TC365 TIME CLOCK with automatic daylight saving operation

Introduction

The TC365 is a simple to program time clock with automatic daylight saving time correction. It offers 6

programmable time zones and can operate from a wide range of input voltages (AC or DC)

Dimensions: 80 x 73 x 20 mm

Input Voltage: 9 - 28V DC, 7 – 20V AC

Input Current: 10mA (Relay off) 45mA (Relay on)

(30mA and 70mA With Backlit Display)

Output: Changeover Relay contacts

Contact ratings: 120VAC / 24VDC @ 2A

Settings: 6 Time Zones. These can be set to operate daily, weekdays,

weekend and individual days or switched off

GMT/BST: Automatic Operation

Backup: On board battery backup will keep time and time zone settings

for > 100 hours

Connection is via a 5 way terminal block

The 2 terminals marked PWR are to be connected to a power supply either AC or DC in the following range 9-

28V DC or 7-20V AC. Note the voltage input is not polarity conscious. The remaining 3 terminals (NC, C, NO)

are voltage free changeover contacts rated at 120VAC/ 24VDC @2A

The Display shows the date on the 8 left-hand digits in DD/MM/YY format. The time is displayed on the next 6

digits in HH:MM format. The colon will flash once every second. The last character on the right will be blank if

the relay is off and # if the relay is on

Pressing the UP (Black) button replaces the date with the day of week, this returns to the date when the

button is released

Pressing the DOWN (Grey) button changes the state of the output relay. This will remain in operation until the

next on / off time is reached, or the DOWN button is pressed again.

When one of the preset on times is reached the relay will operate. This will remain on until the off time is

reached or the relay output is overridden by pressing the DOWN button

Table of Contents

Do you have a question about the TC365 and is the answer not in the manual?

Page 1 TC365 TIME CLOCK with automatic daylight saving operation Introduction The TC365 is a simple to program time clock with automatic daylight saving time correction. It offers 6 programmable time zones and can operate from a wide range of input voltages (AC or DC)
Page 2 PROGRAMMING The TC365 is programmed using only 3 buttons. Each button has the following function PROG (Yellow) used to enter program mode and to step through program items UP (Black) replaces the date with the day of week during normal operation. Increments the flashing item in program mode DOWN (Grey) overrides the relay output On to Off or vice versa during normal operation.
