Summary of Contents for Soundmask SM-GR-3100
- Page 1 OPERATING MANUAL RANDOM DIGITAL SOUND GENERATOR MODEL SM-GR-3100 www.soundmask.com.au...
-
Page 2: Important Safety Information
Do not block any of the ventilation openings. future reference. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus that produce heat. www.soundmask.com.au... -
Page 3: General Description
› Power output to speakers 7W Dimensions & Weight 483 x 155 x 45 mm, 2 Kg Compliance Safety information Mount unit in locations that provide unobstructed air movement to minimise the risk of overheating. Copyright © 2015 Soundmask Australia Pty Ltd. All Rights Reserved. -
Page 4: User Interface
XLR output connector for EQ - 3 pin XLR connectors are fully balanced where pin 2 is hot, pin 3 is cold and pin 1 is ground (shield). Main Power - Connects via a standard IEC socket. A compatible power cord is supplied with the unit. ON/OFF switch. www.soundmask.com.au... -
Page 5: Dimensional Diagram
DIMENSIONAL DIAGRAM 4 3 0 m m 1 5 5 m 4 5 m m 4 5 m m 4 8 3 m Copyright © 2015 Soundmask Australia Pty Ltd. All Rights Reserved. - Page 6 EXAMPLE LAYOUT RANDOM DIGITAL NOISE GENERATOR SM-GR-3100 DIGITAL EQUALIZER SM-EQ-2000 DIGITAL DISTRIBUTOR SM-DX-4800 DIGITAL AMPLIFIER SM-DA-8000 CEILING TRANSDUCER SM-T-1200 › Each SM-T-1200 pictured represents 100 transducers. NOTES › The SM-DA-8000 is capable of servicing up to 800 transducers. › Diagram not to scale.
-
Page 7: Troubleshooting
To the best of our knowledge, the material contained within this document was accurate at the time of printing. No liability or otherwise is assumed for the accuracy of this document. No warranty is given or implied as to the accuracy of any part of the document. Copyright © 2015 Soundmask Australia Pty Ltd. All Rights Reserved.
