NEW POL NWD605DX User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
EN
Dishwasher / User Manual
NWD605DX

Advertisement

Table of Contents
loading

Related Manuals for NEW POL NWD605DX

Summary of Contents for NEW POL NWD605DX

  • Page 1 Dishwasher / User Manual NWD605DX...
  • Page 2 Thank you for choosing this product. This user manual contains important information on safety and instructions intended to assist you in the operation and maintenance of your appliance. Please take the time to read this user manual before using your appliance and keep this book for future reference.

  • Page 3: Table Of Contents

    CONTENTS 1 SAFETY INSTRUCTIONS ................4 1.1 General Safety Warnings ....................4 1.2 Installation Warnings .....................5 1.3 During Usage........................6 2 INSTALLATION ....................9 2.1 Machine Positioning .......................9 2.2 Water Connection ......................9 2.3 Water Inlet Hose ......................9 2.4 Drain Hose (Model Depending) ..................10 2.5 Electrical Connection ....................10 2.6 Fitting The Machine Undercounter ................11 3 TECHNICAL SPECIFICATIONS ..............

  • Page 4: Safety Instructions

    1 SAFETY INSTRUCTIONS 1.1 General Safety Warnings • Read these instructions carefully before using your appliance and keep this manual for future reference. Please check the packaging of your machine before installation and the outer surface of the machine once the packaging has been removed. Do not operate the machine if it appears damaged or if the packaging has been opened.

  • Page 5: Installation Warnings

    There may be some residue left in the machine after washing. Keep children away from the machine when it is open. 1.2 Installation Warnings • Choose a suitable and safe place to install your machine. • Only original spare parts should be used with the machine.

  • Page 6: During Usage

    Always use the coated plug supplied with your machine. If the electrical cable is damaged, it should only be replaced by a qualified electrician. • Connect the hose directly to the water inlet tap. The pressure supplied by the tap should be a minimum of 0.03 MPa and a maximum of 1 MPa.
  • Page 7 Do not open the door while the machine is in operation, hot water may spill out. Safety devices ensure the machine stops if the door is opened. The machine door should not be left open. It may cause accidents. Place knives and other sharp objects in the cutlery basket in a blade-down position.
  • Page 8 Pull the plug to disconnect the machine from the mains, never pull on the cord. EN - 8...

  • Page 9: Installation

    2 INSTALLATION 2.3 Water Inlet Hose 2.1 Machine Positioning When positioning the machine, place it in an area where dishes can be easily loaded and unloaded. Do not put the machine in an area where the ambient temperature falls below 0°C. Read all warnings located on the packaging before removing the packaging and positioning the machine.

  • Page 10: Drain Hose (Model Depending)

    2.4 Drain Hose (Model Depending) 2.5 Electrical Connection WARNING: Your machine is set to operate at 220-240 V. If the mains voltage supply to your machine is 110 V, connect a transformer of 110/220 V and 3000 W between the electrical connection. Connect the product to a grounded outlet protected by a fuse complying with the values in the...

  • Page 11: Fitting The Machine Undercounter

    2.6 Fitting The Machine Undercounter If you wish to fit your machine undercounter, there must be sufficient space to do so and the wiring-plumbing must be suitable to do so (1). If the space under the countertop is suitable for fitting your machine, remove the worktop as shown in the illustration (2).

  • Page 12: Technical Specifications

    3 TECHNICAL SPECIFICATIONS 3.2 Technical Specifications 12 place Capacity settings Dimensions Height 850(mm) Width 598(mm) Depth 598(mm) Net weight 40 kg Operating 220-240V voltage / 50 Hz frequency Total current 10(A) Total power 1900(W) Maximum: Water supply 1 (MPa) pressure Minimum: 0.03 (MPa) 3.1 General Appearance...
  • Page 13 RECYCLING • Some machine components and packaging consist of recyclable materials. • Plastics are marked with the international abbreviations:(>PE<, >PP<, etc. ) • The cardboard parts consist of recycled paper. They can be put into waste paper containers for recycling. •...

  • Page 14: Before Using The Appliance

    4 BEFORE USING THE 4.3 Fill The Salt (IF AVAILABLE) APPLIANCE To add softener salt, open the salt compartment cap by turning it counter 4.1 Preparing Your Dishwasher For First clockwise. (1) (2) At first use, fill the compartment with 1 kg salt and water (3) until it is almost overflowing.

  • Page 15: Test Strip

    4.4 Test Strip Run water Keep the Shake the Wait Set the hardness level of through the strip in the strip. (1min.) your machine tap (1min.) water (1sec) second munite munite NOTE: The level is set to 3 as default. If the water is well water or has a hardness level above 90 dF, we recommend that you use filter and refinement devices.

  • Page 16: Detergent Usage

    4.8 Detergent Usage 4.10 Using Combined Detergents Only use detergents specifically designed These products should be used according for domestic dishwashers. Keep your to the manufacturer’s instructions. detergents in cool, dry places out of reach Never put combined detergents into the of children.
  • Page 17 In order to change the rinse aid level, follow the below steps before turning on the machine: • Push the programme button and hold it down. • Turn the machine on. • Hold down the programme button until “rA” disappears from the display. Rinse aid setting follows water hardness setting.

  • Page 18: Loading Your Dishwasher

    5 LOADING YOUR DISHWASHER 5.1 Recommendations Remove any coarse residue on dishes For best results, follow these loading before placing the dishes in the machine. guidelines. Start the machine with full load. Loading the household dishwasher up to the capacity indicated by the manufacturer will contribute to energy and water savings.
  • Page 19 Height Adjustment Height Adjustable Rack (peg type) The upper basket includes a mechanism which enables the height of the basket The height adjustable racks enable glasses to be adjusted up (1) or down (2) without and cups to be placed on or under the having to remove the basket.

  • Page 20: Alternative Basket Loads

    5.2 Alternative Basket Loads Unsuitable Items For Dishwashing Lower Basket • Cigarette ashes, candle leftovers, polish, paint, chemical substances, iron-alloy materials. • Forks, spoons and knives with wooden, bone, ivory or nacrecoated handles; glued items, items soiled with abrasive, acidic or base chemicals. •...

  • Page 21: Programme Table

    6 PROGRAMME TABLE Program Quick 30’ Super 50’ Intensive 65°C Auto Hygiene 70°C Name: Standard program for Suitable for Suitable normally Suitable for normally for heavily soiled daily Suitable for Auto program lightly soiled soiled daily soiled dishes Type of Soil: using dishes heavily soiled for heavily...

  • Page 22: The Control Panel

    7 THE CONTROL PANEL change the delay time, first press the Start/ Pause button (7) and then the delay button to select a new delay time. To activate the new delay time, press the Start/Pause button (7) again. To cancel the delay, you need to switch to 0 hour by pressing the Delay button.

  • Page 23: Changing A Programme

    8. Rinse Aid Indicator 7.1 Changing a Programme When the rinse aid level is low, the rinse If you would like to change the programme aid lack warning indicator turns on and you when the machine is already running. should fill the rinse aid chamber. Press the Start/Pause 9.

  • Page 24: Switching The Machine Off

    Buzzer Sound Control When the End led turns on, (Model Depending) switch your machine off by To change the buzzer sound level, follow pressing the On/Off button. the below steps: 1. Open the door and press Half Load (6) and Tablet (5) buttons at the same time for 3 seconds.

  • Page 25: Cleaning And Maintenance

    8 CLEANING AND 8.1 Filters MAINTENANCE Clean the filters and spray arms at least once a week. If any food waste remains Cleaning your dishwasher is important to or foreign objects on the coarse and maintain the machine’s service life Make sure that the water softening setting fine filters, remove them and clean them (If available) is done correctly and correct...

  • Page 26: Spray Arms

    8.2 Spray Arms 8.3 Drain Pump Make sure that the spray holes are not Large food residues or foreign objects which clogged and that no food waste or foreign were not captured by the filters may block object is stuck to the spray arms. If there is the waste water pump.

  • Page 27: Troubleshooting

    9 TROUBLESHOOTING FAULT POSSIBLE CAUSE TROUBLESHOOTING Your Dishwasher is not plugged in. Plug your Dishwasher in. Switch your Dishwasher on by pressing the Your Dishwasher is not switched on. On/Off button. Fuse blown. Check your indoor fuses. The programme does not start.
  • Page 28 FAULT POSSIBLE CAUSE TROUBLESHOOTING Use the correct amount of detergent, as Not enough detergent used. instructed in the programme table. Rinse aid dosage and/or water Increase rinse aid and/or water softener softener setting set too low. level. Whitish stains remains on dishes.
  • Page 29 AUTOMATIC FAULT WARNINGS AND WHAT TO DO TROUBLE POSSIBLE FAULT WHAT TO DO CODE Make sure the water inlet tap is open and water is flowing. Separate the inlet hose from the tap and clean the filter of Water inlet system failure the hose.
  • Page 30 5XXXXXXXX...
