I
MPRO
SPECIFICATIONS
Working Environment .................
Scanner Operation.......................
Input Voltage ................................
Power Requirements
Maximum Current Drawn from
the USB Port .........................
Third-party Port ...........................
Installer Interfaces
Registration Interface
Power Indicator
Power LED ..............
Diagnostic Indicators
USB Tx LED ............
USB Rx LED ...........
RS485 Tx LED ........
RS485 Rx LED ........
ImproX RRA or RRM
Status Indicator
Status LED ..............
Buzzer
Volume and Tone ......
X R
I
NTERFACE
ImproX (RS) Registration Interface
INSTALLATION MANUAL
MODEL NUMBER: XRS902-1-0-GB-XX
EGISTRATION
The ImproX RS is designed to work in an
indoor (dry) environment similar to IP20. The
ImproX RS is, therefore, NOT sealed against
water.
125 kHz.
5 V DC Supplied from the USB Port.
Current (mA)
200
5 V DC
0.1 V is supplied to power the single
Reader connected to this Port. A maximum of
100 mA can be supplied from this Port.
Blue (steady) (externally visible).
Red (flashing) (internally visible).
Green (flashing) (internally visible).
Red (flashing) (internally visible).
Green (flashing) (internally visible).
Bi-colour, Red or Green LED.
Four volume, single tone (Software
dependent).
Power (W)
1.0

Advertisement

loading

Related Manuals for impro IMPROX XRS902-1-0-GB-XX

Summary of Contents for impro IMPROX XRS902-1-0-GB-XX

  • Page 1 MODEL NUMBER: XRS902-1-0-GB-XX MPRO EGISTRATION NTERFACE ImproX (RS) Registration Interface INSTALLATION MANUAL SPECIFICATIONS Working Environment ....The ImproX RS is designed to work in an indoor (dry) environment similar to IP20. The ImproX RS is, therefore, NOT sealed against water. Scanner Operation.......

  • Page 2: Installation Information

    INSTALLATION INFORMATION Accessories Find the following when unpacking the Registration Interface: An ImproX (RS) Registration Interface housed in a Black, Aluminium extruded Cabinet. The Cabinet consists of a Top Cover, a Base and two End Plates (each End Plate is attached with three Thread Cutter Screws (M3 x 8 mm)). Four Brass Wood Screws (3.5 mm x 25 mm).
  • Page 3 DIP-switch Settings The format selection for each type of device that can be connected to the Third-party Port is made by setting the internal DIP-switches as indicated in Table 1. Terminals ‘A’ and ‘B’ in Table 1 are on the Third-party Port Terminal Block. NOTE: DIP-switch Position Format...
  • Page 4 CONNECTING THE REGISTRATION INTERFACE Figure 1 shows a detailed connection diagram for the ImproX RS. Figure 1: Typical ImproX RS Electrical Connections XRS305-0-0-GB-05 June 2007 Page 4...
  • Page 5 Keep the Fixed Address Label in a safe place, as you may need the Label at a later date if you wish to upgrade your Software. GUARANTEE OR WARRANTY This product conforms to our Guarantee or Warranty details placed on our Web Site, to read further please go to www.impro.net. USER NOTES XRS305-0-0-GB-05 June 2007...
  • Page 6 USER NOTES XRS305-0-0-GB-05 June 2007 Page 6...
  • Page 7 USER NOTES XRS305-0-0-GB-05 June 2007 Page 7...
  • Page 8 This manual is applicable to the ImproX (RS) Registration Interface, XRS902-1-0-GB-01. (The last two digits of the Impro stock code indicate the issue status of the product). ImproX RS\English Manuals\LATEST ISSUE\ XRS305-0-0-GB-05 Issue 06 Jun 2007 ImprX RS-insm-en-06.docx XRS305-0-0-GB-05 June 2007...
