XN
Site Preparation Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Kongsberg XN and is the answer not in the manual?

Questions and answers

sigmund novak
March 17, 2025

We purchased a Kongsberg XN SYSTEM--sn # 841452--machine type: XN24s from an auction. Do you have a floor plan of placing/connecting all the components ? Mainly the vacuum pump--soft starter--chiller--radiator and all the connections to the unit--computer and controlls.

0
1 comments:
Mr. Anderson
May 14, 2025

The floor plan for placing and connecting the components of the Esko Kongsberg XN24s system should include the following:

1. System Placement:
- The destination room must be large enough to fit the entire system.
- Ensure sufficient maintenance clearance around the system.
- Confirm that door openings and access ways are large enough for equipment entry.
- Rigging equipment like a forklift and pallet truck should be available.

2. Electrical Connections:
- Provide main power for the CAM table and vacuum pump.
- Use short-circuit protection with fuses and insulation failure protection per local standards.
- Required outlets:
- Three-phase outlet for the vacuum pump.
- Single-phase outlets for vacuum pump control, table, PC/monitor.

3. Compressed Air Supply:
- Pressurized air outlet should be available.
- Ensure the air source meets specifications for pressure, capacity, and moisture content.

4. Environmental Requirements:
- Suitable floor material in the installation area.
- Maintain proper temperature and humidity levels.

5. Safety and Noise Considerations:
- Plan the machine location considering noise levels.
- Provide hearing protection for operators.
- DynaGuard Safety System should be unobstructed; it stops the system if safety beams are broken or if someone is too close.

6. Remote Diagnostics:
- Install a “Direct Dial In” telephone line.
- Provide a network connection for the front-end system.

The soft starter, chiller, and radiator are not specifically detailed in the context, but they should be placed close to their respective connection points, with proper spacing, ventilation, and access for maintenance.

This answer is automatically generated

0
sigmund novak
March 25, 2025

We purchased a Kongsberg XN SYSTEM--sn # 841452--machine type: XN24s from an auction. Do you have a floor plan of placing/connecting all the components ? Mainly the vacuum pump--soft starter--chiller--radiator and all the connections to the unit--computer and controlls. Any tech in the Kenosha, wi. 53143 area that could assist us?

0

Related Manuals for Esko Kongsberg XN

Summary of Contents for Esko Kongsberg XN

  • Page 1 Site Preparation Manual...

  • Page 2: Table Of Contents

    Contents 1. Preface......................................5 2. Change record....................................6 3. Introduction.....................................7 3.1 Welcome....................................7 3.2 About Installation................................7 4. Receiving Equipment from Esko............................9 4.1 Inspection of Equipment..............................9 4.2 Temporary Storage................................9 4.3 System Label..................................9 4.4 Table Transport.................................10 5. Packaging Specification.................................12 5.1 XN20, Packaging................................12 5.2 XN22, Packaging................................12...
  • Page 3 Contents 10. Tables, Specification................................30 10.1 XN20....................................30 10.2 XN22....................................31 10.3 XN24....................................33 10.4 XN40....................................35 10.5 XN44....................................37 10.6 XN46....................................38 10.7 XN48....................................40 11. XN with Extension Table..............................43 11.1 XN20....................................43 11.2 XN22....................................44 11.3 XN24....................................46 11.4 XN40....................................
  • Page 4 18.6 Technical Information, Vacuum Pumps........................70 18.7 Sound Suppression Box for Vacuum Pump......................71 19. E-save for Vacuum Pump..............................73 19.1 Installation..................................73 19.2 Electrical Requirements..............................74 19.3 Dimensions..................................74 20. Cutting Table with Controller.............................76 20.1 Requirements..................................76 20.2 Direct Mains Connection............................76 20.3 Ground System................................76 20.4 Un-interruptible Power System..........................76 20.5 Noise Level..................................77 21.

  • Page 5: Preface

    1. Preface Site Preparation Manual Kongsberg XN Note: We remind you that only the Esko Staff, or persons having received appropriate training, are allowed to handle, manipulate or do repairs on the system. Copyright 2014, Esko-Graphics Kongsberg AS, Norway ©...

  • Page 6: Change Record

    2. Change record Description Date dd-mm-yy 16-03-2014 jhbe First version of the document 28-05-2014 jhbe Packaging information improved. Dimension drawings and tables has been improved. All relevant Extension table configurations are now described.

  • Page 7: Introduction

    • Prepare the destination room. • Prepare all electrical supplies. • Prepare compressed air supply. If an air compressor is delivered from Esko, a suitable place for the unit should be prepared. • Prepare a suitable room for the vacuum pump. Due to its acoustic noise, the vacuum pump should be located in a room away from people.
  • Page 8 Immediately after an item is unpacked, it must be inspected carefully for signs of damage.   Note: We remind you that only the Esko Staff, or persons having received appropriate training, are allowed to handle, manipulate or do repairs on the system.

  • Page 9: Receiving Equipment From Esko

    The goods are not to be opened without the presence of qualified Esko Service Engineer or partners. If damage is found while unpacking the unit, the Service Engineers from Esko need to make photos of this and sent it to shipper.
  • Page 10 4.4 Table Transport Due to its high weight, special attention should be paid to the methods used to bring the table tops into the destination room. Typical weights (one table section): Table XN20 XN22 XN24 XN4x Note: • Recommendations are valid for all mechanical parts. •...

  • Page 12: Packaging Specification

    5. Packaging Specification 5.1 XN20, Packaging Metric Crates Length, L Width, W Height, H Weight (kg) Net weight (cm) (cm) (cm) (kg) 1. Table (standard) 2. Traverse (standard) 3. Frame (standard) 4. Chiller 5. Noice reduction box 6. Air Compressor 7.

  • Page 13: Xn24, Packaging

    Crates Length, L Width, W Height, H Weight (kg) Net weight (cm) (cm) (cm) (kg) 6. Air Compressor 7. Vacuum Cleaner Imperial Crates Length, L Width, W (in) Height, H Weight (lbs) Net weight (in) (in) (lbs) 1. Table (standard) 116,9 78,0 14,2...

  • Page 14: Xn40, Packaging

    Crates Length, L Width, W (in) Height, H Weight (lbs) Net weight (in) (in) (lbs) 7. Noise reduction box 44,9 40,9 33,9 171,6 151,8 8. Air Compressor 47,2 31,5 36,2 191,4 147,4 9. Vacuum Cleaner 53,5 28,7 59,1 272,8 228,8 5.4 XN40, Packaging Metric Crates...

  • Page 15: Xn46, Packaging

    Crates Length, L Width, W Height, H Weight (kg) Net weight (cm) (cm) (cm) (kg) 4. Traverse (standard) 5. Frame (standard) 6. Chiller 7. Noise reduction box 8. Air Compressor 9. Vacuum Cleaner Imperial Crates Length, L Width, W (in) Height, H Weight (lbs) Net weight (in) (in)

  • Page 16: Xn48, Packaging

    Imperial Crates Length, L Width, W (in) Height, H Weight (lbs) Net weight (in) (in) (lbs) 1. Table (standard) 98,8 80,7 14,2 825,0 600,6 2. Table Mid (standard) 98,8 67,7 14,2 726,0 539,0 3. Table (standard) 98,8 80,7 14,2 825,0 600,6 4.Traverse (standard) 132,7...
  • Page 17 Crates Length, L Width, W (in) Height, H Weight (lbs) Net weight (in) (in) (lbs) 5. Traverse (standard) 132,7 20,5 39,4 440,0 290,4 6. Frame (standard) 98,8 52,0 36,2 990,0 792,0 7. Frame (standard) 98,8 52,0 36,2 682,0 462,0 8. Frame (standard) 98,8 52,0 36,2...

  • Page 18: Room Preparation

    6. Room Preparation 6.1 About Room Preparation The accuracy obtained from the system depends upon room standards. In order to maintain the high accuracy, the instructions given here must be adhered to. The accuracy of the system is related to a temperature of +20° C / +68° F, and a relative humidity of 50%.

  • Page 19: Floor Load And Level

    Note: • Handling Heavy Materials is a danger to personal health. • Actions should be taken to avoid manual lifting of Heavy Materials. 6.6 Floor Load and Level The floor must be level and capable of supporting an evenly distributed load of 500 kg/m² (0.7 lbs/in²). The flatness of the floor area prepared for the machine should be within +/- 5 mm (+/- 0.2 in.).

  • Page 20: Noise Level

    Ensure the headroom (Hg) is sufficient allowing the gallows to move freely: Inch XN2x 2300 XN4x 2300 6.9 Noise Level The system generates a noise that can be hazardous if people have to work nearby the machine over time. Note: •...

  • Page 21: Dynaguard Safety System

    7. DynaGuard Safety System The DynaGuard Safety System consists of four light beams, two in front of the traverse and two behind. In addition, there is a stop mechanism mounted on each end of the traverse. Machine movement will stop and servo power will be switched off if: •...

  • Page 22: System Layout

    8. System Layout Typical installation This symbol indicates components to be provided by the customer. Includes both outlets and connectors. Should be prepared before table installation begins. Single phase outlets for vacuum pump control. Three phase outlet for vacuum pump. Single phase outlets for table, PC/monitor.

  • Page 23: Introduction

    8.1 Introduction A recommended System Layout for the different types of tables is shown in the illustration below. Requirements 1. A minimum spacing between the equipment and walls. 2. A minimum spacing between the units required by maintenance personnel. Recommendations 1.
  • Page 24 Note: 1) - We recommend that you add additional space on this side of the table, due to: • For the operator, provide easy access to the whole working area. • For Customer Service – ease access to controller unit. Attention area Material load...

  • Page 25: Cables, Hoses And Fuses

    9. Cables, Hoses and Fuses XN with front panel XN with RWS...
  • Page 26 XN with MultiCUT XN with MultiCUT HP...

  • Page 27: Symbols Used In Figures

    XN with sheet feeder 9.1 Symbols used in Figures Symbol Explanation Main Power Unit cabinet Electric cable ( mains, three phase )   Electric cable ( mains single phase )   Hoses (vacuum, pressurized air)   Electric cable (network cable)  ...

  • Page 28: Specifications

    9.2 Specifications Item Description Voltage / Fuse size Plug to be Total Length Length supplied by outside customer Cutting Table Network       Connection. Customer responsible Mains Power 1 m / 3 ft 115V / 10A for PC 230V / 10A Communication PC - table Mains Power...
  • Page 29 Item Description Voltage / Fuse size Plug to be Total Length Length supplied by outside customer Cutting Table Mains for 15 m / 49 ft 12 m / 39 3 x 230V / 20A Vacuum 3 x 380V / 10A Cleaner 230/380V is configurable at installation time.

  • Page 30: Tables, Specification

    10. Tables, Specification 10.1 XN20 XN20 with front panel XN20 with Revolving Work Station...

  • Page 31: Xn22

    XN20 with conveyor belt Measures XN20 Distance Inch W2x_01 1920 75.6 W2x_02 2800 110.2 W2x_03 3620 142.5 L20_01  2090   82.3 L20_02  12.2 L20_03  2000 78.7 L20_04  36.6 L20_05  2370  93.3 Wf2x 1845 72.6 Lf2x 1210 47.6 10.2 XN22...
  • Page 32 XN22 with front panel XN22 with Revolving Work Station...

  • Page 33: Xn24

    XN22 with conveyor belt Measures XN22 Distance Inch W2x_01 1920 75,6 W2x_02 2800 110,2 W2x_03 3620 142,5 L22_01  3040   119,7 L22_02  20,3 L22_03  2950 116,1 L22_04  1880 74,0 L22_05  3160  124,4 Wf2x 1845 72,6 Lf22 1925 75,8 10.3 XN24...
  • Page 34 XN24 with front panel XN24 with Revolving Work Station XN24 with conveyor belt Measures XN24 Distance Inch W2x_01 1920 75,6 W2x_02 2800 110,2...

  • Page 35: Xn40

    Distance Inch W2x_03 3620 142,5 L24_01  4050   159,4 L24_02  3485 137,2 L24_03  18,7 L24_04  3960 155,9 L24_05  2890  113,8 Wf2x 1845 72,6 Lf2x 1210 47,6 10.4 XN40 XN40 with front panel...
  • Page 36 XN40 with Revolving Work Station XN40 with conveyor belt Measures XN40 Distance Inch W4x_01 2450 96,5 W4x_02 3320 130,7 W4x_03 4120 162,2 L40_01  2090   82,3 L40_02  12,6 L40_03  2000 78,7 L40_04  36,6...

  • Page 37: Xn44

    Distance Inch L40_05  2370  93,3 Wf4x 2375 93,5 Lf4x 1210 47,6 10.5 XN44 XN44 with front panel XN44 with Revolving Work Station...

  • Page 38: Xn46

    XN44 with conveyor belt Measures XN44 Distance Inch W4x_01 2450 96,5 W4x_02 3320 130,7 W4x_03 4120 162,2 L44_01  4050 159,4 L44_02  3485 137,2 L44_03  18,7 L44_04  3960 155,9 L44_05  2890  113,8 Wf4x 2375 93,5 Lf4x 1210 47,6 10.6 XN46 XN46 with front panel...
  • Page 39 XN46 with Revolving Work Station...

  • Page 40: Xn48

    XN46 with conveyor belt Measures XN46 Distance Inch W4x_01 2450 96,5 W4x_02 3320 130,7 W4x_03 4120 162,2 L46_01  5730 225,6 L46_02  5165 203,3 L46_03  3425 134,8 L46_04  18,7 L46_05  5640  222,0 L46_06  4570 179,9 L46_07  5850 230,3 Wf4x 2375 93,5 Lf4x 1210 47,6...
  • Page 41 XN48 with front panel XN48 with Revolving Work Station...
  • Page 42 Measures XN48 Distance Inch W4x_01 2450 96,5 W4x_02 3320 130,7 W4x_03 4120 162,2 L48_01  7410 291,7 L48_02  6845 269,5 L48_03  5105 201,0 L48_04  3425 134,8 L48_05  475  18,7 L48_06  7320 288,2 L48_07  6250 246,1 Wf4x 2375 93,5 Lf4x 1210 47,6...

  • Page 43: Xn With Extension Table

    11. XN with Extension Table Table: Weight XN2x XN4x One section 60 kg / 130 lbs 60 kg / 130 lbs 11.1 XN20 XN20 with one front extension table...

  • Page 44: Xn22

    XN20 with one rear extension table XN20 with one front and one rear extension table Measures XN20 with extension tables Distance Inch W2x_01 1920 75,6 L20_06  4130   162,6 L20_07  3500 137,8 L20_08  5920 233,1 L20_09  4670 183,9 11.2 XN22...
  • Page 45 XN22 with one front extension table XN22 with one rear extension table XN20 with one front and one rear extension table Measures XN22 with extension tables Distance Inch W2x_01 1920 75,6 L22_06  4920   193,7 L22_07  4300 169,3 L22_08  6720 264,6...

  • Page 46: Xn24

    Distance Inch L22_09  5460 215,0 11.3 XN24 XN24 with one front extension table XN24 with two front extension tables...
  • Page 47 XN20 with one rear extension table XN24 with two rear extension tables XN24 with one front and one rear extension table Measures XN24 with extension tables Distance Inch W2x_01 1920 75.6 L24_07  5930 233.5...

  • Page 48: Xn40

    Distance Inch L24_08  5300 208.7 L24_09  7690 302.8 L24_10  7070 278.3 L24_11  5930 233.5 L24_12  7730 304.3 L24_13  6470 254.7 11.4 XN40 XN40 with one front extension table XN40 with one rear extension table...

  • Page 49: Xn44

    Measures XN40 with extension tables Distance Inch W4x_01 2450 96,5 L40_06  4130   162,6 L40_07  3500 137,8 11.5 XN44 XN44 with one front extension table XN44 with one rear extension table Measures XN44 with extension tables Distance Inch W4x_01 2450 96,5 L44_07 ...

  • Page 51: Xn With Sheet Feeder

    12. XN with Sheet Feeder i-SF2x Sheet Feeder i-SF4x Sheet Feeder Measures, Sheet Feeder Distance Inch Wsf2x_01 2520 93,7 Wsf4x_01 3030 141,7 Lsf2x_01  925   130,7 12.1 XN20...
  • Page 52 XN20 with Sheet Feeder XN20 with Sheet Feeder and load table XN20 with Sheet Feeder and load and unload table Measures XN20 with Sheet Feeder Distance Inch Ws2x_01 2380 93,7 Ws2x_02 3600 141,7 Ls20_01  3320   130,7 Ls20_02  4380 172,4 Ls20_03 ...

  • Page 53: Xn22

    12.2 XN22 XN22 with Sheet Feeder XN22 with Sheet Feeder XN22 with Sheet Feeder...

  • Page 54: Xn24

    Measures XN22 with Sheet Feeder Distance Inch Ws2x_01 2380 93.7 Ws2x_02 3600 141.7 Ls22_01  4110   161.8 Ls22_02  5170 203.5 Ls22_03  6870 270.5 12.3 XN24 XN24 with Sheet Feeder XN24 with Sheet Feeder and load table...

  • Page 55: Xn40

    XN24 with Sheet Feeder and load and unload table XN24 with Sheet Feeder and two load tables Measures XN24 with Sheet Feeder Distance Inch Ws2x_01 2380 93.7 Ws2x_02 3600 141.7 Ls24_01  5120   201.6 Ls24_02  6180 243.3 Ls24_03  7880 310.2 Ls24_04 ...
  • Page 56 Measures XN40 with Sheet Feeder Distance Inch Ws4x_01 2890 113.8 Ws4x_02 4130 162.6 Ls40_01  3310   130.3 Ls40_02  4370 172.0 Ls40_03  6060 238.6...

  • Page 57: Xn44

    12.5 XN44 XN44 with Sheet Feeder XN44 with Sheet Feeder and load table XN44 with Sheet Feeder and load and unload table...
  • Page 58 XN44 with Sheet Feeder and two load tables Measures XN44 with Sheet Feeder Distance Inch Ws4x_01 2890 113.8 Ws4x_02 4130 162.6 Ls44_01  5120   201.6 Ls44_02  6180 243.3 Ls44_03  7880 310.2 Ls44_04  7750 305.1...

  • Page 59: Front End Pc

    13. Front End PC The Front End PC is shipped in the same box as the table frames. When RWS is included, the Front End PC is located inside the RWS bracket. 13.1 Configuration For the control system to work properly, it is a requirement that the operator has “Administrator privileges”...

  • Page 60: Dimensions

    Subject Requirements Required by the following option Serial line One serial line for cutting table.   Serial line One serial line for IBAG inverter. HPMU Serial line One serial line for sheet feeder Sheet feeder communication (solved using USB to serial adapter). Display  ...

  • Page 61: Pc Table

    14. PC Table Description Metric Imperial Height, adjustable from 620 mm 25 inch Width 800 mm 32 inch Depth 800 mm 32 inch Weight 20 kg 44 lbs For systems without RWS, a PC table is included. The PC table is shipped in the same box as the frames.

  • Page 62: Operator Station

    15. Operator Station Dimension Description Metric Imperial Hrev 550 mm 21.6 inch Wrev 690 mm 27.2 inch Drev 680 mm 26.8 inch 150 mm 5.9 inch 430 mm 16.9 inch Weight  ...
  • Page 63 Rotation The work station top can be rotated 90 Shipment The Operator Station will be shipped in the same box as the table frame, partly assembled. Alternative Position This is the standard Revolving work station position. This is the alternative Revolving work station position.

  • Page 64: Roll Feeder

    16. Roll Feeder Total machine length is extended by 700 mm / 28 in. plus space for roll handling.

  • Page 65: Compressed Air System

    17. Compressed Air System 17.1 General The Compressed Air System consists of: • Air Source. • Industry Pressurized Air or dedicated Air Compressor. • Connection Hose. • Air Regulator Valve. The customer is required to provide the pressurized air source. The customer is required to install the airline that leads from the air source to the table room and terminate the line with a quick connector (Air Source Outlet).

  • Page 66: Purchase Compressor

    (1) - Measured with 4 suction cups and 2 air knives. Air consumption depends upon the number of air knives and number of suction cups. 17.4 Purchase Compressor Guidelines to the customer when purchasing / installing a compressor. The surface of the compressor gets hot. Ensure there is enough free space around the compressor. The illustration shows a compressor top view, A >= 1 m / 40 in.

  • Page 67: Vacuum System

    18. Vacuum System 18.1 Introduction The Vacuum System consists of: • Vacuum pump(s) • Connection Tube(s), diameter 75 mm. Note: • The pump(s) should be located outside the room as recommended. • If the vacuum pump is supplied locally, be sure parts for installing the pump and the ø75 mm tubes are available.

  • Page 68: Recommended Mains Fuses/Cable Dimensions

    XN20/22/24/40, XN20/22/24/40, XN44/46/48, 50Hz XN44/46/48, 60Hz 50Hz 60Hz SB 0530 D 6,3 kW – 60 Hz SB 0710 D 7,5 kW – 50 Hz SB 0710 D 8,3 kW – 60 Hz x) Vacuum pump from this size and up is recommended. 18.3 Recommended Mains Fuses/Cable Dimensions Pump Eff.
  • Page 69 • Using a Soft Start unit • Inverter control (E-Save). Note: The wall outlet shall meet the following requirements according to EN60204-1: • Short circuit protection by fuses according to table in chapter 'Cables and hoses'. • Insulation failure protection by automatic disconnection or alarm signal. It is the customer's responsibility to prepare the electrical installation according to local requirements.

  • Page 70: Vacuum Extern Kit, Content

    Abbreviations Description Control relay ( ON / OFF ) Motor overload relay E-Save E-Save control unit 18.5 Vacuum Extern Kit, Content This kit is included in all machine deliveries: 18.6 Technical Information, Vacuum Pumps SB 0310 D SB 0430 D SB 0710 D SB 0710 D SB 0200 D SB 0430 D SB 0530 D 1/3 - phase 3 Voltage 230/ 400V 230/ 400V 230/ 400V 230/ 400V 230/ 400V 230/ 400V 230/ 400V...

  • Page 71: Sound Suppression Box For Vacuum Pump

    SB 0310 D SB 0430 D SB 0710 D SB 0710 D SB 0200 D SB 0430 D SB 0530 D Length L 13,9 14,3 19,6 19,6 12,5 14,3 19,6 (inch) Width W 15,1 15,1 19,7 19,7 13,3 15,1 19,7 (inch) Height H 15,2...

  • Page 73: E-Save For Vacuum Pump

    19. E-save for Vacuum Pump Vacuum Pump control using a variable frequency drive (VFD) is available as an option 19.1 Installation The Inverter should be mounted on the wall, close to the vacuum pump. The Inverter is ready to run as soon as the Mains Power is switched on. Note: The inverter is generating noise, thus it is recommended to mount the Inverter together with the Vacuum Pump in a separate room.

  • Page 74: Electrical Requirements

    To allow for heat dissipation, ensure free space around the Inverter. 19.2 Electrical Requirements Type Plug Fuse Total Length Length outside supplied size Cutting Table customer 3 x 400V Mains vac. 5 m / 16 ft pump Vacuum on/off control 15 m /49 ft 12 m / 39 ft cable...
  • Page 75   16,0      ...

  • Page 76: Cutting Table With Controller

    20. Cutting Table with Controller 20.1 Requirements Environmental Requirements Description Requirements Temperature: Operating: +10°C to +30°C / +50°F to +86°F Relative Humidity: Operating: 30% to 80% Mains Power Requirements Description Requirements Voltage: 115V / 230V AC  +10%,  Single-Phase Frequency: 50/60 Hz +5%. Transients should not exceed 100V for 10 us. Power: 1000 VA 20.2 Direct Mains Connection...

  • Page 77: Noise Level

    Other devices, as Air Compressor, Vacuum Cleaner and controller for HPMU should connect directly to a wall outlet. The capacity of a UPS – device should be ≈ 2000 W. 20.5 Noise Level Description A-weighted sound pressure level. Material dependant. dB(A) Table running silent tooling, average 78.5 –...

  • Page 78: Multicut/Multicut Hp

    21. MultiCUT/MultiCUT HP 21.1 Requirements Mains Power Requirements Description Requirements Voltage: 115V / 230V AC  +10%,  Single-Phase Frequency: 50/60 Hz +5%. Power, MultiCUT 1000 VA Power, MultiCUT-HP 3000 VA 21.2 Direct Mains Connection See chapter Direct Mains Connection, Guidelines. 21.3 Pressurized Air requirements For MultiCUT, it is important that the pressurized air level is constantly above 7 bar measured locally at the outlet for the table.
  • Page 79 Description dB(A) A-weighted sound pressure level (Lpf) (Material dependant)

  • Page 80: Chiller For Multicut Hp

    22. Chiller for MultiCUT HP 22.1 Requirements Mains Power Requirements Description Requirements Voltage: 230V AC  +10%,  1-Phase Frequency: 50/60 Hz +5%. Power: 2000 VA Environmental Requirements Description Requirements Temperature Operating: +10°C to +41°C / +50°F to +106°F 22.2 Direct Mains Connection See chapter Direct Mains Connection, Guidelines.
  • Page 81 Lch=700 mm Wch=510 mm. Height 440 mm / 27,5 x 20 x 17.3 in. Air input / output Assure free space 0,5 m / 20 in. on the air input side. Assure free space 1 m / 40 in. on the air output side. No chiller beneath cutting table Chiller level...
  • Page 82 Within shown limits, the chiller can be located above or beneath cutting table level.

  • Page 83: Vacuum Cleaner For Multicut

    23. Vacuum cleaner for MultiCUT 23.1 Requirements Description Requirements Voltage: 230V / 380V AC  +/- 10%,  3-phase Frequency: 50/60 Hz +/- 5%. Power: 2200 VA 23.2 Direct Mains Connection See chapter Direct Mains Connection, Guidelines. 23.3 Installation Dimensions Footprint 620 x 800 mm, height 1650 mm / 24.4 x 31.5 in, height 65 in. Diffuser on air output...
  • Page 84 Included in the shipment is an air diffuser, ready to be mounted onto the suction unit output.

  • Page 85: Direct Mains Connection, Guidelines

    24. Direct Mains Connection, Guidelines A wall outlet for mains connection should be located in a position where it is visible from the equipment. Alternatively, a lockable Main Power ON/OFF switch can be installed. This to avoid main power accidentally being switched on while maintenance is carried out. All installations should be according to local regulations.

  • Page 86: Site Prep Ready, Check List

    25. Site Prep Ready, Check List Dear Customer Proper preparation of the system site is perhaps the most important factor in the prevention of unnecessary delays and problems before, during and after the installation. Furthermore, a correctly planned and maintained system site will ensure an efficient and safe operating environment for your system, protecting your investment for many years to come.
