Summary of Contents for CO2 Meter RAD-0102-6
- Page 1 User Manual and Installation Guide INSERT IMAGE RAD-0102-6 Remote CO2 Storage Safety 3 Alarm CO2Meter 105 Runway Drive Ormond Beach, FL 32174 USA (877) 678-4259 Copyright © CO2Meter, Inc. All Rights Reserved. Revision 01.02...
- Page 2 Warning! This product should only be used as described in this manual. If the equipment is used outside of the manner specified by CO2Meter, the protection provided by the equipment may be diminished. This equipment should be installed/serviced by qualified personnel only. Please contact Support@CO2Meter.com for more...
-
Page 3: Table Of Contents
Contents General information on Carbon Dioxide Safety ....................4 Introduction to the RAD-0102-6........................... 5 Key Features..................................... 5 Display ......................................6 Icons and Symbols ................................. 6 Specifications ................................7 Layout ..................................8 SEU (Sensor Unit) ................................... 9 RDU (Remote Display Unit) .............................. 10 Strobes ..................................... -
Page 4: General Information On Carbon Dioxide Safety
General information on Carbon Dioxide Safety 4 | P a g e R A D - 0 1 0 2 - 6 / M a n u a l a n d I n s t a l l a t i o n G u i d e... -
Page 5: Introduction To The Rad-0102-6
Introduction to the RAD-0102-6 Thank you for selecting the RAD-0102-6 CO2 Storage Safety Three Alarm. This monitor is designed to detect Carbon Dioxide levels in the ambient air to protect employees and customers. CO2 monitors are required in most jurisdictions by code. -
Page 6: Display
Display Icons and Symbols Icon/Symbol Description CO2 Level Icon: Displays the live ambient carbon dioxide levels of the area 1216 being monitored. Updates every 2 seconds. DIAG Technician diagnostics feature. Communication test. Alarm Icon: 1 alarm. (5,000TWA) Alarm Icon: Configurable 2 alarm. -
Page 7: Specifications
Specifications CO2 Specification Measurement Range 0 - 50,000ppm (5%) display 10ppm at 0~10,000ppm; Display Resolution 0.01% at 1-5% Accuracy +/-200ppm or +/-10% reading Pressure Dependence Auto pressure compensation, built in barometer. (50 to 110 kPa) Response Time CO2: <2min by 90% CO2 AL1 (TWA ) 5000TWA CO2 AL2... -
Page 8: Layout
Layout SEU (Sensor Unit) A. CO2 Sensor L. Buzzer B. LCD display M. Reset Button C. Power (Green LED) N. 4-20mA Output D. AL1 (Red 1 LED) O. Battery E. AL2 (Red 2 LED) P. DC Power Supply F. AL3 (Red 3 LED) Q. -
Page 9: Seu (Sensor Unit)
When the CO2 TWA value drops below 5000ppm (TWA), AL1 (Red1 LED) will stop blinking and Relay 1 will be inactive. When the RAD-0102-6 detects a CO2 value that exceeds the AL2 CO2 level, AL2 (Red 2 LED) will blink, the buzzer will sound, and Relay 2 will be triggered. -
Page 10: Rdu (Remote Display Unit)
Number: CM-1027. Power The RAD-0102-6 comes pre-wired with a 12V power supply that plugs in to a wall outlet. The 12V power supply can be removed and 24V DC can be wired directly to the device through the terminal block. Please use a 24V DC power converter to properly convert your AC power source. -
Page 11: Installation
Plug the CAT5 cable into the designated ports. Communication between the SEU and RDU is complete. 5. The RAD-0102-6 has 3 relay outputs connected to the programmed alarm settings. All relays are normally open/closed dry contacts. Any of the relays can be used to control an external device (fan, HVAC system, etc.) or can be wired to the... -
Page 12: Operation
Operation Start-up Verify that the RAD-0102-6 is properly wired, and 12-24VDC power is being supplied to the correct pin positions in the mating connector (see page 10). Check all wiring connections before powering. After power-up, the monitor provides accurate CO2 measurements after a 5 second warm up. -
Page 13: Configuring Al1
Configuring AL1 1. Press Mode until the “AL1” & “CO2” icon flash. 2. Press Enter to select. AL1 level will flash. 3. Use Up/Down arrow to select new alarm level. 4. Press Enter to confirm. Configuring AL2 1. Press Mode until the “AL2” & “CO2” icon flash 2. -
Page 14: Latch On/Off
Latch ON/OFF 1. Press and hold Up & Enter button for 10 seconds. 2. Change to Advance Mode by pressing Mode, and choose Lat Mode. 3. Press Up/Down to set Latch Mode On or Off. 4. Press Enter to Save. (Fault light will keep flashing if AL3 is activated, indicating unit went into alarm status.) Baro ON/OFF 1. -
Page 15: Calibration
Calibration 1. Flow 100% Pure Nitrogen (N2) (0% CO2) into CO2 Sensor Entry (Item A in Layout). Wait 3-5 minutes before starting calibration, then execute the “ZEro” calibration. (Continue to flow calibration gas throughout entire process) 2. Press Mode until CALI is flashing in small print under the CO2 reading. 3. -
Page 16: System Test
System Test 1. Press Mode until the “DIAG” icon flashes. 2. Press Enter, the five LEDs will blink, and the buzzer will sound. Factory Reset 1. Press Mode until the “ReFactSet” icon flashes. 2. Press Enter Up/Down to choose either “Yes” or “No”. 3. -
Page 17: Maintenance
Maintenance The RAD-0102-6 is a low maintenance safety monitor that requires little maintenance after initial installation. It is recommended to calibrate the internal NDIR CO2 Sensor annually. This calibration can be completed in the field, or the monitor can be returned to CO2Meter to perform the calibration. -
Page 18: Product Returns
Product Returns If any Product fails under normal use, you may return it to us, by first submitting a customer case support ticket (submission here). Policies and procedures for returns and refunds related to the same are located at www.co2meter.com/pages/faq. All returns for refund after thirty (30) days from shipment of the applicable product will incur a 25% re-stocking fee.
