Quick reference guide
PROGRAMME
START BUTTON
SELECTOR
The indicator lights up during operation, flashes when a fault occurs, and goes off
KNOB
at the end of the programme.
(see "Table of
START BUTTON RESET FUNCTION:
programmes"
Press this button for at least 2 seconds; the selected programme and options will
below).
be cancelled. Main failure displays (repeated flashing of the START indicator lamp)
can be cancelled by RESETTING. Detailed instructions are given in chapter
"What to do if...".
Table of programmes
P
Programmes
1
AutoSensor
2
Pre-Wash
3
Quickwash
4
2)
Eco
5
Intensive
1)
Programme data obtained in conformity with European standard EN 50242, obtained under normal conditions (without additional
options) and may vary depending on conditions. Differences of up to 20 minutes are possible with sensor programmes as a result of
the appliance's automatic calibration system.
2)
Reference programme for energy label in compliance with EN 50242 regulations. - Note for Testing Institutes: for detailed information on
the EN/Standard loading comparison test and other tests, contact the following address: "nk_customer@whirlpool.com".
3)
The antibacterial action has been tested by the Institut Pasteur of Lille (France), based on the NF EN 13697 standard of November 2001.
START
DELAY
option
(see at right for options description)
Available
Loading instructions
options
Delay
Recommended programme for
Multizone
50-65°C
routine washes, with dried-on food
Antibacterial
(e.g. EN 50242).
rinse
Delay
cold
Crockery to be washed later.
Multizone
Lightly soiled crockery, with no
Delay
45°C
dried-on food. * Use of tablets not
Multizone
recommended.
Delay
Multizone
Normally soiled crockery.
50°C
Antibacterial
Energy-saving programme.
rinse
Delay
Recommended programme for heavily
Multizone
70°C
soiled crockery, especially suitable for
Antibacterial
pots and pans.
rinse
BEFORE USING THE APPLIANCE FOR THE
FIRST TIME CAREFULLY READ THIS QUICK
REFERENCE GUIDE AND THE ASSEMBLY
INSTRUCTIONS! THE GUARANTEE IS NOT
APPLICABLE IF FAULTS ARE CAUSED BY
INCORRECT USE OF THE APPLIANCE.
Options and display description
SALT INDICATOR
When lit, the salt reservoir
MULTI
ANTI-
ON/OFF
needs to be refilled.
ZONE
BACTERIAL
BUTTON
option
RINSE
option
Consumption
Deter-
RINSE AID INDICATOR
gent
When lit, the rinse aid dispenser needs
1)
Litres
kWh
Minutes
to be refilled.
X
11-16 1.10-1.50
100-130
DELAYED START
BUTTON
4.0
0.03
14
Press the button (repeatedly)
to delay the start of the
programme. Adjustable from 1
to 24 hours. With each press of
X *
11.0
0.80
30
the button, the delayed start
indicator increases by one hour
and after 24 restarts from 00.
Then press the START button.
The dishwasher will start after
X
12.0
1.05
165
the set time.
X
14.0
1.55
155
FAULT INDICATION AND WASH TIME DISPLAY
In normal operation it indicates the remaining time (h:mm),
whereas with "Delayed start" selected it indicates the time
remaining until programme start (hh).
If "F.." appears on the display, see chapter "What to do if...".
HALF LOAD/MULTIZONE
ANTIBACTERIAL RINSE
Allows you to choose the
This function activates an
washing zones. Press this button
antibacterial rinse at the end of
to select the wash zones:
the wash cycle, guaranteeing a
further reduction of bacteria.
both racks
Press the button to activate or
deactivate the function. This
function can be used with
only upper rack
those programmes marked
with the relative description in
table. The dishwasher door
only lower rack
must be kept shut for the
entire duration of the
programme in order to
guarantee reduction of
bacteria. If the door is opened
the indicator lamp starts
flashing.
ADG 6240
5019 396 01788
Chart
3)
GB -1-
