Summary of Contents for Falcon BRs 4

Page 1 C6 V. 3.0 FALCON BRs 4...
Page 3 PLEASE KEEP THIS HANDBOOK IN A SAFE PLACE, AND HAND IT OVER TO THE NEW OWNER IF YOU SELL THE CRAFT. Thank you for choosing Falcon. We trust you will get a great deal of pleasure out of the boat. Best regards,...
Page 4: Table Of Contents
Table of contents PAGE 18.9.2 Canopy GENERAL SECTION 18.9.3 Maintaining the door/hatch glides General information Definitions Guarantee Before use Registering Insurance Before leaving shore PAGE Transporting the boat TECHNICAL SECTION Hoisting the boat Technical specifications Design categories Transportation Before launching the boat Equipment Boat gradle Location of the equipment...
Page 5: General Information
The boat and equipment installed at the boatyard are guaranteed according to the enclosed guarantee terms. Separate letters of guarantee and contact information for the suppliers are attached. For other guarantee issues, please contact your nearest Falcon dealer. See www.falconboats.fi for a list of dealers.
Page 6: Before Use
2. Before use 2.1 Registering In Finland, according to Boating regulations, a boat equipped with an outboard or inboard motor or a stern drive engine of over 15 kW, or a watercraft which has a hull length of at least 5,5 m according to the manufacturer and is equipped with a motor or a sail, must be registered.
Page 7: Before Leaving Shore
3. Before leaving shore Familiarise yourself with this owner's handbook. Always check at least the following items before leaving shore: Weather and forecast Consider the wind, waves and visibility. Is the design category, size and equipment of your boat, as well as the skills of the skipper and crew sufficient for the waters you are going to? In strong winds and rough seas portholes, doors, hatches and vents must be closed to prevent water from getting into/onto the boat.
Page 8: Transporting The Boat
4. Transporting the boat 4.1 Lifting the boat When lifting the boat, we recommend to use a proper frame. Lifting without frame will cause considerable large compressive force to the hull of the boat and may cause damage to it. If not using a frame, make sure that the hoisting belts are long enough.
Page 9: Boat Gradle
4. Transporting the boat 4.4 Cradle In the drawing there is the boat cradle and dimensions for it. It is important that the cradle is made sturdy enough, so it can withstand the weight of boat securely. Make sure that there is no visible nails or screws that could scratch the aluminium or gelcoat- surface.
Page 10: Mooring The Boat To The Quay
5. Mooring the boat to the quay Examples of different types of mooring: When coming ashore or mooring to a quay the boat has to be secured properly. The basic rule is that the boat, when moored, should withstand high winds and rough seas. The boat should not be moored with temporary fastenings if the crew is not nearby.
Page 11: Anchoring And Mooring
7. Anchoring and mooring Moor your boat carefully, even in sheltered places, because weather conditions can change rapidly. Do not moor the boat with the stern facing the open sea, because high waves could wash onto the boat. Mooring ropes should be equipped with elastic shock absorbers to slacken the tension. To prevent abrasion, use suitable fenders.
Page 12: Leaving Shore
8. Leaving the shore 8.1 Safety instructions Fasten down all loose objects. All passengers must wear a life jacket. All passengers must remain seated when the boat is in motion. At least two persons must be capable of operating the boat. Special care should be taken when filling the fuel tank.
Page 13: Controls
9. Controls 9.1 Indicators Engine oil pressure gauge Speedometer Indicates the pressure of Indicates the speed the engine oil. Check the of the boat in km/h or KNOTS normal pressure range in knots. the engine instructions handbook. Tachometer Indicates the revolutions of Fuel gauge the engine per minute (RPM).
Page 14: Switches
9. Controls 9.2 Switches With these switches you can control the functions of the boat. Depending on the boat model and accessories, you can find these switches from your boat. Learn the function of each switch before going out with your boat. Navigation lights Bilge pump Anchor light...
Page 15: Steering
9. Controls 9.3 Steering Depending on the manufacturer of the engine the steering system may have different operating principles, for example cable or hydraulic steering. Some models may have power steering. All equipment needs regular maintenance to function properly. WARNING! Inadequate maintenance of controls may lead to loss of control over the boat.
Page 16: Stability
10. Stability Falcon boats are designed for good stability by placing heavy loads low down and by keeping the open deck space and other recesses on deck to a minimum. However, large breaking waves are always a serious danger to stability.
Page 17: Fire Protection
12. Fire protection Ensure that any load in the boat does not interfere with access to fire-fighting equipment. Inform all members of the crew about the location and operation of fire-fighting equipment, the location of discharge openings into the engine space, and the location of emergency routes and exits. Keep the bilges clean and regularly check for fuel and gas vapours or fuel leaks.
Page 18: Proper Use
13. Proper use - other recommendations and guidelines 13.1 Ventilation In unfavourable circumstances (following wind) and slow speed exhaust gases may get into the cabin through an open door. Keep the door shut if you smell exhaust gases inside the boat and ventilate through deck hatches.
Page 19: Carbon Monoxide Hazard
13. Proper use - other recommendations and guidelines 13.4 Carbon monoxide hazard...
Page 20: Steering Features
14. Steering features 14.1 Trim adjustments You can adjust the running attitude of the boat versatile by using trim tabs. The basic directions are as follows: - at half-planing speeds "bow down" position - when the boat is planing and the waves are small, lift the bow up slowly and follow the log to notice for how long the speed is increasing - in head sea lower bow down to soften the motions.
Page 21: Engine Start-Up
14. Steering features 14.2 Engine start-up Before starting the engine, ensure that the gear is in neutral, as shown on the warning plate attached at the front of the helm station (Fig. 7). Sudden starting may endanger persons on board. Figure 7.
Page 22: Visibility From Helm Station
15. Visibility from helm station Driving in nice weather and with a calm sea is simple but remember to arrange for proper lookouts as per International Regulations for Preventing Collisions at Sea (COLREG). Always ensure that the visibility from the helm station is as good as possible: - people, curtains, etc.
Page 23: General Service Instructions
17. General service instructions 17.1 Washing and cleaning Keep your boat clean and tidy. It increases comfort, safety, and the resale value of the craft. Washing and waxing is normally sufficient care for the deck and sides. Special boat shampoos are the most suitable agents for washing.
Page 24: Regular Maintenance Of The Engine
Make sure that there are no liquids in any tubes that can get frozen. Lift your Falcon out of the water in good time before it ices over. The craft must not be left in an icy environment.
Page 25: Actions Prior To, And After, Boating Season
18. Maintenance 18.6 Actions prior to, and after, boating season A new boat does not really need any special maintenance at the beginning of the season, but if the boat is used in polluted waters, special care should be taken with shells, which may become attached to the hull.
Page 26: Maintenance Of The Railing
18. Maintenance 18.8 Maintenance of the railing The railing is made of acid-proof steel. When lifting the boat do not use steel wires or shackles in direct contact with the acid-proof components. Make sure no parts of the boat are scratched or damaged during transportation. If any damage occurs, the railings and fittings should be polished and waxed carefully.
Page 27 Owners handbook Technical part...
Page 28: Technical Specifications
19. Technical specifications Falcon 4 BRs The boat has a serial number, the CIN-code. The CIN-code is marked on the right side of the back of the hull of the craft. Write down the CIN-code in the chart below. When you contact the manufacturer or retail dealers, tell them the CIN-code as well as the type of the boat to ensure that you get the suitable spare parts.
Page 29: Design Categories
20. Design categories Design categories are as follows: Category A: This craft is designed to be used in conditions in which wind forces may exceed 8 on the Beaufort scale (ca. 21 m/s) and waves may be 4 m high. In these conditions, category A vessels are largely self-sufficient.
Page 30: Equipment
21. Equipment Dry powder extinguisher CAUTION! The boat is equipped with a dry powder Never turn off the current by the extinguisher rated 13A 70 BC. The total effect of main switch while the engine is the boat’s extinguishers must be at least 8A running.
Page 31 22. Location of the equipment Falcon 4 BRs 1. Main switch and fuses 2. Extinguisher 3. Navigation lights 4. CE-plate 5. Fuel filler 6. Bilge pump 7.CIN-code 8. Draining (make sure the drain holes are not blocked) 9. Cockpit draining...
Page 32: Location Of The Equipment
22. Location of the equipment Falcon 4 BRs 1. Fuel tank 50 L 2. Battery 3. Suction head of manual bilge pump 4. Thru hull fitting of bilge pump 5. Fuel filter * OPTIONAL 2. 2. The locations of the equipment can vary depending on the accessories installed.
Page 33: Loading
23. Loading The maximum recommended load for the boat can be calculated as follows: the total weight of persons on board (the default mass of an adult is 75 kg and of a child 37.5 kg). basic equipment kg consumable liquids (fresh water, fuel etc.) in portable containers kg consumable liquids (fresh water, fuel etc.) in permanently installed tanks kg (filled to the maximum capacity) dry provisions and other stores kg...
Page 34: To Prevent Water Entering The Vessel
24. To prevent water entering the vessel 24.1 Openings in the hull and deck The locations of the outlets/inlets and their closing valves are illustrated in section 22. Location of the equipment. We recommend closing the valves (except for rain water drainage in the open deck space) when the boat is left without crew.
Page 35: Fuel System Functioning
25. Fuel system functioning Fuel filling hole Fuel tank ventilation valve Fuel tank ventilation valve connector Fuel tank Fuel tank filling hose connector Fuel level sensor Fuel filling hose Fuel return hose (only for diesel engines) Engine Fuel filter (assembled to the fuel filling hose) The location of equipment may vary depending on the model or the equipment.
Page 36: Electrical System
32. Electrical system The fuses fitted in Falcon boats are so-called automatic fuses, which can be reactivated after overload by pressing the toggle that has flipped downwards. Do not alter the rated amps of the fuses or install any electrical components exceeding the rated current of the circuit.
Page 37: Wiring Diagrams
33.Wiring diagram Falcon 4 BRs The electric wiring diagram is in the pocket at the back cover of this manual! Fuses Navigation light Bilge pump 12 V DC + usb Chart plotter © Bella-Veneet Oy reserves the right to make changes to the electrical systems.
Page 39 Bella-Veneet Oy Väliköntie 10 FI- 70700 Kuopio www.bellaboats.fi © Bella-Veneet Oy We reserve the right to make changes without prior notice.
