S
UPER P4STA User's Manual
[Parallel Port Mode]
This option set the mode for the onboard Parallel port.
The settings are
"SPP" , "EPP", "ECP", and "ECP+EPP". The default setting is "ECP".
[EPP Mode Select]
This option allows the user to select the EPP mode.
The settings are "EPP
1.9" and "EPP 1.7". The default setting is "EPP 1.7 ".
[ECP Mode Use DMA]
This option allows the user to select the ECP use DMA mode.
The settings
are "1" and "3".
The default setting is "3 ".
[Game Port Address]
This option allows the user to set the Game Port address.
The settings
are "Disabled", "201" and "209".
The default setting is "201 ".
[Midi Port Address]
This option allows the user to set the Midi Port address.
The settings are
"Disabled", "330", "300", and "290".
The default setting is "330".
[Midi Port IRQ]
This option allows the user to set the Midi Port IRQ.
The settings are "5",
and "10".
The default setting is "10".
4-14
