Page 1 GC 339+ 203883-00 47.0643 v2 - 10.2022...
Page 2: Table Of Contents
GC 339+ Translation of the original operating instructions for device version 0600 Contents Symbols and illustrations .................4 Abbreviations .......................4 Product liability ....................4 Safety ......................5 Intended use........................5 Safety notes ........................5 Safety-conscious working ....................6 Environmentally conscious working ................6 Description ....................7 Scope of delivery .......................9 Work to be done before installation ..........9 Installing the drive......................9 Safety sensor system .....................
Page 3 GC 339+ 10.1 Single leaf installation and separate activation ..........25 10.2 Wall mounting ......................... 27 Maintenance ...................27 Fault messages and troubleshooting ..........28 Technical data ..................30 Accessories / spare parts ..............31...
Page 4: Symbols And Illustrations
GC 339+ Symbols and illustrations Warning notices In these instructions, warning notices are used to warn against material damage and injuries. Always read and observe these warning notices. Observe all measures marked with the warning symbol and warning word. Explanation of symbols In these instructions, the following symbols are used for setting and config- uration work: Symbol...
Page 5: Safety
à Make sure that the cover of the drive is fitted correctly and earthed. à If unauthorised changes are made to the system, GEZE cannot be held li- able in any way whatsoever for any resulting damage, and the statement of approval for use in escape and rescue routes is no longer valid.
Page 6: Safety-Conscious Working
Safety GC 339+ à The risk assessment and installation of the sensor and the door system in compliance with national and international regulations and door safety standards are the responsibility of the door manufacturer. à The manufacturer cannot accept any responsibility for defective installa- tion or setting of the sensor.
Page 7: Description
GC 339+ Description Description The GC 339+ safety sensor has an infrared field for protection. The mutual influence of several sensor systems with hazardous effect is not possible. Unintentional stop signals are possible where detectors are mounted next to one another, since their infrared measuring ranges overlap and each sensor could activate the other.
Page 8 Description GC 339+ Cover IR lens (interface) Setting push button (grey) Width adjustment of the IR Button for setting the angle of curtain the IR curtain (red) IR lens (transmitter) Main connector...
Page 9: Scope Of Delivery
GC 339+ Work to be done before installation 2. 1 Scope of delivery Work to be done before installation 3. 1 Installing the drive Make sure that the cover of the drive is fitted correctly and earthed.
Page 10: Safety Sensor System
Work to be done before installation GC 339+ Safety sensor system One combined detector per passage direction is installed on automatic sliding doors. The GC 339+ safety sensor may be required in addition for larger opening widths. For escape and rescue routes: à...
Page 11: Installation
GC 339+ Installation Installation 4. 1 Installation without accessories Avoid extreme vibrations. Do not cover the sensor. Keep away from fluorescent lamps. Keep away from moving objects. Avoid highly reflective objects in the infrared range. Keep a distance of at least 150 mm away from lights, signs or hot air curtains.
Page 12: Installation With Ceiling Installation Kit
Installation GC 339+ Installation with ceiling installation kit Ceiling installation kit Ceiling installation kit, short...
Page 13 GC 339+ Installation click click click...
Page 14: Installation With Mounting Bracket
Installation GC 339+ Installation with mounting bracket DIN 7981 8 × ½“...
Page 15: Installation With Weather Hood
GC 339+ Installation Installation with weather hood...
Page 16: Cabling
Installation GC 339+ Cabling Heed wiring diagrams for the sliding door drives. GC 339+ GC 339+ SIS1 24Vsw 110 mA 24Vsw SIS2 SIS1 SIS2 24Vsw 24Vsw IR curtain Test When activated, the output of the GC 339+ is opened (GND applied to the SIO input).
Page 17: Retrofit
GC 339+ Retrofit Retrofit GC 339+ SIS1 GC 339 SIS1 24Vsw 110 mA 24Vsw 24Vsw SIS2 110 mA 24Vsw SIS2 SIS1 SIS2 SIS1 SIS2 24Vsw 24Vsw 24Vsw 24Vsw Commissioning 6. 1 Protection area The position of the IR curtain in relation to the door can be checked using a spot finder.
Page 18 Commissioning GC 339+ Activate 4 visible Adjust the tilt angle of the active Yellow LED is flashing spots.* infrared detector. on spot finder Alignment correct. max. 9 cm max. 20 cm * Visibility depends on the environmental conditions. à Test the width of the required area using a piece of paper (DIN A4), since the spot finder detects over the whole emission area.
Page 19: Settings
GC 339+ Commissioning Testing the emission area. à The “IR: width” parameter must be set identically (see chapter 8). à The complete NSK of the door must be covered. Set additional IR:Width parameters. Standard-conform sensor setting according to DIN 18650 / EN 16005 Installation height Detection width DIN 18650 / EN 16005 2.00 m...
Page 20: Configuration Possibilities
Configuration possibilities GC 339+ Teach-in 2 sec. Teach-in with door movement 4 sec. Configuration possibilities 7. 1 Using the LCD menu 7.1.1 Display during normal function Opening impulse Protection Image shown negative Set contrast = active exit 7.1.2 Menu navigation English Back Password...
Page 21: Changing And Storing Values
GC 339+ Settings 7.1.4 Changing and storing values IR:Immunity IR:Immunity IR:Immunity >2.8m 4 <2.8m 2 >2.8m 4 7.1.5 Checking values using the remote control Settings 8. 1 Presettings Choose the following default settings or configure the settings yourself (see chapter 7). Pre-setting STANDARD: Standard...
Page 22 Settings GC 339+...
Page 23 GC 339+ Settings...
Page 24: Last Installation Steps
Last installation steps GC 339+ Last installation steps Before leaving the installation, check the sensor for correct function.
Page 25: Further Installation Situations
GC 339+ Further installation situations Further installation situations 10. 1 Single leaf installation and separate activation Installation height Distance between Max. leaf width* Detection width DIN detector and main 18650/EN 16005 closing edge 2000 1150 2000 2200 1350 2200 2500 1650 2500 3000...
Page 26 Further installation situations GC 339+ Distance Main closing edge Installation height Protection; 2 m height according to DIN 18650 / EN 16005 Leaf width Detection width...
Page 27: Wall Mounting
GC 339+ Maintenance 10.2 Wall mounting According to DIN 18650/EN 16005, the distance between the inner active infrared detectors must not exceed 200 mm. In the case of other dimensions, please contact the sales department first. Installation height a Max. reveal depth b (in mm) (in mm) 2000...
Page 28: Fault Messages And Troubleshooting
Fault messages and troubleshooting GC 339+ Fault messages and troubleshooting Effect Cause Elimination display The ORANGE LED The sensor has Switch the power supply flashes 1 x detected an internal off and on. error. Replace the sensor if the ORANGE LED continues to flash.
Page 29 GC 339+ Fault messages and troubleshooting Effect Cause Elimination display – The RED LED The sensor is vibrat- Check whether the lights up sporad- ing. sensor has been fixed in ically place correctly. Check the position of cable and cover. The sensor senses Start teach-in with door the door.
Page 30: Technical Data
Technical data GC 339+ Technical data Power supply 12 V to 24 V, AC ±10%; 12 V to 30 V, DC ±10% Power consump- < 2.5 W tion Installation height 2 m to 3.5 m Temperature –25 °C to +55 °C, 0 to 95% relative humidity, non-condensing range Protection class IP54 according to EN 60529 Presence Detection mode...
Page 31: Accessories / Spare Parts
GC 339+ Accessories / spare parts Accessories / spare parts Material no. Ceiling bracket 153568 151253 (black) Ceiling installation kit 151254 (white) Ceiling installation kit 200682 (short) Weather hood 158250 Curved adapter 151540 Remote control 100061...
Page 32 Accessories / spare parts GC 339+ Material no. Spot finder 112321 203864 (black) Cover 203866 (according to RAL) IR window 203867 Replacement cable 203868 2.5 m...
Page 33 GC 339+ Accessories / spare parts...
