Stock Code： 835766
PRINTER
USER MANUAL
EC-JET400
Excellent EC-JET
Intelligent Choice

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EC-JET400 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EC-JET EC-JET400

Summary of Contents for EC-JET EC-JET400

  • Page 1 Stock Code： 835766 PRINTER USER MANUAL EC-JET400 Excellent EC-JET Intelligent Choice...

  • Page 2: Disclaimer

    EC-JET. Disclaimer Information of a technical nature and particulars of the product and its use are given by EC-JET in good faith. However, it is acknowledged that there may be errors or omissions in this user manual.

  • Page 3: Safety

    Only fully trained and competent personnel should operate or maintain EC-JET printers. If you are in any doubt as to your ability to operate or maintain the printer, DO NOT DO SO; consult your supervisor for guidance or contact your local EC-JET distributor who will be happy to advise you.

  • Page 4: Inks And Solvents

    If the Material Safety Data Sheets have not been supplied or are not available, please contact your local EC-JET distributor. ALWAYS refer to the Material Data Safety Sheets before working with inks and solvents.

  • Page 5: Table Of Contents

    Content Contents Copyright Notice ..........................i Disclaimer ............................i About this Manual ..........................i Safety................................ii Warnings and Cautions ........................ii Lethal voltages ...........................ii Operation ............................ii Inks and Solvents ..........................iii First Aid ............................. iii In Case of Emergency ......................iii Noise Emissions ......................
  • Page 6 Content Message Fields ........................19 Passwords ..........................19 Entering the Password .......................19 Password Levels ........................20 Creating, Editing and Delecting Message Fields ................20 Deleting Text Characters ....................21 Editing Fields ........................21 Deleting Fields ........................21 Creating Date Fields ......................21 Creating Sequential Number Fields ..............
  • Page 7 Content Printhead Cleaning Procedure ....................43 Replenishing Ink and Solvent ......................44 Cleaning / Replacing the Air Filter ....................45 Warning and Fault Messages ........................46 Summary of Warnign Messages .....................46 System Failures ........................46 Print Faulures .........................46 System Warning ....................
  • Page 8 Content Accessories ............................72 Power Connection ..........................72 Attaching the Printhead to the Production Line ................73 Print Height ...........................74 Setting up the Photocell .........................74 Photocell Connections ......................74 Setting up the Shaft Encoder ......................75 Shaft Encoder Connections ....................75 Selecting the Encoder, Gearing, and Print Width ..........

  • Page 9: Using This Manual

    Other problems should be dealt with by EC-JET or an authorized EC-JET distributor. Authorized EC- JET distributors are trained by EC-JET to maintain and repair your printer in a safe and professional manner. They are also kept up-to-date with the very latest technical information. Do not risk damage...

  • Page 10: Introduction

    Safety section carefully before attempting to use the EC-JET printer. Printer System Overview The EC-JET printers provide a means of application of printed information onto a wide range of products. This information would typically be the date, production codes, consumer information, product or corporate identification, product traceability, and many others.

  • Page 11: System Description

    Introduction System Description The EC-JET printers are designed to provide versatile, uninterrupted operation in factory environments The models available, together with available raster types and compatible printheads are as follows. EJ02 CHARACTERS PRINTHEAD TYPE RASTER TYPES PRINTER MODEL 7 GEN STD...

  • Page 12: Ink Blockage Prevention

    A potential problem arises on shutdown when ink is left in the nozzle; as it is fast drying it will soon dry and clog up the nozzle. To overcome this, special procedures to clear the nozzle are necessary. With EC-JET printers the clean up procedures at shutdown are achieved by an automatic flushing system.

  • Page 13: Principles Of Operation

    Introduction Principles of Operation A conducting ink is supplied under pressure to an ink gun and forced EJ04 out through a small nozzle of typically 50 to 70 microns in diameter. As it passes through the nozzle the liquid is piezo-electrically pulsed (modulated) and the stream breaks up into a continuous series of drops which are equally spread and are of the same size.

  • Page 14: Controls And Indicators

    Controls and Indicators Controls and Indicators This section describes the user interface for the EC-JET printer - the screen display, keyboard keys, function keys and cursor control keys. Front Panel The front panel layout is shown below. User Manual...
  • Page 15 Controls and Indicators 5242 User Manual...

  • Page 16: Screen Display

    When illuminated, this indicates that a serious printer failure has occurred. In this event, it may be necessary to contact your local EC-JET distributor. Start and Stop keys Start Key This initiates the start-up sequence which is responsible for carrying out internal checks and regulating the ink flow until it is ready for printing.

  • Page 17: Cursor Control Keys

    Controls and Indicators Simply press the [stop] key and the printer will initiate the shutdown sequence, which takes approximately three minutes. While the machine is shutting down, the following status message will be displayed in the status line of the display: EJ07 CURRENT MESSAGE TEST PRINT...

  • Page 18: Function Keys

    Controls and Indicators Function Keys These are used to select options and other menus. They are labelled F1, F2 , F3 and F4 and they occupy the area to the left of the keyboard. The options each key selects are shown on the menu displays. Text Control Keys The [caps] key is used to lock the keyboard into upper case and also to make use of European characters.

  • Page 19: Advanced Editing Features

    Controls and Indicators Advanced Editing Features To make editing easier and give further control over the appearance of messages, there are a number of extra features available from the keyboard. Moving to Start and End of Message To move the cursor to the start of the message, hold the [shift] key down and press the left arrow key. To move the cursor to the end of the message, hold the [shift] key down and press the right arrow key.

  • Page 20: Getting Started

    “Appendix 1: Installation and Setting Up”. Power Connection The EC-JET range of printers are designed to operate on a single-phase 50/60 Hz AC supply of 90 to 240 V. This means that any AC voltage within this range will power the printer satisfactorily.

  • Page 21: Checking The Current Status Of The Printer

    The printer is now switched on and awaiting further commands. Explanation of screen contents are detailed in “Controls and Indicators”. Checking the Current Status of the Printer The EC-JET printer provides two on-screen visual guides as to its current status (condition) - the System Status Line and the PRINT STATUS screen. System Status Line System Failures System failures occur when a condition is detected that prevents normal printer operation.

  • Page 22: Printing

    If print quality is poor, recheck all your settings and refer to the “Troubleshooting” section of this manual. If the cause of the problem still cannot be identified, call your local EC-JET distributor. Stopping (switching off) the Printer CAUTION: NEVER STOP the printer by the mains power switch while in the Printing or Jet Running modes;...
  • Page 23 Getting Started EJ24 CURRENT MESSAGE TEST PRINT F1： ：Check Status F3： ：Change Setup 00000 PRESSURE PHASE Waiting for SHUTDOWN... 2006-03-24 14:01:38 Wait for the system to carry out its shutdown functions, which includes clearing the nozzle of the printhead. When the printer has finished its shutdown sequence, the following message will appear in the status line of the display: EJ25 CURRENT MESSAGE...

  • Page 24: Using The System

    Using the System Using the System The system is driven by menus which provide options to be selected or changed to suit the requirements of the user. This illustration shows an overview of all the menus and their hierarchical relationship. EJ26 START UP SCREEN...

  • Page 25: I V Moving Around The Menus

    Using the System Moving around the Menus The CURRENT MESSAGE screen is the first to be displayed after the start up procedure has been completed, and at this stage it is necessary to press one of the function keys (F1 through F4) to select the appropriate menu.
  • Page 26 Using the System Options and Display The options and display data are as follows: F1 : Change Message this will display the EDIT MESSAGE screen. F2 : Check Status this will display the PRINT STATUS screen. F3 : New Message this will display the MESSAGE HEIGHT menu.

  • Page 27: Message Description

    Using the System The number of Message Height rasters available depends on the type of printhead in use. Select the raster type you require by moving the cursor next to it and pressing [enter]. The EDIT MESSAGE screen will then be displayed and the message can be created as described in “Getting Started”...

  • Page 28: Message Fields

    Using the System EJ32 CHARACTER SETS 5 HighCaps 24 Chinese Raster Type 7 Gen Std 7 HighCaps 7 Chinese 9 HighCaps 12 HighCaps 12 Chinese 16 HighCaps 16 Chinese 16 HighFull 24 HighCaps Logo Edit 7 Gen Std 7 Min Std 12 Gen Std 16 Gen Std 24 Gen Std...

  • Page 29: Password Levels

    Using the System EJ33 CURRENT MESSAGE TEST PRINT F1： ：Check Status F3： ：Change Setup 00000 PRESSURE PHASE Jet Off 2006-03-24 14:01:38 The PASSWORD menu is used as described below: EJ34 PASSWORD > Password Print Height Scale Height Print Width 00000 PRESSURE PHASE Jet Off...

  • Page 30: Deleting Text Characters

    Using the System Timed Message Sequential Number Date Logo Remote In the following pages, you will be shown how to create this message and therefore how to use the message editing menus. Deleting Text Characters You may use the [del] key to delete the character immediately whilst typing the text a Text Field. Editing Fields A field may be edited by pressing the [enter] key while the cursor is anywhere in the field.
  • Page 31 Using the System EJ39 EDIT MESSAGE TEST Sell by F1： ：Bold Off F3： ：Key-Name 00000 PRESSURE PHASE Jet Off 2006-03-24 14:01:38 The cursor is located at the end of the text so press the space bar to create some space between the text and the date field we are about to create.

  • Page 32: Creating Sequential Number Fields

    Using the System formats of your own. For the purpose of this example we will choose the format “dd mmm yy” which will read (for example) “11 NOV 00”, when the message is actually printed on that day. This is done by moving the cursor to the required format using the up/down arrow keys until the menu cursor is pointing to it.

  • Page 33: Decrement Count

    Using the System EJ44 EDIT MESSAGE TEST Sell by dd mmm yy F1： ：Bold Off F3： ：Key-Name 00000 PRESSURE PHASE Jet Off 2006-03-24 14:01:38 The cursor is now located in a position not already occupied by a field, so type in the word”BATCH”: EJ45 EDIT MESSAGE TEST...

  • Page 34: Creating Time Fields

    Using the System For our example, use the arrow key to locate the End Number, press the [enter] key to select it and type in the value 0000 and press the [enter] key. In response to this, the system will default to a Start Number of 9999 and a Current Number of 9999: EJ48 SEQUENTIAL NUMBER...

  • Page 35: Creating Timed Message Fields

    Using the System EJ52 EDIT MESSAGE TEST Sell by dd mmm yy BATCH 9999 hh:mm F1： ：Bold Off F3： ：Key-Name 00000 PRESSURE PHASE Jet Off 2006-03-24 14:01:38 The current time will replace the hh:mm when editing is complete. Creating Timed Message Fields Up to 10 timed messages are allowed per Timed Message field, each associated with a unique time at which the timed message will appear in the current printer message.
  • Page 36 Using the System until another timed message occurs. Since the only message defined so far occurs at midnight, the system will print until one minute before midnight, whereupon it will start printing again at midnight. In other words, once it starts printing, it will never stop. In practice, therefore, it is necessary to have at least two timed messages in a field.

  • Page 37: Creating Remote Fields

    Using the System EJ60 EDIT MESSAGE TEST Sell by dd mmm yy BATCH 9999 hh:mm Day Shift F1： ：Bold Off F3： ：Key-Name 00000 PRESSURE PHASE Jet Off 2006-03-24 14:01:38 Notice that the last created timed message is displayed in the message area. This will be replaced with the appropriate message at the time of printing.

  • Page 38: Printing The Message

    Using the System EJ62 SELECT FIELD TYPE Sequential No. Date Remote > LOGO LOGO > LOGO 00000 PRESSURE PHASE LOGO 2 Jet Off LOGO 3 2006-03-24 14:01:38 LOGO 4 00000 PRESSURE PHASE Jet Off 2006-03-24 14:01:38 Use the up/down arrow keys to locate the Logo you wish to use and press the [enter] key to activate the choice.

  • Page 39: Listing Error Message

    Only ONE bottle of APPROVED Ink or Solvent should be added when the level is reported LOW. If the level is still reported LOW after adding one bottle of ink or solvent, it could be that the level sensors are faulty. In this case you should contact your local EC-JET Distributor.
  • Page 40 Using the System EJ66 SET UP > Password > Print Height > Scale Height > Print Width 00000 PRESSURE PHASE Jet Off 2006-03-24 14:01:38 Print Delay Print Count Reverse Message Bold Ratio Set Time Set Date Aux In Photocell Shaft Encoder Conduit Length Head Height Print Head Code...

  • Page 41: Password

    Using the System EJ67 USER LEVEL 1 PASSWORD USER LEVEL 2 PASSWORD Setup Menu Options Jet Off Jet Running Printing Jet Off Jet Running Printing Password Print Height Scale Height Print Width Print Delay Print Count Reverse Message Bold Ratio Set Time Set Date Aux In...

  • Page 42: Print Width

    Using the System Print Width Minimum width (i.e. the fastest the printer can print) is 0. The width of printed characters may be increased by increasing the stored value. When used in conjunction with Shaft Encoder “On” the width is equivalent to shaft encoder pulses between rasters. Print Delay This is the delay between prints (Photocell Off/Enable) or the delay between the photocell triggering and print appearing on the product (Photocell Triggered).

  • Page 43: Shaft Encoder

    Using the System Shaft Encoder The print must be stopped to change this option. Select ”On” if a shaft encoder is to be used, or “Off” if it is not. (See “Appendix 1: Installation and Setting Up” for shaft encoder setup). Conduit Length The jet must be stopped to set up this option.

  • Page 44: Alarm

    Using the System This option allows different combinations of events to be selected to trigger the alarm relay. Selecting the Alarm option will display the following menu: EJ69 ALARM > Fail Only Fail or Warn Print Disabled 00000 PRESSURE PHASE Jet Off 2006-03-24 14:01:38...

  • Page 45: Change Language

    Using the System into the PASSWORD screen, the CHANGE PASSWORD menu would have provided the option of changing both levels of password: EJ72 CHANGE PASSWORD > ECJET1 ECJET2 ECJET3 00000 PRESSURE PHASE Jet Off 2006-03-24 14:01:38 Change Language Printing must be stopped to change this option. It allows the user to define which language the screens and menus are displayed in.

  • Page 46: Diagnostics

    Diagnostics Diagnostics There are a large number of diagnostic functions. However, not all functions are valid at all times - some are only valid when the jet is stopped (e.g. “Clear Nozzle”); some are valid only when the jet is running and printing is stopped (e.g.

  • Page 47: Stop Jet

    Diagnostics Test Print Triggers patterns manually from the keyboard. This is the equivalent of a photocell trigger and starts the print. If a shaft encoder is in use and the line is stopped then the pattern will only be printed when the line restarts. The command is only valid if the photocell mode has been set to “Triggered”...

  • Page 48: Flush Shut Down

    Diagnostics The following message will appear in the status line of the display while the Clear Nozzle sequence is being performed: “Clearing Nozzle : Please Wait” During this cycle, the printhead must be inverted and the correct type of solvent applied to the nozzle. The procedure for clearing the nozzle is described later in this manual.

  • Page 49: System Timing Information

    The current read pressure being measured by the pressure transducer. This will normally be the same as Press (Set Pressure), accurate to +14 bits.and -14 bits. Your local EC-JET distributor may ask you to read-off the values shown against some of the above parameters to help diagnose any problems you may have.

  • Page 50: Phase

    4. Use Quick Start Jet to try and obtain VOD measurements and ascertain if ink is thick or thin. Filter Purge Used by EC-JET approved Service Engineers when a new main ink filter is fitted: Sets a fixed pressure of 120 bits to purge the new filter and resets the Filter Change time to 2000 hours.

  • Page 51: Routine Maintenance

    SOLVENT. DO NOT USE SOLVENTS IN CONFINED AREAS WITHOUT ADEQUATE VENTILATION. CAUTION: Use only EC-JET solvent. Ensure that the solvent matches the type used in the printer. CAUTION: Do not use excessive amounts of solvent. It is not recommended that solvent is used frequently to remove ink from the front panel and LCD screen as this can lead to deterioration of the membrane surface.

  • Page 52: Printhead Cleaning Procedure

    Routine Maintenance Printhead Cleaning Procedure While wearing approved, solvent resistant gloves: Remove the printhead cover tube and hold the printhead as shown below. Place a suitable container underneath and wash the entire printed circuit board (PCB) surface with the appropriate solvent. Do not use the wrong solvent; make sure it is the solvent corresponding to the ink type being used in the printer.

  • Page 53: Replenishing Ink And Solvent

    NOTE: The printer will not start if ink or solvent are low. CAUTION: Use only EC-JET ink and solvent. Do not add any more ink or solvent until requested by the printer overfilling could seriously damage the printer. EJ88 Cleaning/Replacing the Air Filter...
  • Page 54 Routine Maintenance Pull the air filter from side of cabinet . Clean the filter or replace it Refit the cleaned filter in its housing or fit a replacement filter if it is changed. Close up the cover. To the machine that its number after SN: C5000 Hold up the front of machin lightly.

  • Page 55: Warning And Fault Messages

    Warning and Fault Messages Warning and Fault Messages This section describes the printer warning messages for the EC-JET printers. The error messages may occur at any time and are NOT a direct response to user commands, although a user response may be required.

  • Page 56: System Failures

    Warning and Fault Messages System Failures System failures occur when the software detects a condition which prevents normal printer operation. If a system failure is reported by the printer, contact your local distributor immediately. WARNING: LETHAL VOLTAGE. UNKNOWN HIGH VOLTAGES MAY BE PRESENT WITH SOME SYSTEM FAILURES.

  • Page 57: Charge

    (see “Changing the System Setup”). Build-up of ink on the sensors: Clean the printhead. Blocked filter: Contact your local EC-JET distributor for assistance. 2.04 300V Power Supply Possible cause The 300 volt power supply output is out of tolerance or has failed: Call your local EC-JET distributor.

  • Page 58: System Warnings

    Allow the printer to run to bring the viscosity back into range. There is a pressure loss in the system: Call your local EC-JET distributor. 3.01 Jet Shut Down Incomplete This indicates that the printer was previously switched off while the jet was running or before the printer had completed the shutdown routine.

  • Page 59: Over Speed (Print Go)

    Warning and Fault Messages 3.02 Over Speed (Print Go) This indicates that the printer may have missed printing at least one pattern or is receiving false triggers from the photocell. When the Photocell Mode is set to Trigger, each print delay is started following the photocell trigger. At the end of the delay a “print go”...

  • Page 60: Bad Print Head Code

    3.10 Charge Calibration Range Contact your local EC-JET distributor if this error is reported. 3.11 Safety Override Detected This warning message alerts the user when the safety override link is fitted.

  • Page 61: Memory Failure

    Possible cause The battery backup has failed (exhausted battery). Recharge the battery by switching the printer on for 24 hours. Otherwise, contact your local EC-JET distributor. 3.17 Memory Corrupt The system will still function but some values may have been reset to their defaults.

  • Page 62: Troubleshooting

    Troubleshooting Introduction This section provides general advice on fault diagnosis on the EC-JET Ink Jet Printers, as well as specific procedures for identifying and rectifying faults. Fault diagnosis is complicated by the number of variables involved in producing good print quality. Fast, non-contact printing involves fluid dynamics, physics, electronics, computing and chemistry.

  • Page 63: Identifying Faults

    Troubleshooting Make use of the Diagnostics options to check and record the jet monitoring parameters of Pressure, Velocity Of Drop, Modulation and Phase. Compare these with the reference values and identify any out-of-specification measurements. (See “Diagnostics”) Make print samples (if possible) and examine the prints carefully for signs of print quality problems. - Only when all of the symptoms have been noted should an attempt be made to identify the possible cause of the problem.
  • Page 64 Troubleshooting EJ93 Top (or bottom) of pattern missing Gutter Clipping…………………………………………………………………………………FC05 Section of the pattern missing or distorted. Printhead Cover Catch (obstruction in cover slot)…………………………………………FC06 Uneven stretching of the pattern. Shaft Encoder Faults (shaft encoder slipping)………………………………………………FC09 Squashed print. Pattern not blurred. Deflector Voltage Faults………………………………………………………………………FC10 Product tilting along the axis of the conveyor travel.

  • Page 65: Identifying Faults By Symptom

    Troubleshooting Identifying Faults by Symptom When it is not possible to identify a fault by the visible effect on the print sample, it becomes necessary to look for other symptoms. For example, it may not be possible to start the jet satisfactorily, so it will be impossible to obtain any sort of print.
  • Page 66 Troubleshooting Symptom and Possible Causes Fault Code BEFORE SWITCHING ON Ink deposits in the printhead or on the cover slot. Jet Alignment Problems ........................FC32 Ink leaking from gutter Gutter Problems ..........................FC35 AFTER SWITCHING ON Ink leaking from gutter. Gutter Problems ..........................FC35 Low pressure warning on start-up.

  • Page 67: Problem Solving

    Troubleshooting Problem Solving This sub-section describes the faults identified in the previous sub-section “Identifying Faults”. For each fault, identified by a fault code (FC) number, procedures are given for confirming the presence of the fault, and actions necessary to rectify the fault. Fault codes not referenced in this manual are faults that can only be rectified by a Service Engineer.
  • Page 68 Troubleshooting EJ96 Cover clipping zone NOTE: It is sometimes possible for the least deflected drops to clip the cover slot, in which case the effect is similar to the Gutter Clipping fault PRINT SAMPLE(Gutter clipping) EJ95 Most commonly, the drops are lost at the bottom of the print, as in the above print sample. Whether the top or the bottom of the print is missing, a typical result of printhead cover catch is a fine diffuse spray of drops.

  • Page 69: Problem Solving - Ink System Mechanical Faults

    Troubleshooting Cause and Cure Clean the exit slot using the appropriate solvent for the type of ink being used in the printer. Make sure that the printhead cover is correctly positioned and securely fitted on the printhead. NOTE: Some of the Printhead Cover Catch print samples may show similarities with Phasing Errors problems.

  • Page 70: Problem Solving - Printhead Mechanical Faults

    If clearing the nozzle does not solve the problem, it will be necessary to call your local Distributor for a EC-JET approved engineer. Clearing the Printhead Nozzle The nozzle has a very small orifice and it is possible for this orifice to become blocked in a number of ways, for instance: dried ink, foreign debris introduced into the ink supply, or contamination of ink types.
  • Page 71 Troubleshooting “D” key which will call up the DIAGNOSTICS menu directly. EJ101 DIAGNOSTICS > Stop Print > Test Print > Clean Nozzle > Nozzle Flush 00000 PRESSURE PHASE Jet off 2006-03-24 14：01：38 Use the up/down cursor keys to locate the Clear Nozzle option. Press [enter] and type in the number of Clear Nozzle sequences you wish to run.
  • Page 72 (inadequate suction): very thick ink, e.g. pressure is 40 points above the reference pressure value. If you suspect a gutter blockage, do not attempt to clear it yourself; contact EC-JET or your local distributor. FC36 Vibration Problems Vibration can cause a number of problems, the most prominent of which are described here.
  • Page 73 Troubleshooting EJ103 Product tilting from side to side along the axis of conveyor travel Notice how characters are distorted in width as the product tilts under the printhead Product tilting from side to side at 90 degrees to the axis of conveyor travel Notice how characters are distorted in height...
  • Page 74 Troubleshooting EJ104 Character without high frequency vibration Character with high frequency vibration across the conveyor Character with high frequency vibration in direction of conveyor travel To determine whether high frequency vibration is affecting the product or the printhead, simply pass a piece of paper under the printhead and trigger the print.
  • Page 75 Troubleshooting EJ105 Push paper steadily Hold printhead steady Push paper steadily under the printhead to damp any vibration under the printhead Knocks and Strong Vibrations Testing for product vibration Testing for printhead vibration Strong vibration and knocking to the printhead is the most serious vibration problem likely to occur, since this will affect operation of the printer itself.
  • Page 76 Troubleshooting EJ106 EC-JET FORCE Impact or vibration in this direction causes drops to collide with the VOD sensor and gutter edge Gutter moves out of drop stream causing drops to dirty the head by colliding with either side of the gutter Jet obstruction due to high impact knock or excessive vibration.
  • Page 77 Troubleshooting EJ107 The photocell informs the printer that a product is in position for printing In response to this (if a Delay Has been set) the printer software Will begin to count rasters. It will not print until the number Of rasters counted PRINTHEAD is equal to the Delay value PHOTOCELL...
  • Page 78 Troubleshooting EJ108 In this example, the message Is so long that the printer is unable to finish printing it Before the next product arrives. This causes the "Overspeed" warning message to be displayed Message Would end here Message started here Photocell detects arrival of next Product before the current message has finished printing...

  • Page 79: Technical Specification

    Technical Specification Technical Specification Introduction The EC-JET Continuous Ink Jet Printer is a fast, reliable, non-contact printer capable of applying sell- by dates, batch codes and other variable information to a wide range of substrates on the production line. Technical Data...

  • Page 80: Memory Capacity

    Technical Specification Level Control Ink tank sense low: Warning reported at approximately 750 ml Solvent tank sense low: Warning reported at approximately 750 ml Performance Solvent consumption: <8 ml/h at 20 Celsius ambient using EC1240 MEK black ink Memory Capacity Message storage capacity: Up to 46 messages Logo storage capacity:...

  • Page 81: Appendix 1: Installation & Setting Up

    Power Connection The EC-JET range of printers are designed to operate on a single phase, 50/60 Hz AC supply of 90 to 240 V at 50/60 Hz. This means that any AC voltage within this range will power the printer satisfactorily.

  • Page 82: Attaching The Printhead To The Production Line

    DAMAGE CAUSED TO EITHER MACHINE OR PERSONNEL DUE TO INCORRECT OR FAULTY WIRING. Attaching the Printhead to the Production Line The printhead can operate from any angle if clamped in place with a EC-JET head bracket to ensure secure and vibration free operation. EJ109...

  • Page 83: Print Height

    (it must not be connected to 0 volts). CAUTION: Electromagnetic Compatibility performance may be compromised by the use of unsuitable photocells. Use only EC-JET approved accessories. User Manual...

  • Page 84: Setting Up The Shaft Encoder

    The calculations shown in the next few pages should be used to select the optimum arrangement for your application. EC-JET will be happy to advise on the best position and gearing for shaft encoder installation.

  • Page 85: Selecting The Encoder, Gearing, And Print Width

    CAUTION: EMC performance may be compromised by the use of unsuitable shaft encoders. Use only EC-JET approved accessories. Selecting the Encoder, Gearing, and Print Width When using a shaft encoder it is vitally important that the calculations are followed and the print width is computed based on the geometry of the set up.
  • Page 86 (a whole number) to give the actual raster pitch. This should be as close as possible to the required raster pitch. The table below gives the encoder pitches for standard EC-JET encoders and wheels. The encoder pitch for other gearing or drives can be calculated using:...
  • Page 87 Pitch Factor Encoder Pitch (mm) rounded to the nearest whole number. Using the example from Step 1, the required raster pitch is 0.373 mm. A standard EC-JET encoder and wheel will be used to try to achieve this. EJ116 Encoder Pitch x Pitch Factor...
  • Page 88 The specified frequency varies with encoder type: EJ118 Specified Frequency Encoder Type (kHz) 2500p.p.r. 20.0 5000p.p.r. 20.0 This gives the following maximum encoder speeds for standard EC-JET encoders and wheels: EJ119 Encoder 500 mm circ. 200 mm circ. 333 mm circ. 2500p.p.r. 1.6m/s 4.0m/s 2.66m/s...

  • Page 89: Troubleshooting Encoder And Print Width Problems

    Using the Printer Alarm Output When there is a print warning or failure, the printer activates a 24 volt external alarm, where fitted. The Alarm Beacon available from EC-JET is as follows: Alarm Beacon Single Stage 24V. The pin connections are as follows:...

  • Page 90: Purging (Or Priming) The Filters

    Appendix 1:Installations & Setting Up Purging (or priming) the Filters After a main ink filter change, the filter must be completely filled with ink before the system is run. For this purpose, a Filter Purge option is available from the DIAGNOSTICS menu. This procedure should only be performed by an authorized service engineer following filter replacement.

  • Page 91: Appendix 2: Printable Line Speeds

    Appendix 2: Printable Line Speed Appendix 2: Printable Line Speeds The following table shows the line speed at which good printing will be obtained for each raster type and printhead model at ideal pitch: EJ121 LINE SPEEDS PER PRODUCT FREQUENCY (m/s) Printhead Type 7 GEN STD 16 GEN STD...

  • Page 92: Appendix 3: Line Speeds Per Product Frrequency

    Appendix 3: Line Speeds per Product Frequency Appendix 3: Line Speeds per Product Frequency This table shows a reference to line speeds according to the product pitch (gap between products) and the products per minute. EJ122 LINE SPEED PER PRODUCT FREQUENCY (m/s) 1000 1500 Product Pitch...
  • Page 93 Pharmapack Technologies Corporation Address:No.16 Huang Qi Shan Road,Yong He Address:No.16 Huang Qi Shan Road,Yong He Economic Zone,GETDD,Guangzhou,China. Economic Zone,GETDD,Guangzhou,China. Tel:+86-20-82209518 Fax:+86-20-82209511 Tel:+86-20-82215907 Fax:+86-20-82213367 http://www.ec-jet.com http://www.pppharmapack.com E-mail:market@ec-jet.com E-mail:market@pppharmapack.com Pharmapack North America Pharmapack Europe Pharmapack Packaging Equipment CO.India Pvt.Ltd. Address:5095 East Airport Drive...
