NivoGuide® 8200
Two-wire 4 ... 20 mA/HART
Rod and cable probe
-196 ... +280 °C, -196 ... +450 °C
TDR sensor for continuous level and interface
measurement of liquids
Technical information / Instruction manual
Document ID: 61899

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UWT NivoGuide 8200 and is the answer not in the manual?

Questions and answers

Related Manuals for Solutions UWT NivoGuide 8200

Summary of Contents for Solutions UWT NivoGuide 8200

  • Page 1 NivoGuide® 8200 Two-wire 4 … 20 mA/HART Rod and cable probe -196 … +280 °C, -196 … +450 °C TDR sensor for continuous level and interface measurement of liquids Technical information / Instruction manual Document ID: 61899...

  • Page 2: Table Of Contents

    NivoGuide® 8200 • Two-wire 4 … 20 mA/HART Contents Contents About this document ....................... 4 Function ........................... 4 Target group ........................4 Symbols used........................4 For your safety ......................... 5 Authorised personnel ....................... 5 Appropriate use ........................ 5 Warning about incorrect use ..................... 5 General safety instructions ....................
  • Page 3 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART Contents Trademark ........................77 Safety instructions for Ex areas Take note of the Ex specific safety instructions for Ex applications. These instructions are attached as documents to each instrument with Ex approval and are part of the operating instructions. Editing status: 2019-07-30...

  • Page 4: About This Document

    NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 1 About this document About this document Function This operating instructions provides all the information you need for mounting, connection and setup as well as important instructions for maintenance, fault rectification, the exchange of parts and the safety of the user. Please read this information before putting the instrument into operation and keep this manual accessible in the immediate vicinity of the device.

  • Page 5: For Your Safety

    NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 2 For your safety For your safety Authorised personnel All operations described in this documentation must be carried out only by trained, qualified personnel authorised by the plant operator. During work on and with the device, the required personal protective equipment must always be worn. Appropriate use NivoGuide 8200 is a sensor for continuous level measurement.

  • Page 6: Eu Conformity

    NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 2 For your safety EU conformity The device fulfils the legal requirements of the applicable EU direc- tives. By affixing the CE marking, we confirm the conformity of the instrument with these directives. The EU conformity declaration can be found on our homepage. Electromagnetic compatibility Instruments in four-wire or Ex-d-ia version are designed for use in an industrial environment.

  • Page 7: Product Description

    NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 3 Product description Product description 3.1 Configuration Type label The type label contains the most important data for identification and use of the instrument: Fig. 1: Layout of the type label (example) Instrument type Product code Approvals (option) Power supply and signal output, electronics Protection rating Probe length (measurement accuracy optional) Process and ambient temperature, process pressure...

  • Page 8: Principle Of Operation

    NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 3 Product description – If necessary, further certificates Information: Optional instrument features are also described in this operating instructions manual. The respective scope of delivery results from the order specification. Principle of operation Application area The NivoGuide 8200 is a level sensor with cable or rod probe for continuous level or interface measurement, particularly suitable for applications in high temperatures up to +450 °C (842 °F).
  • Page 9 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 3 Product description Fig. 3: Interface measurement 1 Sensor reference plane (seal surface of the process fitting) d1 Distance to the interface d2 Distance to the level TS Thickness of the upper medium (d1 - d2) h1 Height - Interface h2 Height - Level L1 Lower medium L2 Upper medium...

  • Page 10: Packaging, Transport And Storage

    NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 3 Product description Output signal The instrument is always preset to the application "Level measure- ment". For the interface measurement, you can select the requested output signal with the setup. Packaging, transport and storage Packaging Your instrument was protected by packaging during transport.

  • Page 11: Mounting

    NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 4 Mounting Mounting General instructions Screwing in On devices with a threaded fitting, the hexagon on the process fitting must be tightened with a suitable wrench. See chapter "Dimensions" for wrench size. Warning: The housing or the electrical connection may not be used for screw- ing in! Depending on the device version, tightening can cause dam- age, e.

  • Page 12: Mounting Instructions

    NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 4 Mounting the process conditions in chapter "Technical data" of the operating instructions or on the type label. Make sure before mounting that all parts of the instrument exposed to the process are suitable for the existing process conditions. These are mainly: •...
  • Page 13 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 4 Mounting Type of vessel Plastic vessel/Glass vessel The guided microwave principle requires a metallic surface on the process fitting. Therefore, in plastic vessels, etc., use an instru- ment version with flange (from DN 50) or place a metal sheet (ø > 200 mm/8 in) beneath the process fitting when screwing it in. Make sure that the plate has direct contact with the process fitting. When mounting rod or cable probes in vessels without metal walls, e.g. in plastic vessels, the measured value can be influenced by strong electromagnetic fields (emitted interference according to EN 61326: class A).
  • Page 14 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 4 Mounting ≤ 150 mm ( 5.91") DN40 ... DN150 ≤ 100 mm (3 .94") > DN150 ... DN200 Fig. 6: Mounting socket When welding the socket, make sure that the socket is flush with the vessel top. Fig. 7: Socket must be installed flush Unfavourable mounting 2 Socket flush - optimum mounting Welding work Before beginning the welding work, remove the electronics module from the sensor.
  • Page 15 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 4 Mounting Fig. 8: Mounting of the sensor with inflowing medium Measuring range The reference plane for the measuring range of the sensors is the sealing surface of the thread or flange. Keep in mind that a min. distance must be maintained below the refer- ence plane and possibly also at the end of the probe - measurement in these areas is not possible (dead zone). The length of the cable can be used all the way to the end only when measuring conductive products. These dead zones for different mediums are listed in chap-...
  • Page 16 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 4 Mounting Microwaves can penetrate many plastics. This is why plastic tubes are problematic for measurement applications. If durability is no problem, we recommend the use of uncoated metal standpipes. When the NivoGuide 8200 is used in bypass tubes, contact with the tube wall must be avoided.
  • Page 17 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 4 Mounting Note: Measurement in a standpipe is not recommended for extremely adhe- sive products. In case of slight buildup, you should choose a bypass tube with bigger diameter. Instructions for the measurement: •...
  • Page 18 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 4 Mounting ø 150 - 200 mm ø 150 - 200 mm (5.91 - 7.87") (5.91 - 7.87") Fig. 10: Mounting in a standpipe Holes (for mixing) Standpipe - vertically mounted - max. deviation 10 mm (0.4 in) Ventilation opening A Rod probe with spacer (steel) B Cable probe with centering weight...
  • Page 19 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 4 Mounting • A false signal suppression with installed sensor is generally rec- ommended to achieve the best possible accuracy. Mounting in the vessel Instruments for a temperature range up to +280 °C (536 °F) or up to insulation +450 °C (842 °F) have a distance piece between process fitting and electronics housing.
  • Page 20 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 4 Mounting Keep in mind that measurement is not possible below the fastening point. Fig. 12: Fasten the probe Measuring probe Retaining sleeve Fixing facility If there is a risk of the cable probe touching the vessel wall during operation due to product movements or agitators, etc., the measuring probe can be strained.
  • Page 21 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 4 Mounting If internal installations such as struts, ladders, etc. are present on the vessel wall, the measuring probe should be mounted at least 300 mm (11.81 in) away from the vessel wall. You can find further information in the supplementary instructions of the rod extension.

  • Page 22: Connecting To Power Supply

    NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 5 Connecting to power supply Connecting to power supply Preparing the connection Safety instructions Always keep in mind the following safety instructions: • Carry out electrical connection by trained, qualified personnel authorised by the plant operator • If overvoltage surges are expected, overvoltage arresters should be installed Warning: Only connect or disconnect in de-energized state.

  • Page 23: Connecting

    NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 5 Connecting to power supply Note: Prior to setup you have to replace these protective caps with ap- proved cable glands or close the openings with suitable blind plugs. On plastic housings, the NPT cable gland or the Conduit steel tube must be screwed into the threaded insert without grease.

  • Page 24: Wiring Plan, Single Chamber Housing

    NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 5 Connecting to power supply Fig. 14: Connection steps 5 and 6 Single chamber housing Double chamber housing 6. Insert the wire ends into the terminals according to the wiring plan Information: Solid cores as well as flexible cores with wire end sleeves are insert- ed directly into the terminal openings. In case of flexible cores without end sleeves, press the terminal from above with a small screwdriver,...

  • Page 25: Wiring Plan, Double Chamber Housing

    NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 5 Connecting to power supply Electronics and connec- tion compartment 4...20mA 6 7 8 Fig. 15: Electronics and connection compartment - single chamber housing Voltage supply, signal output For display and adjustment module or interface adapter For external display and adjustment unit Ground terminal for connection of the cable screening Wiring plan, double chamber housing...
  • Page 26 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 5 Connecting to power supply Connection compartment 4...20mA Display 6 7 8 Fig. 17: Connection compartment - double chamber housing Voltage supply, signal output For display and adjustment module or interface adapter For external display and adjustment unit Ground terminal for connection of the cable screening...

  • Page 27: Set Up With The Display And Adjustment Module

    NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 6 Set up with the display and adjustment module Set up with the display and adjustment module Insert display and adjustment module The display and adjustment module can be inserted into the sensor and removed again at any time. You can choose any one of four differ- ent positions - each displaced by 90°.

  • Page 28: Adjustment System

    NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 6 Set up with the display and adjustment module Fig. 19: Installing the display and adjustment module in the double chamber housing In the electronics compartment In the connection compartment Note: If you intend to retrofit the instrument with a display and adjustment module for continuous measured value indication, a higher lid with an inspection glass is required.
  • Page 29 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 6 Set up with the display and adjustment module – Move to the menu overview – Confirm selected menu – Edit parameter – Save value • [->] key: – Change measured value presentation – Select list entry –...

  • Page 30: Parameter Adjustment - Quick Setup

    NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 6 Set up with the display and adjustment module Parameter adjustment - Quick setup Quick setup To quickly and easily adapt the sensor to the application, select the menu item "Quick setup" in the start graphic on the display and adjustment module.
  • Page 31 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 6 Set up with the display and adjustment module Info: Instrument name, hardware and software version, date of manu- facture, instrument features Note: For optimum adjustment of the measuring point, the individual sub- menu items in the main menu item "Setup"...
  • Page 32 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 6 Set up with the display and adjustment module Application - Medium Coax probes can be only used in liquids. In this menu item, the fixed type adjusted medium type "Liquid" is displayed. Application - Application In this menu item, you can select the application. You can choose between level measurement and interface measurement.
  • Page 33 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 6 Set up with the display and adjustment module Application - Dielectric This menu item is only available if you have selected interface meas- constant urement under the menu item "Application". In this menu item you can enter the dielectric constant of the upper medium.
  • Page 34 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 6 Set up with the display and adjustment module Enter the suitable distance value in m for the empty vessel (e.g. distance from the flange to the probe end) corresponding to the per- centage value. The distance refers tot he sensor reference plane (seal surface of the process fitting).
  • Page 35 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 6 Set up with the display and adjustment module If you have selected interface measurement under the menu item "Application", you can adjust the damping for the level and the inter- face separately. The default setting is a damping of 0 s.
  • Page 36 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 6 Set up with the display and adjustment module Fig. 21: Vessel height and socket correction value D Vessel height +h Positive socket correction value -h Negative socket correction value Current output mode In the menu item "Current output mode"...
  • Page 37 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 6 Set up with the display and adjustment module Note: A false signal suppression detects, marks and saves these false signals so that they are no longer taken into account for the level and interface measurement.
  • Page 38 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 6 Set up with the display and adjustment module • Select menu items and show data • Read data from the sensor into the display and adjustment module Caution: When the PIN is active, adjustment via PACTware/DTM as well as other systems is also blocked.
  • Page 39 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 6 Set up with the display and adjustment module The default setting for the displayed value 1 is "Filling height Level". Displayed value 2 In this menu item, you define the indication of the measured value on the display. You can display two different measured values. In this menu item, you define measured value 2. The default setting for the displayed value 2 is the electronics tem- perature.
  • Page 40 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 6 Set up with the display and adjustment module Peak values, distance The respective min. and max. measured value is saved in the sen- sor. The two values are displayed in the menu item "Peak values, distance".
  • Page 41 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 6 Set up with the display and adjustment module In another window you can carry out a reset of the two peak values separately. Information: If one of the display values flashes, there is actually no valid value available. Echo curve The menu item "Echo curve" shows the signal strength of the echoes over the measuring range in V.
  • Page 42 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 6 Set up with the display and adjustment module Echo curve memory With the menu item "Setup" the echo curve it is possible to save at the time of setup. This is generally recommended; for using the Asset Management functions it is necessary.
  • Page 43 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 6 Set up with the display and adjustment module The following reset functions are available: Delivery status: Restores the parameter settings at the time of ship- ment from the factory, incl. order-specific settings. Any stored false signal suppression or user-programmed linearisation curve, as well as the measured value memory, are deleted.
  • Page 44 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 6 Set up with the display and adjustment module Menu item Default value Scaling level - 100 % corresponds to Scaling level - 0 % corresponds to Scaling variable - Interface Volume Scaling unit - Interface Litres Scaling format - Interface...
  • Page 45 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 6 Set up with the display and adjustment module • Read from sensor: Read data from sensor and store into the display and adjustment module • Write into sensor: Store data from the display and adjustment module back into the sensor The following data or settings for adjustment of the display and ad- justment module are saved:...
  • Page 46 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 6 Set up with the display and adjustment module In menu item "Scaling format" you define the scaling format on the display and the scaling of the measured level value for 0 % and 100 %. Scaling interface Since scaling is very extensive, scaling of the interface value was divided into two menu items.
  • Page 47 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 6 Set up with the display and adjustment module Probe type In this menu item you can select the type and size of your probe from a list of all possible probes. This is necessary to adapt the electronics optimally to the probe. HART mode The sensor offers the HART modes "Analogue current output" and "Fix current (4 mA)".

  • Page 48: Saving The Parameterisation Data

    NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 6 Set up with the display and adjustment module Factory calibration date In this menu item, the date of factory calibration of the sensor as well as the date of the last change of sensor parameters are displayed via the display and adjustment module or via the PC.

  • Page 49: Diagnostics And Servicing

    NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 7 Diagnostics and servicing Diagnostics and servicing Maintenance Maintenance If the device is used properly, no special maintenance is required in normal operation. Cleaning The cleaning helps that the type label and markings on the instrument are visible.
  • Page 50 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 7 Diagnostics and servicing Function check: The instrument is being worked on, the measured value is temporarily invalid (for example during simulation). This status message is inactive by default. Out of specification: The measured value is unreliable because an instrument specification was exceeded (e.g. electronics temperature).
  • Page 51 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 7 Diagnostics and servicing Code Cause Rectification DevSpec State in CMD 48 Text mes- sage F113 EMC interference Remove EMC influences Bit 12 of Byte 0 … 5 Communica- Transmission error during ex- Exchange 4-wire power supply tion error ternal communication with unit or electronics...

  • Page 52: Rectify Faults

    NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 7 Diagnostics and servicing Code Cause Rectification DevSpec Text message State in CMD 48 S601 Level echo in the close range not Reduce level Bit 9 of available Byte 14 … 24 Overfilling 100 % adjustment: Increase value Check mounting socket...
  • Page 53 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 7 Diagnostics and servicing Fault rectification The first measures are: • Evaluation of fault messages • Checking the output signal • Treatment of measurement errors 4 … 20 mA signal Connect a multimeter in the suitable measuring range according to the wiring plan.
  • Page 54 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 7 Diagnostics and servicing Measurement error with constant level Fault description Cause Rectification Measured value shows a Min./max. adjustment not correct Adapt min./max. adjustment too low or too high level Incorrect linearisation curve Adapt linearisation curve Running time error (small measurement Repeat setup...

  • Page 55: Exchanging The Electronics Module

    NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 7 Diagnostics and servicing Measurement error during emptying Fault description Cause Rectification Measured value remains False signal larger than the level echo Eliminate false signals in the close range unchanged in the close Level echo too small Remove contamination on the probe.

  • Page 56: Exchange Or Shorten Cable/Rod

    NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 7 Diagnostics and servicing Exchange or shorten cable/rod Exchanging the cable/rod The cable or rod (meas. part) of the probe can be shortened, if neces- sary. To loosen the rod or cable you need a fork spanner with spanner width 13.

  • Page 57: How To Proceed If A Repair Is Necessary

    NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 7 Diagnostics and servicing 5. Shorten the cable/rod with a cut-off wheel or metal saw at the marking. Take note of the specifications in the following illustration when shortening the cable. 6. Cable with gravity weight: Shift the cable according to the drawing into the gravity weight 7. Cable with gravity weight: Fasten cable with the pins, torque 7 Nm (5.16 lbf ft) Cable with centering weight: Fasten cable with the pins, torque 7 Nm (5.16 lbf ft) and fix the clamping part on the centering...

  • Page 58: Dismount

    NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 8 Dismount Dismount Dismounting steps Warning: Before dismounting, be aware of dangerous process conditions such as e.g. pressure in the vessel or pipeline, high temperatures, cor- rosive or toxic media etc. Take note of chapters "Mounting" and "Connecting to voltage supply" and carry out the listed steps in reverse order.

  • Page 59: Supplement

    NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 9 Supplement Supplement Technical data General data 316L corresponds to 1.4404 or 1.4435 Materials, wetted parts Ʋ Process fitting - rod version 316L, 904L (1.4539), Alloy C22 (2.4602) and Aluminium oxide-ceramic 99.7 % (Al ) or Alloy C22 (2.4602) and Aluminium oxide-ceramic 99.7 % (Al Ʋ...
  • Page 60 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 9 Supplement Ʋ Pressure resistance See process pressure of the sensor Conductive connection Between ground terminal, process fitting and probe Process fittings Ʋ Pipe thread, cylindrical (ISO 228 T1) G1½ (DIN 3852-A) Ʋ Pipe thread, conical (ASME B1.20.1) 1½ NPT Ʋ...
  • Page 61 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 9 Supplement Torque for NPT cable glands and Conduit tubes Ʋ Plastic housing max. 10 Nm (7.376 lbf ft) Ʋ Aluminium/Stainless steel housing max. 50 Nm (36.88 lbf ft) Input variable Measured variable Level of liquids Min.
  • Page 62 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 9 Supplement Ʋ Air pressure +860 … +1060 mbar/+86 … +106 kPa (+12.5 … +15.4 psig) Mounting, reference conditions Ʋ Min. distance to internal installations > 500 mm (19.69 in) Ʋ Vessel metallic, ø 1 m (3.281 ft), centric mounting, process fit- ting flush with the vessel ceiling Ʋ...
  • Page 63 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 9 Supplement Fig. 26: Measuring ranges - NivoGuide 8200 Reference plane Probe length L Measuring range (default setting refers to the measuring range in water) Upper dead zone (see following diagrams - grey section) Lower dead zone (see following diagrams - grey section) Typical deviation - Interface measure- ±...
  • Page 64 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 9 Supplement 15 mm (0.591") 2 mm (0.079") -2 mm (-0.079") -5 mm (-0.197") 0,08 m 0,2 m 0,015 m (3.15") (7.874") (0.591") Fig. 27: Deviation NivoGuide 8200 in rod version in water Dead zone (no measurement possible in this area) Probe length 25 mm...
  • Page 65 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 9 Supplement 15 mm (0.591 ") 2 mm (0.079 ") -2 mm (-0.079 ") 10 mm (0.394 ") 0,1m 0,08 m 0,3 m (3.15 (11.811 (3.94 ") ") ") Fig. 29: Deviation NivoGuide 8200 in cable version in water Dead zone (no measurement possible in this area) When using a centering weight, it is only possible to measure up to the upper edge of the cerntering weight.
  • Page 66 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 9 Supplement 25 mm (0.984") 2 mm (0.079") -2 mm (-0.079") -15 mm (-0.591") 0,15 m 0,2 m 0,1 m (5.906") (7.874") (3.937") 0,15 m (5.906") Fig. 31: Deviation NivoGuide 8200 in cable version (4 mm/0.157 in), in medium oil Dead zone (no measurement possible in this area) When using a centering weight, it is only possible to measure up to the upper edge of the cerntering weight.
  • Page 67 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 9 Supplement Gas phase Temperature Pressure 10 bar 50 bar 100 bar 200 bar 400 bar (145 psig) (725 psig) (1450 psig) (2900 psig) (5800 psig) 20 °C/68 °F 0.22 % 1.2 % 2.4 % 4.9 % 9.5 %...
  • Page 68 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 9 Supplement 80°C / 176°F 60°C / 140°F 50°C / 122°F 40°C / 104°F 0°C / 32°F -196°C -150°C -100°C -80°C -50°C 50°C 80°C 100°C 150°C 200°C 250°C 280°C -321°F -238°F -148°F -112°F -58°F 122°F...
  • Page 69 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 9 Supplement 400 bar (5800 psig) 380 bar (5510 psig) 356 bar (5160 psig) 200 bar (2900 psig) 100 bar (1450 psig) -196°C -100°C 0°C 100°C 200°C 280°C (-321°F) (-148°F) (32°F) (212°F) (392°F) (536°F) Fig.
  • Page 70 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 9 Supplement Shock resistance Ʋ Rod probe 25 g, 6 ms according to EN 60068-2-27 (mechanical shock) with rod length 50 cm (19.69 in) Electromechanical data - version IP 66/IP 67 and IP 66/IP 68; (0.2 bar) Cable entry Ʋ...
  • Page 71 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 9 Supplement Voltage supply Operating voltage U Ʋ Non-Ex instrument, Ex-d instrument 9.6 … 35 V DC Ʋ Ex-ia instrument 9.6 … 30 V DC Ʋ Ex-d-ia instrument 15 … 35 V DC Ʋ...

  • Page 72: Dimensions

    NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 9 Supplement Dimensions The following dimensional drawings are only an extract of the possible versions. Aluminium housing ~ 116 mm ~ 87 mm (3.43") (4.57") ø 84 mm ø 84 mm (3.31") (3.31") M16x1,5 M20x1,5...
  • Page 73 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 9 Supplement Stainless steel housing ~ 59 mm (2.32") ø 80 mm (3.15") M20x1,5/ ½ NPT Fig. 38: Housing versions with protection rating IP 66/IP 68 (0.2 bar), (with integrated display and adjustment module the housing is 9 mm/0.35 in higher) Stainless steel single chamber (electropolished) Stainless steel single chamber (precision casting)
  • Page 74 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 9 Supplement NivoGuide 8200, cable version with gravity weight SW 60 (2.36") G1½ / 1½ NPT ø 4 mm ø 4 mm (0.16") (0.16") ø 2 mm (0.08") ø 20 mm ø 20 mm (0.79") (0.79") ø...
  • Page 75 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 9 Supplement NivoGuide 8200, cable version with centering weight SW 60 (2.36") G1½ / 1½ NPT ø 2 mm / ø 4 mm ø 2 mm / ø 4 mm (0.08") (0.16") (0.08") (0.16") Fig.
  • Page 76 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 9 Supplement NivoGuide 8200, rod version SW 60 (2.36") G1½ / 1½ NPT ø 16 mm ø 16mm (0.63") (0.63") Fig. 42: NivoGuide 8200, threaded version Sensor length, see chapter "Technical data" Rod ø...
  • Page 77 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART 9 Supplement Trademark All the brands as well as trade and company names used are property of their lawful proprietor/ originator.
  • Page 78 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART INDEX INDEX Adjustment HART address 47 – Max. adjustment 33, 34 – Min. adjustment 33, 34 Adjustment system 29 Inflowing medium 14 Application 32, 33 Installation position 12 Application area 8 Key function 28 Backlight 39 Language 38 Check output signal 53...
  • Page 79 NivoGuide® 8200 • Two-wire 4 … 20 mA/HART INDEX Units 31 Vessel insulation 19...
  • Page 80 Printing date: All statements concerning scope of delivery, application, practical use and operat- ing conditions of the sensors and processing systems correspond to the information available at the time of printing. Subject to change without prior notice Technical support Please contact your local sales partner (address at www.uwt.de). Otherwise please contact us: UWT GmbH Phone +49 831 57123-0...
