PRODUCT MANUAL
48-in Tractor Rotary Tiller
3-PTO driveline shaft included
Model: TMG-RT120
Please read the product manual completely before assembly
Check against the parts list to make sure all parts are received
Wear proper safety goggles or other protective gears while in assembly
Missing parts or questions on assembly?
Please call: 1-877-761-2819 or email: cs@tmgindustrial.com
Do not return the product to dealer, they are not equipped to handle
your requests
WWW.TMGINDUSTRIAL.COM
Toll Free:1-877-761-2819
Advertisement
Related Manuals for TMG TMG-RT120
Summary of Contents for TMG TMG-RT120
- Page 1 PRODUCT MANUAL 48-in Tractor Rotary Tiller 3-PTO driveline shaft included Model: TMG-RT120 Please read the product manual completely before assembly Check against the parts list to make sure all parts are received Wear proper safety goggles or other protective gears while in assembly Missing parts or questions on assembly? Please call: 1-877-761-2819 or email: cs@tmgindustrial.com...
- Page 2 Technical parameter Model TMG-PT120 Working Width(cm) Blades shaft speed (rpm) Number of blades Tilling depth (cm) 8-12 Fitted power 18-22 Net weight (kg) Gross weight (kg) I. GUARANTEE Materials made by us have guaranteed that no defects are on the materials themselves or that there is no blemish during manufacturing.
- Page 3 limitation and offer all evidences. Under such condition, if the material is not returned, or client appoints a third side to disassemble or repair in advance, the guarantee terms will not work. (5) Work pieces always go wrong and after accepting our technical service guarantee the work pieces are not returned to us.
- Page 4 Ⅲ SAFETY & PREVENTIVE STEPS FOR ACCIDENT During operation, you should always remind yourself to be careful to maintain and replace parts and to obey rules to avoid accident. To operate the machine in a better way, please follow safety rules including these: (1) Stop tractor, waiting all moving parts to stop.
- Page 5 Ⅳ OPERATION & TRAVEL 1. Before using, looks though Operation Manual. Keep center bonnet and side cover level and fill with EP80W90 engine oil. 2. After 30 work hours, screw out plug and bread out bonnets and engine cases before a second operation. Control oil level with meter and break out again after 200 work hours.
-
Page 6: Information Symbols
2. Adjust and install transmission gear (cardan shaft) in special workshop. If there is damage on protective gear, replace it completely. Generally, a chain should be fitted on protective device not only under working condition. 3. When an implement is fitted on tractor, always use pins to lock the crankshaft. If pins go wrong, replace them. - Page 7 3. Read Operation Instruction carefully before using. 4. Output power is 540rpm. 5. Pay attention to the small clods casted out.Frequent inspection for the working parts and components is necessary. 6. Don't interfere the working machine by compelling and keep yourself away from it.
- Page 8 Ⅸ PARTS DRAWING WWW.TMGINDUSTRIAL.COM P8/10 Toll Free:1-877-761-2819...
-
Page 9: Parts List
X PARTS LIST Specification Q’ty Specification Q’ty Protective Cover Back Baffle Left Supporting Plate Nuts M8 Supporting Foot Welding Washer 8 Bolts M10X30 Washer 8 Spring Washer 10 Bolts M8x20 Paper Washer Protective Cover Upper Chain Washer Hitch Left Welding Bearing Nuts M12 Bearing Seat... - Page 10 Specification Q’ty Specification Q’ty Bolts M12x25 Bolts M12X40 Lower Hitch Pin Pad Welding Left Baffle Shaft Welding Washer Small Chain Wheel Bearing 6207-RZ Shaft Spring Washer 30 Blade Shaft Bearing Left Guard Rail Welding Washer Vent Plug M16x1.5 Bolts M12X35 Combined Washer Ø16 Left Blade Chain Cover Welding...
