OPERATION
IF THIS HEATER IS NOT PROPERLY INSTALLED, A HOUSE FIRE MAY RESULT. FOR YOUR
SAFETY, FOLLOW THE INSTLALATION INSTRCUTIONS. CONTACT THE AUTHORITY HAVING
JURISIDCTION (SUCH AS MUNICIPAL BUILDING DEPARTMENT, FIRE DEPARTMENT, FIRE
PREVATION BUREAU, ETC.) CONSULT BEFORE INSTALLATION TO DETERMINE THE NEED TO
OBTAIN A PERMIT. KEEP THESE INSTRUCTIONS FOR FUTURE USE.
TESTED AND LISTED BY:
200 ETHAN ALLEN DRIVE
P.O. BOX 69
SPRUCE PINE, NC 28777
www.buckstove.com
(828) 765-6144
READ AND KEEP THIS MANUAL FOR REFERENCE
HOMESTEADER COOKSTOVE
FREESTANDING UNIT
PREPARATIONS
SAFETY NOTICE
FEATURES
INSTALLATION
MAINTENACE
PFS/TECO, COTTAGE GROVE, WI
MANUFACTURED BY NEW BUCK CORPORATION
TESTED TO: ANSI / UL1482-REV 7 & CAN/ULC-S627
1
SAFETY
REVISED JUNE 2023
Advertisement
Table of Contents
Summary of Contents for BuckMaster HOMESTEADER
- Page 1 READ AND KEEP THIS MANUAL FOR REFERENCE HOMESTEADER COOKSTOVE FREESTANDING UNIT FEATURES PREPARATIONS INSTALLATION OPERATION MAINTENACE SAFETY SAFETY NOTICE IF THIS HEATER IS NOT PROPERLY INSTALLED, A HOUSE FIRE MAY RESULT. FOR YOUR SAFETY, FOLLOW THE INSTLALATION INSTRCUTIONS. CONTACT THE AUTHORITY HAVING JURISIDCTION (SUCH AS MUNICIPAL BUILDING DEPARTMENT, FIRE DEPARTMENT, FIRE PREVATION BUREAU, ETC.) CONSULT BEFORE INSTALLATION TO DETERMINE THE NEED TO...
-
Page 3: Table Of Contents
Table of Contents Caution & Warnings ..........................4 Installing the Floor Protector ........................5 Standard Installation Clearances ......................6 Chimney Connections ..........................7 Chimney Requirements & Masonry Chimneys & Fireplaces ............8 Chimney Height & Stove Dimensions ....................9 Cooking & Fueling Suggestions ......................10 Ventilation, Ash &... -
Page 4: Caution & Warnings
Cautions & Warnings Please read this entire manual before you install or use your new stove. Failure to follow • instructions may result in property damage, bodily injury, or even death. Use only solid wood fuel, dry seasoned cord wood is the preferred fuel. •... -
Page 5: Installing The Floor Protector
Installing the Floor Protector The stove must be placed on a non-combustible floor protector with an R-value of 3 or greater. For multiple layers, add R-values of each layer to determine the overall R-value. In the USA, the floor protector must extend 8”(200mm) beyond each side of the flue loading door and 16”(400mm) to the front. -
Page 6: Standard Installation Clearances
Standard Installation Clearances One of the main necessary precautions when installing a wood stove is to leave sufficient space between the stove (top, sides, back, front, and under stove pipes) and any other material that can catch fire. It is extremely important that you abide by required installation distances and that you abide by local installation regulations. -
Page 7: Chimney Connections
The chimney connector is a single walled pipe used to connect the stove to the chimney. For use with the Homesteader Cookstove the chimney connector must be 6” (150mm) in diameter, with a minimum thickness of 24-gauge black or blued steel. The chimney connector must be suitable for solid fuel, in good condition, and kept clean. -
Page 8: Chimney Requirements & Masonry Chimneys & Fireplaces
Chimney Requirements DO NOT CONNECT THIS UNIT TO A CHIMNEY FLUE SERVING ANOTHER APPLIANCE. DO NOT CONNECT TO ANY AIR DISTRIBUTION DUCT OR SYSTEM This stove must be connect to a 6” (150mm) factory built UL 103 HT chimney (ULC S629), in Canada or a code—approved masonry chimney with a flue liner. -
Page 9: Chimney Height & Stove Dimensions
Chimney Height The connected chimney must be the required height above the roof and any other nearby obstructions. The chimney must be at least 3’ (900mm) higher than the highest point where it passes through the roof and at least 2’ (600mm) higher than the highest part of the roof or structure that is within 10’... -
Page 10: Cooking & Fueling Suggestions
Cooking The Homesteader Cookstove has the firebox at the bottom and the oven above. Heat is directed around the over by closing the middle damper located on the side of the stove. Before lighting your Homesteader Cookstove ensure that the damper control is properly located so that it closes. -
Page 11: Ventilation, Ash & Creosote Removal
Ventilation Suggestions It is important to note that wood combustion consumes ambient oxygen in the room. In the case of negative pressure, it is a good idea to allow fresh air in the room, either by opening a window slightly or by installing a fresh air intake system on an outside wall. DO NOT ALTER THE DAMPER ADJUSTMENT RANGE TO INCREASE THE FIRING FOR ANY REASON!!! Maintenance Disposal of Ashes... -
Page 12: Inspection And Cleaning & Glass Replacement
Apart from removing creosote buildup within the appliance, the only other maintenance required for the Homesteader cookstove is to ensure that the door assembly components are well maintained. The glass on the firebox and oven door can be cleaned with steel wool and water. It is not advisable to use a cleaner that contains caustic and abrasive cleaners. -
Page 13: Warranty Information
NEW BUCK CORPORATION (NBC) "LIMITED WARRANTY" FOR THE BUCK STOVE PLEASE READ THIS WARRANTY CAREFULLY PRODUCTS COVERED This warranty covers the new Buck Stove heating unit, so long as it is owned by the original purchaser, including optional and standard accessories purchased at the same time, subject to terms, limitations, and conditions herein set out. - Page 14 If for any reason you are dissatisfied with the suggested procedures, you may contact us in writing at: New Buck Corporation Customer Service Department P. O. Box 69 Spruce Pine, NC 28777 Email: info@buckstove.com CONDITIONS AND EXCLUSIONS Replacement of parts may be in the form of new or fully reconditioned parts, at NBC's option. There is no other express warranty.
-
Page 15: Product Registration
To be completed by selling distributor / dealer / customer: Name ____________________________________________________________________ (Last) (First) Address____________________________________________________________________ City__________________________ State_______________ Zip_____________________ Customer Email______________________________________________________________ Homesteader Cookstove Serial Number ____________________________________________ Installation Date: Day__________ Month___________ Year______________ Installer’s Name______________________________________________________________ Installer’s Certification Number__________________________________________________ Dealer’s Name_______________________________________________________________ City___________________________ State_________________ Zip___________________...
