Warning/Status Codes - ebm-papst S3G500-ZQ12-90 Operating Instructions Manual

S3G500-ZQ12-90
Impeller not Imbalance in rotating
running smoothly parts
Motor not turning Mechanical blockage
Line voltage faulty
Faulty connection
Broken motor winding Replace device
Inadequate cooling
Ambient temperature
too high
Impermissible
operating point (e.g.
back pressure too
high)
In the event of further malfunctions, contact ebm-papst.

6.1 Warning/status codes

The LED on the electronics housing shows the motor status with various
colors and flash codes. The flash codes have a frequency of 2 Hz.
Each flash code is followed by a pause lasting 3 seconds. The following
colors are used: Green: no warning or fault. Orange: There is a warning.
No user intervention is required for warnings. Red: There is at least one
error. See the following table. If there are multiple simultaneous errors,
their associated flash codes are displayed in succession. If there are
simultaneous warnings and errors, only the errors are displayed.
6.1.1 Warning codes
Number of pulses Motor status - LED
orange
1 Current limitation in
action
2 Line impedance too
high (DC-link voltage
unstable)
3 Power limiter in action
4 Output stage
temperature high
5 Motor temperature high
