Summary of Contents for Chicago Pneumatic STG 244
- Page 1 Safety and operating instructions Trowel STG 244, 375, 479 www.cp.com...
-
Page 3: Table Of Contents
STG 244, 375, 479 Contents Contents Introduction ............................. 5 About the Safety and operating instructions ..................5 Safety instructions ..........................5 Safety signal words ..........................5 Personal precautions and qualifications ..................5 Personal protective equipment ......................5 Drugs, alcohol or medication ......................5 Operating, precautions ........................ - Page 4 Troubleshooting ............................ 24 Technical data ............................25 Machine data - STG 244 ........................25 Weights and dimensions for options - STG 244 ................25 Machine data - STG 375 ........................26 Weights and dimensions for options - STG 375 ................26 Machine data - STG 479 ........................
-
Page 5: Introduction
STG 244, 375, 479 Safety and operating instructions Introduction Safety signal words Thank you for choosing Chicago Pneumatic brand The safety signal words Danger, Warning and products. For over a century, the Chicago Caution have the following meanings: Pneumatic brand has represented performance and innovation in the pneumatic tool industry. -
Page 6: Operating, Precautions
Safety and operating instructions STG 244, 375, 479 No person who is under the influence of drugs, Never use the machine in the proximity of ► ► alcohol or medication may operate the material that can generate sparks. Remove all machine. - Page 7 STG 244, 375, 479 Safety and operating instructions created by the use of the machine and the on advice from health and safety experts. potential for disturbing existing dust. Consult with experts. Use proper engineering controls to minimize ► DANGER Exhaust gas hazard...
- Page 8 Safety and operating instructions STG 244, 375, 479 WARNING Vibration hazards WARNING Trapping hazard Normal and proper use of the machine exposes There is a risk of neck ware, hair, gloves, and the operator to vibration. Regular and frequent clothes getting dragged into or caught by rotating exposure to vibration may cause, contribute to, or machine parts.
-
Page 9: Transport, Precautions
STG 244, 375, 479 Safety and operating instructions If the machine has a silencer, check that it is in Wait until the engine, exhaust pipe, and ► ► place and in good working condition. bottom of the machine have cooled down before carrying out maintenance work. -
Page 10: Overview
Design and function STG 244, STG 375 and STG 479 are intended to be used for finishing newly cast concrete surfaces. The concrete surface can be power floated with a K. Spark plug floating disc or floating blades and power L. -
Page 11: Instruction Manual Label
STG 244, 375, 479 Safety and operating instructions Instruction manual label Tilted position label WARNING Tilted position Gekippte lage The operator must read the safety, operation and maintenance instructions before operating the Cutting hazard label machine. Lifting point label Safety label SKIVA DEMONTERAS FÖRE KRANLYFT. -
Page 12: Installation
Safety and operating instructions STG 244, 375, 479 2. Fold the upper handle to its lowest position Check the machine's data plate for weight ► during transport. information. Lifting the machine 1. Always use the machine's lifting eye (A) to lift the machine. -
Page 13: Fitting And Removing The Trowel Blades
STG 244, 375, 479 Safety and operating instructions STG 375/479 4. Never overfill the tank. Due to the movement 1. Lean the trowel forwards so it rests on the of the fuel within the tank, it is possible to have support frame. -
Page 14: Operating Near Edges
Safety and operating instructions STG 244, 375, 479 Operating near edges WARNING Overturning hazard When operating along edges, at least two thirds of the machine must be on a surface with full bearing strength, otherwise the machine can tip over. -
Page 15: Stopping The Engine
STG 244, 375, 479 Safety and operating instructions the engine speed with the throttle control (B) on the left side while keeping the operating handle in a firm grip. 4. Turn the switch (D) to ON. 8. Push the clutch handle (G) on the right side until it reaches the operating handle. -
Page 16: Operating
Safety and operating instructions STG 244, 375, 479 Finishing When starting the finishing operation, never set the trowels up over 1/4" pitch. Best results are obtained by letting the machine move right or left, backwards or forwards, approximately 4" with each revolution of the trowels. -
Page 17: Adjusting The Blade Angle
STG 244, 375, 479 Safety and operating instructions ◆ To decrease the blade angle, turn the twist pitch knob counterclockwise. ◆ Move forward: Press down the right side of the handle and lift the left side of the handle in one movement to move the trowel forward. -
Page 18: Maintenance
Safety and operating instructions STG 244, 375, 479 Maintenance Every 10 hours of operation (daily) Regular maintenance is a basic requirement for the continued safe and efficient use of the machine. Maintenance routines: Follow the maintenance instructions carefully. ◆ Check and replenish the fuel. -
Page 19: After The First 20 Hours Of Operation
STG 244, 375, 479 Safety and operating instructions 6. Fill with oil (C). 7. Refit the dipstick (D). 8. Start the engine and allow the engine to idle a few minutes before increasing to full power. Every 200 hours of... -
Page 20: Checking Spark Plug
Check, clean and replace the spark plug. 2. Clean engine cooling flanges (B). 3. Adjust the engine's valve (C) clearance. Cleaning the blade shafts - STG 244 Every 500 hours of Disassemble the blade shafts from the hub and operation (or yearly) clean the parts carefully. -
Page 21: Cleaning The Blade Shafts - Stg 375/479
STG 244, 375, 479 Safety and operating instructions Cleaning the pressure plate Check the status of the lubrication of the bearings. Use the same grease as for the shafts. 1. Loosen and remove the screw (A) and the washer (B). - Page 22 14. Attach the clutch wire conduit to the protective ring by winding the nuts (K). 15. Engage clutch wire by winding the screw (H). Tightening torque (STG 244/375): 0.55 Nm. Tightening torque (STG 475): 0.9 Nm. 16. Refit the spring (G).
-
Page 23: Storage
STG 244, 375, 479 Safety and operating instructions Storage Clean the machine properly before storage, in • order to avoid hazardous substances. See “Dust and fume hazard”. If the machine is stored in the service position, • the fuel tank must not be filled more than half full. -
Page 24: Troubleshooting
Safety and operating instructions STG 244, 375, 479 Troubleshooting Problem Cause Solution The trowel does not start. Start switch in off position. Turn the switch on. Fuel cock off. Open the fuel cock. Fuel tank empty. Fill up the tank. -
Page 25: Technical Data
Synthetic Mobil SHC 634 Weights Net weight, kg (lbs) 58 (128) Operating weight, kg (lbs) 60 (132) Weights and dimensions for options - STG 244 STG 244 Floating disc, kg (lbs) 2 (4.4) Floating disc, mm (in.) 610 (24) Trowel blades, four units, kg (lbs) 9 (19.8) -
Page 26: Machine Data - Stg 375
Safety and operating instructions STG 244, 375, 479 Machine data - STG 375 STG 375 F TP STG 375 F QP Engine Manufacture/Type Honda GX 160, 4-stroke, manual start. Honda GX 160, 4-stroke, manual start. Power, kW (hp) 3.6 (4.8) @ 3.600 rpm 3.6 (4.8) @ 3.600 rpm... -
Page 27: Machine Data - Stg 479
STG 244, 375, 479 Safety and operating instructions Machine data - STG 479 STG 479 F TP STG 479 F QP Engine Manufacture/Type Honda GX 270, 4-stroke, manual start. Honda GX 270, 4-stroke, manual start. Power, kW (hp) 6.3 (8.4) @ 3.600 rpm 6.3 (8.4) @ 3.600 rpm... -
Page 28: Noise And Vibration Declaration Statement
Safety and operating instructions STG 244, 375, 479 Noise and vibration declaration statement Guaranteed sound power level Lw according to EN ISO 3744 in accordance with directive 2000/14/EC. Sound pressure level Lp according to EN ISO 11201, EN 500-4. Vibration value determined according to EN 500-4. See table ”Noise and vibration data” for the values etc. -
Page 29: Dimensions
STG 244, 375, 479 Safety and operating instructions Dimensions STG 244 mm (in.) 1485 (58.46) 730 (28.74) 610 (24.02) 843 (33.18) 9800 1838 01 | Original instructions... - Page 30 Safety and operating instructions STG 244, 375, 479 STG 375 mm (in.) 1985 (78.15) 791 (31.14) 950 (37.40) 1169 (46.02) 9800 1838 01 | Original instructions...
- Page 31 STG 244, 375, 479 Safety and operating instructions STG 479 mm (in.) 2217 (87.28) 791 (31.14) 1200 (47.24) 1374 (54.10) 9800 1838 01 | Original instructions...
-
Page 32: Ec Declaration Of Conformity
Safety and operating instructions STG 244, 375, 479 EC Declaration of Conformity EC Declaration of Conformity (EC Directive 2006/42/EC) We, Construction Tools EOOD, hereby declare that the machines listed below conform to the provisions of EC Directive 2006/42/EC (Machinery Directive) and 2000/14/EC (Noise Directive), and the harmonised standards mentioned below. - Page 36 2017-01-23 | No. 9800 1838 01 © Construction Tools EOOD...
