Electric fireplace with remote control
Models: EF2001 EF2002 EF2003
INSTALLATION AND USER
INSTRUCTIONS
Please read all instructions
carefully and retain for future
reference!
Content
Important Safety Instructions ........................ 3&3
Getting Started .............................................. 3&4
Contents of Carton (fig. A) ................................ 5
Helpful Advice Before Fitting ........................... 5
Installation ......................................................... 5
Placing pebbles .................................................. 6
Instructions for Use ............................................ 6
Safety Cut-Off .................................................... 7
Troubleshooting ................................................. 7
Replacing the Lamp ........................................... 8
Cleaning ............................................................. 8
Technical Specification ...................................... 8
Disposal ............................................................. 8
Advertisement
Table of Contents
Related Manuals for AMBION FLAME EF2001
Summary of Contents for AMBION FLAME EF2001
-
Page 1: Table Of Contents
Electric fireplace with remote control Models: EF2001 EF2002 EF2003 INSTALLATION AND USER INSTRUCTIONS Please read all instructions carefully and retain for future reference! Content Important Safety Instructions ......3&3 Getting Started ..........3&4 Contents of Carton (fig. A) ........ 5 Helpful Advice Before Fitting ...... -
Page 2: Important Safety Instructions
Important Safety Instructions When using this electrical appliance, basic precautions should be followed to reduce the risk of fire, electric shock, and injury to person, including the following: a) This heater must be used on an AC supply only and the voltage marked on the heater must correspond to the supply voltage. -
Page 3: Getting Started
WARNINGS: a) Do not use the heater in reach of a shower, bath or a swimming pool. b) Heater is not located immediately below a socket-outlet c) If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or a similarly qualified person in order to avoid a hazard. -
Page 4: Contents Of Carton (Fig. A)
Contents of Carton (fig. A) ■ Heater. ■ Wall fixing bracket. Fixing screws and wall plugs. ■ Remote control. ■ ■ Instruction Manual. serial name quantit number Carton Packin Form Fixed Angle (Embedded t e) Remote control Plastic lu M4*35mm 9 or 10 Screws 4*35mm 9 or 10... - Page 5 Remove the screws used for transportation and focation on both sides For Recessed Mount: ---+...
-
Page 6: Installation
Remove the screws used for transportation and fixation on both sides For Wall Mount: 1100mm Installation for Wall Mount a) Do not connect the appliance until properly fixed to the wall and the instructions is read fully. b) The minimum distances must be observed. c) For installation of the appliance, care must be taken not to damage concealed cables. -
Page 7: Placing Pebbles
g) Use the bracket as table template and mark five drill positions on the wall. Make sure that these holes are level. Observe the recommended fixing dimensions. h) Put the bracket aside and drill holes with a depth of 35 mm using an 8 mm drill bit. Clean the holes from dust and insert one plug in each hole. -
Page 8: Safety Cut-Off
High Main Switch Switch Heating Heating Setting Setting Coverage is strictly prohibited Air Intake Air Outlet Air Intake Remote Receiver FLAME POWER HIGH Safety Cut-Off This appliance is fitted with a safety cut-off which will operate if the fire overheats (e.g. due to blocked air vents). -
Page 9: Replacing The Lamp
Replacing the Lamp Warning-Always disconnect from the power supply before removing lamp. Only a qualified engineer can replace the fault lamp. Cleaning Warning-Always disconnect from the power supply before cleaning heater For general cleaning use a soft clean duster-never use abrasive cleaners. The glass viewing screen should be cleaned carefully with a soft cloth.
