Summary of Contents for PLANET ECLIPSE EMEK 68CAL
- Page 1 WORKSHOP MANUAL .68CAL PLANET ECLIPSE: EMEK .68CAL...
- Page 2 WARNING READ CAREFULLY BEFORE USE THE PLANET ECLIPSE EMEK IS NOT A TOY. PAINTBALL SAFETY RULES MUST BE FOLLOWED AT NeverputyourfingeroranyforeignobjectsintothepaintballfeedtubeoftheEMEK. ALL TIMES. Never allow pressurised gas to come into contact with any part of your body. Careless or improper use of the EMEK, including failure to follow instructions and warnings within Alwaysremovethefirststageregulator and relieve all residual gas pressure from the EMEK before this Workshop Manual could cause serious injury or death.
-
Page 3: Table Of Contents
LEAKS FROM THE INLINE REGUALTOR PAL LOADER NOT FEEDING PAL QD LOADER NOT FEEDING BREAKING PAINT IN THE BREECH OR BARREL SHOOTING MULTIPLE SHOTS WHEN TRIGGER HELD DOWN PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL EMEK .68 CAL © 2022 PLANET ECLIPSE LTD... -
Page 4: Bolt System
BOLT SYSTEM BOLT GUIDE BOLT #10-32X0.5” CAP HEAD SCREW BACKCAP VALVE CHAMBER SPOOL SWITCH SPOOL SPRING GUIDE SPOOL SPRING PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL EMEK .68 CAL © 2022 PLANET ECLIPSE LTD... -
Page 5: Frame Assembly
FRAME ASSEMBLY PLATE SCREW TRIGGER SPRING 3-WAY & TRANSFER BLOCK TRIGGER PLATE TRIGGER PUSH ROD FRAME TRIGGER PIN TRIGGER SAFETY 3-WAY PIN PUSH ROD PIN PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL EMEK .68 CAL © 2022 PLANET ECLIPSE LTD... -
Page 6: 03 3-Way Valve
3-WAY VALVE SOLENOID GASKET 3-WAY CAP TRANSFER BLOCK 3-WAY SPOOL SOLENOID GASKET 4X1 NBR70 O-RING #6 SPOOL SEAL 3-WAY BODY #6 SPOOL SEAL PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL EMEK .68 CAL © 2022 PLANET ECLIPSE LTD... -
Page 7: Fl 3-Way Valve
TRANSFER BLOCK SOLENOID GASKET 3-WAY SPOOL QEV DIAPHRAM 3-WAY SPOOL GUIDE 4X1 NBR70 O-RING 004 NBR70 O-RING QEV CAP 3-WAY SPOOL SPACER 004 NBR70 O-RING 3-WAY BODY PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL EMEK .68 CAL © 2022 PLANET ECLIPSE LTD... -
Page 8: Asa Screws
ASA SCREWS FRAME NUT FRAME NUT 10-32 UNF X 1” CAP HEAD SCREW PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL EMEK .68 CAL © 2022 PLANET ECLIPSE LTD... -
Page 9: Regulator Assembly
PURGE POPPET SPRING ADJUSTER SCREW REGULATOR CAP 011 NBR70 O-RING 016 NBR70 O-RING REGULATOR BODY REGULATOR PISTON 015 NBR70 O-RING 015 NBR70 O-RING REGULATOR SPRING ASA BODY PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL EMEK .68 CAL © 2022 PLANET ECLIPSE LTD... -
Page 10: Pal Feedtube Assembly
006 NBR70 O-RING FEED SWIVEL FEED LEVER 10-32 UNF X 0.625” CAP HEAD SCREW 10-32 UNF X 0.5” CAP HEAD SCREW PAL FEEDTUBE PALS PLUNGER 3X1 NBR70 O-RING PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL EMEK .68 CAL © 2022 PLANET ECLIPSE LTD... -
Page 11: Pal Qd Feedtube Assembly
PAL QD FEEDTUBE ASSEMBLY LATCH BUTTON 10-32 UNF X 0.5” CAP HEAD SCREW PAL QD FEED NECK PAL PLUNGER 3X1 NBR70 O-RING PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL EMEK .68 CAL © 2022 PLANET ECLIPSE LTD... -
Page 12: Detent Assembly
DETENT ASSEMBLY RIGHT DETENT COVER RUBBER DETENT 6-32 UNC X 0.3125” COUNTER SUNK SCREW LEFT DETENT COVER BS PLUG PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL EMEK .68 CAL © 2022 PLANET ECLIPSE LTD... -
Page 13: Can
020 NBR70 O-RING SECTION B-B 017 NBR70 O-RING PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL EMEK .68 CAL © 2022 PLANET ECLIPSE LTD... -
Page 14: Bolt
BOLT 015 NBR90 O-RING 013 NBR70 O-RING SECTION C-C 14X2 NBR70 O-RING BOLT PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL EMEK .68 CAL © 2022 PLANET ECLIPSE LTD... -
Page 15: Bolt Guide
BOLT GUIDE 014 NBR70 O-RING 14X2 NBR70 O-RING 013 NBR70 O-RING 013 NBR70 O-RING 013 NBR70 O-RING SECTION D-D BOLT GUIDE PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL EMEK .68 CAL © 2022 PLANET ECLIPSE LTD... -
Page 16: Spool
SPOOL 012 NBR70 O-RING 011 NBR70 O-RING 008 NBR70 O-RING 012 NBR70 O-RING SECTION E-E SPOOL SPOOL INSERT PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL EMEK .68 CAL © 2022 PLANET ECLIPSE LTD... -
Page 17: Switch
SWITCH 016 NBR70 O-RING 016 NBR70 O-RING SECTION G-G SWITCH PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL EMEK .68 CAL © 2022 PLANET ECLIPSE LTD... -
Page 18: Valve Chamber
VALVE CHAMBER 020 NBR70 O-RING VALVE CHAMBER SECTION F-F 020 NBR70 O-RING 020 NBR70 O-RING PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL EMEK .68 CAL © 2022 PLANET ECLIPSE LTD... -
Page 19: Leaking Down Barrel
14X2 NBR70 O-RING (R) 017 NBR70 O-RING (C) SPOOL SWITCH BODY METAL BODY SWITCH 011 NBR70 O-RING (C) (INSIDE FACE) (R) (INSIDE FACE) (R) 012 NBR70 O-RING (R) PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL EMEK .68 CAL © 2022 PLANET ECLIPSE LTD... -
Page 20: First Shot Drop Off (Fsdo)
BOLT (INSIDE FACE) (C) 013 NBR70 O-RING (C) BOLT (OUTSIDE FACE) (R) 013 NBR70 O-RING (R) 017 NBR70 O-RING (R) SPOOL SWITCH 016 NBR70 O-RING (R) 011 NBR70 O-RING (R) PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL EMEK .68 CAL © 2022 PLANET ECLIPSE LTD... -
Page 21: 18 'Puffs' And Does Not Fire
020 NBR70 O-RING (R) SPOOL 008 NBR70 O-RING (R) (IF THIS O-RING IS DAMAGED, INCORRECTLY SIZED OR NOT LUBRICATED CORRECTLY THEN THE MARKER MAY EXHIBIT CONSTANT LOW VELOCITY) PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL EMEK .68 CAL © 2022 PLANET ECLIPSE LTD... -
Page 22: Leaks From The 3-Way Valve
SOLENOID GASKET (R) TRANSFER BLOCK #6 SOLENOID SEAL (C) (TOP AND BOTTOM)(R) EMEK BODY (R) 4X1 NBR70 O-RING (C) SOLENOID GASKET (R) 3-WAY BODY (R) 010 NBR70 O-RING (R) PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL EMEK .68 CAL © 2022 PLANET ECLIPSE LTD... -
Page 23: Leaks From The Fl 3-Way Valve
TRANSFER BLOCK (TOP AND BOTTOM) (R) SOLENOID GASKET (R) QEV DIAPHRAM (R) SPOOL GUIDE (INSIDE FACE) (R) 3-WAY BODY (R) 010 NBR70 O-RING (R) 4X1 NBR70 O-RING (R) PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL EMEK .68 CAL © 2022 PLANET ECLIPSE LTD... -
Page 24: High Velocity
CLEAN AND CHANGE HIGHLIGHTED SEALS AND FACES (C) = COMMON FAULT (R) = RARE FAULT REGULATOR ADJUSTER SCREW REGULATOR PISTON REGULATOR SEAL (R) PURGE POPPET (R) REGULATOR PISTON (C) PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL EMEK .68 CAL © 2022 PLANET ECLIPSE LTD... -
Page 25: Leaks From The Inline Regualtor
REGULATOR CAP (R) 011 NBR70 O-RING (R) 016 NBR70 O-RING (C) REGULATOR PISTON (R) REGULATOR BODY (R) REGULATOR BODY (R) 011 NBR70 O-RING (R) ASA MAIN BODY (R) PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL EMEK .68 CAL © 2022 PLANET ECLIPSE LTD... -
Page 26: Pal Loader Not Feeding
(R) = RARE FAULT PAL FEEDNECK PLUNGER PORT (C) PAL PLUNGER (R) 3X1 NBR70 O-RING (C) BODY SHELL PLUNGER PORT (R) METAL BODY PLUNGER PORT & BLEED HOLE (R) PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL EMEK .68 CAL © 2022 PLANET ECLIPSE LTD... -
Page 27: Pal Qd Loader Not Feeding
(R) = RARE FAULT PAL FEEDNECK PLUNGER PORT (C) PAL PLUNGER (R) 3X1 NBR70 O-RING (C) BODY SHELL PLUNGER PORT (R) METAL BODY PLUNGER PORT & BLEED HOLE (R) PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL EMEK .68 CAL © 2022 PLANET ECLIPSE LTD... -
Page 28: Breaking Paint In The Breech Or Barrel
BREAKING PAINT IN BREECH OR BARREL CLEAN AND CHANGE HIGHLIGHTED SEALS AND FACES (C) = COMMON FAULT (R) = RARE FAULT RUBBER DETENT (C) RUBBER DETENT (C) 013 NBR70 O-RING (R) PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL EMEK .68 CAL © 2022 PLANET ECLIPSE LTD... -
Page 29: Shooting Multiple Shots When Trigger Held Down
CLEAN AND CHANGE HIGHLIGHTED SEALS AND FACES (C) = COMMON FAULT (R) = RARE FAULT 016 NBR70 O-RING (C) 020 NBR70 O-RING (C) 012 NBR70 O-RING (C) PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL EMEK .50 CAL © 2023 PLANET ECLIPSE LTD... - Page 30 130 Franklin Street Unit 14 Premier Park, Acheson Way Pe-Paintball.De Gmbh Building L4 & L5 Trafford Park Road, Trafford Park © Planet Eclipse Ltd. Langenberger Str. 9 Tor 5 & 6 Warren, RI, 02885, USA Manchester, M17 1GA, England Düsseldorf 40233, Germany...
