- Page 1 Installation Manual Intellivox ADC-V90 & ADC-H90 models (SKU: IVX-576125, IVX-577125, IVX-577135, IVX-576126, IVX-577126 and IVX-577136) EN 54 -24...
-
Page 2: Ec Declaration Of Conformity
® Intellivox ADC Installation Manual EC DECLARATION OF CONFORMITY This document confirms that the product manufactured by Harman Professional Kft. and described hereafter is in conformity with the following directive(s) and meets the requirements of the following standard(s): Applicable directive(s) -
Page 3: Declaration Of Performance
Part 24: Components of voice alarm systems - Loudspeakers Provided options Type B Name, registered trade name or registered trade mark and contact address of the manufacturer as required pursuant to Article 11(5): Name Harman Professional Kft. Address Szilva u. 1-3. H-7632 Pecs Hungary www.jblpro.com Branding/Trade name Models are sold under both AXYS &... - Page 4 JBL Professional ® Intellivox ADC Installation Manual Where applicable, name and contact address of the authorised representative whose mandate covers the tasks specified in Article 12(2): Not applicable System or systems of assessment and verification of constancy of performance of the construction product as set out in Annex V: System 1 Declaration of performance concerning a construction product covered by a harmonised standard:...
- Page 5 JBL Professional Intellivox ADC Installation Manual ® Declared performance: Essential characteristics Performance Harmonised technical specification EN 54-24:2008 - Type B Frequency response limit Passed Section 4.2 Reproducibility Passed Section 5.2 Rated impedance Passed Section 5.3 Horizontal and vertical coverage angles Passed Section 5.4 Maximum sound pressure level...
- Page 6 JBL Professional ® Intellivox ADC Installation Manual 10. The performance of the product identified in points 1 and 2 is in conformity with the declared performance in point 9. This declaration of performance is issued under the sole responsibility of the manufacturer identified in point 4.
-
Page 7: User's Notice And Disclaimer
JBL Professional Intellivox ADC Installation Manual ® USER’S NOTICE AND DISCLAIMER No part of this manual including the software The information contained in this manual has described in it may be reproduced, transmitted, been carefully checked for accuracy; however no transcribed, stored in a database system or guarantee is given with respect to its correctness. -
Page 8: Table Of Contents
JBL Professional Intellivox ADC Installation Manual ® TABLE OF CONTENTS EC declaration of conformity ..........2 Declaration of Performance . -
Page 9: Important Safety Instructions
JBL Professional ® Intellivox ADC Installation Manual 1. IMPORTANT SAFETY INSTRUCTIONS This symbol is intended to alert you to the 8) Do not install near any heat sources such as radiators, presence of uninsulated dangerous voltages heat registers, stoves, or other apparatus (including within the product’s enclosure that may be amplifiers) that produce heat. -
Page 10: Introduction
JBL Professional Intellivox ADC Installation Manual ® 2. INTRODUCTION APPLICABLE MODELS, AND VARIANTS This manual describes the recommended installation procedure for the JBL Intellivox ADC range of loudspeakers. The Intellivox ADC range is available in two versions: The ADC range are compact 100 V/70 V line units intended •... -
Page 11: What's In The Packaging
JBL Professional ® Intellivox ADC Installation Manual WHAT’S IN THE PACKAGING In addition to the loudspeaker itself, each unit is packed with the following items: • Installation manual (this document) • ADC Datasheet • Box containing: ITEM Mounting brackets Speaker mounting Mounting bracket fixings 30 mm hex-headed screws with washers and wall plugs (wall) -
Page 12: Installation Guide
JBL Professional Intellivox ADC Installation Manual ® 3. INSTALLATION GUIDE PREPARING FOR INSTALLATION INTELLIVOX ADC CONNECTIONS Before starting to install the Intellivox ADC loudspeaker, a The Intellivox ADC range loudspeakers are designed to number of points should be considered. be connected to 100 V or 70 V line speaker distribution systems. -
Page 13: Mechanical Installation
JBL Professional ® Intellivox ADC Installation Manual MECHANICAL INSTALLATION Acoustic Centre Mounting an Intellivox ADC loudspeaker is a straight- forward procedure, but it is essential to understand that the precise mounting location is extremely critical. The correct mounting location is defined as part of the acoustical design process and the installer should make sure that he/she has this information before commencing to mount the Intellivox ADC. -
Page 14: Model H90 Only
JBL Professional Intellivox ADC Installation Manual ® MODEL H90 ONLY The location of the acoustic centre of the Model H90 is Reference point for acoustical mounting in the centre of the unit, both horizontally and vertically. position - H90 This is indicated by the yellow sticker on the front grill. The H90 should be mounted accurately so that its acoustic centre is at the position identified by the site survey. -
Page 15: Model V90 Only
JBL Professional ® Intellivox ADC Installation Manual MODEL V90 ONLY permitting the Intellivox to be rotated through 45 or 90 Model V90 only: There are three options for mounting degrees either way respectively. Refer to page 17 for the Intellivox ADC Model V90: ordering information. -
Page 16: Mounting Procedure
JBL Professional Intellivox ADC Installation Manual ® MOUNTING PROCEDURE 7. Remove the front grill from the loudspeaker by gently lifting it at the locations of the ‘snap-on’ fittings which The general procedure for mounting the Intellivox ADC hold it in place. Remove the protective foam. Unscrew Models V90 or H90 using the standard brackets is described the four self-tapping screws securing the connector below. -
Page 17: Wiring Details
JBL Professional ® Intellivox ADC Installation Manual WIRING DETAILS TAP SETTING When the Intellivox ADC has been mounted in the The internal 100 V/70 V transformer’s primary tapping correct position, it may be connected up. Connection is should be set according to the power requirements of the straightforward;... -
Page 18: Correction Eq And High-Pass Filter
JBL Professional Intellivox ADC Installation Manual ® CORRECTION EQ AND HIGH-PASS FILTER Note that this does not apply to the integral load monitoring of the AXYS PB-400/PB-800 Many building systems will include some Industry Amplifiers; these amplifiers do not use a provision for equalization (EQ) adjustment at the signal DC signal for load monitoring purposes. -
Page 19: Pilot-Tone Indicator
JBL Professional ® Intellivox ADC Installation Manual SPEAKER PROTECTION In a PA/VA system, it is important that the failure of a single loudspeaker does not incapacitate the rest of the system. HOLE FOR SECURITY SCREW M4 TAPPED HOLE The ADC range of speakers incorporate three protection FRONT OF systems to prevent this. -
Page 20: Appendices
JBL Professional Intellivox ADC Installation Manual ® 4. APPENDICES OPTIONAL ACCESSORIES Listed below are some optional accessories which may be required for a particular installation. DESCRIPTION ORDER SKU Intellivox wall bracket set (2 pcs), 25 mm, RAL 9007 IVX-802227 Intellivox hinge bracket 90°, RAL 9007 IVX- 802005 Intellivox swivel bracket 90°, RAL 9007 IVX- 806668... - Page 21 JBL Professional 8500 Balboa Boulevard Northridge, CA 91329 U.S.A. © Copyright 2020 JBL Professional www.jblpro.com...
