Components
ITEM
DESCRIPTION
A
Headboard
B
Headboard Leg
C
Wing
Please note: actual product may look different
than illustration.
HARDWARE
5/8" x 5/16" bolt
(H1)
x 4
—
1 1/4" washer
(H2)
x 20 —
1" x 1/4" bolt
(H3)
x 4
—
1/4" nuts
(H4)
x 4
—
2" x 5/16" bolt
(H5)
x 8
—
Please note: you will need a flat head screwdriver and a wrench to asseble
your headboard.
QTY
1
2
2
H U B B A R D H E A D B O A R D A S S E M B L Y
Q U E S T I O N S ? C A L L 1 . 8 0 0 . 5 4 2 . 7 5 5 3
W I N G B A C K
A
C
B
1
Advertisement
Table of Contents
Related Manuals for Crate&Barrel WINGBACK HUBBARD
Summary of Contents for Crate&Barrel WINGBACK HUBBARD
- Page 1 W I N G B A C K H U B B A R D H E A D B O A R D A S S E M B L Y Components ITEM DESCRIPTION Headboard Headboard Leg Wing Please note: actual product may look different than illustration.
- Page 2 W I N G B A C K H U B B A R D H E A D B O A R D A S S E M B L Y Step 1 Attach (C) wing to (A) headboard using (H5) bolts and (H2) washer.
- Page 3 W I N G B A C K H U B B A R D H E A D B O A R D A S S E M B L Y Step 2 Insert (B) headboard leg through hole of (A) headboard and align the slots with the holes.
- Page 4 W I N G B A C K H U B B A R D H E A D B O A R D A S S E M B L Y Step 3 Attach assembled headboard to your bed frame using (H3) bolts, (H2) washers and (H4) nuts.
- Page 5 W I N G B A C K H U B B A R D H E A D B O A R D A S S E M B L Y Warranty LIMITED WARRANTY Skyline Furniture Inc. guarantees its upholstered furniture against defects in construction for a period of one (1) year.
