S
UPER P4STA User's Manual
To Install:
With the tabs
pulled outward,
insert the RIMM
module
vertically and
press down
straight down
until it snaps
into place. Pay
attention to the
alignment of the
two notches.
Top View of RIMM Slot
Tab
2-5 Port/Control Panel Connector Locations
The I/O ports are color coded in conformance with the PC99 specification to
make setting up your system easier. See Figure 2-3 below for the colors
and locations of the various I/O ports.
USB
Mouse
Ports-0/1
(Green)
(Black)
Keyboard
(Purple)
Figure 2-3. I/O Port Locations and Definitions
Figure 2-3.
Side View of RIMM Installation into Slot
Tab
Notch
Tab
Note: Notches
should align
with their
receptive points
on the slot.
Parallel Port
(Burgundy)
COM1 Port
(Turquoise)
RIMM Installation
RIMM
RIMM Slot
Tab
COM2 Port Line Out Line In Mic
(Lime) (Light blue) (Pink)
(Turquoise)
2-6
To Remove:
Use your thumbs to
gently push out the tabs
at both ends of the
module. This should
release it from the slot.
Game Port
(Gold)
Tab
Notch
Tab
