INSTALLATION GUIDE
EN
PELLET STOVE
ST.MORITZ PN08
Instructions in English

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ST.MORITZ PN08 and is the answer not in the manual?

Questions and answers

Related Manuals for ARCO ST.MORITZ PN08

Summary of Contents for ARCO ST.MORITZ PN08

  • Page 1 INSTALLATION GUIDE PELLET STOVE ST.MORITZ PN08 Instructions in English...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS TABLE OF CONTENTS ....................II INTRODUCTION ......................1 1-WARNINGS AND WARRANTY CONDITIONS ..............2 2-INSTALLATION ......................8 3-DRAWINGS AND TECHNICAL FEATURES ..............17 4-UNPACKING ......................19 5-CLADDING ASSEMBLY .....................21 6-DISASSEMBLING THE PANEL FOR FAN CLEANING ............30 7-TOP DISASSEMBLY ....................31 8-ELECTRICAL CONNECTION..................32 9-ANTENNA ASSEMBLY .....................33 10-LOADING THE PELLETS ..................34 11-FIRST START-UP ....................35 12-REMOTE CONTROL MAX ..................37...

  • Page 3: Introduction

    INTRODUCTION Dear Customer, our products are designed and manufactured in compliance with European reference Standards for construction products (EN13240 wood-burning stoves, EN14785 pellet-burning appliances, EN13229 fireplaces/wood-burning inserts, EN 12815 wood-burning cookers), with high quality materials and extensive experience in the transformation processes. The products also meet the essential requirements of Directive 2006/95/EC (Low Voltage) and Directive 2004/108/EC (Electromagnetic Compatibility).

  • Page 4: 1-Warnings And Warranty Conditions

    1-WARNINGS AND WARRANTY CONDITIONS SAFETY PRECAUTIONS • Installation, electrical connection, function test and maintenance must only be carried out by authorised and qualified personnel. • Install the product in accordance with all local and national legislation and regulations in force in the region or state. •...
  • Page 5 1-WARNINGS AND WARRANTY CONDITIONS • Many of the surfaces of the product get very hot (door, handle, glass, smoke extraction pipes, etc.). Avoid coming into contact with these parts without adequate protective clothing or suitable means, such as gloves with thermal protection or “cold handle” operating systems. •...
  • Page 6 1-WARNINGS AND WARRANTY CONDITIONS • Assess the static conditions of the surface on which the weight of the product will rest and provide suitable insulation if it is made of flammable material (e.g. wood, fitted carpet or plastic). • When the appliance is not used, it must be disconnected from the mains and all the doors/covers on the product must remain closed.
  • Page 7 1-WARNINGS AND WARRANTY CONDITIONS INFORMATION: Please contact the retailer or qualified personnel authorised by the company to resolve a problem. • You must only use the fuel specified by the manufacturer. • When the product is switched on for the first time it is normal for it to emit smoke due to the paint overheating for the first time. Therefore make sure the room in which it is installed is well ventilated.
  • Page 8 1-WARNINGS AND WARRANTY CONDITIONS EXCLUSIONS The guarantee does not cover malfunctions and/or damage to the appliance that arise due to the following causes: • Damage caused during transportation or relocation • all parts that develop faults due to negligence or improper use, incorrect maintenance, installation that does not comply with the manufacturer’s instructions (always refer to the installation and use manual provided with the appliance) •...
  • Page 9 1-WARNINGS AND WARRANTY CONDITIONS SPARE PARTS In the event of a malfunction, consult the retailer who will forward the call to the Technical Assistance Service. Use only original spare parts. The retailer or service centre can provide all necessary information regarding spare parts. We do not recommend waiting for the parts to be worn before having them replaced.

  • Page 10: 2-Installation

    2-INSTALLATION The instructions in this chapter refer explicitly to the Italian installation regulation UNI 10683. In any case, always observe the domestic regulations in force. PELLETS Wood pellets are manufactured by hot-extruding compressed sawdust which is produced during the working of natural dried wood. The compactness of the material is guaranteed by the lignin contained in the wood itself and allows pellets to be produced without glue or binders.
  • Page 11 If the floor is made of wood, it is recommended to fit a floor protection sheet in compliance with the Standards in force in the country of installation. Non-flammable walls Flammable walls ST.MORITZ PN08 A = 5 cm A = 5 cm B = 5 cm B = 5 cm If the floor is made of combustible material, it is recommended to use protection made of non-combustible material (steel, glass...) that...
  • Page 12 2-INSTALLATION FOREWORD This chapter on the Smoke Flue has been produced in reference to the prescriptions of European regulations (EN13384 - EN1443 - EN1856 - EN1457). The chapter provides indications for installing an efficient and correct smoke flue but is under no circumstances to substitute the regulations in force, which the qualified technician must be in possession of.
  • Page 13 2-INSTALLATION TECHNICAL CHARACTERISTICS Have the efficiency of the flue checked by an authorised technician. The flue must be sealed against flue gasses, in a vertical direction without narrowing, be made with materials impermeable to smoke, condensation, thermally insulated and suitable to resist normal mechanical stress over time (we recommend fireplaces made of A/316 or refractory material with insulated round section double chamber).
  • Page 14 2-INSTALLATION ROOF AT 60° ROOF AT 45° 45° 60° A = MIN. 2.60 metres A = MIN. 2.00 metres FIGURE 5 FIGURE 6 B = DISTANCE > 1.20 metres B = DISTANCE > 1.30 metres C = DISTANCE < 1.20 metres C = DISTANCE <...
  • Page 15 2-INSTALLATION MAINTENANCE The flue must be kept clean, since the deposit of soot or unburned oils reduces the cross-section reducing the draft and thus compromising the efficient functioning of the heater and, if large build-ups accumulate, can catch fire. The flue and chimneypot must be cleaned and checked by a qualified chimney sweep at least once a year.
  • Page 16 2-INSTALLATION EXTERNAL AIR INLET It is mandatory to provide an adequate external air intake that supplies the combustion air required for the product to work properly. The flow of air between the outside and the installation room may be direct, through an inlet in an external wall of the room; or indirect, via air intake from adjoining rooms and connecting permanently with the installation room (see Figure 9 b).
  • Page 17 2-INSTALLATION DISTANCE (metres) The air inlet must be at a distance of: 1.5 m UNDER Windows, doors, smoke outlets, cavities, ..1.5 m HORIZONTALLY Windows, doors, smoke outlets, cavities, ..0.3 m ABOVE Windows, doors, smoke outlets, cavities, ..1.5 m AWAY from smoke outlet CONNECTION TO FLUE...
  • Page 18 2-INSTALLATION EXAMPLES OF CORRECT INSTALLATION 1. Installation of Ø150mm flue with hole for the passage of the tube increased by: minimum 100 mm around the tube if next to non flammable parts such as cement, brick, etc.; or minimum 300 mm around the tube (or as prescribed by data tags) if next to flammable parts such as wood etc.

  • Page 19: 3-Drawings And Technical Features

    3-DRAWINGS AND TECHNICAL FEATURES DRAWINGS AND CHARACTERISTICS DIMENSIONS ST.MORITZ PN08 80 79 Ø80 Technical Dept. - All rights reserved - Reproduction is prohibited...
  • Page 20 3-DRAWINGS AND TECHNICAL FEATURES TECHNICAL CHARACTERISTICS ST. MORITZ PN08 Nominal output power 8 kW (6880 kcal/h) Minimum power output 2,4 kW (2064 kcal/h) Efficiency at Max 93,0% Efficiency at Min 93,0% Temperature of exhaust smoke at Max 160 °C Temperature of exhaust smoke at Min 110 °C Particulate /OGC / Nox (13%O 22 mg/Nm3 - 3 mg/Nm3 - 93 mg/Nm3...

  • Page 21: 4-Unpacking

    4-UNPACKING PREPARATION AND UNPACKING The packaging consists of a recyclable cardboard box in line with RESY standards and a wooden pallet. All packaging materials can be reused for similar use or eventually disposed of as urban solid waste, in compliance with the regulations in force. After having removed the packaging make sure the product is intact.
  • Page 22 4-UNPACKING Position the stove and connect it to the flue pipe. Use the four adjustable feet (J)to get the stove correctly levelled so that the smoke outlet is lined up with the connecting pipe. If the stove needs to be connected to an outlet pipe which goes through the rear wall (to connect to the flue), take utmost care to make sure that the joint is not forced.

  • Page 23: 5-Cladding Assembly

    5-CLADDING ASSEMBLY Live electrical parts: only power the product once it has been fully assembled. On delivery, the stove has no stone cladding, as shown in the image below. The stone panels have codes on the inside required for correct positioning (see image below). On the right side they are called D1/D2/D3 and on the left side S1/S2/S3, to be placed from the bottom upwards.
  • Page 24 5-CLADDING ASSEMBLY Attention! The stones are delicate, therefore handle with care. The stone panels are marked on the inside as shown in the drawing below. Comply with the markings in the assembly stage.
  • Page 25 5-CLADDING ASSEMBLY POSITIONING OF STONE BASE “S5” To assemble the base proceed as follows: • Take from the packaging 2 “S5” pieces • adjust the feet of the stove structure at about 8 cm from the floor (adjust foot height if required after inserting panel “S5”) •...
  • Page 26 5-CLADDING ASSEMBLY INSTALLING THE FRONT PANEL Move panel “S4” close to the structure, centre the firebox door and position it to match the holes (two at the top and two at the bottom). Fasten panel “S4” to the structure using 4 M5x20 screws.
  • Page 27 5-CLADDING ASSEMBLY INSTALLING THE UPPER PANELS Place the two “S5” panels onto the structure, ensuring they are positioned with the same distances as the base. Fasten panel “S5” to the stove structure from underneath the top using 4 M8x15 screws (“z”) and 4 M8x24 washers (“y”) (4 on the right and 4 on the left).
  • Page 28 5-CLADDING ASSEMBLY INSTALLING THE SIDE LOWER PANEL To install the side panels proceed as follows: • take panel D1 • insert edges “f” on the panel into holes “e” on the structure • ensure side panel “D1” is aligned with the front panel •...
  • Page 29 5-CLADDING ASSEMBLY ADJUSTING THE SIDE PANELS In the rear of the panel is a plate with a screw “g” that is snug onto the structure. If the stone panel “D1” (subsequently “D2” or “D3”) is not aligned with the front panel, act as follows: •...
  • Page 30 5-CLADDING ASSEMBLY FIXING THE SIDE PANELS After carrying out all panel adjustments, secure it to the structure using a screw “g” M4x16. This operation applies to all side panels.
  • Page 31 5-CLADDING ASSEMBLY CENTRAL AND UPPER PANEL Carry out the same operations as for the lower panel. Technical Dept. - All rights reserved - Reproduction is prohibited...

  • Page 32: 6-Disassembling The Panel For Fan Cleaning

    6-DISASSEMBLING THE PANEL FOR FAN CLEANING S4_a Proceed as follows to remove only the lower plate for fan maintenance: • open the firebox door • remove the two screws “u” • in the lower part remove the two screws “v” At this point it is possible to remove the stone panel S4_a S4_a S4_a...

  • Page 33: 7-Top Disassembly

    7-TOP DISASSEMBLY TOP DISASSEMBLY To remove the metal top “F” it is required to remove stone panel “D3” and “S3”. Next, unscrew the two “t” screws on the right and left of the structure, extract the edge of the top from the structure and remove it. Technical Dept.

  • Page 34: 8-Electrical Connection

    8-ELECTRICAL CONNECTION ELECTRICAL CONNECTION First connect the power cable to the back of the stove and then to a wall socket. The main switch must only be activated to switch the stove on; otherwise, it is advisable to keep it switched off. It is recommended to disconnect the power cable when the stove is not used.

  • Page 35: 9-Antenna Assembly

    9-ANTENNA ASSEMBLY ASSEMBLY OF CONTROL PANEL ANTENNA • Take the antenna “A” from the bag containing the instructions • Screw the antenna “A” clockwise on screw “V” near the control panel until the mobile part is positioned upwards. Attention! Tighten the antenna completely without forcing it to prevent reception damage. Technical Dept.

  • Page 36: 10-Loading The Pellets

    10-LOADING THE PELLETS LOADING THE PELLETS The fuel is loaded at the top of the stove by lifting the door by its rubber handle. Pour the pellets in slowly so that it is deposited at the bottom of the hopper. If loading pellets when the stove is running, open the door of the tank using the stove mitten that comes with the stove itself.

  • Page 37: 11-First Start-Up

    11-FIRST START-UP PRECAUTIONS BEFORE START-UP GENERAL PRECAUTIONS Remove any objects that may burn from the brazier (manual, various adhesive labels or any polystyrene). Check that the brazier is positioned correctly and rests properly on the base. The first start-up may not be successful as the feed screw is empty and does not always manage to load the required amount of pellets in time to light the flame.
  • Page 38 11-FIRST START-UP If the flame fails to ignite, despite the regular flow of pellets, check that the brazier is seated correctly: it must rest snugly against the interlocking slot and be clean of any ash scaling. If no anomaly is found during this inspection, there may be a problem with the product components or installation may not be correct.

  • Page 39: 12-Remote Control Max

    12-REMOTE CONTROL MAX GENERAL FEATURES OF THE LCD REMOTE CONTROL The remote control works at a transmission frequency of 434.5 MHz. Power the product with 3 AAA batteries as follows: Remove the battery compartment cover by pressing and lifting according to the arrow Insert the batteries observing the correct polarity (+) and (-) Close the battery compartment cover.
  • Page 40 12-REMOTE CONTROL MAX REMOTE CONTROL OPERATION General rules By pressing key A for 1” the product is switched on and off. Key C is used to make all changes. Key E is used to confirm the changes. By pressing key B one selects the product operating mode. Use key D to see the SLEEP setting. Whichever the mode is, press key A briefly (or leave the keypad idle for 7”) to go back to the initial display.
  • Page 41 12-REMOTE CONTROL MAX TIMER Mode (TIMER) Select this operating mode to switch the product on and off automatically, according to 6 customised time slots (P1 – P6). The following can be set for each time slot: • Switch-on time • Switch-off time •...
  • Page 42 12-REMOTE CONTROL MAX Sleep function The sleep mode allows to quickly set the time at which the product must switch off. This function is only available in MAN and AUTO mode. It is set as follows: from the POWER setting (by pressing key D - see previous paragraph), press key D again to access the SLEEP mode setting.
  • Page 43 12-REMOTE CONTROL MAX TIMER settings TIMER time slot display In TIMER mode, to display the time slots simply press key D for 2”. With key C one can scroll the 6 time slots freely, quickly checking the saved settings (figure 8). By pressing key D or A one goes back to the basic display. Modifying the TIMER time slots MO TU WE TH FR SA SU...

  • Page 44: 13-Emergency Panel

    13-EMERGENCY PANEL There is an emergency panel on the side-rear part of the stove, designed to detect any malfunctions and also for product control if the remote control is not working. A - DISPLAY; indicates a series of information on the stove, as E - Three-position selector to select the power well as the identification code of any malfunction.

  • Page 45: 14-Safety Devices

    14-SAFETY DEVICES SAFETY DEVICES The product is fitted with the following safety devices. SMOKE TEMPERATURE PROBE It detects the temperature of the smoke, thereby enabling start-up or stopping the product when the temperature drops below the preset value. PELLET HOPPER TEMPERATURE PROBE If the temperature exceeds the preset safety value, it immediately stops the product, which must cool down before the stove is restarted.

  • Page 46: 15-Alarms

    15-ALARMS ALARM ALERTS In the event an operating anomaly occurs the stove starts switching off due to the alarm and informs the user of the type of fault that has taken place via a 3 digit code which stays displayed on the rear emergency panel. The alarm is indicated permanently by the relative 3 digit code, by a flashing red LED that lights up on the emergency panel and an intermittent sound signal for the first 10 minutes of the alarm.
  • Page 47 15-ALARMS Pellet supply fault Contact an authorised service centre to have the component replaced. The remote control has been out of the Move the remote control within the reception range reception range of the stove for over three of the stove (or change the remote control batteries in hours (or the batteries are flat).
  • Page 48 15-ALARMS Mechanical stove block The following conditions may cause the mechanical stove block: • Structure overheating (“A03”) • Smoke overheating (“A04”) • During stove operation air has entered the combustion chamber or there is an obstruction in the chimney flue (“A05”) The block is signalled on the display and with a sound signal.

  • Page 49: 16-Recommendations For Safe Use

    16-RECOMMENDATIONS FOR SAFE USE ONLY CORRECT INSTALLATION AND APPROPRIATE MAINTENANCE AND CLEANING OF THE APPLIANCE CAN GUARANTEE CORRECT OPERATION AND SAFE USE OF THE PRODUCT. We would like to inform you that we are aware of cases of malfunctioning of domestic pellet-fuelled heating products, mainly due to incorrect installation and inappropriate maintenance.

  • Page 50: 17-Cleaning

    17-CLEANING EXAMPLE OF A CLEAN BRAZIER EXAMPLE OF A DIRTY BRAZIER Only by properly servicing and cleaning the product is it possible to ensure its safety and correct operation. CAUTION! All the cleaning operations of all parts must be performed with the product completely cold and the plug disconnected.
  • Page 51 17-CLEANING CLEANING THE AIR FILTER When the stove is installed, one must fit the rear of the stove with the wire mesh air filter, whose purpose is to prevent dirt entering the motor body and the internal sensor. It is recommended to check that the filter is clean every 15/20 days. If needed remove fluff or the material that has deposited on it. Inspection and cleaning are required more frequently if there are pets in the house.
  • Page 52 17-CLEANING PERIODIC CLEANING PERFORMED BY A QUALIFIED TECHNICIAN CLEANING THE HEAT EXCHANGER AND THE LOWER COMPARTMENT Half-way through the winter season, but especially at the end, the compartment through which the exhaust smoke passes will need to be cleaned. This cleaning process is mandatory in order to facilitate the general removal of all combustion residue, before it becomes very difficult to remove it due to the humidity compacting it over time.
  • Page 53 17-CLEANING CLEANING THE EXCHANGER Remove the top when the stove is cold. Next, at the front of the stove, near the exchanger, remove plates “r” by loosening screws “q” and loosening screw “x”. On the side of the exchanger, loosen screws “o” and remove plates “p” (one on the right and one on the left). If needed replace the gasket.
  • Page 54 17-CLEANING The exchanger can now be lifted and the walls of the hearth can be scraped with a stiff rod or a bottle brush, so that the dirt falls into the lower compartment. CAUTION: the exchanger must be cleaned at the end of the season by an authorised and qualified technician so that any worn seals may be replaced.
  • Page 55 17-CLEANING CLEANING THE SMOKE EXHAUST SYSTEM AND GENERAL CHECKS Clean the smoke extractor system, especially around the “T” joints, elbows and any horizontal sections of the smoke duct. For information on periodically cleaning the flue, contact a skilled chimney sweep. Check the seal of the ceramic fibre gaskets on the door of the stove.
  • Page 56 17-CLEANING END-OF-SEASON SHUTDOWN At the end of each season, before switching the product off, it is recommended to remove all the pellets from the hopper with a vacuum cleaner with a long pipe. When not in use the appliance must be disconnected from the mains power supply. It is recommended to remove the power cable for additional safety, especially in the presence of children.

  • Page 57: 18-Faults/Causes/Solutions

    18-FAULTS/CAUSES/SOLUTIONS ATTENTION! All repairs must only be carried out by a specialised technician, with the product switched off and the plug disconnected. ANOMALY POSSIBLE CAUSES SOLUTIONS The pellets are not fed into the The pellet hopper is empty. Fill the hopper with pellets. combustion chamber.
  • Page 58 18-FAULTS/CAUSES/SOLUTIONS ANOMALY POSSIBLE CAUSES SOLUTIONS The product works for a few minutes Start-up phase is not completed. Repeat start-up. and then switches off. Temporary power cut. Switch it back on. Clogged smoke duct. Clean the smoke duct. Faulty or malfunctioning temperature Check and replace the probes.
  • Page 59 18-FAULTS/CAUSES/SOLUTIONS ANOMALY POSSIBLE CAUSES SOLUTIONS The air fan does not switch on. The product has not reached the Wait. temperature. The remote control does not work. The remote control battery is flat. Replace the battery. Remote control faulty. Replace the remote control. The product always runs at maximum The room thermostat is in the maximum Reset the temperature of the remote...

  • Page 60: 19-Circuit Board

    19-CIRCUIT BOARD MOTHERBOARD WIRING KEY 1. SMOKE FAN ENCODER 8. AIR FAN 2. GEAR MOTOR ENCODER 9. GEAR MOTOR 3. PRESSURE TRANSDUCER 10. SMOKE FAN 4. SMOKE TEMPERATURE PROBE 11. SPARK PLUG 5. SOFTWARE UPDATE 12. SWITCH 6. EMERGENCY PANEL 7.
