Q180 Series
Tiny Desktop PC
Read the detailed information in the Safety and Warranty Guide
before using this computer.
Notes:
• Figures and illustrations in this Quick Reference are
provided for reference only and may differ from actual
product appearance.
• Product design and specifications may be changed without
notice.
• The color and shape may vary depending on the model.
Attention: Be sure not to block any air vents on the computer.
Blocked air vents may cause thermal problems.
Version: 1.0
2011.08
31500792
Initial setup instructions
Connect to power

Front view

Rear view

Install optical drive (selected
models only)
Power button
Hard disk drive indicator
Optical drive
Memory card reader
USB ports (2)
Headphone connector
Microphone connector
SPDIF port
VGA connector
USB ports (5)
HDMI-out port
Ethernet connector
Power connector
1
2
