Summary of Contents for EVZEN ELITE AVENZOR EVZ5
- Page 1 ® ELITE AVENZOR EVZ5 Wireless Controller PS5 PRO CONTROLLER Instruction Manual ACUH-ZCT2B EVZ5...
- Page 2 Access the Control Panel To access the control panel, you must remove the cover with the Evzen logo, using the screwdriver that comes with the kit. Insert the screwdriver in the location shown in the image below and apply a little force toward the outside of the controller, so then the cover should come off.
- Page 3 Ajustments Map Remapping System Mechanized Method Height Limiter Opening Screws Mechanical Remap System Remapping is simple, with the panel open, just use the screwdriver in the point that you want adjust and turn until you find the desired option. You can choose among four adjustment options on each paddle. Use the guide below as a reference.
- Page 4 Operation Mode The Avenzor paddles work with two modes of operation, both are mecha- nical and without any digital resources, so you can have zero delay. To adjust, the L key accompanying the controller will be necessary. Mode 1 Free Mechanized In the Free mode, the paddle is free of material tension force.
- Page 5 Range and Sensitivity Limiter To make the adjustments you will need the L key that comes with the control. Range Limiter With the range limiter the paddle recoil is less, the turn after the click is decreased. To configure the range, turn the screw on the desired paddle, just like indicated in the illustration to adjust, turning clockwise the range decreases and on the reverse side it increases.
- Page 6 Changing Paddles To change and adjust the paddles, you will need the L key that accompanies the control. Remove the Control Panel With the cover removed, you must remove the screws that hold the base. Panel Screws L Key Removing and Changing Paddles...
- Page 7 *For Controllers Mounted with Two Paddles Factory-mounted controllers with two paddles come with a protective vinyl in the slot of the central paddles. To install the four paddles, remove the vinyl by pulling one of its ends to detach it.
- Page 8 Extra - Special Adjustment Option Some Avenzor controllers have an extra adjustment below the paddles this adjustment works creating a distance between the paddle and the button leaving less sensitive. To adjust you must remove all paddles and insert a screw that comes in the Avenzor accessory box, rotating until the screw enters inside the base of the controller, after fixing it in the place you can adjust the height it will be rotating counterclockwise.
