ANS Z83.26-2014 • CSA 2.37-2014 Gas-Fired Outdoor Infrared Patio Heaters
User Manual No. 6
Models: 9710020, 9710021
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flames.
3. If odor continues, keep away from the appliance and
immediately call your gas supplier or fire department.
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
An LP-cylinder not connected for use shall not be
stored in the vicinity of this or any other appliance.
WARNING:
DANGER
Improper installation, adjustment, alteration, service or
maintenance can cause property damage, injury or death.
Read the installation, operation and maintenance
instructions thoroughly before installing or servicing this
equipment.
R
1
OUTDOOR
PATIO HEATER
DANGER
WARNING
For Outdoor Use Only
CARBON MONOXIDE HAZARD
This appliance can produce
carbon monoxide which has
no odor. Using it in an enclosed
space can kill you. Never use this
appliance in an enclosed space
such as a camper, tent, car or home.
WARNING
C
R
R
US
Advertisement
Table of Contents
Related Manuals for CAMBRIDGE CUW020-BRN
Summary of Contents for CAMBRIDGE CUW020-BRN
- Page 1 User Manual No. 6 Models: 9710020, 9710021 OUTDOOR PATIO HEATER DANGER FOR YOUR SAFETY If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flames. 3. If odor continues, keep away from the appliance and immediately call your gas supplier or fire department.
-
Page 2: Package Contents
PACKAGE CONTENTS QUANTITY Reflector Panel Reflector Plate Head Assembly Post Tabletop Main Frame Gas Hose Regulator Wheel Wheel Axes... -
Page 3: Safety Information
HARDWARE CONTENTS (shown actual size) Wing nut Flange Screw Washer Φ6 Qty. 3 Bolt Cap nut M6 X 10 Qty. 9 Washer Φ8 M6 X 12 Reflector Qty. 9 Qty. 4 Qty. 9 Qty. 11 Qty.8 spacer Qty. 3 Wrench Stainless steel Battery Deck ring... - Page 4 SAFETY INFORMATION DANGER DANGER • EXPLOSION - FIRE HAZARD • CARBON MONOXIDE HAZARD • Keep solid combustibles, such as building materials, • This heater is a combustion appliance. All paper or cardboard, a safe distance away from the combustion appliances produce carbon monoxide heater as recommended by the instructions.
-
Page 5: Burn Hazard
SAFETY INFORMATION WARNING WARNING California Proposition 65 • This product is fueled by propane gas. Propane gas Combustion by-products produced when using is invisible, odorless, and flammable. An odorant is this product contain chemicals known to the State normally added to help detect leaks and can be of California to cause cancer, birth defects, and described as a “rotten egg”... - Page 6 ASSEMBLY INSTRUCTIONS 1. Fix the support post (D) with 4pcs M6x30 bolts (LL) and M6 flange nuts (AA). Hardware Used Bolt M6 x 30 M6 Flange nut 2. Put the tabletop (E) throught the support, secure the tabletop with 4pcs M6X12 bolts. Hardware Used Bolt M6 x 12 3.
- Page 7 ASSEMBLY INSTRUCTIONS 4. Attach reflector spacers (CC) and three washers Ø8 (DD) to screen cover. Tighten the reflector spacers. Hardware Used Reflector spacer Washer Φ8 5. Attach head assembly to post. 5-1. Unscrew four stainless steel bolts M6 X 10 (II). Hardware Used Stainless steel bolt M6 X 10 5-2.
- Page 8 ASSEMBLY INSTRUCTIONS 6. WARNING:Remove protective cover before assembling. Note: If necessary for proper alignment of reflector sections, loosen each bolt prior to further assembly and retighten after sections are aligned. 7. 7-1.Slide two reflector panels together. Insert one screw M6 X 10 (FF). Slide one washer (EE) over threaded end of screw M6 X 10 (FF) and screw on cap nut (GG) loosely.
- Page 9 ASSEMBLY INSTRUCTIONS Support heater. Slide three washers washer Φ8 (DD ) over threaded end of spacer. Locate reflector assembly on 3 spacers. Install three washers Φ8 on spacers and securely tighten wing nuts (HH) but do not overtighten. Hardware Used Washer Φ8 Wing nut 9.
- Page 10 ASSEMBLY INSTRUCTIONS WARNING: A dented, rusted or damaged propane cylinder may be hazardous and should be checked by your propane supplier. Never use a propane cylinder with a damaged valve connection. The propane cylinder must be constructed and marked in accordance with the specifications for LP gas cylinders of the U.S.
- Page 11 OPERATION INSTRUCTIONS Leak Check WARNING • Perform all leak tests outdoors. • Extinguish all open flames. • NEVER leak test when smoking. • Do not use the heater until all connections have been leak tested and do not leak. Hose / Regulator Regulator / Cylinder connection connection...
-
Page 12: Carbon Monoxide Hazard
OPERATION INSTRUCTIONS DANGER • CARBON MONOXIDE HAZARD • For outdoor use only. Never use inside house, or other unventilated or enclosed areas. This heater consumes air (oxygen). Do not use in unventilated or enclosed areas to avoid endangering your life. Caution: Do not attempt to operate until you have read and understand all General Safety Information in this manual and all assembly is complete and leak checks have been performed. - Page 13 OPERATION INSTRUCTIONS Lighting: 1. Turn on the valve on the gas cylinder. 2. Press and turn the control knob to HI (maximum) position (anti-clockwise 90º). (Figure 1) 3. Holding down the control knob, press the igniter button several times until the main flame is ignited. Release the control knob 10 seconds after the ignition.
-
Page 14: For Your Safety
OPERATION INSTRUCTIONS WARNING FOR YOUR SAFETY Be careful when attempting to manually ignite this heater. When Heater is ON: Emitter screen will become bright red due to intense heat. The color is more visible at night. Burner will display tongues of blue and yellow flame. These flames should not be yellow or produce thick black smoke, indicating an obstruction of airflow through the burners. -
Page 15: Care And Maintenance
OPERATION INSTRUCTIONS 9. Heater is away from gasoline or other flammable liquids or vapors. 10. Heater is away from windows, air intake openings, sprinklers and other water sources. 11. Heater is at least 2 feet on top and at least 3 feet on sides from combustible materials. 12. - Page 16 CARE AND MAINTENANCE Signs of possible blockage include: Gas odor with extreme yellow tipping of flame. Heater does NOT reach the desired temperature. Heater glow is excessively uneven. Heater makes popping noises. Spiders and insects can nest in burner or orifices. This dangerous condition can damage the heater and render it unsafe for use.
-
Page 17: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Wait until the propane cylinder Propane cylinder is frosted over warms up and is defrosted Burner won’t light Blockage in orifice Clear blockage Control knob is not in ON position Turn control knob to ON Turn cylinder valve OFF and replace Gas pressure is low cylinder... -
Page 18: One-Year Limited Warranty
ONE-YEAR LIMITED WARRANTY This product is inspected, tested and carefully packaged to minimize the chance of damage during shipment. If a part within one year from the date of purchase proves to be defective in material or fabrication under normal use, the part will be repaired or replaced. The Company's obligation under the warranty is to replace or repair defective parts at our discretion. -
Page 19: Replacement Parts List
REPLACEMENT PARTS LIST QUANTITY Reflector Panel Reflector Plate Head Assembly Post Tabletop Main Frame Gas Hose Regulator Wheel Wheel Axes...
