Instruction Manual
P B-128_e
Leak-Detector
Article No. 101267
Type No. LS 100
LS 100 Leak Detector for leak detection in pneumatic systems
RIEGLER & Co. KG, Sales Engineering
edition 07/2019
page 1 from 8
Schützenstraße 27 | 72574 Bad Urach
Phone +49 7125 9497-642
technik@riegler.de
Subject technical changes.
Advertisement
Related Manuals for RIEGLER LS 100
Summary of Contents for RIEGLER LS 100
- Page 1 Instruction Manual P B-128_e Leak-Detector Article No. 101267 Type No. LS 100 LS 100 Leak Detector for leak detection in pneumatic systems RIEGLER & Co. KG, Sales Engineering edition 07/2019 page 1 from 8 Schützenstraße 27 | 72574 Bad Urach Phone +49 7125 9497-642 technik@riegler.de...
- Page 2 Improper handling or use of force cancels all warranty claims. Operating principle LS 100 ultrasonic leak detector allows maintenance personnel to confirm a diagnosis on the spot by being able to clearly discriminate among various equipment sounds. This is accomplished by an electronic process called 'heterodyning' that accurately converts the ultrasounds sensed by the instrument into the audible range where users can hear the audible signal through a headphone.
- Page 3 Air leaks produce wide-band ultrasounds in the range of 20 ... 80 kHz. The higher the frequency the more energy it contains. But higher frequencies can't be transported in air that far. That's why LS 100 operates at a centre frequency of 40 kHz which compromises an optimum between energy and distance.
- Page 4 Instruction Manual P B-128_e Leak-Detector Article No. 101267 Type No. LS 100 Use with aluminium extension tube Technical data Operating frequency: 40 kHz ±2 kHz Plugs: 1) 4 pole connector shared by headphone and battery charger 2) 3.5mm stereo phone jack for sensor or sensor cable connection.
- Page 5 The sensor unit can be unplugged from the main instrument by pulling the unit out of the holder. A separate coiled extension cable is used to connect the sensor to the main unit. Operation of instrument Figure A: LS 100 operation diagram RIEGLER & Co. KG, Sales Engineering edition 07/2019 page 5 from 8 Schützenstraße 27 | 72574 Bad Urach...
- Page 6 In addition, as slight changes begin to occur in mechanical equipment, the directional nature of ultrasound allows these potential warning signals to be detected in time, before actual failure occurs. Typical applications of LS 100 are compressed air leak detection, vacuum leak detection, steam trap inspection and detection of arcing, tracking and corona in electrical equipment.
- Page 7 For detection of these small holes in compressed air LS 100 is designed. You can point with the LS 100 to the pipe or to the component of interest. The integrated laser pointer will assist you in case of a measurement from a distance.
- Page 8 This is also the case if the serial number has been changed, damaged or removed. The warranty time for the LS 100 is 12 months for the instrument, 6 months for accessory parts. Warranty services do not extend the warranty time.
