User Manual for your
UBETFD602SS
UBVFFAO60SS
UBEMF610
UBEMF611
UBEMF612
NOTE
: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference; for
you or any person not familiar with the operation of the appliance.
Advertisement
Table of Contents
Related Manuals for SPARES ZONE UBETFD602SS
Summary of Contents for SPARES ZONE UBETFD602SS
- Page 1 User Manual for your UBETFD602SS UBVFFAO60SS UBEMF610 UBEMF611 UBEMF612 NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference; for...
-
Page 2: Table Of Contents
Contents Environmental note Important safety information 4 - 6 Specifications 7 - 9 Product and aperture dimensions Product specifications Standard accessories Electrical details Cooling fan Control panel Oven programmer/timer display Setting and using the oven programmer/timer 10-14 Selecting manual operation mode Setting clock (the time of day) The oven timer Before first use... -
Page 3: Environmental Note
Environmental note o The packaging materials that the manufacturer uses are environmentally friendly and can be recycled. o Please discard all packaging material with due regard for the environment. -
Page 4: Important Safety Information
IMPORTANT SAFETY INFORMATION Your safety is of the utmost importance to us. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this booklet, please contact the Customer Care Department. - Page 5 Warning and safety instructions o This appliance complies with all current European safety legislation. The manufacturer does wish to emphasise that this compliance does not remove the fact that the appliance surfaces will become hot during use and retain heat after operation. o This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been...
- Page 6 o Do not attempt to lift or move cooking appliances by using the oven door or handle, as this may cause damage to the appliance or result in injury to the person lifting the appliance. Cleaning o Cleaning of the oven should be carried out on a regular basis. o Great care should be taken whilst using this appliance and when following the cleaning procedure.
- Page 7 Declaration of conformity This appliance complies with the following European Directives: - 2014/35/EU regarding “low voltage” - 2014/30/EU regarding “electromagnetic disturbances” - Regulation (EC) N° 1935/2004 regarding “materials in contact with food” o The above directives comply with 93/68/EEC regarding CE marking. o The manufacturer declares that the oven is built using certified materials and requires the appliance to be installed in accordance with the standards currently in force.
-
Page 8: Specifications
Depth: 530 mm 560 mm (min) Product specifications o 9 oven functions (UBEMF610/UBEMF611/UBEMF612) 4 oven functions (UBETFD602SS/UBVFFAO60SS ) o Energy efficiency class: A o Oven net/gross capacity: 58/65 liters o LED fully programmable timer o Cooling fan o Thermostatically controlled grill... -
Page 9: Standard Accessories
Handle Screws(ST4x35) Electrical details Rated Voltage: 220-240 Vac, 50/60 Hz Supply Connection: Rated max power : 2.20 kW (UBETFD602SS/UBVFFAO60SS ) 2.90 kW (UBEMF610/UBEMF611/UBEMF612) Mains Supply Lead: 3 x 1.0mm² Oven Light Bulb: 25 W/300°C screw type pygmy Cooling fan o A tangential cooling fan is fitted inside of this appliance, to make the internal temperature of the oven stable and the external surface temperature lower. -
Page 10: Control Panel
Control Panel UBEMF610/UBETFD602SS UBEMF611 UBEMF612 UBVFFAO60SS... -
Page 11: Oven Programmer/Timer Display
1) Oven function selector knob 2) Thermostat control knob 3) Minute minder button 4) Duration button 5) End cook button 6) Manual operation button 7) Minus button 8) Plus button 9) LED display A) Power indicator light B) Oven operating light Oven programmer/timer display 10) Auto function symbol 11) Minute minder symbol... -
Page 12: Setting Clock (The Time Of Day)
Setting clock (the time of day) After setting your oven for manual operation, you should also set the time of day. o After pressing the manual operation button (6), use the minus button (7) and plus button (8) to adjust the time that appears in the display. -
Page 13: Setting The Minute Minder Function
o We would recommend that an appropriate stainless steel cleaner and polish is regularly used on the stainless steel surfaces of this appliance. Setting the minute minder function You are able to set the minute minder at any time, regardless of whether an oven function has been selected. -
Page 14: Setting The End Cook Function
o It is then possible to set the duration of the cooking time that you require. o Press the duration button (4) and the display will show a value of 00:00. Set the period of the duration function to countdown for, by using the minus (7) and plus (8) buttons. -
Page 15: Setting The Start And End Time Function
o Press the end cook button (5) and the display will show a value of 00:00. Set the time of day that you wish the oven to stop cooking at by using the minus (7) and plus (8) buttons. The timer will calculate how long the cooking time will be, based on the time of day that you have selected and show it on the display. - Page 16 o Press the duration button (4) and the display will show a value of 00:00. Set the period of time that you wish to cook for, by using the minus (7) and plus (8) buttons. The word AUTO will appear on the timer display.
-
Page 17: Selecting A Cooking Function And Temperature
When a function is selected, the power indicator light will come on. Oven functions (UBETFD602SS/UBVFFAO60SS ) OVEN LIGHT: Separate light control which allows the light to be switched on, even when the oven is not cooking. -
Page 18: Oven Functions
Oven functions (UBEMF610/UBEMF611/UBEMF612) OVEN LIGHT: Separate light control which allows the light to be switched on, even when the oven is not cooking. Defrosting: This function allows all frozen foods to be rapidly and delicately thawed thanks to the internal fan. Bottom &... -
Page 19: Thermostat Control Knob
Intensive hot air (Rear heater with fan and bottom element on): A crisp underside to pizza bases, quiches and pastry cases can be achieved by activating the intensive hot air setting. No need to preheat the oven when using this setting when cooking from frozen. -
Page 20: Cooking Guidelines
Cooking guidelines o Please refer to the information given on food packaging for guidance on cooking temperatures and times. Once familiar with the performance of your appliance, temperatures and times can be varied to suit personal preference. o If you are using the fan oven function, then you should follow the information given on the food packaging for this particular mode of cooking. -
Page 21: Warnings
Warnings o Keep the oven door closed when using any of the cooking functions, including the grill functions. o Do not use aluminium foil to cover the grill pan or heat items wrapped in aluminium foil under the grill. The high reflectivity of the foil could potentially damage the grill element. -
Page 22: Cleaning And Maintenance
o The sides of the cavity are moulded to provide positions for the shelves or enamelled baking tray to rest on. Ensure that you select a shelf position at the same height on both sides of the cavity. The oven shelf has safety stops to prevent accidental withdraw. After engaging the oven shelf into the side racks, as you push the oven shelf into the oven, lift the front of the shelf slightly to bypass the stops and allow the oven shelf to slide fully into the racks. -
Page 23: Replacing The Oven Bulb
o You should make sure that the cooking temperature that is selected is appropriate for the food that you are cooking. You should also ensure that the food is placed in an adequately sized dish and use the enamelled baking tray where appropriate. o Outer parts of the oven should only be cleaned with warm soapy water, using either a sponge or soft cloth. -
Page 24: Removing The Oven Door For Cleaning
o Unscrew the bulb anti-clockwise and remove it from its holder. o Replace the bulb with a 25 W/300°C, screw type pygmy. o Do not use any other type of bulb. o Place the lamp cover back into position. Removing the oven door for cleaning To facilitate the cleaning of the inside of the oven and the outer frame of the oven, the door can be removed as follows: o The hinges (A) have two movable bolts... -
Page 25: Removing The Inner Door Glass For Cleaning
o IMPORTANT: You should make sure that the door is supported at all times and that you place the door on some padded material whilst cleaning it. o The oven door and door glass should only be cleaned using a damp cloth and a small amount of detergent. -
Page 26: Installation
o Unscrew the bracket latch that is in the corner of the top of the door. Remove the glass from the door and clean with warm soapy water. o After cleaning, insert the glass panel correctly back into the door. Screw the bracket latch back into place. - Page 27 must still be accessible even when your oven is located in its housing. o To connect the oven power cord, remove the cover on the terminal block, in order to gain access to the contacts inside. Make the connection, securing the cord in place with the cable clamp provided and then immediately close the terminal block cover again.
-
Page 28: Installing The Oven Into The Kitchen Cabinet
Installing the oven into the kitchen cabinet Positioning the appliance o Ensure that the aperture that you will be fitting the oven into is of the size given in the above diagram. o The oven must be fitted into an oven housing with the ventilation cut-outs shown in the “Ventilation requirements”... -
Page 29: Ventilation Requirements
Ventilation requirements (Figure shows the ventilation and cut-out requirements for the installation of the appliance into a standard kitchen unit). (Figure shows the ventilation and cut-out requirements for the installation of the appliance into a tall housing unit). o Ensure that the oven has been securely fixed into the housing unit. -
Page 30: My Appliance Isn't Working Correctly
My appliance isn’t working correctly o The oven isn’t coming on. * Check that the oven is in manual operation mode. * Check that you have selected a cooking function and a cooking temperature. o There appears to be no power to the oven and grill. * Check that the appliance has been connected to the electrical mains supply correctly. - Page 31 o The oven light is not working * Refer to the “Replacing the oven bulb” section. o I am getting condensation in my oven * Steam and condensation is a natural by product of cooking any food with high water content, such as frozen food, chicken etc. * You may get condensation in the oven cavity and forming between the oven door glasses.
- Page 32 Please refer to the conditions of guarantee that appear on the warranty card that you receive with the appliance. IMPORTANT: The manufacturer operates a policy of continuous improvement and reserves the right to adjust and modify its products without prior notification.
