- Page 1 TP05 Slim-profile aluminum alloy M.2 SSD cooling kit www.silverstonetek.com...
-
Page 2: Warranty Terms And Conditions
Installation Guide / Installationsanleitung / Guide d'installation Warranty terms & conditions / G a r a n t i e b e d i n g u n g e n Términos y condiciones de la garantía /Termes et conditions de la garantie /... - Page 3 Preparation Place the thermal pad on the aluminum alloy base and remove the adhesive film. Be careful not to cover the screw mounting holes. *For single-sided particle M.2 SSD (flat back without components), please use 1.75mm pad; For double-sided particle (both sides with components), please use 0.5mm pad Platzieren Sie die Wärmefalle an der Basis aus Aluminiumlegierung und entfernen Sie die Klebefolie.
- Page 4 Preparation Insert M.2 SSD and align the mounting holes. Setzen Sie die M.2-SSD ein und richten Sie die Montagelöcher aus Insérez le SSD M.2 et alignez les trous de montage Inserte el SSD M.2 y alinee los agujeros de montaje Inserisci M.2 SSD a allinea i fori di montaggio...
- Page 5 Preparation Paste thermal pad (0.5mm) on the M.2 SSD and remove the film die Folie...
- Page 6 Preparation Align the mounting holes with the top cover of the heat sink. Apply some pressure to ensure a tight fit Richten Sie die Montagelöcher an der oberen Abdeckung des Kühlkörpers aus. Wenden Sie für eine feste Passung etwas Druck an Alignez les trous de montage avec le couvercle supérieur du dissipateur thermique.
- Page 7 Preparation Fasten a total of four screws on both sides Bringen Sie insgesamt vier Schrauben an beiden Seiten an Fixez les quatre vis des deux côtés Atornille un total de cuatro tornillos a ambos lados Serra le quattro viti su entrambi i lati...
- Page 8 Preparation Install onto motherboard Am Motherboard installieren Installez sur la carte mère Montalo sulla scheda madre...
-
