Supero SUPER P4STA User Manual page 61

Chapter 4: Award BIOS
[Onboard Serial Port 1/Port 2]
This option allows the user to set the address and the corresponding IRQ
for the Serial Port1 and Serial Port 2. The settings are "Disabled" , "3F8/
IRQ4", "2F8/IRQ3", "3E8/IRQ4", "2E8/IRQ3", and "Auto ". The default setting
for Serial Port1 is "3F8/IRQ4" and the defualt for Port 2 is is "2F8/IRQ3".
[UART Mode Select]
This option allows the user to select the UART mode for BIOS. The settings
are "IrDA", "ASKIR", and "Normal". The default setting is "Normal".
[RxD, TxD Active]
the function of RxD, TxD
This option allows the user to set the settings for
Active
. The settings are "Hi, Hi", "Hi, Lo", "Lo, Hi", and "Lo, Lo". The
default setting is "Hi, Lo".
[IR Transmission Delay]
If "Enabled", the transmssion of IR (-Infra Red) Signals will be delayed.
The settings are "Enabled" and "Disabled". The default setting is "Enabled".
[UR2 Duplex Mode]
The option set the mode for the UR2 Duplex Mode. The settings are "Full"
and "Half". The default setting is "Half".
[Use IR Pins]
This item sets the mode for Use IR Pins. The settings are "RxD2, TxD2" and
"IR-Rx2Tx2". The default setting is "IR-Rx2Tx2".
[Onboard Parallel Port]
This option allows the user to set the address and the corresponding IRQ
for the onboard Parallel port. The settings are "Disabled" , "378/IRQ7",
"278/IRQ5", and "3BC/IRQ7". The default setting for the Parallel Port1 is
"378/IRQ7".
4-13
