Summary of Contents for TMG TMG-SBC75
-
Page 2: Table Of Contents
TABLE OF CONTENTS TO THE OWNER..........................2/13 SAFETY PRECAUTIONS........................3/13 BRUSH CUTTER ASSEMBLIES......................7/13 OPERATION INSTRUCTIONS......................10/13 MAINTENANCE INSTRUCTIONS.......................11/13 STORAGE INSTRUCTIONS........................12/13 SPECIFICATIONS..........................13/13 WARNING • Please read and understand the product manual completely before assembly • Check against the parts list to make sure all parts are received •... -
Page 3: To The Owner
TO THE OWNER GENERAL COMMENTS Congratulations for having this brush cutter! Your cutter was carefully designed and manufactured to give you years of dependable service. Your cutter will require some minor maintenance(such as cleaning) to keep it in top working condition. Be sure to observe all safety precautions and maintenance procedures as described in this manual. -
Page 4: Safety Precautions
SAFETY PRECAUTIONS The brush cutters are designed to be easy to use and maintain. They are operated by the skid steer auxiliary hydraulics. The cutters mount to the toolbar or quick attach mechanism for easy mounting. BEFORE OPERATION 1.1 Understanding all security labels, and keeping the tags clean, please do not casually graffiti, remove or damage any security labels, such as damage or writing fuzzy should be replaced immediately. - Page 5 SAFETY PRECAUTIONS These are common practices that may or may not be applicable to the products described in this manual. 4/13 TOLL FREE: 1-877-761-2819 www.tmgindustrial.com...
- Page 6 SAFETY PRECAUTIONS 5/13 TOLL FREE: 1-877-761-2819 www.tmgindustrial.com...
- Page 7 SAFETY PRECAUTIONS 6/13 TOLL FREE: 1-877-761-2819 www.tmgindustrial.com...
-
Page 8: Brush Cutter Assemblies
BRUSH CUTTER ASSEMBLIES 7/13 TOLL FREE: 1-877-761-2819 www.tmgindustrial.com... - Page 9 BRUSH CUTTER ASSEMBLIES PART NO. S/N. NUMBER PART DESCRIPTION QTYS NOTE 050872I.02 COVER GB/T 5783-2000 BOLT M8*25 GB/T 5783-2000 FLAT WASHER D8 GB/T 93-1987 SPRING WASHER D8 GB/T 6170-2000 NUT Ｍ８ GB/T 5783-2000 BOLT M12*45 GB/T 93-1987 SPRING WASHER D12 GB/T 97.3-2000 FLAT WASHER D12 050872I.00.01...
- Page 10 BRUSH CUTTER ASSEMBLIES PART NO. S/N. NUMBER PART DESCRIPTION QTYS NOTE GB96.1 BIG WASHER D24 GB/T 97-1 -1987 FLAT WASHER D24 GB/T 93-1985 SPRING WASHER D24 GB/T 6184-2000 LOCK NUT M24 GB/T 6170-2000 NUT M12 GB/T91-2000 SPLIT PIN D5*50 GB/T 9458-1988 SLOTTED HEX NUT M24*2 050872I.00-06 GASKET...
-
Page 11: Operation Instructions
OPERATION INSTRUCTIONS The brush cutter has 3 cutting blades, can increase cutting frequency and improve cutting efficiency, and cut off the tall grass and brush up to 2'' in diameter. 1. Attach the cutter to the toolbar or quick attach mechanism of your skid steer loader, raise the back of the unit of the ground about 4'' to allow the material to clear from under the cutting deck as you travel forward. -
Page 12: Maintenance Instructions
MAINTENANCE INSTRUCTIONS 1. Check the skid steer loader hydraulic system to ensure an adequate level of hydraulic oil every day. 2. Check all the fasteners loose regularly, and tighten them promptly every day. 3. Check the hydraulic system whether leak, if does, replace the new hose joints or hoses every day. -
Page 13: Storage Instructions
STORAGE INSTRUCTIONS 1. Clean all the debris, all mud, dirt and grease. 2. Replace all the blades at the same time and don't try to weld or straighten damaged blades; loss of integrity may result. 3. Inspect the unit for bent, loose, cracked, damaged or missing parts, Order any parts required, and make the necessary repairs to avoid delays when starting next season. -
Page 14: Specifications
SPECIFICATIONS MODEL TMG-SBC75 TOTAL LENGTH (MM) 2345 TOTAL WIDTH (MM) 2035 TOTAL HEIGHT (MM) TOTAL WEIGHT (KGS) CUTTING WIDTH (MM) 1830 MIN.CUTTING HEIGHT (MM) ≥50 SYSTEM FLOW (L/MIN) 60-80 MAX. PRESSURE (MPA) CUTTING BLADE NUMBER (PCS) 13/13 TOLL FREE: 1-877-761-2819...
