S
UPER P4STA User's Manual
• BIOS support for USB keyboard
• Real-time clock wake-up alarm
• Main switch override mechanism
• External modem ring-on
Onboard I/O
• Dual Ultra DMA Bus Master with DMA IDE 100MB supported
• 1 floppy port interface (up to 2.88 MB)
• 2 Fast UART 16550A compatible serial ports
• 1 EPP (Enhanced Parallel Port) and ECP (Extended Capabilities Port)
supported parallel port
• PS/2 mouse and PS/2 keyboard ports
• 1 infrared port
• 4 USB (Universal Serial Bus) ports
Other
• Internal/external modem ring-on
• Recovery from AC power loss control
• Wake-on-LAN (WOL)
• Multiple CPU clock frequency ratio selections (set in BIOS)
CD Utilities
• BIOS flash upgrade utility
• Drivers for 850 chipset utilities
Dimensions
•
ATX: 12" x 9.6" (305 x 244 mm)
1-8
