UINICS CU-675 Series Operation Manual

Batch counter

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

Operation Manual

【

ＭＯＤＥＬ：ＣＵ－６７５ Series

Communi

Input

Series

name

cation

Signal

CU-675

RS2

RS4

RS4W

Batch

Sensor

Voltage

・

NPN open collector Pulse

・AC85～264V free power

・DIN W72×H144×D122 mm

RS-232C Communication

RS-485 Communication（２-Wire）

RS-485 Communication（４-Wire）

Analog current input（DC4～20mA）For deviation

detection

Standard Sensor Power DC12V 100mA Below

S24

Sensor Power DC24V 60mA Below

counter

Function

／Voltage Pulse input

【 4th edition 13th January 2016 】

】

＠CU-675(4)-E

Table of Contents

Need help?

Do you have a question about the CU-675 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for UINICS CU-675 Series

Page 1 Operation Manual 【】 Batch counter ＭＯＤＥＬ：ＣＵ－６７５ Series Communi Input Sensor Series Function name cation Signal Voltage ・／Voltage Pulse input NPN open collector Pulse CU-675 ・AC85～264V free power ・DIN W72×H144×D122 mm RS-232C Communication RS-485 Communication（２-Wire） RS4W RS-485 Communication（４-Wire） Analog current input（DC4～20mA）For deviation detection Standard Sensor Power DC12V 100mA Below Sensor Power DC24V 60mA Below...
Page 2 Precautions Please read this Operation Manual including the following precautions carefully to ensure safe use of your meter. ！＜Caution＞ Do not use this product for applications outside of the product specifications. ！＜Caution＞ User-conducted alterations and modifications of the unit should not be performed as they may impair functioning or cause failure and accidents.
Page 3: Table Of Contents
Contents 1．About confirmation of an attachment. and a guaranteed period ・・・・・・・・・・・・・1 2．Specifications ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・2～4 3．Overview of Operation ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・5 4．Mounting meter ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・6 5．Connecting terminal boards ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・7～9 6．Construction of input circuit,output circuit ・・・・・・・・・・・・・・・・・・・・・10 7．Setting the dip switch ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・11 8．Names and Functions of components on front ・・・・・・・・・・・・・・・・・・・・12～14 9．The setting menu ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・15～16 10．Initial setting values and initialization・・・・・・・・・・・・・・・・・・・・・・・17 11．SV value (target value) of call and change settings・・・・・・・・・・・・・・・・・18...
Page 4: 1．About Confirmation Of An Attachment. And A Guaranteed Period ・・・・・・・・・・・・・1
1．About confirmation of an attachment and a guaranteed period About confirmation of an attachment． When you received as a product, please confirm whether it includes the following. （１）ＣＵ－６７５（The chosen specification）・・・・・・・・・・・・・・・１（２）ＣＵ－６７５ Operation manual （This book）・・・・・・・・・・・・・・１（３）Installation turniture ・・・・・・・・・・・・・・・・・・・・・・・・４（４）Drip-proof Packing ・・・・・・・・・・・・・・・・・・・・・・・・・・１...
Page 5: 2．Specifications ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・2～4
2．Specifications 【 Standard specifications 】 Table.１ Item Specifications Mesurement accuracy Scaling（Conversion instrument）± 0 to the 1 (accumulate) (At the time of correction display current position and function stop) Total display Upper tier：6 Digits red color LED character height10mm PV display （Measured value） Middle tier：6 Digits red color LED character height10mm SV display（Target value）...
Page 6 Control signal From the start signal output、 to the PV display value (measured value) reaches the SV value(target value).In the output, control signal display (RUN), lamp lighting. Output Relay 1c contact output method AC250V（DC30V）5A MAX（Resistance load） Deceleration signal Two-stage opening and closing or Deceleration mode switching Two-stage opening and closing：From the Start time to the preset value that is to OFF, the output was stop before preset of the SV value(target value).
Page 7 （２）Analog input（options: Type A2） Table.2 Survey type Measurement deviation detection Input level DC4 to 20mA Display interval Fixed 0.5 seconds Display accuracy ±0.3％F.S.±1digit A/D bit conversion About 7000 Resolution A/D measurement interval About 20ms Temperature characteristic ±50ppm Input impedance Input resistance 250Ω Measurement display range 0 to 9999 Setting range deviation upper...
Page 8: 3．Overview Of Operation ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・5
3．Overview of Operation ① Control operation（Automatic operation） 1) When the start key or start signal was ON, SV value （Target value）is quoted and batch control is started. Note）Can not change the value SV during batch control. The setup can be performed when batch control has stopped.
Page 9: 4．Mounting Meter ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・6
4．Mounting meter How to mount meter 1． Cut the panel to insert the indicator (meter) from the front. Panel cut size. Fig.1 2． Please push the Fitting for fixing body. Into a right and left both sides of the meter. Fig.2 3．...
Page 10: 5．Connecting Terminal Boards ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・7～9
5．Connecting terminal boards ≪ Terminal block connection diagram ≫ Fig.4 A．3-wire type pulse sensor Fig.5 B．2-wire type pulse sensor Fig.6 ① Sensor input Please connect to the terminal block 1, 2, 3. ② Reset signal When the reset signal was ON、the PV measurement value return to”0”. Also、abnormal output release too.（It is the same as the reset key on the front panel.）...
Page 11 ④ Start signal Input signal in during the stop,start the batch control,output a control signal at the same time. When the abnormal signal measurement be output, start the batch control after release of abnormal signal measurement. （It is the same behavior as the start key on the front panel） Please Connect to the terminal block 7, 8.
Page 12 ！・ Power supply confirmation 1）Always turn the power off before commencing wiring work.There is fear of the electric shock. 2）Checking the power input Please check once again the input voltage. 3）Wire correctly after often confirming the terminal stand label. 4）The wiring technique is different depending on the kind of the sensor、Please refer P.7 Fig.4 to Fig.6.
Page 13: 6．Construction Of Input Circuit,Output Circuit ・・・・・・・・・・・・・・・・・・・・・10
6．Construction of input circuit,output circuit Sensor input Fig.7 Signal input Fig.8 Analog input Fig.9 Signal output Fig.10 - 10 -...
Page 14: 7．Setting The Dip Switch ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・11
7．Setting the dip switches Sensor input response, sensor input (NPN open collector or Voltage pulse) can be selected by changing the switch. Table.4 １２Ｏ NPN open collector input ＯＮ Voltage pulse Input ＯＦＦ Input frequency less than 50Hz(LO) ＯＮ...
Page 15: 8．Names And Functions Of Components On Front ・・・・・・・・・・・・・・・・・・・・12～14
8．Names and functions of components on front Fig.12 TOTAL P.V. S.V. Lamp display unit Key operation unit ① TOTAL display Display measurement：Display the TOTAL value（Total）. Mode setting：Display mode No. ② PV display Display measurement：display the PV value（Measured value）. Mode setting：Disuplay the date value according to the mode. ③...
Page 16 Lamp display unit The lamp of the control status was display. Fig.13 Function Signage Color Function description. Control signal ① ＲＵＮ Green When the control signal is output、lights. display Slowdown signal ② ＳＬＷ Green When the slowdown signal is output, lights. display End signal ③...
Page 17 ～ Key operation unit Fig.14 Name Display name Function description Mark key Measure display Setting SV value. ＳＶ ① Each setting Not use. Measure display CH mode、switch the CH No. ＣＨ ② Switch the SV setting value and CH setting. CＨ...
Page 18: 9．The Setting Menu ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・15～16
9．The setting menu <<Test mode>> - 15 -...
Page 19 <<Various setting operations>> - 16 -...
Page 20: 10．Initial Setting Values And Initialization・・・・・・・・・・・・・・・・・・・・・・・17
10．Initial setting values and initialization If the specifications desired by the user are requested prior to shipment, the meter will be set these settings. Other wise, the regular factory settings are shown below. Value setting of each mode Table.5 Mode Ｎｏ. Initial setting Note Ａ～Ｄ...
Page 21: 11．Sv Value (Target Value) Of Call And Change Settings・・・・・・・・・・・・・・・・・18
11．SV value (target value) of call and change settings When set up the SV value of deta,Please perform the operation of each key as shown in the following figure. Operation key Display Operating procedure Press ＡＢＣＤＥＦ Display 「SV」in A to B Ｓ...
Page 22: 12．Content And Setting The Each Mode・・・・・・・・・・・・・・・・・・・・・・・・・19～30
12．Content and setting the each mode ≪ 1．Operating method the mode setting ≫ When set up the mode, Please perform the operation of each key as shown in the following figure. Operation key Display Operating procedure Press ＡＢＣＤＥＦ Display 「P-00」in A to D Ｐ...
Page 23: 2．Content Of The Each Mode And Set Value≫・・・・・・・・・・・・・・・・・・20
≪2．Content of the each mode and set value≫ Mode No. Mode control operation・Start operation・set SV value・Display decimal point ＡＢＣＤＥＦＰ－００Ｐ－００ＧＨＩＪＫＬ０１０１１ TOTAL display decimal point ０：...
Page 24 Fig.16 Fig.17 〔Start operation〕 0：Resetstart PV value displayed by start signal ON now is reset, and measurement is started from "0." 1：Normalstart It continues from PV value displayed by start signal ON now, and starts measurement (which is not reset). A display is cleared by "0"...
Page 25 Mode No. Setting of（unit conversion）PV display data scaling ＡＢＣＤＥＦＰ－０１Ｐ－０１ＧＨＩＪＫＬ１０００３－ｎＥＸＰ-value 10 ｎ＝0～9 Converted value 0001～9999 （Do not set 0000） With input of this converter and EXP-value, it is possible to set the magnification per 1 pulse.
Page 26 Mode No. Setting of deceleration signal（deceleration flow value）ＡＢＣＤＥＦＰ－０３Ｐ－０３ＧＨＩＪＫＬ ※A decimal point can be set up to the 3rd place. ０１５．０ It sets to a decimal point by a Shift key, and moves a decimal point by a rise key.
Page 27: Mode No.04」Setting Of Termination Signal Of Output Timing And Output Width ・・・・・・24
Mode No. Setting of termination signal of output timing and output width ＡＢＣＤＥＦＰ－０４Ｐ－０４ＧＨＩＪＫＬ０．５０．１ Output width 0.1～9.9 sec（0.0 holds an output.） Output timing 0.0～9.9 sec 〔Output timing〕...
Page 28: Mode No.05」Current Display Position Correction・Setting Of The Measurement Operation ・25
Mode No. Current display position correction・setting of the measurement operation ＡＢＣＤＥＦＰ－０５Ｐ－０５ＧＨＩＪＫＬ００ Measurement operation 0：The usual measuremen 1：Measurement, only while a control signal is outputting.
Page 29 Mode No. Setting of total display scaling data ＡＢＣＤＥＦＰ－０７Ｐ－０７ＧＨＩＪＫＬ１０００３－ｎＥＸＰ-value 10 ｎ＝0～9 Converted value 0001～9999 （Do not set 0000） With input of this converter and EXP-value, it is possible to set the magnification per 1 pulse.
Page 30 Mode No. Setting of analog input scaling data （A2-type）ＡＢＣＤＥＦＰ－０９Ｐ－０９ＧＨＩＪＫＬ ※A decimal point can be set up to the 3rd place. １０００． It sets to a decimal point by a Shift key, and moves a decimal point by a rise key.
Page 31 〔setting of output of Upper and lower limit〕 Please set up whether it outputs with an upper and lower limit value, it outputs by upper limit, or it outputs by a lower limit. The relation between judgment prohibition time and a deviation unusual output becomes as it is shown in the following figures.
Page 32 Mode No. Setting of deviation error (analog input) lower limit value （A2-type）ＡＢＣＤＥＦＰ－１２Ｐ－１２ＧＨＩＪＫＬ００００ Lower limit 0000～9999 （A decimal point is interlocked with a setup of P-09.）〔Setting of upper limit value〕...
Page 33: 13．Mode Protect Function・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・31
13．Mode protect function If this function is turned on, change of mode setting will be made impossible. (The up key is canceled.) The mode protect at the time of the shipment becomes OFF. Please perform the call of mode protection and the setting method by the following key operation at the time of measurement.
Page 34: 14．Setting Of Channel Value And Change・・・・・・・・・・・・・・・・・・・・・・・・32～33
14．Setting of channel value and change When you set up channel data, please operate each key as follows. Operation key Display The contents of operation is pushed. ＡＢＣＤＥＦ “SV”is displayed on A～B, and C～L becomes Ｓ...
Page 35 A setup of each channel data ＡＢＣＤＥＦＣＨ－０ＣＨＧＨＩＪＫＬ A decimal point is interlocked with the decimal ０～９００００００ point of a measurement value. Preset value（Target value）...
Page 36: 15．Setting Of Total Value And Change・・・・・・・・・・・・・・・・・・・・・・・・・・・34
15．Setting of total value and change When you set up total data, please operate each key as follows. Display The contents of operation Is pushed. ＡＢＣＤＥＦ “total” is displayed on A～E, and F～L becomes ｔｏｔＡＬＧ...
Page 37: 16．Analog Input Of Adjustment ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・35
16．Analog input of adjustment ！＜Caution＞ ※When the display of analog input voltage is adjusted, please change according to the following procedure. If a power supply is switched on pushing, it will become analog input adjustment mode. Display The contents of operation If power activation is carried out pushing this Ａ...
Page 38: 17．Communication・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・36～37
１7．Communication （RS2-type/RS4-type/RS4W-type） When RS-232C and RS-485 communication is used, please set up a baud rate, a bit, parity, ID, etc. in the modes 13 and 14. When writing in a preset value using communication, it is the setting method of SV value in the mode 00 (P.
Page 39 Meter Pin NO. Name Name ２ＲＤＳＤ（ＴｘＤ）３ＳＤＲＤ（ＲｘＤ）５ＳＧＳＧ７ＲＳＣＳ（ＣＴＳ）８ＣＳＲＳ（ＲＴＳ） Communication operation １．Checksum ①Checksum computing range （Command 1）＠ × × ＲＤ１ △ △ CR This range is object of a checksum.
Page 40 ２．Status ① The view of status Status has written the hexadecimal number by 2 bytes of character string. ② Status allotment ００ Normal communication. ０１ Communication fault. ３．Communication format Table.７ Measurement data lead Command format ＠××ＲＤ１△△CR （TOTAL） Response format ＠××◇◇±□□□□□□△△CR Measurement data lead Command format ＠××ＲＤ２△△CR...
Page 41 １8．External dimensions External dimensions Fig.２０ TOTAL P.V. S.V. Panel cut dimensions （ Unit： mm） - 38 -...
Page 42: 19．About A Noise Countermeasure ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・39
１9．About a noise coutermeasure When influence of noise occurred, please be careful about the following. When doing a blackout and a malfunction by influence of noise, please be initialized（Refer to page 17） Please take notes of the value setting of each mode. If it becomes normal, please take the following measure.
Page 43: 20．Troubleshooting・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・40
20．Troubleshooting When abnormality occurred, please check it as follows. Ｎｏ． Problem Checking point Solution Display does not ap →Has it connected with the →Connect correctly according to １ pear at all. rear terminal correctly? “Connecting terminal Is the screw tightened boards”...
Page 44 Head Office : 123-1, Kami, Nishi-ku, Sakai-city, Osaka, Japan. TEL.81-72-274-6001 FAX.81-72-274-6005 Tokyo Branch : TEL.81-3-5256-8311 FAX.81-3-5256-8312...
