Menu Time Menu Settings Menu Media Player 1/2 Supported Formats and Codes... -
Page 4: Introduction
Introduction 2. This device must accept any interference Thank you for choosing SWEDX Digital Signage received, including interference that may products. Please read this manual thoroughly cause undesired operation before operating the product. Make sure the display was not damaged in transit. Should the... -
Page 5: Basic Operation
Basic operation or others incidents. Please contact a • Use AC 100-240V 50~60 Hz power outlet for technical authorized by SWEDX the product power supply Departure in holidays • lf the screen of the product is not on, please •... -
Page 6: Contents
Contents 4. AV Included items: Input for AV (Audio/Video) sources 5. IR* Input for external infrared receiver. See Matrix function 6. RS232 OUT* Output for RS232 signal. See Matrix function 6. RS232 IN* Input for RS232 signal. See Matrix function 2 x AAA Battery Notice AC Cable... -
Page 7: Swl/Swlt Specific Information
SWL/SWLT specific information Lamina base assembly instructions The SWL/SWLT series are equipped with external inputs to provide easy access. The external inputs are USB external input. It can be connected to Media Player 1 or 2. It can also be connected to a media player such as Mini PC or Android box Rj45 input. -
Page 8: Remote Control For Sds/Swl/Swlt
SDS-series (digital signage screens). BLUE LED light will stop flashing For the MX/UMX-series the included remote control is model “FR” (see page 9) A On/Off key is also available in recent SWEDX products. POWER INPUT AUDIO COPMONENT... -
Page 9: Remote Control Buttons (Fr5)
Remote control buttons (FR5) 1. On/Off button 37. Not applicable for this 2. Shortcut to HDMI1,2,3 product 3. Number buttons for 38. Shortcut to AV direct channel access 39. Not applicable for this 4. Display additional product information 40. Fast forward 5. -
Page 10: Remote Control Buttons (Fr-Ir)
Remote control buttons (FR-IR) 1. On/Off button 37. Not applicable for this 2. Shortcut to HDMI1,2,3 product 3. Number buttons for 38. Shortcut to AV direct channel access 39. Not applicable for this 4. Display additional product information 40. Fast forward 5. -
Page 11: Main Operations
Main Operations sub-menu. • Use UP & DOWN buttons to navigate in the Turning On And Off OSD Menu. The product turns on automatically when it • Press EXIT button to exit the OSD Menu. is connected to power. When the product is in Stand-by mode press POWER on the OSD Menu Structure remote control or the On/Off button on the... - Page 12 Picture which means if the signal resolution is lower than 3840x2160 then the picture will be shown according to its original size. Just Scan Just Scan mode will display crispier picture with Picture Mode Standard scaling to fill the entire screen. Contrast Brightness Noise Reduction...
-
Page 13: Sound Menu
Sound Sound Mode Standard Treble Bass Balance Surround Sound Off SPDIF Mode Select Move Return MENU Use the Sound menu to adjust the sound settings to meet desired requirements: Sound Mode Choose between predefined settings: Standard: Suitable for normal programs Music: Suitable for music program Movie: Suitable for movies Sports: Suitable for sport programs... - Page 14 Time Timer example: Timer Mode: Customize Mode: Mon~Fri Time 1: ON Clock 2016/01/Jan 10:05:18 On Time: 08:00 Timer Mode Customize Off Time: 13:00 Set Timer Mode: Saturday Auto Sleep Never Time 1: ON On Time: 10:00 Off Time: 13:00 Mode: Sunday Select Move Return...
-
Page 15: Settings Menu
Available options are HDMI 1.4 or HDMI 2.0. Products with support for HDMI 2.0 are recommended to take full advantage of the 4K feature in Swedx product. No Signal Screen Change the background color of the display when no signal is detected. Available options are black or blue. - Page 16 MEMC (Motion Estimation/Motion Compensation) Fan Setting Off Overheating Protection Off OSD Mode Landscape Matrix ID No Signal Standby Off MEMC(Requires Restart) Select Move Return MENU Enhancement to compensate the difference between the screens refresh rate and signal frame rate. Active for smoother motion and deactivate for shorter input lag.
-
Page 17: Media Player
Media Player 1/2 is chosen the product will display automatically all video and picture files stored in the USB flash drive. When Video is chosen the product will display Play Mode Automatic automatically only all video files stored in the Media Type Video USB flash memory. -
Page 18: Supported Formats And Codes
Supported Formats and Codecs Format Video Codec Audio Codec Resolution Frame Rate Mbit/s 23,976~30≤ MJPEG 640x480 ≤ 10Mbps 16Mbps DIVX.311/DIVX4/DIVX5 720x576 ≤ 10Mbps XVID/MPEG- 1920x1080 ≤ 20Mbps 2/MPEG4/H.264 MP3, WMA, AAC, MP2, MPEG-2/MPEG-4/H.264 MPEG-2 ≤ 40Mbps Video MPEG-1/MPEG-2 ≤ 20Mbps MPEG-4/H.264 MPEG1 352X288... -
Page 19: Matrix Video Wall Information
Matrix Video Wall Information Check the Com port number assigned by In matrix video wall screens the following items Windows to the RS232 to USB adapter are included (SMC = Swedx Matrix Kit) HDMI splitter HDMI cables Network cables Infrared remote receiver... - Page 20 Connect the RS232 OUT from the first screen to In the Set screen options set the following: the RS232 IN in the second screen and so on Serial: Set the COM-port number assigned in the according to the figure below device manager Row: Set the desired rows quantity Col: Set the desired columns quantity...
-
Page 21: Troubleshooting
Troubleshooting recommended resolution is 3840x2160@60Hz Before contacting SWEDX service or your dealer, perform the following simple checks. If The image is too light or too dark you cannot solve the problem using the Adjust the Brightness and Contrast instructions below, note the model and serial... -
Page 22: Warranty And Service
Before you contact us, please consult the workmanship during the warranty period, troubleshooting section in your user's manual or SWEDX will, at its sole option repair or replace SWEDX's FAQ web pages at the product with a similar product, provided the http://www.swedx.com to see if you can easily... -
Page 23: How To Get Service
Limitation of liability If your SWEDX product fails to work as warranted above, your sole and exclusive remedy shall be repaired or replaced. SWEDX's maximum liability under this limited warranty is expressly limited to... - Page 25 Your Digital Signage Partner www.swedx.com...
