OWNER'S MANUAL
Dirt Bike
No one under the age of 16 should operate this Dirt bike without adult supervision.
Parents should consider child's age, size, maturity and ability before allowing to ride.
Always wear a helmet; It could save your Life!
This manual should be considered as a permanent part of the vehicle and should remain with
the vehicle when resold or otherwise transferred to a new user or operator. The manual
contains important safety information and instructions which should be read carefully before
operating the vehicle.
Please obtain, review, and follow the municipal, provincial and government acts and
regulations pertaining to owning and operating an off-road vehicle.
This manual is applicable to RPS110S, RPS110DLX, RPS125S and RPS125DLX models.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RPS125S and is the answer not in the manual?

Questions and answers

Summary of Contents for PPS RPS125S

  • Page 1 Please obtain, review, and follow the municipal, provincial and government acts and regulations pertaining to owning and operating an off-road vehicle. This manual is applicable to RPS110S, RPS110DLX, RPS125S and RPS125DLX models.
  • Page 2 Congratulations on your purchase of the Ricky Power Sports LLC. Dirt Bike. Your bike is warranted to be free of manufacturing defects in the material and workmanship for a period of 90 days from the date of purchase. During the warranty period Ricky Power Sports LLC. will at its option, repair, provide replacement parts or replace your Ricky Power Sports LLC.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Notice to User’s ........................ 2 Safe Operation ........................3 Pre-Ride Checklist ......................3 Safty Gear ........................4 Location of Warning Lables ....................5 Main Data ......................... 5 Parts & Subassembles ....................... 7 Components Locations ...................... 8 OPERATION ........................10 Fuel Valve ........................

  • Page 4: Notice To User's

    NOTICE TO USER’S Important notes: This manual includes four models RPS110DLX, RPS110S, RPS125DLX and RPS125S. The pictures in the manual are quoted as RPS110DLX. The positions of parts of other models are the same, so it will not be repeated. Please refer to the real vehicle.

  • Page 5: Safe Operation

    SAFE OPERATION A pre-operation check must be conducted before starting the engine. This check will insure safety, prevent mishaps, and prevent damage to components. It is strongly suggested that all operators take a certified motorcycle rider’s course prior to operating the vehicle. Full attention is required during driving;...

  • Page 6: Safty Gear

    b) Properly inflate both tires. We recommend that you inflate the front tire to 15 psi and the rear tire to 20 psi. Do not exceed 32 psi. 5. Drive chain a) Check condition and tension. b) Lubricate and adjust tension as necessary. 6.

  • Page 7: Location Of Warning Lables

    LOCATION OF WARNING LABLES Read and follow all of the warnings labels on your Dirt bike. Make sure you understand all the labels. Keep the labels on the Dirt bike. Do not remove them for any reason. If a label come off or become difficult to read, you should get a replacement by contacting Ricky Power Sports LLC.

  • Page 8: Main Data

    MAIN DATA ENGINE DESCRIPTION 110 series 125 series Engine Type Single cylinder, air cooled, four stroke, horizontal machine Displacement (ml) 106.693 Bore×Stroke (mm) 52.4×49.5 54×54 Compression Ratio 9:0:1 9:0:1 Max. Power (kw/r/min) 5.0kW/7500rpm 6.0kW/7500rpm Max. Torque (N.m/r/min) 7.5N.m/5500rpm 9.5N.m/5500rpm Max. Speed (Km/h) Lubrication Pressure, splash Clutch Type...

  • Page 9: Parts & Subassembles

    PARTS & SUBASSEMBLES NOTE: RPS110DLX model is quoted in the following contents. The pictures of other models are the same and will not be repeated.

  • Page 10: Components Locations

    COMPONENTS LOCATIONS Model 110DLX Model 110S NOTE: The panel decal may not match the actual vehicle, please refer to the actual vehicle.
  • Page 11 Model 125DLX Model 125S NOTE: The panel decal may not match the actual vehicle, please refer to the actual vehicle.

  • Page 12: Operation

    OPERATION FUEL VALVE Fuel filling The capacity of the fuel tank is 6.0L. Unscrew the gas cap by turning it counter clockwise and carefully fill the tank with unleaded gasoline through the opening. DO NOT MIX GAS AND OIL TOGETHER, THIS IS A 4-STROKE ENGINE. Replace the gas cap by carefully aligning the threads on the cap and the tank and turning the cap clock wise.

  • Page 13: Engine Starting

    ENGINE STARTING CAUTION Verify oil level prior to starting. Starting the engine with low or no oil will damage the engine. WARING Never start the engine in a closed place as the exhausted gas from the vehicle contains toxic carbon monoxide. 1.

  • Page 14: Breaking In The Engine

    BREAKING IN THE ENGINE The first 600 Miles of operation should be considered the “Break-in” period and special attention shall be paid to the following points: 1. Take special care not to increase the RPM’s of the engine while climbing steep slopes. Never drive your dirt bike continuously for more than 50km (30 miles) without increasing and decreasing the throttle.

  • Page 15: Gear Shifting

    GEAR SHIFTING Reduce throttle before shifting. Never increase the throttle while shifting gears. Pull in the clutch lever, located on the left hand grip. Depress the Shift lever to place the gear in 1st, lift up the lever to shift to 2nd, 3rd, 4th and 5th.

  • Page 16: Check-Ups, Adjustment And Maintenance

    4. Do not use the front brake only or coast using the neutral gear especially when descending or driving at a high speed. 5. Decrease the throttle when braking. CHECK-UPS, ADJUSTMENT AND MAINTENANCE Checking the Oil Check the engine oil each time prior to operating the dirt bike. The oil level should be between the upper and lower lines of the oil sight gauge located on the right cover of the crankcase.

  • Page 17: Changing The Oil, Cleaning Oil Filter Screen

    CHANGING THE OIL, CLEANING OIL FILTER SCREEN 1. of the engine and let the oil drain into an approved collection container. DO NOT PERFORM THIS PROCEDURE WHILE THE ENGINE IS HOT. SERIOUS BURNS COULD RESULT FROM CONTACT WITH HOT OIL. 2.

  • Page 18: Checking & Cleaning The Air Filter

    CHECKING & CLEANING THE AIR FILTER Air filter is located under left side plastic cowling. Cowling will need to be removed. Take the air filter out and check to see if it is dirty or torn. Remove foam element and wash with water and allow it to dry per instructions below.

  • Page 19: Adjusting The Carburetor

    ADJUSTING THE CARBURETOR When the vehicle leaves the factory, the idle speed has been optimized and the user does not need to adjust it. If the idle speed is indeed unstable, please go to the local dealer for treatment. CAUTION The vehicles have no adjustable operating parameter.

  • Page 20: Clutch Adjustment

    4. To add brake fluid, unscrew cap on top of brake fluid container. Add DOT3 or DOT4 brake fluid. Do not mix brake fluid types. CLUTCH ADJUSTMENT To adjust the clutch lever play: 1. Remove the adjuster cover (slide back on cable).

  • Page 21: Adjustment Of Chain

    ADJUSTMENT OF CHAIN 1. When chain adjustment is needed, loosen rear axle nut . 2. Turn the chain adjusting brackets on the left and right sides to adjust the tension of the chain and to align the marking of the chain adjuster with the engraved lines in the similar position on both sides.

  • Page 22: Fuel Supplying Check

    FUEL SUPPLYING CHECK 1. Make sure there is adequate fuel in the fuel tank. 2. Check that the engine stop switch is in the “RUN “ position. 3. Check that the fuel valve is in the “ON” position. 4. Make sure there is enough fuel reaching the carburetor from the fuel tank. WARNING Draining fuel from the carburetor could be hazardous.

  • Page 23: Vehicle Washing

    COMPLAINT: Engine stalls 1. Make sure there is enough fuel in the fuel tank. 2. Check to see that the spark plug is not fouled. Remove the spark plug and clean it. Replace it, if necessary. 3. Make sure the fuel valve is not clogged, and the fuel tank is not clogged, either. 4.

  • Page 24: Resumption Of Service After Storage

    1. Change engine oil and clean oil and air filters. 2. Drain off fuel from the fuel tank and carburetor, spray atomized anti-rust oil onto the inside wall of the tank and then close the tank. Dispose of any drained fuel properly so as not to adversely affect the environment.

  • Page 25: Table Of Torque Of Fasteners

    20~25 Nm(15~18 ft.lb.) Bolt for tightening upper joining plate or 15~20 Nm(11~15 ft.lb.) front fork with shock absorber NOTE: RPS125S model is quoted in the following contents. The pictures of other models are the same and will not be repeated.

  • Page 26: Resumption Of Service

    RESUMPTION OF SERVICE 1. Remove the covering and clean the vehicle. Change the lubricating oil if the vehicle has been off service for more than 4 months. 2. Drain off the anti-rust solution from the fuel tank, followed by filling fuel therein to the required level.

  • Page 27: Maintenance Schedule

    MAINTENANCE SCHEDULE Owner’s Manual for the ATV is available upon EPA’s request. To keep the performance good, the vehicle should be checked and maintained at certain interval. The meanings of capital in following table are: I: Inspection, including check, clean, lubricate, refuel, repair or replacing if necessary. A: Adjusting C: Cleaning R: Replacing T: Tightening Odometer (km) Items...

  • Page 28: Serial Number Location

    SERIAL NUMBER LOCATION You need to know the frame and engine serial numbers to get title documents for your Dirt Bike. You also need these numbers to help your authorized service center or Ricky Power Sports LLC. order parts. The Frame number is stamped on front of Dirt bike frame. The engine number is located on the left side of the engine housing.

  • Page 29: Wire Diagram

    WIRE DIAGRAM...

  • Page 31: Kt Powersports Llc- Emission-Related Warranty

    KT POWERSPORTS LLC– EMISSION-RELATED WARRANTY YOUR WARRANTY RIGHTS AND OBLIGATIONS The emission-related warranty period for this vehicle begins on the date the vehicle is delivered to the first purchaser other than an authorized dealer, or the date it is first used as a demonstrator, lease, or company vehicle, whichever comes first and continues for 5,000 km or 30 months, whichever comes first, provided there has been no abuse, neglect or improper maintenance of your vehicle.
  • Page 32 defective or causes a failure of a warranted parts, your claim for repair to bring your vehicle into compliance with applicable standards may be denied. If an emergency situation exists when a warranted part, device, or component or a dealer is not reasonably available to the owner, repairs may be performed at any available service establishment, or by the owner, using any replacement part, device, or component.
  • Page 33 Ricky Power Sports, LLC. 2425 Camp. Avenue, Carrollton, TX 75006 Toll Free: 844-250-2199...
