I N S T R U CT I O N M A N UA L
( S E / E N / D E / F R / E S / I T )
AquaT Toilet - Manual
M A N UA L M O D E L S - C o m f o r t , C o m p a c t & S u p e r C o m p a c t
O R I G I N A L I N S T R U CT I O N S / T R A N S L AT I O N O F O R I G I N A L I N S T R U CT I O N S
I B - 412 - 1 R 0 6 ( 0 5 / 2 019 )
R E A D A N D U N D E R STA N D T H I S M A N UA L P R I O R TO O P E R AT I N G O R S E R V I C I N G T H I S P R O D U CT
Comfort
Compact
Super Compact
Advertisement
Table of Contents
Summary of Contents for SPXFLOW Johnson Pump AquaT Comfort
- Page 1 I N S T R U CT I O N M A N UA L ( S E / E N / D E / F R / E S / I T ) AquaT Toilet - Manual M A N UA L M O D E L S - C o m f o r t , C o m p a c t & S u p e r C o m p a c t O R I G I N A L I N S T R U CT I O N S / T R A N S L AT I O N O F O R I G I N A L I N S T R U CT I O N S I B - 412 - 1 R 0 6 ( 0 5 / 2 019 ) R E A D A N D U N D E R STA N D T H I S M A N UA L P R I O R TO O P E R AT I N G O R S E R V I C I N G T H I S P R O D U CT...
-
Page 2: Installation Instructions, General
Instruction manual- AquaT Manual marine toilet Applications General instructions for all possible installations SPX FLOW Johnson Pump Comfort and Compact bowl manually operated marine toilets can be installed in both power and sailing craft, either above You need: or below the waterline, for use on sea, river, lake or canal. •... - Page 3 Alternative 2 Alternative 3 Toilet above the waterline Toilet waste discharging into holding tank, dis- You may use a 19 mm. (3/4”) non-return valve charge elbow below top of holding tank at any • Run the inlet hose by the most direct route from the inlet seacock time to the flushing pump inlet tail •...
-
Page 4: Installation Instructions
Safety Pipework loosing All pipeworks must be fastened both in the gate side and in the remain- Ensure that these instructions reach the owner, the skipper or the operator ing ones with a stainless steel hose clamp. Please keep in mind that an of the craft, as it contains important safety information on completion of eventual leak might cause the craft to sink, with consequent loss of life use Installation:... -
Page 5: Maintenance Instructions
Cleaning Put the toilet in the selected position. Using the holes in the base as a guide, mark the positions for the 4 screws holes on the mounting A regular flushing with clean (sea)-water represents one of the most effec- surface. - Page 6 Winterization Refit Pump assembly on the toilet as follows • Locate the bottom valve gasket on its pegs on the base and locate Drain the complete system both as a protection against frost damage and the joker valve in the discharge elbow. to avoid the growth in the pipework of bacteria that could cause unpleasant •...
-
Page 7: Dimensions And Weight
Dimensions & Weight Part. nr. Description weight inch 80-47625-01 AquaT Toilet Manual Super Compact 13,39 23,82 11,81 15,75 8,46 18,11 inch 80-47229-01 AquaT Toilet Manual Compact 13,39 25,59 13,78 15,75 8,46 17,91 inch 80-47230-01 AquaT Toilet Manual Comfort 14,37 28,54 12,99 18,50 9,84 18,31 inch... - Page 8 Enlarged drawings Learn more about boat faucets and showers we have.
