The manufacturer and its distributors cannot be held responsible for any damages caused by improper use or misuse of this SpaceLas laser system. The owner/user is fully responsible for using this product in accordance to laser safety regulations of the country or state where the system is being used.
WHAT IS INCLUDED 1 X Laser projector 1 X Flight case/ Plastic hard case (selectable) 1X Safety key for projector 1 X E-stop RJ45 plug (Shunt) 1X Power cord 1X Metal safety wire UNPACKING INSTRUCTIONS Open the flight case/ carton box carefully unpack everything inside. Ensure all parts are present and in good condition.
SAFETY NOTES WARNING! This projector is a Class 4 laser product. It must never be used for audience-scanning applications. The output beam of the projector must always be at least 3 meters above the floor in the audience. See the Proper Operation section for further information. Please read the following notes carefully! They include important safety information about the installation, usage, and maintenance of this product.
TECHNICAL SPECIFICATIONS Laser: Laser Classification: Class 4 Laser sources:Full diode lasers Beam diameter (1/e2):<4.0mm Beam divergence (1/e2):<1.0mrad (full angle) Laser Wave Length:445-640nm Maximum total output power:<14, 000mW Projector: Scanner:35kpps@8° Aperture:5mm Scan angle:50degree,Max:70degree Laser emission window:B+W antireflective coated AC power input:100-240VAC / 50-60Hz Input power:200W maximum Max.
Page 6
6. THE SPECIFICATION OF THE FRONT AND REAR PANEL REMOTELOCK SCAN SAFETY On/Off ETHERNET POWER SWITCH FUSE 6.3A SECURITY KEY SWITCH INPUT OUTPUT 1. ON/OFF, POWER SWITCH 2. POWER IN/OUT 3. MAIN FUSE HOLDER 4. SAFETY WIRE EYELET 5. KEY SWITCH 6.
Page 7
8. REMOTE INTERLOCK / REMOTE E-STOP BOX 1. If you do not use E-stop box, please insert the white RJ45 plug (shunt) to the projector. (Refer photo below) 2. Connect the remote E-stop box to any of the RJ45 connector (Remote lock) on the rear of the projector using Ethernet cable.
Page 8
10. OPERATION OF 360DEGREE BRACKET 360 degree 11. EASY BEAM ALIGNMENT MECHANISM 1. Screw bolt 1, to access the color alignment of red laser. 2. Screw bolt 2, to access the color alignment of green laser. bolt 2 bolt 1...
PROPER USE This product is for overhead mounting only. For safety purposes, this projector should be mounted on steady elevated platforms or sturdy overhead supports using suitable hanging clamps. In all cases, you must use safety cables. International laser safety regulations require that laser products must be operated in the fashion illustrated below, with a minimum of 3 meters (9.8 ft) of vertical separation between the floor and the lowest laser light vertically.
WIRING DIAGRAM Fuse Scanners power supply(PUS) RGB Module power supply(PUS) AC110/ 230V NI Power Switch 0V 0V 12V 12V - 24V GND + 24V KeyOn/Off Switch RGB Driver board Interlock Emission LED + - + - + - Auto power cut swtich DB-25-pin Mechanical...
Page 11
ILDA CONNECTION Connect the projector to your controller using a standard 25-pin ILDA cable (DB-25). Be sure to tighten the connecting screws to ensure the cable does not become disconnected. This projector is wired to accept ILDA standard analog signals for X, Y and color information. The ILDA standard uses a DB-25 cable to carry these signals from the controller to the projector.
