Pro-Tech SP-655-R Series User Manual

8.4”/10.4”/15”/17” intel celeron n3350 / j3455 processor flat aluminum panel pc
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER
MANUAL
SP-6558-R/SP-6550-R/SP-6555-R/SP-6557-R M1
SP-655X-R
8.4"/10.4"/15"/17" Intel
N3350 / J3455 Processor
Flat Aluminum Panel PC
Celeron
®
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SP-655-R Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Pro-Tech SP-655-R Series

  • Page 1 USER MANUAL SP-655X-R 8.4”/10.4”/15”/17” Intel Celeron ® ® N3350 / J3455 Processor Flat Aluminum Panel PC SP-6558-R/SP-6550-R/SP-6555-R/SP-6557-R M1...
  • Page 2 SP-6558-R / SP-6550-R / SP-6555-R / SP-6557-R ® ® 8.4”/10.4”/15”/17” Intel Celeron N3350 / J3455 Processor Flat Aluminum Panel PC COPYRIGHT NOTICE & TRADEMARK All trademarks and registered trademarks mentioned herein are the property of their respective owners. This manual is copyrighted in Dec. 2021. You may not reproduce or transmit in any form or by any means, electronic, or mechanical, including photocopying and recording.
  • Page 3 FCC NOTICE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 4: Table Of Contents

    Contents Revision History .................... vi Introduction ..................1-1 About This Manual ..............1-2 Getting Started ..................2-1 Package List ................2-2 System Overview ..............2-3 System Specifications ............. 2-17 Safety Precautions ..............2-19 System Configuration ................. 3-1 External I/O Ports Diagrams ............. 3-2 3.1.1 SP-655X-R Bottom I/O Ports Diagram ......
  • Page 5 3.5.7 USB 3.0 PORT (USB2) ........... 3-14 3.5.8 USB 2.0 PORT (USB3) ........... 3-15 3.5.9 Programmable GPIO PIN HEADER ........ 3-15 3.5.10 I2C WAFER ..............3-15 3.5.11 MCU FW Rewrite Connector ........... 3-16 3.5.12 SYSTEM FAN CONNECTOR ......... 3-16 3.5.13 DC POWER INPUT CONNECTOR .........
  • Page 6 Installing Sound Driver Utility ............ 4-9 ® Installing Intel Serial I/O Driver Utility ........4-10 ® Installing Intel Thermal Analysis Tool ........4-11 Microsoft Hotfix KB3211320 and KB3213986 Driver Installation ....................4-12 BIOS SETUP ..................5-1 Introduction ................5-2 Accessing Setup Utility ..............
  • Page 7 Configuration ..............5-25 5.4.7.4 F81964 Super IO Configuration – Serial Port 4 Configuration ..............5-26 5.4.8 Advanced – USB Configuration ........5-27 5.4.9 Advanced – Platform Trust Technology ......5-28 Chipset ..................5-29 5.5.1 Chipset – North Bridge ............ 5-30 5.5.2 Chipset –...
  • Page 8 SP-6558-R System Exploded Diagram (PoE SKU) .......A-17 SP-6558-R Panel Module Exploded Diagram (PoE SKU) .....A-18 SP-6555-R System Exploded Diagram (Normal SKU) ......A-20 SP-6555-R Panel Module Exploded Diagram (Normal SKU) ....A-21 SP-6555-R System Exploded Diagram (PoE SKU) .......A-23 SP-6555-R Panel Module Exploded Diagram (PoE SKU) .....A-24 SP-6557-R System Exploded Diagram (Normal SKU) ......A-26 SP-6557-R Panel Module Exploded Diagram (Normal SKU) ....A-27 SP-6557-R System Exploded Diagram (PoE SKU) .......A-29...

  • Page 9: Revision History

    Revision History The revision history of SP-6558-R / SP-6550-R / SP-6555-R / SP-6557-R User Manual is described below: Version No. Revision History Date Initial Release 2021/12/30...

  • Page 10: Introduction

    Introduction This chapter provides the introduction for SP-6558-R / SP-6550-R / SP-6555-R / SP-6557-R system as well as the framework of the user manual. The following topic is included: • About This Manual SP-655X-R USER MANUAL Page: 1-1...

  • Page 11: About This Manual

    Chapter 1 Introduction 1.1 About This Manual Thank you for purchasing our SP-6558-R / SP-6550-R / SP-6555-R / SP-6557-R system. The SP-6558-R / SP-6550-R / SP-6555-R / SP-6557-R system is an updated system designed to be comparable with the highest performance of IBM AT personal computers.

  • Page 12: Getting Started

    Getting Started This chapter provides the information for SP-6558-R / SP-6550-R / SP-6555-R / SP-6557-R system. It describes how to set up the system quickly and outlines the system specifications. The following topics are included: • Package List • System Overview •...

  • Page 13: Package List

    Chapter 2 Getting Started 2.1 Package List If you discover any of the items listed below are damaged or lost, please contact your local distributor immediately. Item Q’ty SP-6558-R / SP-6550-R / SP-6555-R / SP-6557-R System Manual / Driver DVD Quick Guide SP-655X-R USER MANUAL Page: 2-2...

  • Page 14: System Overview

    Chapter 2 Getting Started 2.2 System Overview Unit: mm SP-6558-R and SP-6550-R Front View 260.12 (SP-6550-R) 224.83 (SP-6558-R) SP-6558-R Rear View C.L.75 (VESA) SP-655X-R USER MANUAL Page: 2-3...
  • Page 15 Chapter 2 Getting Started Unit: mm SP-6550-R Rear View C.L.75 (VESA) SP-6558-R Side View SP-655X-R USER MANUAL Page: 2-4...
  • Page 16 Chapter 2 Getting Started Unit: mm SP-6550-R Side View SP-6558-R Top View (Normal SKU) 217.5 ANT3 ANT4 ANT1 ANT2 (option) (option) COM3 COM2 USB2.0 COM4 SP-655X-R USER MANUAL Page: 2-5...
  • Page 17 Chapter 2 Getting Started Unit: mm SP-6558-R Top View (PoE SKU) 217.5 DIO or COM2 COM3 COM4 LAN4 LAN3 SP-6550-R Top View (Normal SKU) 249.6 217.5 ANT1 ANT4 ANT2 ANT3 (option) (option) COM3 COM2 COM4 USB2.0 SP-655X-R USER MANUAL Page: 2-6...
  • Page 18 Chapter 2 Getting Started Unit: mm SP-6550-R Top View (PoE SKU) 249.6 217.5 COM3 DIO or COM2 COM4 LAN3 LAN4 SP-6558-R Bottom View HDMI COM1 Power DC IN LAN2/ Line Out Button (12/24V) LAN1 LAN2 LAN1 HDMI Extended Remote Switch Connector Power LED DC IN (12/24V)
  • Page 19 Chapter 2 Getting Started SP-6550-R Bottom View HDMI COM1 Power DC IN LAN2/ Line Out Button (12/24V) LAN1 LAN2 LAN1 HDMI Extended Remote Switch Connector Power LED COM1 DC IN (12/24V) Ext. PWR SW Quarter View (Normal SKU) SP-655X-R USER MANUAL Page: 2-8...
  • Page 20 Chapter 2 Getting Started Quarter View (PoE SKU) SP-655X-R USER MANUAL Page: 2-9...
  • Page 21 Chapter 2 Getting Started SP-6555-R and SP-6557-R Unit: mm SP-6555-R Front View 365.28 SP-6557-R Front View 395.75 SP-655X-R USER MANUAL Page: 2-10...
  • Page 22 Chapter 2 Getting Started Unit: mm SP-6555-R Rear View C.L.75 (VESA) SP-6557-R Rear View C.L.75 (VESA) SP-655X-R USER MANUAL Page: 2-11...
  • Page 23 Chapter 2 Getting Started Unit: mm SP-6555-R Side View 75.08 SP-655X-R USER MANUAL Page: 2-12...
  • Page 24 Chapter 2 Getting Started Unit: mm SP-6557-R Side View Top View (Normal SKU) 357.5 (SP-6555-R) 387.5 (SP-6557-R) 217.5 (option) ANT3 ANT4 ANT1 ANT2 (option) (option) COM2 COM3 (option) USB2.0 COM4 SP-655X-R USER MANUAL Page: 2-13...
  • Page 25 Chapter 2 Getting Started Unit: mm Top View (PoE SKU) COM3 COM4 LAN3 LAN4 DIO or COM2 DIO or COM2 COM3 COM4 LAN3 LAN4 SP6555-R Bottom View HDMI Line Out DC IN (12/24V) LAN2/ Power LAN1 Button COM1 LAN2 LAN1 HDMI Extended Remote Switch Connector...
  • Page 26 Chapter 2 Getting Started SP6557-R Bottom View HDMI DC IN Line Out (12/24V) LAN2/ Power LAN1 Button COM1 LAN2 LAN1 HDMI Extended Remote Switch Connector Power LED DC IN (12/24V) COM1 Ext. PWR SW Quarter View (Normal SKU) SP-655X-R USER MANUAL Page: 2-15...
  • Page 27 Chapter 2 Getting Started Quarter View (PoE SKU) SP-655X-R USER MANUAL Page: 2-16...

  • Page 28: System Specifications

    Chapter 2 Getting Started 2.3 System Specifications System CPU Type ® ®  Intel Celeron J3455: 10w, 4C, 2.3GHz ® ®  Intel Celeron N3350: 6w, 2C, 2.4GHz  1 x SO-DIMM socket, supporting 1600/1866 DDR3L Memory Support DRAM up to 8GB (non-ECC) ...
  • Page 29 Chapter 2 Getting Started I/O Ports (Bottom Side)  4 x USB 3.0 Sound  1 x Line Out  2 x GbE LAN (support Wake-On-LAN) ® LAN1 & 2: Intel I210AT Serial Port  COM1: RS-232 Power Input  3-pin DC In terminal block (lockable) Power On / Off ...

  • Page 30: Safety Precautions

    Chapter 2 Getting Started 2.4 Safety Precautions Before operating this system, read the following information carefully to protect your systems from damages, and extend the life cycle of the system. Check the Line Voltage • The operating voltage for the power supply should be 12V, 19V or 24V DC; otherwise, the system may be damaged.

  • Page 31: System Configuration

    System Configuration This chapter contains helpful information about the jumper & connector settings, and component locations for the main board. The following topics are included: • External I/O Ports Diagrams • Connector & Jumper Quick Reference Table • System Main Board Component Locations •...

  • Page 32: External I/O Ports Diagrams

    Chapter 3 System Configuration 3.1 External I/O Ports Diagrams 3.1.1 SP-655X-R Bottom I/O Ports Diagram DC IN (12/24V) LAN2/ HDMI Power LAN1 COM1 Button Line Out Extended LAN2 LAN1 HDMI Remote Switch Connector Power LED DC IN (12/24V) COM1 Ext. PWR SW 3.1.2 SP-655X-R Top I/O Ports Diagram (Normal SKU) USB 2.0 COM3...

  • Page 33: Jumper & Connector Quick Reference Table

    Chapter 3 System Configuration 3.2 Jumper & Connector Quick Reference Table 3.2 Jumper & Connector Quick Reference Table JUMPER Description NAME COM3 Pin9 RI/5V/12V Selection JP_COM3 COM4 Pin9 RI/5V/12V Selection JP_COM4 LVDS VCC Voltage Selection JP_VDD1 USB Power Source Selection JP_USBSW1 Clear CMOS Data Selection LVDS Backlight Control Selection...

  • Page 34: Component Locations Of System Main Board

    Chapter 3 System Configuration 3.3 Component Locations Of System Main Board 3.3.1 Top View of System Main Board VGA1 LAN2 LAN1 HDMI1 USB2 USB1 JP_COM3 JP_COM4 COM4 JLPC1 JI2C1 JP_USBSW1 JMCU1 COM3 JDIO1 COM2 SATA_PWR1 M_SATA1 COM1 SO_DIMM1 JFP1 M_PCIE1 AUDIO1 PWR2 LVDS1...
  • Page 35 Chapter 3 System Configuration WARNING: Always disconnect the power cord when you are working with connectors and jumpers on the main board. Make sure both the system and peripheral devices are turned OFF as sudden surge of power could damage sensitive components.

  • Page 36: Bottom View Of System Main Board

    Chapter 3 System Configuration 3.3.2 Bottom View of System Main Board Figure 3-2 Main Board Component Location (Rear View) SP-655X-R USER MANUAL Page: 3-6...

  • Page 37: How To Set Jumpers

    Chapter 3 System Configuration 3.4 How To Set Jumpers You can configure your board by setting the jumpers. A jumper consists of two or three metal pins with a plastic base mounted on the card. By using a small plastic "cap", also known as the jumper cap (with a metal contact inside), you are able to connect the pins.
  • Page 38 Chapter 3 System Configuration Jumper diagrams Jumper settings SP-655X-R USER MANUAL Page: 3-8...

  • Page 39: Setting Main Board Connectors And Jumpers

    Chapter 3 System Configuration 3.5 Setting Main Board Connectors and Jumpers 3.5.1 COM3 and COM4 PIN9 Definition Selection Guide JP_COM3, JP_COM4: COM3 and COM4 Port pin9 RI/5V/12V Selection SELECTION JUMPER SETTING JUMPER ILLUSTRATION (Default Setting) JP_COM3 JP_COM4 +12V JP_COM3 JP_COM4 JP_COM4 JP_COM3 SP-655X-R USER MANUAL...

  • Page 40: Com Port

    Chapter 3 System Configuration 3.5.2 COM PORT COM1 (RS-232) Connector Pin Assignment: ASSIGNMENT ASSIGNMENT COM1_DCD COM1_DSR COM1_RX COM1_RTS COM1_TX COM1_CTS COM1_DTR COM1_RI COM2 (RS-232) Connector Pin Assignment: COM1/ ASSIGNMENT ASSIGNMENT COM2_DCD COM2_DSR COM2 COM2_RX COM2_RTS COM2_TX COM2_CTS COM2_DTR COM2_RI COM2 (RS-422) Connector Pin Assignment: ASSIGNMENT ASSIGNMENT COM2 (RS-485) Connector Pin Assignment:...
  • Page 41 Chapter 3 System Configuration COM3 (RS-232) Connector Pin Assignment: ASSIGNMENT ASSIGNMENT COM3_DCD COM3_DSR COM3_RX COM3_RTS COM3_TX COM3_CTS COM3_DTR COM3_RI_SEL COM3/ COM4 (RS-232) Connector Pin Assignment: ASSIGNMENT ASSIGNMENT COM4 COM4_DCD COM4_DSR COM4_RX COM4_RTS COM4_TX COM4_CTS COM4_DTR COM4_RI_SEL Note: COM3, COM4: Pin 9 is selectable for RI, +5V or +12V by jumper setting. Default setting is RI, please see “COM3 and COM4 PIN9 Definition Selection Guide”...

  • Page 42: Vga Port

    Chapter 3 System Configuration 3.5.3 VGA PORT VGA1: VGA Port, D-Sub 15-pin (I/O port) VGA1 PIN ASSIGNMENT PIN ASSIGNMENT PIN ASSIGNMENT CRT_RED CRT_GREEN CRT_DATA CRT_BLUE CRT_HSYNC CRT_VCC CRT_VSYNC CRT_CLK 3.5.4 HDMI PORT HDMI1: HDMI Port Connector ASSIGNMENT ASSIGNMENT HOT_PLUG_DET I2C_DATA I2C_CLK CLK- CLK+...

  • Page 43: Lan Port

    Chapter 3 System Configuration 3.5.5 LAN PORT LAN1 and LAN2: LAN RJ-45 Port (rear I/O) LAN1 / LAN2 LAN1 Pin Assignment LAN2 Pin Assignment PIN ASSIGNMENT PIN ASSIGNMENT LAN1_MDIP0 LAN2_MDIP0 LAN1_MDIN0 LAN2_MDIN0 LAN1_MDIP1 LAN2_MDIP1 LAN1_MDIP2 LAN2_MDIP2 LAN1_MDIN2 LAN2_MDIN2 LAN1_MDIN1 LAN2_MDIN1 LAN1_MDIP3 LAN2_MDIP3 LAN1_MDIN3...

  • Page 44: Dual Usb 3.0 Port (Usb1)

    Chapter 3 System Configuration 3.5.6 Dual USB 3.0 PORT (USB1) USB1: USB 3.0 port x 2 USB 3.0 signals PIN ASSIGNMENT PIN ASSIGNMENT USB3_RXN2 USB3_RXP2 USB2_P2_DP USB3_TXN2 USB2_P2_DN USB3_TXP2 VCC5_USB1 USB3_RXN1 USB3_RXP1 USB1 USB2_P1_DP USB3_TXN1 USB2_P1_DN USB3_TXP1 VCC5_USB1 3.5.7 USB 3.0 PORT (USB2) USB2: USB 3.0 port x 2 USB 3.0 signals PIN ASSIGNMENT...

  • Page 45: Usb 2.0 Port (Usb3)

    Chapter 3 System Configuration 3.5.8 USB 2.0 PORT (USB3) USB3: Internal USB 2.0 Port x 2 USB 2.0 signals PIN ASSIGNMENT PIN ASSIGNMENT VCC5_USB3 VCC5_USB3 USB2_P5_DN USB2_P6_DN USB2_P5_DP USB2_P6_DP USB3 3.5.9 Programmable GPIO PIN HEADER JDIO1: GPIO pin header and 5V power. PIN ASSIGNMENT PIN ASSIGNMENT VCC5...

  • Page 46: Mcu Fw Rewrite Connector

    Chapter 3 System Configuration 3.5.11 MCU FW Rewrite Connector JMCU1: MCU FW Rewrite Connector PIN ASSIGNMENT MCU_5VSB JMCU1 MCU_SPD MCU_SPC 3.5.12 SYSTEM FAN CONNECTOR FAN1: System Fan Connector PIN ASSIGNMENT VCC12 SYSFANIN FAN1 SYSFANOUT Notes: Fan speed mode can be set by BIOS or API. Default BIOS setting is “Auto Duty-Cycle Mode”.

  • Page 47: Mini Pci Express Slot

    Chapter 3 System Configuration 3.5.14 MINI PCI EXPRESS SLOT M_PCIE1: Mini PCI Express Slot ASSIGNMENT ASSIGNMENT PCIE_WAKEJ V3P3S Reserved Reserved VCC1_5 M_CLKREQJ Reserved Reserved M_PCIE_CLKN Reserved M_PCIE_CLKP Reserved Reserved Reserved Reserved Reserved PMU_PLTRST_N PCIE_P2_RXN V3_3SB PCIE_P2_RXP VCC1_5 M_PCIE1 SMB_3P3_SCL PCIE_P2_TXN SMB_3P3_SDA PCIE_P2_TXP USB2_P7_DN...

  • Page 48: Msata Connector

    Chapter 3 System Configuration 3.5.15 mSATA Connector M_SATA1: mSATA Slot (USB type mPCIe card is supported.) ASSIGNMENT ASSIGNMENT V3P3S_MSATA SATA_RXP1 V3P3S_MSATA SATA_RXN1 SATA_TXN1 M_SATA1 SATA_TXP1 USB2_P0_DN USB2_P0_DP V3P3S_MSATA V3P3S_MSATA V3P3S_MSATA SP-655X-R USER MANUAL Page: 3-18...

  • Page 49: Lvds Connector

    Chapter 3 System Configuration 3.5.16 LVDS CONNECTOR LVDS1: LVDS Connector ASSIGNMENT ASSIGNMENT LVDS_VCC LVDS_CLKB_DP LVDS_CLKB_DN LVDS_B2_DN LVDS_B2_DP LVDS_B1_DP LVDS_B1_DN LVDS1 LVDS_B3_DN LVDS_B3_DP LVDS_B0_DN LVDS_B0_DP LVDS_CLKA_DP LVDS_CLKA_DN LVDS_A2_DN LVDS_A2_DP LVDS_A1_DP LVDS_A1_DN LVDS_A0_DN LVDS_A0_DP LVDS_A3_DN LVDS_A3_DP LVDS_VCC LVDS_VCC SP-655X-R USER MANUAL Page: 3-19...

  • Page 50: Slide Switch For Lvds Resolution Selection

    Chapter 3 System Configuration 3.5.17 SLIDE SWITCH FOR LVDS RESOLUTION SELECTION Jumper Name: SW1 Description: Slide Switch for LVDS Resolution/Channel/Color Bit Selection SELECTION SETTING 800 x 600 1CH/18bit (Default Setting for SP-6558-R) 1024 x 768 1CH/18bit (Default Setting for SP-6550-R & SP-6555-R) 1024 x 768 1CH/24bit...
  • Page 51 Chapter 3 System Configuration SELECTION SETTING 1280 x 960 1CH/18bit 1280 x 1024 2CH/24bit (Default Setting for SP-6557-R) 1366 x 768 1CH/18bit 1366 x 768 1CH/24bit 1440 x 900 2CH/24bit (continued on the next page) SP-655X-R USER MANUAL Page: 3-21...
  • Page 52 Chapter 3 System Configuration 1400 x 1050 2CH/24bit 1600 x 900 2CH/24bit 1680 x 1050 2CH/24bit 1600 x 1200 2CH/24bit 1920 x 1080 2CH/24bit 1920 x 1200 2CH/24bit SP-655X-R USER MANUAL Page: 3-22...

  • Page 53: Front Panel Connector

    Chapter 3 System Configuration 3.5.18 FRONT PANEL CONNECTOR JFP1: Front Panel Connector ASSIGNMENT ASSIGNMENT HDD LED+ POWER LED+ HDD LED- RESET BTN JFP1 POWER BTN 3.5.19 HD AUDIO CONNECTOR AUDIO1: HD Audio Connector for Line In/Line Out/Mic In. ASSIGNMENT ASSIGNMENT LINE-OUT-L LINE-OUT-L HD_GND...

  • Page 54: Panel Inverter Connector

    Chapter 3 System Configuration 3.5.20 PANEL INVERTER CONNECTOR JINV1: Panel Inverter Connector ASSIGNMENT VCC12 VCC12 LVDS_BKLCTL JINV1 LVDS_BKLTEN 3.5.21 SATA 3.0 CONNECTOR SATA1: Serial ATA 3.0 Connector ASSIGNMENT SATA_TXP0 SATA_TXN0 SATA_RXN0 SATA1 SATA_RXP0 3.5.22 SATA Power CONNECTOR SATA_PWR1: Serial ATA Power Connector ASSIGNMENT VCC5 SATA_PWR1...

  • Page 55: Bios Reset Connector

    Chapter 3 System Configuration 3.5.23 BIOS RESET CONNECTOR JP9: BIOS Reset Usage Connector This connector is only for Protech's engineers. (Purpose: BIOS reset). Please do not use this connector; otherwise, the system might be crashed. 3.5.24 LVDS BACKLIGHT CONTROL SELECTION Jumper Name: JP7 Description: Jumper for selecting PIN4 (LVDS_BKLCTL) voltage of JINV1.

  • Page 56: Lvds Vcc Voltage Selection

    Chapter 3 System Configuration 3.5.25 LVDS VCC VOLTAGE SELECTION Jumper Name: JP_VDD1 Description: Voltage selection jumper for selecting PIN1, PIN29, PIN30 (LVDS_VCC) voltage of LVDS1. JUMPTER SELECTION JUMPER ILLUSTRATION SETTING 3.3V (Default Setting) JP_VDD1 JP_VDD1 Note: Please refer to PANEL INVERTER CONNECTOR for more information about pin definition of JINV1.

  • Page 57: Clear Cmos Data Selection

    Chapter 3 System Configuration 3.5.27 CLEAR CMOS DATA SELECTION JP4: Clear CMOS Data Selection Step 1. Remove the main power of the PC. Step 2. Close JP4 (pins 1-2) for 6 seconds by a cap. Step 3. Remove the cap which is just used on JP4 (1-2), so that JP4 returns to “OPEN”.

  • Page 58: Software Utilities

    Software Utilities This chapter provides the detailed information that guides users to install driver utilities for the system. The following topics are included: ® • Installing Intel Chipset Software Installation Utility ® • Installing Intel Trusted Execution Engine Driver Utility •...
  • Page 59 Chapter 4 Software Utilities 4.1 Introduction Enclosed with SP-6558-R / SP-6550-R / SP-6555-R / SP-6557-R Series package is our driver utilities contained in a DVD-ROM disk. Refer to the following table for driver locations: For Windows 10 2019 64-bit OS: Filename (Assume that Purpose DVD- ROM drive is D :)
  • Page 60 Chapter 4 Software Utilities For Windows 10 2016 64-bit OS: Filename (Assume that Purpose DVD- ROM drive is D :) D: \Driver\Platform\WIN ® 10-2016\Chipset\ Intel Chipset Device Software installer D: \Driver\Platform\WIN 10-2016\Graphics\GFX_64bits_15.45. ® Intel HD Graphics installer 15.64.4599\ D:\ Driver\Platform\WIN ®...
  • Page 61 Chapter 4 Software Utilities It is strongly recommended that you follow the WARNING: installation sequence below: (1) Chipset Driver (2) Hotfix Driver (3) Graphics Driver (4) TXE Driver (5) Other Drivers SP-655X-R USER MANUAL Page: 4-4...
  • Page 62 Chapter 4 Software Utilities ® Installing Intel Chipset Software Installation Utility Introduction ® The Intel Chipset Software Installation Utility installs the Windows *.INF files to the target system. These files outline to the operating system how to configure the Intel chipset components in order to ensure that the following functions work properly: Core PCI and ISAPNP Services •...

  • Page 63: Installing Intel ® Trusted Execution Engine Installation Utility

    Chapter 4 Software Utilities ® 4.3 Installing Intel Trusted Execution Engine Installation Utility To install the utility, simply follow the steps below: Connect the USB DVD-ROM device to SP-6558-R / SP-6550-R / SP-6555-R / SP-6557-R and insert the driver disk. Select Windows 10 2019 or Windows 10 2016 OS platform.

  • Page 64: Installing Graphics Driver Utility

    Chapter 4 Software Utilities Installing Graphics Driver Utility The GRAPHICS interface embedded in SP-6558-R / SP-6550-R / SP-6555-R / SP-6557-R can support a wide range of display types. To install the Graphics driver utility, follow the steps below: Connect the USB DVD-ROM device to SP-6558-R / SP-6550-R / SP-6555-R / SP-6557-R and insert the driver disk.

  • Page 65: Installing Lan Driver Utility

    Chapter 4 Software Utilities Installing LAN Driver Utility Enhanced with LAN function, SP-6558-R / SP-6550-R / SP-6555-R / SP-6557-R supports various network adapters. To install the LAN Driver, follow the steps below: Connect the USB DVD-ROM device to SP-6558-R / SP-6550-R / SP-6555-R / SP-6557-R and insert the driver disk.

  • Page 66: Installing Sound Driver Utility

    Chapter 4 Software Utilities Installing Sound Driver Utility The sound function enhanced in this system is fully compatible with ® Windows 10 64bit. To install the Sound Driver, follow the steps below: Connect the USB DVD-ROM device to SP-6558-R / SP-6550-R / SP-6555-R / SP-6557-R and insert the driver disk.

  • Page 67: Installing Intel ® Serial I/O Driver Utility

    Chapter 4 Software Utilities ® Installing Intel Serial I/O Driver Utility To install the Serial I/O Driver, follow the steps below: Connect the USB DVD-ROM device to SP-6558-R / SP-6550-R / SP-6555-R / SP-6557-R and insert the driver disk. Select Windows 10 2019 or Windows 10 2016 OS platform. Open the Serial IO folder where the driver is located.

  • Page 68: Installing Intel ® Thermal Analysis Tool

    Chapter 4 Software Utilities ® Installing Intel Thermal Analysis Tool ® During Windows installation procedure, the Intel Thermal Analysis Tool installation is optional. User can install the tool for personal usage. ® To install the Intel Thermal Analysis Tool, follow the steps below: Connect the USB DVD-ROM device to SP-6558-R / SP-6550-R / SP-6555-R / SP-6557-R and insert the driver disk.

  • Page 69: Microsoft Hotfix Kb3211320 And Kb3213986 Driver Installation

    Chapter 4 Software Utilities Microsoft Hotfix KB3211320 and KB3213986 Driver Installation Introduction The Microsoft Hotfix kb3211320 and kb3213986 Driver that needs to be installed depends on the system's specific hardware and firmware features. The installer, compatible with Windows 10 2016 only, detects the system's capabilities and installs the relevant drivers and applications.

  • Page 70: Bios Setup

    BIOS SETUP This chapter guides users how to configure the basic system configurations via the BIOS Setup Utilities. The information of the system configuration is saved in BIOS NVRAM so that the Setup information is retained when the system is powered off. The BIOS Setup Utilities consist of the following menu items: Main Menu •...

  • Page 71: Introduction

    Chapter 5 BIOS Setup 5.1 Introduction The BE-0986 board uses an AMI (American Megatrends Incorporated) Aptio BIOS that is stored in the Serial Peripheral Interface Flash Memory (SPI Flash) and can be updated. The SPI Flash contains the built-in BIOS setup program, Power-On Self-Test (POST), PCI auto-configuration utility, LAN EEPROM information, and Plug and Play support.
  • Page 72 Chapter 5 BIOS Setup EFI BIOS provides an user interface that allows you to modify hardware configuration, e.g. change the system date and time, enable/disable a system component, determine bootable device priority, set up personal password, etc., which is convenient for engineers to perform modifications and customize the computer system and allows technicians to troubleshoot the occurred errors when the hardware is faulty.

  • Page 73: Accessing Setup Utility

    Chapter 5 BIOS Setup 5.2 Accessing Setup Utility After the system is powered on, BIOS will enter the Power-On Self-Test (POST) routines and the POST message will be displayed: Figure 5-2. POST Screen with AMI Logo Press <Del> or <Esc> to access the Setup Utility program and the Main menu of the Aptio Setup Utility will appear on the screen as below: SP-655X-R USER MANUAL...
  • Page 74 Chapter 5 BIOS Setup BIOS Setup Menu Initialization Screen You may move the cursor by <↑> and <↓> keys to highlight the individual menu items. As you highlight each item, a brief description of the highlighted selection will appear on the right side of the screen. The language of the BIOS setup menu interface and help messages are shown in US English.
  • Page 75 Chapter 5 BIOS Setup BIOS Setup Description Navigation Key Select a different menu screen (move the cursor from the <←> and <→> selected menu to the left or right). Select a different item (move the cursor from the <↑> and <↓> selected item upwards or downwards) <Enter>...

  • Page 76: Main

    Chapter 5 BIOS Setup 5.3 Main Main Menu Path The Main menu allows you to view the BIOS Information, change the system date and time, and view the user access privilege level. Use tab to switch between date elements. Use <↑> or <↓> arrow keys to highlight the item and enter the value you want in each item.
  • Page 77 Chapter 5 BIOS Setup BIOS Setting Options Description/Purpose It is recommended to disable Built-in Display function for the system without LVDS. BXT SOC No changeable options Displays the SOC stepping. MRC Version No changeable options Displays the MRC version. TXE FW No changeable options Displays the TXE FW version.

  • Page 78: Advanced

    Chapter 5 BIOS Setup 5.4 Advanced Advanced Menu Path This menu provides advanced configurations such as ACPI Settings, Onboard Device Configuration, Hardware Monitor, F81964 Watchdog, S5 RTC Wake Settings, CPU Configuration, F81964 Super IO Configuration, USB Configuration and Platform Trust Technology. Advanced Menu Screen BIOS Setting Options...

  • Page 79: Advanced - Acpi Settings

    Chapter 5 BIOS Setup 5.4.1 Advanced – ACPI Settings Menu Path Advanced > ACPI Settings The ACPI Settings allows users to configure relevant ACPI (Advanced Configuration and Power Management Interface) settings, such as Hibernation (S4) and Enable Sleep (S3). ACPI Settings Screen BIOS Setting Options Description/Purpose...

  • Page 80: Advanced - Onboard Device Configuration

    Chapter 5 BIOS Setup 5.4.2 Advanced – Onboard Device Configuration Advanced > Onboard Device Configuration Menu Path Onboard Device Configuration Screen BIOS Setting Options Description/Purpose - RS-422 COM2 Mode - RS-232 (default) Selects COM2 mode. Selection - RS-485 SP-655X-R USER MANUAL Page: 5-11...

  • Page 81: Advanced - Hardware Monitor

    Chapter 5 BIOS Setup 5.4.3 Advanced – Hardware Monitor Menu Path Advanced > Hardware Monitor The Hardware Monitor allows users to monitor the health and status of the system such as CPU temperature, system temperature, system fan speed and voltage levels in supply.

  • Page 82: Smart Fan Mode Configuration

    Chapter 5 BIOS Setup BIOS Setting Options Description/Purpose Detects and displays the voltage level VSB5V No changeable options of VSB5V in supply. Detects and displays the battery VBAT No changeable options voltage. 5.4.3.1 Smart Fan Mode Configuration Menu Path Advanced > Hardware Monitor > Smart Fan Mode Configuration Smart Fan Mode Configuration Screen BIOS Setting...

  • Page 83: Smart Fan Mode Configuration - [Manual Duty Mode]

    Chapter 5 BIOS Setup 5.4.3.2 Smart Fan Mode Configuration – [Manual Duty Mode] Menu Path Advanced > Hardware Monitor > Smart Fan Mode Configuration > [Manual Duty Mode] Smart Fan Mode Configuration Screen (Manual Duty Mode) BIOS Setting Options Description/Purpose Manual Duty Mode - 0% Manual mode fan control.

  • Page 84: Advanced - F81964 Watchdog

    Chapter 5 BIOS Setup 5.4.4 Advanced – F81964 Watchdog Menu Path Advanced > F81964 Watchdog If the system hangs or fails to respond, enable the F81964 watchdog function to trigger a system reset via the 255-level watchdog timer. F81964 Watchdog Screen BIOS Setting Options Description/Purpose...

  • Page 85: Advanced - S5 Rtc Wake Settings

    Chapter 5 BIOS Setup 5.4.5 Advanced – S5 RTC Wake Settings Menu Path Advanced > S5 RTC wake Settings The S5 RTC Wake Settings enables/disables the system to wake up at a preset time of a day from S5 State using RTC alarm. S5 RTC Wake Settings Screen BIOS Setting Options...

  • Page 86: S5 Rtc Wake Settings [Fixed Time]

    Chapter 5 BIOS Setup 5.4.5.1 S5 RTC Wake Settings [Fixed Time] Menu Path Advanced > S5 RTC Wake Settings [Fixed Time] S5 RTC Wake Settings Screen (Fixed Time) BIOS Setting Options Description/Purpose Multiple options Sets an hour for a scheduled Wake up hour ranging from 0 to 23 power-on event.

  • Page 87: S5 Rtc Wake Settings [Dynamic Time]

    Chapter 5 BIOS Setup 5.4.5.2 S5 RTC Wake Settings [Dynamic Time] Menu Path Advanced > S5 RTC Wake Settings [Dynamic Time] S5 RTC Wake Setting Screen (Dynamic Time) BIOS Setting Options Description/Purpose Wake up minute increase Multiple options Sets a period of time (in minutes) to ranging from 1 to 5 wake up the system after it enters S5 state.

  • Page 88: Advanced - Cpu Configuration

    Chapter 5 BIOS Setup 5.4.6 Advanced – CPU Configuration Advanced > CPU Configuration Menu Path The CPU Configuration provides advanced CPU settings such as CPU power management and some information about CPU. CPU Configuration Screen BIOS Setting Options Description/Purpose Socket 0 CPU Information Sub-Menu Soket specific CPU Information.

  • Page 89: Socket 0 Cpu Information

    Chapter 5 BIOS Setup 5.4.6.1 Socket 0 CPU Information Menu Path Advanced > CPU Configuration > Socket 0 CPU Information Socket 0 CPU Information Screen BIOS Setting Options Description/Purpose CPU Branding String No changeable options Displays CPU Branding String. CPU Signature No changeable options Displays CPU Signature.

  • Page 90: Cpu Power Management Configuration

    Chapter 5 BIOS Setup 5.4.6.2 CPU Power Management Configuration Menu Path Advanced > CPU Configuration > CPU Power Management Configuration CPU Power Management Configuration Screen BIOS Setting Options Description/Purpose EIST - Disabled Enables/Disables Intel Speed Step - Enabled feature for dynamic scaling processor (default) frequency.

  • Page 91: Configuration

    Chapter 5 BIOS Setup 5.4.7 Advanced – F81964 Super IO Configuration Menu Path Advanced > F81964 Super IO Configuration The F81964 Super IO Configuration allows users to configure the serial ports 1-4. F81964 Super IO Configuration Screen BIOS Setting Options Description/Purpose Super IO Chip (F81964) No changeable options Displays the super I/O chip model.

  • Page 92: F81964 Super Io Configuration - Serial Port

    Chapter 5 BIOS Setup 5.4.7.1 F81964 Super IO Configuration – Serial Port 1 Configuration Menu Path Advanced > F81964 Super IO Configuration > Serial Port 1 Configuration Serial Port 1 Configuration Screen BIOS Setting Options Description/Purpose - Disabled Serial Port Enables/Disables COM1.
  • Page 93 Chapter 5 BIOS Setup 5.4.7.2 F81964 Super IO Configuration – Serial Port 2 Configuration Menu Path Advanced > F81964 Super IO Configuration > Serial Port 2 Configuration Serial Port 2 Configuration Screen BIOS Setting Options Description/Purpose - Disabled Serial Port Enables/Disables COM2.
  • Page 94 Chapter 5 BIOS Setup 5.4.7.3 F81964 Super IO Configuration – Serial Port 3 Configuration Menu Path Advanced > F81964 Super IO Configuration > Serial Port 3 Configuration Serial Port 3 Configuration Screen BIOS Setting Options Description/Purpose - Disabled Serial Port Enables/Disables COM3.
  • Page 95 Chapter 5 BIOS Setup 5.4.7.4 F81964 Super IO Configuration – Serial Port 4 Configuration Menu Path Advanced > F81964 Super IO Configuration > Serial Port 4 Configuration Serial Port 4 Configuration Screen BIOS Setting Options Description/Purpose - Disabled Serial Port Enables/Disables COM4.

  • Page 96: Advanced - Usb Configuration

    Chapter 5 BIOS Setup 5.4.8 Advanced – USB Configuration Advanced > USB Configuration Menu Path The USB Configuration allows users to configure advanced USB settings such as USB mass storage driver support and mass storage devices. USB Configuration Screen BIOS Setting Options Description/Purpose USB Module Version...

  • Page 97: Advanced - Platform Trust Technology

    Chapter 5 BIOS Setup 5.4.9 Advanced – Platform Trust Technology Menu Path Advanced > Platform Trust Technology The Platform Trust Technology allows users to configure TPM settings. Platform Trust Technology BIOS Setting Options Description/Purpose - Enabled fTPM Enables/Disables fTPM. - Disabled (default) SP-655X-R USER MANUAL Page: 5-28...

  • Page 98: Chipset

    Chapter 5 BIOS Setup 5.5 Chipset Chipset Menu Path This menu allows users to configure advanced Chipset settings such as North Bridge and South Bridge configuration parameters. Chipset Screen BIOS Setting Options Description/Purpose North Bridge Sub-Menu North Bridge Parameters. South Bridge Sub-Menu South Bridge Parameters.

  • Page 99: Chipset - North Bridge

    Chapter 5 BIOS Setup 5.5.1 Chipset – North Bridge Menu Path Chipset > North Bridge North Bridge Screen BIOS Setting Options Description/Purpose Displays the current amount and type Total Memory No changeable options of memory on the system, e.g. "8192 MB (LPDDR3)".

  • Page 100: Chipset - South Bridge

    Chapter 5 BIOS Setup 5.5.2 Chipset – South Bridge Chipset > South Bridge Menu Path South Bridge Screen BIOS Setting Options Description/Purpose HD-Audio Configuration Sub-Menu HD-Audio configuration settings. LPSS Configuration Sub-Menu LPSS configuration settings. PCI Express Configuration Sub-Menu PCI Express configuration settings. SATA Drives Sub-Menu SATA Drives configuration settings.

  • Page 101: South Bridge - Hd-Audio Configuration

    Chapter 5 BIOS Setup 5.5.2.1 South Bridge – HD-Audio Configuration Menu Path Chipset > South Bridge > HD-Audio Configuration HD-Audio Configuration Screen BIOS Setting Options Description/Purpose - Disable HD-Audio Support Enables/Disables HD-Audio support. - Enable (default) SP-655X-R USER MANUAL Page: 5-32...

  • Page 102: South Bridge - Lpss Configuration

    Chapter 5 BIOS Setup 5.5.2.2 South Bridge – LPSS Configuration Menu Path Chipset > South Bridge > LPSS Configuration LPSS Configuration Screen BIOS Setting Options Description/Purpose LPSS I2C #1 Support - Disable Enables/Disables LPSS I2C #1 (D22:F0) - Enable (default) support.

  • Page 103: South Bridge - Pci Express Configuration

    Chapter 5 BIOS Setup 5.5.2.3 South Bridge – PCI Express Configuration Menu Path Chipset > South Bridge > PCI Express Configuration PCI Express Configuration Screen BIOS Setting Options Description/Purpose PCI E Express Root Port 1 Sub-Menu PCIE RP1 parameters (I210 LAN).
  • Page 104 Chapter 5 BIOS Setup – – South Bridge PCI Express Configuration PCI Express Root Port 1 (I210 LAN) Menu Path Chipset > South Bridge > PCI Express Configuration > PCI Express Root Port 1 (I210 LAN) PCI Express Root Port 1 (I210 LAN) Screen BIOS Setting Options Description/Purpose...
  • Page 105 Chapter 5 BIOS Setup South Bridge - PCI Express Configuration - PCI Express Root Port 2 (I210 LAN) Chipset > South Bridge > PCI Express Configuration > PCI Menu Path Express Root Port 2 (I210 LAN) PCI Express Root Port 2 (I210 LAN) Screen BIOS Setting Options Description/Purpose...
  • Page 106 Chapter 5 BIOS Setup South Bridge - PCI Express Configuration - PCI Express Root Port 3 (Mini-PCIe) Chipset > South Bridge > PCI Express Configuration > PCI Menu Path Express Root Port 3 (Mini-PCIe) PCI Express Root Port 3 (Mini-PCIe) Screen BIOS Setting Options Description/Purpose...

  • Page 107: South Bridge - Sata Drives

    Chapter 5 BIOS Setup 5.5.2.4 South Bridge – SATA Drives Menu Path Chipset > South Bridge > SATA Drives SATA Drives Screen BIOS Setting Options Description/Purpose - Enable (default) Enables/Disables the chipset SATA Chipset SATA - Disable controller. Displays SATA drive branding SATA Port 0 No changeable options information if the device exists on...

  • Page 108: South Bridge - Miscellaneous Configuration

    Chapter 5 BIOS Setup 5.5.2.5 South Bridge – Miscellaneous Configuration Menu Path Chipset > South Bridge > Miscellaneous Configuration Miscellaneous Configuration Screen BIOS Setting Options Description/Purpose Restore AC Power Loss - Power On (default) Specifies what state to go to when power is - Power Off re-applied following a power failure (G3 state).

  • Page 109: Security

    Chapter 5 BIOS Setup 5.6 Security Menu Path Security From the Security menu, you are allowed to create, change or clear the administrator password. You will be asked to enter the configured administrator password before you can access the Setup Utility. By setting an administrator password, you will prevent other users from changing your BIOS settings.
  • Page 110 Chapter 5 BIOS Setup BIOS Setting Options Description/Purpose User Password Password can be 3-20 Specifies the user password. alphanumeric characters. Enters sub-menu with option to enabled password protected HDD Security Configuration Sub-Menu HDD/SSD (if supported by SATA device). Create an Administrator or User Password Select the Administrator Password / User Password option from the Security menu and press <Enter>, and the password dialog entry box appears.

  • Page 111: Boot

    Chapter 5 BIOS Setup 5.7 Boot Boot Menu Path This menu provides control items for system boot configuration such as setting setup prompt timeout, enabling/disabling quiet boot and fast boot and changing the boot order from the available bootable device(s). Boot Screen BIOS Setting Options...
  • Page 112 Chapter 5 BIOS Setup BIOS Setting Options Description/Purpose Fast Boot - Disabled (default) Enables or Disables Fast Boot - Enabled Options. OS Selection Windows (default) Selects the target OS. - Android - Intel Linux Boot Option #1~#n - [Drive(s)] Sets the system boot order. - Disabled SP-655X-R USER MANUAL Page: 5-43...

  • Page 113: Save & Exit

    Chapter 5 BIOS Setup 5.8 Save & Exit Save & Exit Menu Path The Save & Exit allows users to save or discard changed BIOS settings as well as load factory default settings. Save Changed BIOS Settings To save and validate the changed BIOS settings, select Save Changes from the Save &...
  • Page 114 Chapter 5 BIOS Setup BIOS Setting Options Description/Purpose Exits and saves the changes in Save Changes and Exit No changeable options NVRAM. Exits without saving any changes Discard Changes and Exit No changeable options made in BIOS settings. Saves the changes in NVRAM and Save Changes and Reset No changeable options resets.

  • Page 115: Appendix A System Diagrams

    Appendix A System Diagrams This appendix includes the exploded diagrams of the system and the parts list as well as the part numbers of the SP-655X-R system. • SP-655X-R System Exploded Diagrams (Normal SKU and PoE SKU) • SP-655X-R Panel Module Exploded Diagrams (Normal SKU and PoE SKU) •...

  • Page 116: Sp-6550-R System Exploded Diagram (Normal Sku

    Appendix A System Diagrams SP-6550-R System Exploded Diagram (Normal SKU) Component Name P/N No. Q’ty SP-6550 Panel Module See Page A-3 and A-4 Flat Head Screw #2/M3x0.5Px5mm 22-215-30005011 BS-E097 Link Box Normal COM1 EXP See Page A-5 and A-6 SP-655X-R USER MANUAL Page: A-2...

  • Page 117: Sp-6550-R Panel Module Exploded Diagram (Normal Sku

    Appendix A System Diagrams SP-6550-R Panel Module Exploded Diagram (Normal SKU) 17 22 14 13 Component Name P/N No. Q’ty SP-6550 Front Cover CHI MEI-2 20-004-01063448 (w/Paint)(Black) SP-6550 Rear Cover Update 80-104-03001448 SP-6550 CHI MEI Panel BKT L1 20-106-03002448 SP-6550 CHI MEI Panel BKT R 20-106-03003448 SP-6550-GUM-R-SP SP-6550-GUM-L-SP...
  • Page 118 Appendix A System Diagrams Component Name P/N No. Q’ty Fillister Head Screw #1 / 22-275-25004011 M2.5x0.45Px4mm Flat Head Screw M2.5x0.45Px8mm 22-115-25080011 Round Head Screwψ3.3 / 22-232-20004811 #1/M2x0.4Px4mm Flat Head Screw #2/M3x0.5Px5mm 22-215-30005011 Round Washer Head Screw #2 / 22-232-30004011 M3x0.5Px4mm 10.4'' Zero Bezel P-CAP Touch Panel 52-380-01085014 (COF) (-30~70°C)

  • Page 119: Sp-655X-R Box Pc Exploded Diagram (Normal Sku

    Appendix A System Diagrams SP-655X-R Box PC Exploded Diagram (Normal SKU) (continued on the next page) SP-S655X-R USER MANUAL Page: A-5...
  • Page 120 Appendix A System Diagrams Component Name P/N No. Q’ty BS-E097 Heatsink Case (Black) See Page A-7 BS-E097 Front Case for Normal-C (Black) SP-6550 Back Case For COM1 20-101-03067448 (w/Paint)(Black) SP-6558 10-8 E097 Link Box Bracket 20-206-03067448 (w/Paint)(Black) 2.5” HDD SATA BE-0986RA-E3N / E4N BE-0986 Flat Head Screw #1 / M2x0.4Px5mm...

  • Page 121: Sp-655X-R Heatsink Exploded Diagram (Normal Sku

    Appendix A System Diagrams SP-655X-R Heatsink Exploded Diagram (Normal SKU) Component Name P/N No. Q’ty BS-E097 Heatsink Case (Black) 81-002-11841007 (217.5x140.6x46mm) BS-E097 CPU CU Block (110x18x2mm) 81-002-21018002 Flat Head Screw #1 / M2x0.4Px5mm 22-215-20005011 SP-S655X-R USER MANUAL Page: A-7...

  • Page 122: Sp-6550-R System Exploded Diagram (Poe Sku

    Appendix A System Diagrams SP-6550-R System Exploded Diagram (PoE SKU) Component Name P/N No. Q’ty SP-6550 Panel Module See Page A-9 and A-10 Flat Head Screw #2/M3x0.5Px5mm 22-215-30005011 BS-E097 Link Box PoE COM1 EXP See Page A-11 and A-12 SP-655X-R USER MANUAL Page: A-8...

  • Page 123: Sp-6550-R Panel Module Exploded Diagram (Poe Sku

    Appendix A System Diagrams SP-6550-R Panel Module Exploded Diagram (PoE SKU) Component Name P/N No. Q’ty SP-6550 Front Cover CHI MEI-2 20-004-01063448 (w/Paint)(Black) SP-6550 Rear Cover Update 80-104-03001448 SP-6550 CHI MEI Panel BKT L1 20-106-03002448 SP-6550 CHI MEI Panel BKT R 20-106-03003448 SP-6550-GUM-R-SP SP-6550-GUM-L-SP...
  • Page 124 Appendix A System Diagrams Component Name P/N No. Q’ty Round Head Screwψ3.3 / 22-232-20004811 #1/M2x0.4Px4mm Flat Head Screw #2/M3x0.5Px5mm 22-215-30005011 Round Washer Head Screw #2 / 22-232-30004011 M3x0.5Px4mm 10.4'' Zero Bezel P-CAP Touch Panel 52-380-01085014 (COF) (-30~70°C) SP-6558/6550 TCB GUM (38x15x1mm) 30-013-01300448 Module_G104X1-L03 PAC8100LF-D1...

  • Page 125: Sp-655X-R Box Pc Exploded Diagram (Poe Sku

    Appendix A System Diagrams SP-655X-R Box PC Exploded Diagram (PoE SKU) (continued on the next page) SP-S655X-R USER MANUAL Page: A-11...
  • Page 126 Appendix A System Diagrams Component Name P/N No. Q’ty BS-E097 Heatsink Case (Black) See Page A-13 BS-E097 Front Case PoE LAN B 20-101-03066416 (w/Paint) (Black) SP-6550 Back Case For COM1 (w/Paint) 20-101-03067448 (Black) SP-6558 10-8 E097 Link Box Bracket 20-206-03067448 (w/Paint) (Black) 2.5”...

  • Page 127: Sp-655X-R Heatsink Exploded Diagram (Poe Sku

    Appendix A System Diagrams SP-655X-R Heatsink Exploded Diagram (PoE SKU) Component Name P/N No. Q’ty BS-E097 Heatsink Case (Black) 81-002-11841007 (217.5x140.6x46mm) BS-E097 CPU CU Block (110x18x2mm) 81-002-21018002 Flat Head Screw #1 / M2x0.4Px5mm 22-215-20005011 SP-S655X-R USER MANUAL Page: A-13...

  • Page 128: Sp-6558-R System Exploded Diagram (Normal Sku

    Appendix A System Diagrams SP-6558-R System Exploded Diagram (Normal SKU) Component Name P/N No. Q’ty SP-6558 Panel Module See Page A-15 and A-16 Flat Head Screw #2/M3x0.5Px5mm 22-215-30005011 BS-E097 Link Box Normal COM1 See Page A-5 and A-6 SP-655X-R USER MANUAL Page: A-14...

  • Page 129: Sp-6558-R Panel Module Exploded Diagram (Normal Sku

    Appendix A System Diagrams SP-6558-R Panel Module Exploded Diagram (Normal SKU) 10 09 Component Name P/N No. Q’ty SP-6558 Front Cover 20-004-01062448 SP-6558 Rear Cover Update 80-104-03002448 SP-6558 GUM-L-SP 34-026-05015448 (171.8x19.25x1.3mm) SP-6558 GUM-R-SP 34-026-05010448 (171.79x15.85x1.3mm) SP-6558 GUM-T-SP 34-026-05012448 (195.28x14.25x1.3mm) SP-6558 GUM-D-SP 34-026-05014448 (195.28x9.34x1.3mm) SP-6550 LCD Sponge (167x4x1mm)
  • Page 130 Appendix A System Diagrams Component Name P/N No. Q’ty 8.4'' Zero Bezel P-CAP Touch 52-380-06800028 Panel(COF)(-30~70°C) 8.4" LCD panel (LED backlight),350nits, 52-351-00841134 SVGA(800x600) SR-6145RA-D0N SP-6558 O Ring 30-013-01200448 For 5-wire Resistive Touch Panel 5-wire Resistive Touch Panel P/N No. Q’ty SP-6558 GUM L SR UPDATE 94-026-05016448 (171.8x19.25x0.8mm)

  • Page 131: Sp-6558-R System Exploded Diagram (Poe Sku

    Appendix A System Diagrams SP-6558-R System Exploded Diagram (PoE SKU) Component Name P/N No. Q’ty SP-6550 Panel Module See Page A-18 and A-19 Flat Head Screw #2/M3x0.5Px5mm 22-215-30005011 BS-E097 Link Box PoE COM1 EXP See Page A-11 and A-12 SP-S655X-R USER MANUAL Page: A-17...

  • Page 132: Sp-6558-R Panel Module Exploded Diagram (Poe Sku

    Appendix A System Diagrams SP-6558-R Panel Module Exploded Diagram (PoE SKU) Component Name P/N No. Q’ty SP-6558 Front Cover 20-004-01062448 SP-6558 Rear Cover Update 80-104-03002448 SP-6558 GUM-L-SP 34-026-05015448 (171.8x19.25x1.3mm) SP-6558 GUM-R-SP 34-026-05010448 (171.79x15.85x1.3mm) SP-6558 GUM-T-SP 34-026-05012448 (195.28x14.25x1.3mm) SP-6558 GUM-D-SP 34-026-05014448 (195.28x9.34x1.3mm) SP-6550 LCD Sponge (167x4x1mm) 30-013-11100448...
  • Page 133 Appendix A System Diagrams Component Name P/N No. Q’ty 8.4" LCD panel (LED backlight), 350nits, 52-351-00841134 SVGA(800x600) SR-6145RA-D0N SP-6558 O Ring 30-013-01200448 For 5-wire resistive Touch Panel Resistive Touch Panel P/N No. Q’ty SP-6558 GUM L SR Update 94-026-05016448 (171.8x19.25x0.8mm) SP-6558 GUM-R-SR 34-026-05011448 (171.79x15.85x0.8mm)

  • Page 134: Sp-6555-R System Exploded Diagram (Normal Sku

    Appendix A System Diagrams SP-6555-R System Exploded Diagram (Normal SKU) Component Name P/N No. Q’ty SP-6565 Front Panel Exp See Page A-21 and A-22 Flat Head Screw #2/M3x0.5Px5mm 22-215-30005011 BS-E097 Link Box Normal COM1 See Page A-5 and A-6 SP-655X-R USER MANUAL Page: A-20...

  • Page 135: Sp-6555-R Panel Module Exploded Diagram (Normal Sku

    Appendix A System Diagrams SP-6555-R Panel Module Exploded Diagram (Normal SKU) Component Name P/N No. Q’ty SP-6555 New Front Bezel (w/Paint) 20-003-01061448 (Black) SP-6555 15 Panel Back Cover Bracket 20-106-03061448 (w/Paint)(Black) SP-6565 LCD Link Holder (w/Paint) 80-129-03006442 (Black) SP-6555 Controller Cover Bracket 20-106-03062448 (w/Paint)(Black) SP-7145 Thin Gap LCD Poron H...
  • Page 136 Appendix A System Diagrams Component Name P/N No. Q’ty LCD Display 15" Projected Capacitive Touch Panel 52-380-00563401 SP-6565 Water O Ring 90-013-01100442 For 5-wire Resistive Touch Panel 5-wire Resistive Touch Panel P/N No. Q’ty Remark SP-7145 Double Coated Tape A For top and 34-026-06201411 (358.49x14.5x0.8mm)

  • Page 137: Sp-6555-R System Exploded Diagram (Poe Sku

    Appendix A System Diagrams SP-6555-R System Exploded Diagram (PoE SKU) Component Name P/N No. Q’ty SP-6565 Front Panel Exp See Page A-24 and A-25 Flat Head Screw #2/M3x0.5Px5mm 22-215-30005011 BS-E097 Link Box PoE COM1 EXP See Page A-11 and A-12 SP-S655X-R USER MANUAL Page: A-23...

  • Page 138: Sp-6555-R Panel Module Exploded Diagram (Poe Sku

    Appendix A System Diagrams SP-6555-R Panel Module Exploded Diagram (PoE SKU) Component Name P/N No. Q’ty SP-6555 New Front Bezel (w/Paint) 20-003-01061448 (Black) SP-6555 15 Panel Back Cover Bracket 20-106-03061448 (w/Paint)(Black) SP-6565 LCD Link Holder (w/Paint) 80-129-03006442 (Black) SP-6555 Controller Cover Bracket 20-106-03062448 (w/Paint)(Black) SP-7145 Thin Gap LCD Poron H...
  • Page 139 Appendix A System Diagrams Component Name P/N No. Q’ty LCD Display 15" Projected Capacitive Touch Panel 52-380-00563401 SP-6565 Water O Ring 90-013-01100442 For 5-wire Resistive Touch Panel 5-wire Resistive Touch Panel P/N No. Q’ty Remark SP-7145 Double Coated Tape A For top and 34-026-06201411 (358.49x14.5x0.8mm)

  • Page 140: Sp-6557-R System Exploded Diagram (Normal Sku

    Appendix A System Diagrams SP-6557-R System Exploded Diagram (Normal SKU) Component Name P/N No. Q’ty SP-6567 Front Panel Exp See Page A-27 and A-28 Flat Head Screw #2/M3x0.5Px5mm 22-215-30005011 BS-E097 Link Box Normal COM1 EXP See Page A-5 and A-6 SP-655X-R USER MANUAL Page: A-26...

  • Page 141: Sp-6557-R Panel Module Exploded Diagram (Normal Sku

    Appendix A System Diagrams SP-6557-R Panel Module Exploded Diagram (Normal SKU) Component Name P/N No. Q’ty SP-6567 Front Bezel(w/Paint)(Black) 20-003-01061443 SP-6557 17 Panel Back Cover Bracket 20-106-03065448 (w/Paint)(Black) SP-6567 LCD Link Holder 80-129-03006443 (w/Paint)(Black) SP-6555 Controller Cover Bracket 20-106-03062448 (w/Paint)(Black) ABON TP A-68170-0401 EPDM-V-B-D1 34-026-06201000 (304x5x1.8mm)
  • Page 142 Appendix A System Diagrams Component Name P/N No. Q’ty Touch Panel1 SP-6567 Water O Ring 90-013-01100443 For 5-wire Resistive Touch Panel 5-wire Resistive Touch Panel P/N No. Q’ty Remark SP-7145 Double Coated Tape A For top and 34-026-06201411 (358.49x14.5x0.8mm) bottom sides SP-7145 Double Coated Tape B For left and 34-026-06202411...

  • Page 143: Sp-6557-R System Exploded Diagram (Poe Sku

    Appendix A System Diagrams SP-6557-R System Exploded Diagram (PoE SKU) Component Name P/N No. Q’ty SP-6567 Front Panel Exp See Page A-30 and A-31 Flat Head Screw #2/M3x0.5Px5mm 22-215-30005011 BS-E097 Link Box PoE COM1 EXP See Page A-11 and A-12 SP-S655X-R USER MANUAL Page: A-29...

  • Page 144: Sp-6550-R Panel Module Exploded Diagram (Poe Sku

    Appendix A System Diagrams SP-6550-R Panel Module Exploded Diagram (PoE SKU) Component Name P/N No. Q’ty SP-6567 Front Bezel(w/Paint)(Black) 20-003-01061443 SP-6557 17 Panel Back Cover Bracket 20-106-03065448 (w/Paint)(Black) SP-6567 LCD Link Holder 80-129-03006443 (w/Paint)(Black) SP-6555 Controller Cover Bracket 20-106-03062448 (w/Paint)(Black) ABON TP A-68170-0401 EPDM-V-B-D1 34-026-06201000 (304x5x1.8mm)
  • Page 145 Appendix A System Diagrams Component Name P/N No. Q’ty Touch Panel1 SP-6567 Water O Ring 90-013-01100443 For 5-wire Resistive Touch Panel 5-wire Resistive Touch Panel P/N No. Q’ty Remark SP-7145 Double Coated Tape A For top and 34-026-06201411 (358.49x14.5x0.8mm) bottom sides SP-7145 Double Coated Tape B For left and 5, 6...

  • Page 146: Installing Sp-6550-R / Sp-6558-R Wall O-Ring

    Appendix A System Diagrams Installing SP-6550-R / SP-6558-R Wall O-Ring Step 1. Place the Wall O-ring into the groove surrounding the back of the front bezel. Step 2. Install the system onto the wall to complete. Place the Wall O-ring into the groove surrounding the back of the front bezel.

  • Page 147: Installing Sp-6555-R / Sp-6557-R Wall O-Ring

    Appendix A System Diagrams Installing SP-6555-R / SP-6557-R Wall O-Ring Step 1. Place the Wall O-ring into the groove surrounding the back of the front bezel. Step 2. Install the system onto the wall to complete. Place the Wall O-ring into the groove surrounding the back of the front bezel.

  • Page 148: Installing Sp-6550-R / Sp-6558-R Vesa Mount

    Appendix A System Diagrams Installing SP-6550-R / SP-6558-R VESA Mount Wall SP-655X-R USER MANUAL Page: A-34...

  • Page 149: Installing Sp-6555-R / Sp-6557-R Vesa Mount

    Appendix A System Diagrams Installing SP-6555-R / SP-6557-R VESA Mount Wall SP-S655X-R USER MANUAL Page: A-35...

  • Page 150: Installing Sp-6550-R / Sp-6558-R Hooks

    Appendix A System Diagrams Installing SP-6550-R / SP-6558-R Hooks Step 1. Install the mounting brackets into the mounting holes on the 4 sides of SP-6550-R using 9 x M3x5mm screws. (Note: It is not necessary to install mounting brackets on SP-6558-R in this step.) Install mounting brackets onto the 4 sides of the Panel PC.
  • Page 151 Appendix A System Diagrams Step 2. Mount SP-6550-R Panel PC equipped with 9 mounting brackets onto the wall firmly. SP-6550-R Wall For SP-6558-R, simply mount the Panel PC onto the wall firmly. SP-6558-R Wall SP-S655X-R USER MANUAL Page: A-37...
  • Page 152 Appendix A System Diagrams Step 3. For SP-6550-R, install 9 x hooks onto the mounting brackets on the four sides of SP-6550-R Panel PC and then fasten the mating screws to secure firmly and complete the installation. SP-6550-R 1. Install the hook. 2.

  • Page 153: Installing Sp-6555 / Sp-6557 Hooks

    Appendix A System Diagrams Installing SP-6555 / SP-6557 Hooks Step 1. Install the mounting brackets into the mounting holes on the 4 sides of SP-6555-R using 10 xM3x5mm screws and 12 x M3x5mm screws for SP-6557-R. Install mounting brackets onto the 4 sides of the Panel PC. Wall SP-S655X-R USER MANUAL Page: A-39...
  • Page 154 Appendix A System Diagrams Step 2. Mount SP-6555-R Panel PC equipped with 10 mounting brackets onto the wall firmly. Mount SP-6557-R Panel PC equipped with 12 mounting brackets onto the wall firmly. Wall SP-655X-R USER MANUAL Page: A-40...
  • Page 155 Appendix A System Diagrams Step 3. Install 10 hooks onto the mounting brackets on the four sides of SP-6555-R Panel PC and 12 hooks for SP-6557-R Panel PC, and then fasten the mating screws to secure firmly and complete the installation.

  • Page 156: Appendix B Technical Summary

    Appendix B Technical Summary This appendix will give you a brief introduction of the allocation maps for the system resources. The following topics are included: • Interrupt Map • I/O Map • Memory Map • Configuring WatchDog Timer • Flash BIOS Update SP-655X-R USER MANUAL Page: B-1...

  • Page 157: Interrupt Map

    Appendix B Technical Summary Interrupt Map Assignment IRQ 0 System timer IRQ 3 Communications Port (COM2) IRQ 4 Communications Port (COM1) IRQ 7 Communications Port (COM3) IRQ 8 System CMOS/real time clock IRQ 10 Communications Port (COM4) IRQ 25 High Definition Audio Controller IRQ 27 Intel(R) Serial IO I2C Host Controller - 5AAC IRQ 54...
  • Page 158 Appendix B Technical Summary Assignment IRQ 72 Microsoft ACPI-Compliant System IRQ 73 Microsoft ACPI-Compliant System IRQ 74 Microsoft ACPI-Compliant System IRQ 75 Microsoft ACPI-Compliant System IRQ 76 Microsoft ACPI-Compliant System IRQ 77 Microsoft ACPI-Compliant System IRQ 78 Microsoft ACPI-Compliant System IRQ 79 Microsoft ACPI-Compliant System IRQ 80...
  • Page 159 Appendix B Technical Summary Assignment IRQ 99 Microsoft ACPI-Compliant System IRQ 100 Microsoft ACPI-Compliant System IRQ 101 Microsoft ACPI-Compliant System IRQ 102 Microsoft ACPI-Compliant System IRQ 103 Microsoft ACPI-Compliant System IRQ 104 Microsoft ACPI-Compliant System IRQ 105 Microsoft ACPI-Compliant System IRQ 106 Microsoft ACPI-Compliant System IRQ 107...
  • Page 160 Appendix B Technical Summary Assignment IRQ 126 Microsoft ACPI-Compliant System IRQ 127 Microsoft ACPI-Compliant System IRQ 128 Microsoft ACPI-Compliant System IRQ 129 Microsoft ACPI-Compliant System IRQ 130 Microsoft ACPI-Compliant System IRQ 131 Microsoft ACPI-Compliant System IRQ 132 Microsoft ACPI-Compliant System IRQ 133 Microsoft ACPI-Compliant System IRQ 134...
  • Page 161 Appendix B Technical Summary Assignment IRQ 153 Microsoft ACPI-Compliant System IRQ 154 Microsoft ACPI-Compliant System IRQ 155 Microsoft ACPI-Compliant System IRQ 156 Microsoft ACPI-Compliant System IRQ 157 Microsoft ACPI-Compliant System IRQ 158 Microsoft ACPI-Compliant System IRQ 159 Microsoft ACPI-Compliant System IRQ 160 Microsoft ACPI-Compliant System IRQ 161...
  • Page 162 Appendix B Technical Summary Assignment IRQ 180 Microsoft ACPI-Compliant System IRQ 181 Microsoft ACPI-Compliant System IRQ 182 Microsoft ACPI-Compliant System IRQ 183 Microsoft ACPI-Compliant System IRQ 184 Microsoft ACPI-Compliant System IRQ 185 Microsoft ACPI-Compliant System IRQ 186 Microsoft ACPI-Compliant System IRQ 187 Microsoft ACPI-Compliant System IRQ 188...
  • Page 163 Appendix B Technical Summary Assignment IRQ 258 Microsoft ACPI-Compliant System IRQ 259 Microsoft ACPI-Compliant System IRQ 260 Microsoft ACPI-Compliant System IRQ 261 Microsoft ACPI-Compliant System IRQ 262 Microsoft ACPI-Compliant System IRQ 263 Microsoft ACPI-Compliant System IRQ 264 Microsoft ACPI-Compliant System IRQ 265 Microsoft ACPI-Compliant System IRQ 266...
  • Page 164 Appendix B Technical Summary Assignment IRQ 285 Microsoft ACPI-Compliant System IRQ 286 Microsoft ACPI-Compliant System IRQ 287 Microsoft ACPI-Compliant System IRQ 288 Microsoft ACPI-Compliant System IRQ 289 Microsoft ACPI-Compliant System IRQ 290 Microsoft ACPI-Compliant System IRQ 291 Microsoft ACPI-Compliant System IRQ 292 Microsoft ACPI-Compliant System IRQ 293...
  • Page 165 Appendix B Technical Summary Assignment IRQ 312 Microsoft ACPI-Compliant System IRQ 313 Microsoft ACPI-Compliant System IRQ 314 Microsoft ACPI-Compliant System IRQ 315 Microsoft ACPI-Compliant System IRQ 316 Microsoft ACPI-Compliant System IRQ 317 Microsoft ACPI-Compliant System IRQ 318 Microsoft ACPI-Compliant System IRQ 319 Microsoft ACPI-Compliant System IRQ 320...
  • Page 166 Appendix B Technical Summary Assignment IRQ 339 Microsoft ACPI-Compliant System IRQ 340 Microsoft ACPI-Compliant System IRQ 341 Microsoft ACPI-Compliant System IRQ 342 Microsoft ACPI-Compliant System IRQ 343 Microsoft ACPI-Compliant System IRQ 344 Microsoft ACPI-Compliant System IRQ 345 Microsoft ACPI-Compliant System IRQ 346 Microsoft ACPI-Compliant System IRQ 347...
  • Page 167 Appendix B Technical Summary Assignment IRQ 366 Microsoft ACPI-Compliant System IRQ 367 Microsoft ACPI-Compliant System IRQ 368 Microsoft ACPI-Compliant System IRQ 369 Microsoft ACPI-Compliant System IRQ 370 Microsoft ACPI-Compliant System IRQ 371 Microsoft ACPI-Compliant System IRQ 372 Microsoft ACPI-Compliant System IRQ 373 Microsoft ACPI-Compliant System IRQ 374...
  • Page 168 Appendix B Technical Summary Assignment IRQ 393 Microsoft ACPI-Compliant System IRQ 394 Microsoft ACPI-Compliant System IRQ 395 Microsoft ACPI-Compliant System IRQ 396 Microsoft ACPI-Compliant System IRQ 397 Microsoft ACPI-Compliant System IRQ 398 Microsoft ACPI-Compliant System IRQ 399 Microsoft ACPI-Compliant System IRQ 400 Microsoft ACPI-Compliant System IRQ 401...
  • Page 169 Appendix B Technical Summary Assignment IRQ 420 Microsoft ACPI-Compliant System IRQ 421 Microsoft ACPI-Compliant System IRQ 422 Microsoft ACPI-Compliant System IRQ 423 Microsoft ACPI-Compliant System IRQ 424 Microsoft ACPI-Compliant System IRQ 425 Microsoft ACPI-Compliant System IRQ 426 Microsoft ACPI-Compliant System IRQ 427 Microsoft ACPI-Compliant System IRQ 428...
  • Page 170 Appendix B Technical Summary Assignment IRQ 447 Microsoft ACPI-Compliant System IRQ 448 Microsoft ACPI-Compliant System IRQ 449 Microsoft ACPI-Compliant System IRQ 450 Microsoft ACPI-Compliant System IRQ 451 Microsoft ACPI-Compliant System IRQ 452 Microsoft ACPI-Compliant System IRQ 453 Microsoft ACPI-Compliant System IRQ 454 Microsoft ACPI-Compliant System IRQ 455...
  • Page 171 Appendix B Technical Summary Assignment IRQ 474 Microsoft ACPI-Compliant System IRQ 475 Microsoft ACPI-Compliant System IRQ 476 Microsoft ACPI-Compliant System IRQ 477 Microsoft ACPI-Compliant System IRQ 478 Microsoft ACPI-Compliant System IRQ 479 Microsoft ACPI-Compliant System IRQ 480 Microsoft ACPI-Compliant System IRQ 481 Microsoft ACPI-Compliant System IRQ 482...
  • Page 172 Appendix B Technical Summary Assignment IRQ 501 Microsoft ACPI-Compliant System IRQ 502 Microsoft ACPI-Compliant System IRQ 503 Microsoft ACPI-Compliant System IRQ 504 Microsoft ACPI-Compliant System IRQ 505 Microsoft ACPI-Compliant System IRQ 506 Microsoft ACPI-Compliant System IRQ 507 Microsoft ACPI-Compliant System IRQ 508 Microsoft ACPI-Compliant System IRQ 509...

  • Page 173: I/O Map

    Appendix B Technical Summary Assignment IRQ 4294967292 Standard SATA AHCI Controller Intel(R) Celeron(R)/Pentium(R) Processor PCI IRQ 4294967293 Express Root Port - 5AD9 Intel(R) Celeron(R)/Pentium(R) Processor PCI IRQ 4294967294 Express Root Port - 5AD8 Note: These resource information were gathered using Windows 10 (the IRQ could be assigned differently depending on OS).
  • Page 174 Appendix B Technical Summary I/O Map Assignment 0x00000070-0x00000070 System CMOS/real time clock 0x00000078-0x00000CF7 PCI Express Root Complex 0x00000080-0x0000008F Motherboard resources 0x00000092-0x00000092 Motherboard resources 0x000000A0-0x000000A1 Programmable interrupt controller 0x000000A4-0x000000A5 Programmable interrupt controller 0x000000A8-0x000000A9 Programmable interrupt controller 0x000000AC-0x000000AD Programmable interrupt controller 0x000000B0-0x000000B1 Programmable interrupt controller 0x000000B2-0x000000B3 Motherboard resources...

  • Page 175: Memory Map

    Appendix B Technical Summary I/O Map Assignment Intel(R) Celeron(R)/Pentium(R) Processor 0x0000D000-0x0000DFFF PCI Express Root Port - 5AD9 Intel(R) Celeron(R)/Pentium(R) Processor 0x0000E000-0x0000EFFF PCI Express Root Port - 5AD8 Intel(R) HD Graphics 0x0000F000-0x0000F03F Intel(R) Celeron(R)/Pentium(R) Processor 0x0000F040-0x0000F05F SMBUS - 5AD4 0x0000F060-0x0000F07F Standard SATA AHCI Controller 0x0000F080-0x0000F083 Standard SATA AHCI Controller 0x0000F090-0x0000F097...
  • Page 176 Appendix B Technical Summary Memory Map Assignment Intel(R) I210 Gigabit Network 0x91280000-0x912FFFFF Connection #2 Intel(R) I210 Gigabit Network 0x9127C000-0x9127FFFF Connection #2 Intel(R) I210 Gigabit Network 0x91180000-0x911FFFFF Connection Intel(R) I210 Gigabit Network 0x9117C000-0x9117FFFF Connection High precision event timer 0xFED00000-0xFED003FF Intel(R) Serial IO I2C Host Controller - 0x91318000-0x91318FFF 5AAC Intel(R) Serial IO I2C Host Controller -...

  • Page 177: Configuring Watchdog Timer

    Appendix B Technical Summary Configuring WatchDog Timer The I/O port address of the watchdog timer is 2E (hex) and 2F (hex). 2E (hex) is the address port. 2F (hex) is the data port. User must first assign the address of register by writing address value into address port 2E (hex), then write/read data to/from the assigned register through data port 2F (hex).
  • Page 178 Appendix B Technical Summary Code example for watch dog timer Enable the watchdog timer and set the timeout interval to 30 seconds. ; ------------------------- Enter to extended function mode ------------------------------- ; ----------------------- Select Logical Device 7 of watchdog timer --------------------- ;---------------------------------Enable Watch dog feature ------------------------------ ;...

  • Page 179: Flash Bios Update

    Appendix B Technical Summary Flash BIOS Update I. Prerequisites Prepare a bootable media (e.g. USB storage device) which can boot the system to EFI Shell. Download and save the BIOS file (e.g. B9861PM1.bin) to the bootable device. Copy AMI flash utility – AfuEfix64.efi (v5.12.02.2028) into a bootable device.
  • Page 180 Appendix B Technical Summary II. AFUEFI Command for System BIOS Update AFUEFI command for system BIOS update AfuEfix64.efi is the AMI firmware update utility; the command line is shown as below: AfuEfix64 <ROM File Name> [option1] [option2]…. Users can type “AfuEfix64/ ?”...
  • Page 181 Appendix B Technical Summary III. BIOS Update Procedure Use the bootable USB storage to boot up the system into the EFI Shell. Type "AfuEfix64 B986xxxx.bin /p /b /n /x” and press Enter to start the flash procedure. (Note that xxxx means the BIOS revision part, e.g. 0PM1…) During the update procedure, you will see the BIOS update process status and its percentage.
  • Page 182 Appendix B Technical Summary Reboot the system and verify if the BIOS version shown on the initialization screen has been updated. SP-655X-R USER MANUAL Page: B-27...
