Summary of Contents for Dynamicnord SBC-20
- Page 1 To download this user manual in additional languages please visit our website’s SERVICE-section – DYNAMICNORD.COM. Ce manuel a été imprimé en utilisant des matériaux respectueux de l’environnement SBC-20 MANUAL BUOYANCY COMPENSATOR...
-
Page 3: Table Of Contents
BCDs. Preparation Standard tank strap Further information and the manual in other languages Weight belt can be found on our website at DYNAMICNORD.COM. Inflator Register your product at DYNAMICNORD.COM to receive Using the inflator all warranty services. -
Page 4: Important Warnings
A face-up swimming position that is save for an unconscious person cannot be guaranteed under all circumstances. WARNING Before diving, make sure you fully understand all the functions and features of the BCD and how to adjust the straps. If in doubt, please contact your DYNAMICNORD dealer. -
Page 5: Important Cautions
The equipment must be serviced by qualified professionals at the prescribed intervals. Repairs and maintenance work must be carried out by an authorized DYNAMICNORD dealer using original spare parts by DYNAMICNORD only. If the equipment is not used in accordance with the purpose... -
Page 6: General Information
(fig. A). The SBC-20 model is approved for use with mono cylinders with a DYNAMICNORD BCDs have a hard carrying frame. Please align maximum volume of 15 liters or a maximum total weight of 20 kg. - Page 7 WARNING To prevent an accidental loss of the tank, ensure that the strap is wrapped tight enough around the tank so that it cannot move or slip on the BCD. Failure to follow these instructions can result in injury or death. WARNING Soak the fabric of the tank strap and tighten it firmly before each use of the BCD.
-
Page 8: Weight Belt
A conventional waist weight belt should never be connected to the BCD. Inflator DYNAMICNORD BCDs are equipped with an inflator. When the inflator is connected to the regulator and – using the quick-connect coupler Make sure both couplers are free of debris before connecting –... -
Page 9: Using The Inflator
Using the inflator INFLATION Inflating the BCD using the inflator valve To inflate the BCD, press the inflator valve button (fig. 6-P). Air should begin to flow into the BCD. By briefly pressing the inflator button repeatedly you can easily control the amount of air during inflation. Inflating the BCD orally The mouthpiece is located at the end of the inflator. -
Page 10: Adjusting The Harness
BCD. Adjusting the BCD to different body sizes All DYNAMICNORD BCDs allow for optimal size adjustment by Function of the pressure relief valve combining different adjustment options. If necessary, the waist belt The pressure relief valve prevents over-inflation of the BCD. -
Page 11: Checking And Use
Checking and use Adjustement options BCD checks before, during and after a dive help identify equipment problems before an unsafe situation arises. The entire equipment must be inspected regularly by an authorized diving equipment repair shop. Circum- ference WARNING NEVER DIVE with a BCD that did not pass any of the inspections and checks before, during or after the dive. -
Page 12: Storage
WARNING WARNING NEVER DIVE with a BCD that is damaged, leaking air, Avoid prolonged or repeated exposure to chlorinated water or malfunctioning. If your BCD gets damaged, leaks air, or as used in swimming pools. Immediately wash your BCD malfunctions, abort the dive as safely and as quickly as after each use in chlorinated water. -
Page 13: Specifications
Low pressure hose / inflator valve WARNING Operating pressure of low pressure 95 – 200 psi (6.5 – 13.8 bar) Due to the excessive strain, BCDs in rental/dive centers or hose and inflator valve used professionally or subjected to intensive use must be checked at least every six months. -
Page 14: Useful Life
Kbely, 197 00 Praha 9, Czech Republic Sources Notified Body No. 2452 Applied Standard: EN1809:2014+A1:2016 EN1809:2014+A1:2016 Bruckmühl, dated 21.01.2022 www.europa.eu This declaration of conformity can also be found at WWW.DYNAMICNORD.COM in the Declarations of Conformity menu. For Fifth Element GmbH Martin Kusche (General Manager) -
Page 15: Risk Assessment And Management
BCD. It should not be used until the problem can be solved. The DYNAMICNORD BCDs are not designed for use on bare skin and may only be worn over a suitable diving suit to avoid friction on the skin. - Page 16 Cord is torn off and tear of during the by an authorized correct size, the correct tank or gone. components. dive. Ascent DYNAMICNORD not assembled size and change may be too technician. properly. it if necessary. fast. Follow the instructions...
- Page 17 PROBLEM CAUSES CONSE- SOLUTION PROBLEM CAUSES CONSE- SOLUTION QUENCES QUENCES D U R I N G T H E D I V E D U R I N G T H E D I V E Loss of Damage to Loss of Initiate imme- Damage to...
-
Page 18: Inspection And Maintenance Interval
Service record Your BCD (including the inflator) should be inspected and serviced by an authorized DYNAMICNORD dealer at least once a year, or more often if you dive frequently. This action is required to maintain the warranty. At the end of this manual you will find a maintenance log for the dealer to record the maintenance performed. -
Page 19: Warranty Information
To validate your warranty, you must register online within 30 days of purchase. All warranty claims are handled by DYNAMICNORD or an authorized DYNAMICNORD dealer. This warranty covers all DYNAMICNORD BCDs with a 2 year warranty. Product warranty registration: Date of purchase www.dynamicnord.com/registration...
