- Page 1 COMFORT BOILER CONTROL User’s manual Manufacturer: AUTOTERM LLC Paleju 72, Marupe, Latvia, LV-2167 warranty@autoterm.com Warranty Department service@autoterm.com Technical Support www.autoterm.com 10.2023 - v1.0...
-
Page 2: Table Of Contents
CONTENTS INTRODUCTION ..........................3 SAFETY INSTRUCTIONS ........................3 LIABILITY ............................4 GENERAL INFORMATION ......................5 1.1. DISPLAY ........................... 5 1.2. ROTARY KNOB ......................... 6 1.3. BACK BUTTON ......................... 6 1.4. QUICK BUTTON ....................... 6 1.5. LED INDICATORS ......................6 MOUNTING AND CONNECTION ....................7 OPERATION AND SETTINGS ..................... -
Page 3: Introduction
Your requirements, so its quality satisfies every customer. Comfort Boiler Control is designed to be intuitive and comfortable to use, to ensure the best experience when it comes to controlling Your climate and domestic water temperature. -
Page 4: Liability
The length of the control panel wiring cannot exceed 15 meters. Personnel certified by AUTOTERM is needed In case of faults in the operation of the heater, contact specialized repair organizations authorized by AUTOTERM. -
Page 5: General Information
1. GENERAL INFORMATION 1. DISPLAY 3. BACK BUTTON 5. LED INDICATORS 2. ROTARY KNOB 4. QUICK BUTTON 1.1. DISPLAY • While in sleep mode: o display is inactive; o screensaver shows: ─ temperature; ─ current time and date; ─ symbol of set operation mode, if active. ─... -
Page 6: Rotary Knob
When an operation mode is active, the respective symbol is displayed on the main screen (under the current time) and it works as a quick menu. By rotating the knob three options can be accessed: • Active operation mode • Shut off the heater •... -
Page 7: Mounting And Connection
To increase the length of control panel wiring, use only designated extension wirings. When connected to the power supply control panel turns on automatically. When turned on LED indicators light up, while showing AUTOTERM logos on the display. Connection process takes approx. up to 20 seconds. If connection is established display shows main screen. -
Page 8: Operation And Settings
3. OPERATION AND SETTINGS 3.1. MAIN MENU The main menu can be accessed from the main screen by pressing the rotary knob once. Navigate through the menu by turning the knob. To enter the selected menu, press the knob once. Is used to set and enable/disable up to 3 timers. - Page 9 Editing the timer Set the time of day for heater to start: • Set hours and confirm; • Set minutes and confirm. Set working duration of the heater. Duration can be set from 30min to 720min* with increasing step of 5min. *up to 120min for liquid heaters Set days for heater to start, where: •...
-
Page 10: Heating
3.3. HEATING In “Heating” menu different operation modes for heating can be set, depending on the connceted heater. To set heater modes select the “Heating” menu from the main menu by pressing the knob once and then select one of the heating modes: Temperature can be set in a range of 0°C up to 30°C, with step of 1°C. - Page 11 Setting Power mode Select “Power mode” from the menu. Set power level and confirm. Set work time and confirm. When mode is active, respective symbol is shown on the main screen. Setting Heat + Ventilation mode Select “Heat + Ventilation” from the menu. Set temperature and confirm.
- Page 12 Water heating mode Select “Water heating mode” from the main menu. Set water temperature and confirm min 50°C max 75°C. Set work time and confirm. When mode is active, respective symbol is shown on the main screen. Default value is 50°C. These settings can be changed in “Settings -> Boiler-> Hysteresis”(default range 10°C.
-
Page 13: Settings
4. SETTINGS In the “Settings” menu general settings for control panel and advanced settings for the heater can be changed. Available settings are displayed depending on the connected heater. To enter the “Settings” menu select it from the main menu by pressing the knob once and select one of the options. -
Page 14: Boiler
BOILER 4.4. BOILER SETTINGS – change boiler settings: • o HYSTERESIS – water heating hysteresis defines heating start and stop sequence. Value can be adjusted from 10°C to 20°C. o TEMPERATURE – controls water temperature in any heating mode. The goal of this LIMIT function is to not allow water to pass above the desired water temperature. -
Page 15: Errors And Maintanace
Failure to do so may lead to premature failure of the heater. That is why AUTOTERM Comfort Boiler Control has a built-in reminder to start the heater for 30 minutes if it has been out of operation for at least 30 days.
