- Page 1 Audfly Directional Speaker User Manual TYPE B Series Audfly Technology (Suzhou) Co., Ltd · 2022 QT-PS-PD-011(A/1)
-
Page 2: Table Of Contents
5.2 Audio Playback and Volume Adjustment ........9 5.3 Audio Playback Distance ..............9 5.4 Playback Application Solution ............. 10 5.5 Integration of Audfly speakers and Conventional Amplifier System ......................12 6. Troubleshooting .................... 13 6.1 Indicator Meanings and Troubleshooting ........ 13 6.2 Low Sound/No Sound.............. -
Page 3: Important Safety Instructions
Audfly Technology (Suzhou) Co.,Ltd 1. Important Safety Instructions Please read all documents carefully before operating the product. Please follow the instructions in this manual. Please keep this manual properly. Please disconnect the power before connecting this product. -
Page 4: Product And Model
Audfly Technology (Suzhou) Co.,Ltd 2. Product and Model TYPE B series FSC5-B1-G FSC5-B2-G Note: The suffix “G” indicates the grey guard. -
Page 5: Product Description
A virtual sound source can also be formed by reflection. Audfly speakers is able to generate highly directional and audible sound due to its unique technology. Compared with conventional speakers, Audfly directional speaker has a function of area-based playback. - Page 6 Audfly Technology (Suzhou) Co.,Ltd source Unique patented audio Low distortion, wider frequency response, supporting processing a variety of directional audio applications technology...
-
Page 7: Product Model And Parameter Information
Audfly Technology (Suzhou) Co.,Ltd 4. Product Model and Parameter Information 4.1 TYPE B Series Product model FSC5-B1-G FSC5-B2-G Maximum sound 80±3dB@2KHz 88±3dB@2KHz pressure level Directivity <15°(-20dB) <15°(-20dB) Input sensitivity 1 Vrms 1 Vrms Maximum input 2.8Vpp 2.8Vpp Frequency range 500Hz-13kHz... - Page 8 Audfly Technology (Suzhou) Co.,Ltd Supported function: external Supported function: external USB player, 2.0 standard USB player, 2.0 standard (max. 32G) (max. 32G) Supported audio file formats: Supported audio file formats: USB player MP3 and WAV MP3 and WAV Supported file system...
-
Page 9: Use
Audfly Technology (Suzhou) Co.,Ltd 5. Use 5.1 Operating Instructions for Amplifier As shown above: Note: Set the ON/OFF button in the OFF position before connecting the power supply. As shown in the figure, press the button to power on or off. If the button bounces, it means that the power supply is connected or disconnected. - Page 10 Audfly Technology (Suzhou) Co.,Ltd socket and the other end (24V DC/3A(or 2.7A) power output plug) into the power input port, as shown in the figure. Connection of the audio cable: plug one end of the 3.5mm audio cable into the audio input port of this product, and connect the other end to the mobile phone, laptop, computer, MP3, and television.
-
Page 11: Audio Playback And Volume Adjustment
5.3 Audio Playback Distance Audfly speakers has high directivity for accurate sound source positioning. In addition, sound can be reflected by the surface of an object. For the best sound effect, it is recommended to keep a distance of at least one meter between the listener and speaker during the playback and volume setting. -
Page 12: Playback Application Solution
Simulated auditory experience. Reflected sound source One unique feature of Audfly speakers is to form a virtual sound source by reflecting the transmitted sound beam via the surface of an object. Note: A main measure to suppress unnecessary reflection is to apply sound- absorbing materials on reflective surfaces. - Page 13 Audfly Technology (Suzhou) Co.,Ltd...
-
Page 14: Integration Of Audfly Speakers And Conventional Amplifier System
Audfly speakers directly or through the audio distributor. Note: Different microphones vary in terms of the working voltage, and their output voltages may exceed the allowable range of Audfly speaker’s amplifier. Because of noise differences in output signals, microphones cannot be directly connected to Audfly speaker’s amplifier. -
Page 15: Troubleshooting
Normally ON in red: if the indicator turns red, it means that this product is faulty. Please turn off this product immediately and restart it in 30s. If this product can still not work properly, please conduct Audfly or its local dealer. 6.2 Low Sound/No Sound ... -
Page 16: Warranty
The remaining warranty period of the original product applies to the new part used for replacement or the repaired product. The new product or part for replacement will be your property, while the replaced one will belong to Audfly Technology (Suzhou) Co., Ltd. - Page 17 Audfly Technology (Suzhou) Co.,Ltd reasonable means to you, and bear the freight arising therefrom. If you do not purchase this product directly from Audfly Technology (Suzhou) Co., Ltd., please contact the authorized agent, authorized dealer or authorized installation company from which you purchase this product, to understand the corresponding transportation and service terms.
-
Page 18: Disclaimer
Audfly Technology (Suzhou) Co.,Ltd 7.3 Disclaimer The warranty of Audfly Technology (Suzhou) Co., Ltd. does not apply to the loss or damage caused by the following factors: Improper installation or failure to follow the installation instructions of Audfly Technology (Suzhou) Co., Ltd.;... - Page 19 Failure to follow the standard operating procedures or instructions of Audfly Technology (Suzhou) Co., Ltd. or provide a suitable environment for use. Please use any Audfly speakers in accordance with relevant national laws and policies as well as the principles of safeguarding national interests and protecting national security.
