Summary of Contents for Amos Apro 5
- Page 1 Apro 5 Digital Slide Scaner Operation Manual AMOS SCIENTIFIC PTY.LTD. ABN37 159 778 1 www.amos-scientific.com - 0 -...
-
Page 2: Table Of Contents
Content 1. Safety Precautions ............................. - 2 - 2. Use Precautions ............................- 2 - 2.1. Before Using ............................- 2 - 2.2. In Use ..............................- 2 - 2.3. Other Precautions ..........................- 3 - 3. Handling Precautions ..........................- 3 - 4. -
Page 3: Safety Precautions
1. Safety Precautions ※ Important Statement: The following safety instructions are presented to protect the device and prevent the user from physical, mental and financial losses. Please read carefully and do after the instructions. It will be all the user’s duty if there is any problem caused by operations against the instructions and we the manufacturer will not responsible for it. -
Page 4: Other Precautions
(5) The normal operation is affected by an earthquake, thunderstorm, lightning, or power failure occurs. 2.3. Other Precautions (1) Only personnel who is well-trained can operate the machine. People without training please don’t operate the machine arbitrarily. (2) When the machine fails, please don’t dissemble or repair by personnel untrained. (3) Do not place heavy objects above the instrument to avoid extrusion deformation. -
Page 5: Brief Introduction Of The Product
4. Brief Introduction of the Product 4.1. Product Characteristics The product is used for scanning pathological sections in medical institutions, laboratories and other places. It is able to make rapid and uninterrupted digital scanning of 5 pathological sections one time and generate a full-vision and high-definition digital pathological image. -
Page 6: Product Formation
4.3. Product Formation Apro 5 Digital Pathological Section Scanner consists of mechanical system, imaging system, software system and computer system. Details are as follows: Items Remarks High-precision Moving Platform Three-axis (X/Y/Z) Automatic Control Mechanical Automatic Loading System Magnification Switch 20X/40X... -
Page 7: Product Identification
4.7. Copyright Information The copyright is owned by AMOS SCIENTIFIC PTY. LTD. It may not be reproduced or disclosed to third parties without the written permission of the Company. AMOS has the Ownership and the Power of Interpretation for this instruction. - Page 8 When the software is started, the READY light on the device is on. When the scanning software is started, the system automatically initializes it. ① ② ③ ① Scanning Software Interface: ①Multi-section Area②Scanning Area③Lens (20x or 40x)
- Page 9 1.1.2 Load the Slices ① Take out the tray and load the slices. ②Lift the hatch up. Place the side of the bar code on the left side, so that the device can automatically identify the code. Gently pull the slider on the right side of the tray, accurately place the slices into the cutting slot, and then reset the latch.
- Page 10 ③Put the tray back on the platform and push in. Then close the hatch door. 1.1.3 Image Previewing At the beginning of scanning, click the previewing button and the software will automatically identify the slices to be scanned and display the tissue shape, size, position and label information on the scanning interface.
- Page 11 The left is multi-section area, and the right is 5pcs of slice previewing image. 1.1.4 Start Scanning Make sure the scanning area and click [Scan] to start scanning. At the moment, the READY light is off and the RUN light is on. click [Scan] to start scanning READY light off, RUN light on A green progress bar displays in the scanning progress.
- Page 12 1.1.5 Scanning Completed Scanning When the progress bar reaches 100%, the scanning is completed. At the moment, the RUN light is off and the READY light is on. The scanning is completed. the RUN light is off and the READY light is on. Scanning Completed 组...
-
Page 13: Image Viewing
5.4. Image Viewing The [Mode] in the lower right corner of the software can switch among browsing mode, preview mode and scanning mode. Support full-vision magnification up to 40× no pole zoom or fixed magnification zoom, seamless image, fast and smooth browsing, no stalling or delay. 双... -
Page 14: Product Management
6. Product Management 6.1. Storage 1.1.7 Please place the instrument away from the wall and the ground. Pay attention to moisture, dust, ventilation and fire to ensure product quality. 1.1.8 When not in use, remove the power cable from the power supply and also remove the power cable from the device. -
Page 15: After-Sales Service
6.3.2 If the cover of the device is stained, gently wipe it with a soft cloth. If the stain is serious, using a soft cloth soaked in neutral detergent, squeezed dry and gently wipe the machine. Then dry the machine with a dry cloth. - Page 16 Published by: AMOS SCIENTIFIC PTY.LTD Factory 24, 632-642 Clayton Road, Clayton South VIC3169，Melbourne, Australia Tel: +61-410190188 ABN 37 159 778 140 www.amos-scientific.com...
