Summary of Contents for Dynamicnord ST-300
- Page 1 To download this user manual in additional languages please visit our website’s SERVICE-section – DYNAMICNORD.COM. ST-300 MANUAL DIVERS WATCH...
- Page 3 Screw-down crown Further information and the manual Setting time and date in other languages can be found on Using the adjustment ring our website at DYNAMICNORD.COM. Properties and type Quartz movement and battery Register your product at Quality preservation DYNAMICNORD.COM to receive all Care warranty services.
- Page 4 WARNINGS ATTENTION ATTENTION Before using the watch, please make sure The divers watch does not guarantee to read and follow the instructions below: the safety of its user. It is a tool that mainly shows the passage of time. Only use this watch in combination with safe diving equipment (dive computer, residual ATTENTION...
- Page 5 BEFORE THE DIVE Make sure that: Make sure that: The watch functions properly. You avoid wearing or storing the watch in The battery is sufficiently charged. the following places for an extended period The adjustment ring can easily be turned of time.
- Page 6 Additional warnings ATTENTION Never disassemble or modify the watch. Failure to strictly observe the following In particular, please be aware that you safety instructions could lead to serious may injure yourself when touching the consequences such as injuries. watch and that there is a risk of an allergic reaction such as a rash and itching.
- Page 7 If condensation can be seen on the inside the watch was purchased or contact of the watch glass or water droplets remain DYNAMICNORD directly as stated on our inside the watch for an extended period website. of time, the watch is no longer waterproof.
- Page 8 In case of malfunction, please contact the Make sure the watch store where the watch was purchased does not hit any hard or contact DYNAMICNORD directly. objects such as rocks. Rotating the adjustment ring can be a bit more difficult under water.
- Page 9 AFTER THE DIVE PARTS AND FUNCTIONS After the dive, please follow the care instructions below. Minute Hour Second Rinse the watch in fresh water to Hand Hand Hand completely remove any seawater, dirt, sand, etc. After cleaning the watch with fresh water, wipe it dry thoroughly.
- Page 10 SCREW-DOWN CROWN The screw-down crown prevents water from entering the watch and any associated malfunctions. Before operating a screw-down crown, it must be loosened. After operating the crown, it must be screwed down again tightly. Before operating the crown, loosen it by turning the crown counter-clockwise.
- Page 11 SETTING TIME AND DATE The watch's date function is designed to Now pull the crown out to the second advance the date once every 24 hours. lock-in position to set the time. Then turn The date changes at around 12:00 a.m. the crown to advance the watch hands (midnight).
- Page 12 USING THE ADJUSTMENT RING After that, the minute hand indicates the elapsed time, by pointing to the graduation By turning the adjustment ring counter- on the ring. clockwise before the dive the elapsed time can be measured. To do so, the "0" mark must be set to the minute hand.
- Page 13 PROPERTIES AND TYPE On the back of the case, the materials and The temperature can also impair the precision properties of your watch are listed. of the quartz movement, changing it by -0.5 water resistance in meters to +0.7 seconds per day. serial number watch body material To reduce energy consumption, pull the...
- Page 14 Remove moisture, sweat or dirt using a where the watch was purchased or contact soft cloth. DYNAMICNORD directly as the watch After contact with sea water, rinse the requires repair and degaussing. watch in clean fresh water and dry it thoroughly.
- Page 15 WRISTBAND The wristband comes into direct contact with Skin irritation and allergies the skin and gets soiled by sweat and dust. A wristband can cause skin irritation for Poor care can therefore accelerate the wear several reasons, such as allergies to metals and tear of the wristband or may cause skin or silicone, or reactions to the skin rubbing irritation.
- Page 16 WRISTBAND EXTENSION Sometimes it is necessary to expand the wristband extension wristband significantly. with clasp Depending on the required length, the included wristband extension is positioned on the free side of the wristband and fixed with the clasp. The extended wristband can then be closed and opened as usual.
- Page 17 Register your product at DYNAMICNORD.COM The watch may only be overhauled by immediately after purchase to receive all DYNAMICNORD or one of its service partners warranty services. who use "DYNAMICNORD ORIGINAL PARTS". For a repair or overhaul, please contact In the case of "external repairs", any warranty...
- Page 18 TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE SOLUTIONS The watch has The battery is empty The battery needs to be changed by a stopped. specialty retailer. Proof of tightness must be provided. The watch has been exposed Normal accuracy will be restored when the to extremely high or low watch is returned to normal temperatures.
- Page 19 PROBLEM POSSIBLE CAUSE SOLUTIONS The watch has The watch has not been Please contact the specialty store where stopped. serviced for more than the watch was purchased. 3 years. The date AM/PM is set incorrectly. Advance the hands 12 hours. changes at 12:00 noon.
- Page 20 Model ST-300 Serial number Date of purchase Manufacturer Warranty and repair Register your product at DYNAMICNORD.COM Fifth Element GmbH immediately after purchase to receive all Pettenkoferstraße 12 warranty services. 83052 Bruckmühl / Germany ENGLISH...
